Leadshine Technology Co. 3DM683 User manual

User sManual
For
3DM683
FullyDigitalThreePhase SteppingDriver
Version 1.0
2009All RightsReserved
Attention:Pleaseread thismanual carefullybeforeusingthe driver!
3/F, Block 2, NanyouTiananIndustrialPark, NanshanDist, Shenzhen, China
T: (86)755-26434369 F: (86)755-26402718
Website: www.leadshine.com E-Mail: [e-mail]
The contentinthismanualhasbeencarefullypreparedand isbelievedtobeaccurate,butno
responsibilityisassumedforinaccuracies.
Leadshinereservestherighttomakechangeswithoutfurthernoticetoanyproductshereinto
improvereliability,function ordesign.Leadshinedoesnotassumeanyliabilityarisingoutofthe
applicationoruseofanyproductorcircuitdescribedherein;neitherdoesitconveyanylicense
underitspatentrightsofothers.
Leadshine sgeneralpolicydoesnotrecommend theuseofitsproductsinlifesupportoraircraft
applicationswhereinafailureormalfunctionoftheproductmaydirectlythreatenlifeorinjury.
AccordingtoLeadshine stermsandconditionsofsales,theuserofLeadshine sproductsinlife
supportoraircraftapplicationsassumesall risksofsuchuseandindemnifiesLeadshineagainst all
damages.
2009byLeadshineTechnologyCompanyLimited.
AllRightsReserved
/ 3DM683-HV

Contents
I
TableofContents
1. Introduction, FeaturesandApplications....................................................................1
Introduction...........................................................................................................1
Features.................................................................................................................1
Applications..........................................................................................................1
2. Specifications............................................................................................................2
ElectricalSpecifications........................................................................................2
MechanicalSpecifications.....................................................................................2
EliminationofHeat...............................................................................................2
OperatingEnvironmentandotherSpecifications..................................................3
3. PinAssignmentandDescription...............................................................................3
ConnectorP1 Configurations................................................................................3
SelectingActivePulseEdgeandControlSignalMode........................................4
ConnectorP2 Configurations................................................................................4
4. ControlSignalConnector(P1)Interface...................................................................4
5. Connecting theMotor................................................................................................5
6. PowerSupplySelection............................................................................................5
RegulatedorUnregulatedPowerSupply..............................................................6
MultipleDrivers....................................................................................................6
SelectingSupplyVoltage.......................................................................................6
7. SelectingMicrostepResolutionand DriverOutputCurrent.....................................6
MicrostepResolutionSelection............................................................................7
CurrentSettings.....................................................................................................8
Dynamiccurrentsetting................................................................................8
Standstill currentsetting................................................................................8
8. Wiring Notes.............................................................................................................9
9. TypicalConnection....................................................................................................9
10. Sequence ChartofControlSignals.......................................................................10
11. ProtectionFunctions..............................................................................................10
Over-currentProtection...............................................................................10
Contents
II
Over-voltageProtection..............................................................................11
PhaseErrorProtection.................................................................................11
ProtectionIndications..................................................................................11
12. FrequentlyAskedQuestions..................................................................................11
ProblemSymptomsand PossibleCauses............................................................12
13. ProfessionalTuningSoftwareProTuner................................................................13
Introduction.........................................................................................................13
SoftwareInstallation...........................................................................................13
ConnectionsandTesting.....................................................................................13
RS232 Interface Connection...............................................................................17
TestingtheSteppingSystem...............................................................................17
SoftwareIntroduction..........................................................................................18
ProTunerMain Window..............................................................................18
ComConfig Window..................................................................................19
Tuning.........................................................................................................19
Anti-ResonanceIntroduction......................................................................22
ProcedureforAchieving OptimumPerformance........................................23
APPENDIX.................................................................................................................29
TwelveMonthLimited Warranty........................................................................29
Exclusions...........................................................................................................29
Obtaining WarrantyService................................................................................29
WarrantyLimitations...........................................................................................29

