LDT 000106 User manual

L ittfinski D aten T echnik ( LDT )
Operating Instruction
Connection Cable (1m)
for the s88-feedback bus and the light controls
Light@Night and Light-DEC
from the Digital-Professional-Series!
Kabel s88 1m Part-No.: 000106
Kabel Light@Night 1m Part-No.: 000106
The interference protected twisted connection cable
of 1 meter length can be used for:
⇒ extending the installation distance of all LDT s88
components or directly to the command station /
interface or to each other (for RM-88-N, RM-88-N-O,
RM-GB-8-N only).
⇒ connecting s88 feedback module from Märklin /
Viessmann directly together at a distance of 1 meter
or extend the installation at 1 meter distance each.
⇒ connecting the Light-Display and Light-Power
Module of the light control Light@Night and
Light-DEC to each other.
This product is not a toy! Not suitable for children under 14 years of age! The kit
contains small parts, which should be kept away from children under 3 years of age!
Improper use will imply danger of injuring due to sharp edges and tips! Please store
this instruction carefully.
Introduction / Safety Information:
You have purchased a connection cable for your digital model
railway.
The connection cable is a high quality product which is supplied
within the assortment of Littfinski DatenTechnik (LDT).
We are wishing you having a good time using this product.
The connection cable comes with a 24 month warranty.
•Please read the following instructions carefully. Warranty will
expire due to damages caused by disregarding the operating
instructions. LDT will also not be liable for any consequential
damage caused by improper use or installation.
•Attention: Please switch off your model railway by
disconnecting the transformers from AC-current before
starting any installation.
Description for Kabel s88:
The connection cable consists of a 1 meter twisted bus cable with
two original s88 pin socket connectors. At one socket is a pin-pin
plug inserted.
1 m
Stiftleiste
pin plug
rosa
pink
rosa
pink
If you want to use the s88 connection cable for connection of the
feedback module RM-88-N, RM-88-N-O or RM-GB-8-N you
have to remove at first the pin-pin plug.
Attach now one socket in that position onto the 6-poles pin bar
of the feedback module that the single white wire corresponds
with white marking at the pin bar.
Please attend to the marking at the pin bar “OUT” and “IN” in
accordance to the operation instruction of the feedback module.
s88-N
OUT IN
s88-N
weiß
ST1
OUT IN
ST2
BU1 BU2
8-fach Rückmeldemodul
mit Gleisbesetztmeldern
8-fold feedback module
with occupancy detectors
RM-GB-8-N
Rev. 1.1
Attach the second pin-socket of the bus-cable directly to the
digital central unit or to the interface respectively to an other
feedback module within the feedback line.
If you
want to use the
s88 connection cable
for connecting two
Märklin or Viessmann
feedback module
together please remove
first the pin-plug.
Insert the pin-
socket
connectors of the
connection cable into
the feedback module
that the cable is
directed to the bott
om.
To assure a constant
orientation has the
white single wire to be
located into the
direction to the middle
of the feedback module.
weiss
white
weiss
white
87654321
9 10 11 12 13 14 15 16
märklin
digital
d e c o d e r s 8 8
87654321
9 10 11 12 13 14 15 16
märklin
digital
d e c o d e r s 8 8
1 m
Verbindungskabel
connection cable
The following draft shows an assembled s88 connection cable
shown from the left side.
rosa
pink
rosa
pink
d e c o d e r s 8 8
If you want to extend the
s88 bus-
connection of the
former LDT
feedback
module RM-DEC-88(-O)
or
RM-GB-8
by 1m please
leave the pin-
pin plug bar
inserted at the socket
connector.
The right side draft
indicates how to
extend the
75cm s88 bus-
cable of a
feedback module RM-
DEC-88 by 1 meters.
Attend to the correct
orientation of the bus
connectors to assure that
the cable colors of the
single wires correspond
exactly.
Stiftleiste 6 pol.
pin-pin plug 6 poles
weiss
white
weiss
white
Verbindungskabel
connection cable
10
9
11
8 7 6 5 4 3 2 1
12 13 14 15 16
Peter Littfinski DatenTechnik
Rueckmeldedecoder RM-DEC-88
16-channel feedback modul
Rev. 3.0
rosa
gelb gruen
braun
weiss grau
INOUT
ST1
ST2
16 Rückmeldeeingänge für den
s88-Rückmeldebus.
