LDA CC1000S03 User manual
User’s Manual
LDA CC- 1000
Control and Monitoring Unit
Model: LDACC1000S03
Index
1. TECHNICAL DESCRIPTION.........................................................................................................1
2. FUNCTIONING DESCRIPTION....................................................................................................1
2.1 Control description....................................................................................................................1
2.2 Re r p nel nd connections.......................................................................................................2
3. TECHNICAL SPECIFICATIONS...................................................................................................4
Index of charts
Ch rt 1: Re r p nel...............................................................................................................................2
Ch rt 2: Connections............................................................................................................................2
Ch rt 3: PIN connections......................................................................................................................3
Ch rt 4: Technic l specific tions..........................................................................................................4
Index of illustrations
Ilustr tion 1: Front p nel......................................................................................................................1
Ilustr tion 2: Displ y............................................................................................................................2
Ilustr tion 3: Re r p nel.......................................................................................................................2
Ilustr tion 4: Connections.....................................................................................................................2
WARNING:
This piece of equipment must not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed over it.
1 TECHNICAL DESCRIPTION
The console CC-1000 provides a user-friendly, easy and intuitive way to manage,
monitor and configure Public Address and Voice Alarm Systems because it works as the
mainframe of the software SIME.
It has a similar architecture as a PC and works with the OS Windows XP Embedded
allowing an easy integration with other technologies and custom made software.
The system has an 8.4’’ touchscreen with an 800x600 resolution to allow an easy
operation without the need of any other peripheral device.
The control unit is designed in flat form with mounting brackets for allowing
installation under the table accordingly occupying the smallest possible space.
The processing unit consists of an industrial system with various optional communication
ports such as Ethernet, USB etc.
It has low power consumption, less than 40W, thanks to the careful selection of
components. Passive ventilation makes operating noise is almost nonexistent.
The CC-1000 includes a CC-MIC microphone which allows recording and voice
message playback and a sound card to use it has music server for background music.
2 FUNCTIONING DESCRIPTION
The system is designed to use it with a custom made software or with the SIME
software. Please consult the appropriate manual for more detailed information regarding
functionality.
2.1 Control description
The system is provided with automatic start in case of power failure.
The display will turn on automatically, however it can be turned off and on with the
button on the frame labeled POWER LED.
1 LDA Audio Tech - Severo Ocho Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805
Ilustration 1: Front panel
From the touchscreen monitor we access to the
configuration menu and adjust the frame size and
refreshment to adapt it to the resolution used by the program.
The control software should start automatically after
power up, the loading process can take several minutes.
2.2 Rear panel and connections
Nº ELEMENT DESCRIPTION
1 Connection ports Described in the next table
2 Power Power connection with Switch 220V ~
Chart 1: Rear panel
Nº ELEMENT DESCRIPTION
1 Ethernet port Ethernet 10/100Mbits
2 USB port For mouse, keyboard, pen-drive, etc.
3 System port Described in the next table
4 Monitor wire Special wire for the monitor connection
Chart 2: Connections
LDA Audio Tech - Severo Ocho Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805 2
Ilustration 2: Display
Ilustration 3: Rear panel
Ilustration 4: Connections
SYSTEM Connector Pin Detail
NOTE: Elements are grouped per functionality, pin numbers are not ordered.
Nº ELEMENT DESCRIPTION
1Audio Input - Input for microphone capsule.(MIC IN)
3Audio Input + Input for microphone capsule.(MIC IN)
5GND GND Input
7Input MAN Operating microphone input pin
9BUSY Busy signal to the microphone
11 AUX Aux signal to the microphone
13 V+ Power output 12V(max. 80mA)
15 V- Power output 12V(max. 80mA)
2Audio + (MIC) Line level microphone audio output
4Audio – (MIC) Line level microphone audio output
6GNDA GND for aux system or processor connection
8MAN (Output) Aux system operation output
10 BUSY (Output) Output Busy line to the aux system
12 AUX (Output) Pin AUX connection to aux system or ASC-82
14 GND (Line Output) GND of the pre-recorded messages
16 AUDIO(Line Output) Audio output for pre-recorded messages from the CC-1000 to the
processor or matrix
Chart 3: PIN connections
IMPORTANT WARNING!
The microphone audio input allows connection to a standard dynamic microphone, DO
NOT CONNECT OTHER AUDIO EQUIPMENT.
3 LDA Audio Tech - Severo Ocho Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805
3 TECHNICAL SPECIFICATIONS
Model CC-1000
Power supply V z
Power consumption W
LCD size ” (202mm) 4:3
LCD resolution pixels
Contrast/Bright cd/m2
Ethernet Interface
USB
Audio ini-jack
Processor Speed GHz
Disipation Pasive
peratingWindows XP Embedded ® (SP2)
Processing unit dimensions 390mm x 206mm x 52mm (LxWxD)
Chart 4: Technical specifications
LDA Audio Tech - Severo Ocho Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805 4
LDA Audio Tech - Severo Ocho Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805