3DM683MicrosteppingDriverManual V1.0
Tel:[phone]WebSite: www.leadshine.com
1. Introduction,Featuresand Applications
Introduction
The3DM683isaversatilityfullydigitalsteppingdriverbasedon aDSP withadvancedcontrol
algorithm.The3DM683isthenextgeneration ofdigitalsteppingmotorcontrols.Itbringsa
uniquelevelofsystemsmoothness,providingoptimumtorqueand nullsmid-rangeinstability.
Motorself-testandparameterauto-setuptechnologyoffersoptimumresponseswithdifferent
motorsand easy-to-use.Thedrivenmotorscanrunwithmuchsmallernoise,lowerheating,
smoothermovement thanmost ofthedriversinthemarkets. Itsuniquefeaturesmakethe3DM683
anidealsolutionforapplicationsthatrequirelow-speedsmoothness.
Features
l Anti-Resonance, provides optimum torque
and nulls mid-range instability
l Motor self-test and parameter auto-setup
technology, offers optimum responses with
different motors
l Multi-Stepping allows alow resolution step
input to produce a higher microstep output
for smooth system performance
l Microstep resolutions programmable, from
200 to 102,400 steps/rev
l Supply voltage upto +60VDC
l Output current programmable, from 0.5A to
8.3A
l Pulse input frequency up to 200 KHz
l TTL compatible and opticallyisolated input
l Automaticidle-current reduction
l Suitable for 3/6 leads Three-phase motors
l Support PUL/DIR and CW/CCW modes
l Over-voltage, over-current, phase-error
protections
Applications
Suitable for a wide range of stepping motors, from NEMA frame size 17 to 34. It can be used in
various kinds of machines, such as laser cutters, laser markers, high precision X-Y tables, labeling
machines, and so on. Its unique features make the 3DM683 an ideal solution for applications that
require both low-speed smoothness and high speed performances.
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
2. Specifications
ElectricalSpecifications(Tj= 25 /77℉)
3DM683
Parameters Min Typical Max Unit
Output current 0.5 - 8.3(5.9RMS) A
Supplyvoltage +20 - +60 VDC
Logicsignal current 7 10 16 mA
Pulseinputfrequency 0 - 200 kHz
Isolationresistance 500 MΩ
MechanicalSpecifications(unit: mm [inch], 1 inch= 25.4 mm)
Figure 1:Mechanicalspecifications
EliminationofHeat
lDriver sreliableworkingtemperatureshouldbe<70 (158 ),and motorworkingtemperature
shouldbe<80 (176 );
lItisrecommendedtouseautomaticidle-currentmode,namelycurrentautomaticallyreduceto
60%whenmotorstops,soastoreducedriverheatingandmotorheating;
lIt isrecommendedtomountthedriververticallytomaximize heatsinkarea. Useforcedcooling
methodtocool thesystem ifnecessary.
/ 3DM683-HV
/ +80
for 3DM683
+80VDC for 3DM683-HV
and
Although 3DM683 is a 3-phase stepper drive, it drives a 3-phase stepper motor 200 steps (1.8 degree)
in full step mode, same as a 2-phase stepper drive. So, there is no need for control system configuation
change when switching from 2-phase stepper system. But 3-phase stepper drive can drive a 3-phase
stepper motor smoother, quieter, and with better higher speed torque.

