Leader Light LL IN8-RSxxx User manual

©MMX - Leader Light – All right reserved If you have any question please, contact [email protected]Edition: A - 2010
01 SAFETY INFORMATION
WARNING!!!
Carefully read before installing, powering or servicing. Nothing to
do if anything misunderstand! Installation can be done only by a
qualied professional in accordance with relevant local codes.
01.1 Safety instructions
Shut down power before installation or maintenance of equipment or
voltage /data source.
Do not modify, alter, or attempt to service the LeaderLight appliance. Doing
so will void the warranty.
Use only the recommended DC voltage source.
Connect the ground to the bottom of the box!
Electrical connections, service and maintenance can be performed only by
qualied professional.
AC power supply of DC power supply must comply with local regulations.
AC power supply must be protected against overvoltage and short circuits.
-
-
-
-
-
-
-
01.2 Operating restrictions
This product was designed for indoor use only!
If the product has been exposed to drastic temperature uctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation
water might damage your unit. Leave the unit switched off until it has
reached room temperature.
Do not operate the product in humid, dusty or too hot/cold environments.
Before connecting, make sure the product is not damaged, wet, or otherwise
damaged.
Unprofessional operation creates the most damages!
For transport use the original packaging.
-
-
-
-
-
-
Operate only with 24V DC stabilized source!
01.3 Fire protection
Follow all safety restrictions.
Device never cover – the minimum space around the vents must be at least
100mm (4 in.).
Allowed maximum ambient temperature is 40°C (104°F).
-
-
-
02 PRODUCT SPECIFICATION
02.1 Technical specication
Power connection: DC24V max. 5W
Input: 8x digital input
Output signal: RS 423/232 LL dened protocol
Ambient temp. (Ta): 0°C ÷ +40°C
Net weight: 0,30 kg
Dimensions LxWxH: 105mm x 75mm x 82mm
Installation: standard DIN installation TS35 – 6DIN
02.2 Product description
Indication of control LED (LED power / data - yellow)
LED Indication Status
LED
Power / Data
On 240ms /
Off 240ms O.K. - device is working correct
03 INSTALLATION
03.1 Unpacking
Unpack carefully.
This is electronic equipment and should be handled carefully.
Damaged delivered package or if are any mechanical parts broken – it must
be claim immediately by the transport company. Photo pictures as evidence
are valuable for future claim.
-
-
-
03.2 Physical installation
Loading capacity of bearing area has to be at least 10 times the weight of all
device clusters.
-
03.3 Connection
Respect all SAFETY INFORMATION 01!
Connect the ground (earth) to the bottom of the module!
LL IN8-RSxxx device may be operated only with 24V DC stabilized source.
In the case of connecting the power supply with more than a prescribed
voltage you can suffer a dangerous electric shock, inict damage equipment
or re.
Shut down power supply from all devices before installation of LL IN8-RSxxx
to end devices.
-
-
-
-
-
Leader Light s.r.o.
M.Gorkeho 33
SK-052 01 Spisska Nova Ves
Slovakia
www.leaderlight.eu
USER MANUAL
LL IN8-RSxxx - Potential free contact module
LL08 300 xxx
xxx - protocol type 0v3, or 0v4, or 0v5
COMPLIMENTS ON YOUR PURCHASE!
All dimensions are in millimeters
Package includes:
LL IN8-RSxxx- 1 pc.
User manual- 1 pc.
Additional items needed:
Data and power cables-
24V DC power supply-
Content:
01 SAFETY INFORMATION
01.1 Safety instructions
01.2 Operating restrictions
01.3 Fire protection
02 PRODUCT SPECIFICATION
02.1 Technical specication
02.2 Product description
03 INSTALLATION
03.1 Unpacking
03.2 Physical installation
03.3 Connection
03.4 Installation factors
03.5 RSX channels
04 MAINTENANCE AND SERVICE
ENVIRONMENTAL PROTECTION
Do not throw away the appliance with the normal household waste at the end of
its life, but hand it in at an ofcial collection point for recycling. By doing this, you
help to preserve the environment.
105
75
+-
82
DC 24V
power
Input - 2 groups
2x 6pin line conector
LL IN8-RSxxx
Made in EU
Leader Light s.r.o. Slovakia, 2010
www.leaderlight.eu
[email protected]
+24V
POWER
DC POWER
IP20, Tmax: 40°C
0V
GROUP 1
In1 In2 In3 In4 Com +V
GROUP 2
In5 In6 In7 In8 Com
DATA
IN
DATA
OUT
D+ D- D+ D-
MODE
DIP
1 2 3 4
+ -
Input/Output
digital signal
6pin line conector
DIP
settings
LED