Rückmeldemodul
RM-DEC-88
Littfinski DatenTechnik (LDT)
www.ldt-infocenter.com
Digital-Profi werden!

Description for Kabel Light@Night:
If you use the PC-light control Light@Night or the Layout-light control Light-DEC and you do not want to connect the Light-Display
respectively Light-Power Module directly onto each other but prefer the installation of the module at a larger distance you can use the
Kabel Light@Night with a length of 1 meters.
Insert the pin-plug connector of the connection cable with the pin plug into the 10-poles socket bar of the previous Light-Display-
respectively Light-Power Module at a position that the white single wire of the connection cable corresponds to the white marking at the
Light-Display- respectively Light-Power Module.
The other side of the cable has to be connected to the 10-poles pin-plug of the next module. Also on this side it has to be assured that
the white single wire of the connection cable corresponds to the white marking at the Light-Display respectively Light-Power Module.
The following draft shows the correct connection of the connection cable. The cable has to be directed to the top.
weiss
white
weiss
white
1m
Stiftleiste (Adapter)
pin plug (adapter)
Bestellbezeichnung /
Order code: Kabel Light@Night 1m
Light Interface (LPT)
Rev. 1.0
Littfinski DatenTechnik (LDT)
BU1
IC2
IC3
IC4
BU2
IC1
C2
C1
Printer
Port
LPT
white
weiss
white
weiss
KL4 KL3 KL2 KL1
KL7
BU1 ST1
4 5 6 7 8
26 27 28 29 30 31 32 25
9
10 11 12 13 14 15 16 18 19 20 21 22 23 24 17
1 2 3
GBS-Display / Light-Display
Littfinski DatenTechnik (LDT)
KL5
braun
gelb
10...18V~
12...24V=
KL6 BU2
IN
39 38 37 36 35 34 33 40
BU3
OUT
Rev. 1.8
white
weiss
white
weiss
KL4 KL3 KL2 KL1
KL7
BU1 ST1
4 5 6 7 8
26 27 28 29 30 31 32 25
9
10 11 12 13 14 15 16 18 19 20 21 22 23 24 17
1 2 3
GBS-Display / Light-Display
Littfinski DatenTechnik (LDT)
KL5
braun
gelb
10...18V~
12...24V=
KL6 BU2
IN
39 38 37 36 35 34 33 40
BU3
OUT
Rev. 1.8
Please pay attention: The first Light-Display respectively Light-Power Module has always to be connected directly to the Light-Interface
(LI-LPT or LI-LAN) the PC-Light-Control Light@Night respectively always directly onto the Basic-Module of the Layout Light-Control
Light-DEC. Therefore is it only possible to use the connection cable Kabel Light@Night for the connection of the second to the first
Module.
Further products from the Digital-Professional-Series:
Kabel s88 0,5m / Kabel Light@Night 0,5m
Connection cable (0.5m) for the s88-feedback bus and the Light Controls Light@Night and Light-DEC.
Kabel s88 2m / Kabel Light@Night 2m
Connection cable (2m) for the s88-feedback bus and the Light Controls Light@Night and Light-DEC.
S-DEC-4
4-fold turnout decoder for four magnet accessories with free programmable decoder addresses and possible external power supply.
SA-DEC-4
4-fold switch-decoder with four bistable relays and free programmable decoder addresses and possible external power supply.
LS-DEC-DB, -DR, -KS, -ÖBB, -SBB, -NS, -NMBS, -BR, -FS, -SJ, -SNCF, -CFL, -USA, -CSD, -8x2
4-fold light signal decoder. Light signals switched directly via decoder addresses.
RM-88-N / RM-88-N-O
16-fold feedback modules for the s88-feedback bus. RM-88-N-O with integrated opto coupling.
RM-GB-8-N
8-fold feedback modules with integrated track occupancy detectors for the s88-feedback bus.
HSI-88-(USB)
High Speed Interface for the s88-feedback bus. Offers the possibility to create three feedback lines. The feedback reports will be
transmitted directly via the command station via the COM- (HSI-88) or the USB-Interface (HSI-88-USB) to the PC.