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Operating EnvironmentandotherSpecifications
Cooling Natural CoolingorForcedcooling
Environment Avoiddust, oil fog andcorrosivegases
AmbientTemperature 0 －50 (32 －122 )
Humidity 40%RH －90%RH
OperatingTemperature 70 (158 )Max
OperatingEnvironment
Vibration 5.9m/s2 Max
StorageTemperature -20 －65 (-4 －149 )
Weight Approx. 270g(9.5oz)
3. PinAssignmentand Description
The3DM683hastwoconnectors,connectorP1forcontrol signalsconnections, andconnectorP2for
powerandmotorconnections.Thefollowingtablesarebriefdescriptionsofthetwoconnectors.
Moredetaileddescriptionsofthepinsandrelatedissuesarepresentedinsection4,5, 9.
ConnectorP1 Configurations
PinFunction Details
PUL+
PUL-
Pulsesignal: Insinglepulse(pulse/direction)mode,thisinputrepresentspulse
signal,eachrisingorfallingedgeactive(softwareconfigurable);4-5Vwhen
PUL-HIGH,0-0.5VwhenPUL-LOW.Indoublepulsemode(pulse/pulse),
thisinputrepresentsclockwise(CW)pulse，activebothathighlevelandlow
level(softwareconfigurable).Forreliableresponse,pulsewidthshouldbe
longerthan2.5μs.Seriesconnectresistorsforcurrent-limitingwhen+12Vor
+24Vused. ThesameasDIRandENAsignals.
DIR+
DIR-
DIRsignal: Insingle-pulsemode,thissignalhaslow/highvoltagelevels,
representingtwodirectionsofmotorrotation;indouble-pulsemode(software
configurable),thissignaliscounter-clock(CCW)pulse，activebothathigh
level andlowlevel(softwareconfigurable).Forreliablemotionresponse,DIR
signalshouldbeaheadofPULsignalby5μsatleast.4-5VwhenDIR-HIGH,
0-0.5VwhenDIR-LOW.Pleasenotethatrotationdirection isalsorelatedto
motor-driverwiringmatch.Exchangingtheconnectionoftwowiresforacoil
tothedriverwill reversemotiondirection.
ENA+
ENA-
Enablesignal: Thissignalisusedforenabling/disablingthedriver.Highlevel
(NPNcontrolsignal,PNPand Differentialcontrolsignalsareonthecontrary,
namelyLowlevelforenabling.)forenablingthedriverandlowlevelfor
disablingthedriver.Usuallyleft UNCONNECTED (ENABLED).
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
SelectingActivePulseEdgeandControlSignalMode
The3DM683supportsPUL/DIRand CW/CCWmodesandpulseactivesatrisingorfallingedge. See
moreinformationaboutthesesettingsinSection13.DefaultsettingisPUL/DIRmodeand rising
edgeactive(NPN, andPNPcontrolsignal isonthecontrary).
ConnectorP2 Configurations
PinFunction Details
GND PowerGround
+Vdc Powersupply, 20~60VDC,IncludingvoltagefluctuationandEMFvoltage.
U MotorphaseU
V MotorphaseV
W MotorphaseW
4. ControlSignalConnector(P1)Interface
The3DM683canacceptdifferentialandsingle-endedinputs(includingopen-collectorand PNP
output).The3DM683 has3opticallyisolatedlogicinputswhicharelocatedonconnectorP1to
acceptlinedrivercontrolsignals.Theseinputsareisolatedtominimizeoreliminateelectricalnoises
coupledontothedrivecontrolsignals.Recommend uselinedrivercontrolsignalstoincreasenoise
immunityofthedriverininterference environments.Inthefollowingfigures,connectionsto
open-collectorandPNPsignalsareillustrated.
Figure 2:Connectionstoopen-collectorsignal(common-anode)

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 3:ConnectiontoPNPsignal(common-cathode)
5. ConnectingtheMotor
The3DM683candriveany3leador6leadthreephasehybridsteppingmotors.Theconnection
betweenthedriverand3-phasesteppingmotorsincludestwodifferentkindsofconnections,namely
delta-connectionandstar-connection.Usingdelta-connection,theperformancesofthemotorunder
highspeedconditionarebetter,butthedrivercurrentishighertoo(about1.73timesthemotorcoil
current);whileusingstar-connection,thedrivercurrentequalstothemotorcoil current.
Figure 4:Motorconnections
6. PowerSupplySelection
The3DM683canmatchmediumandsmallsize steppingmotors(fromNEMAframesize 14to34)
madebyLeadshineorothermotormanufacturesaroundtheworld.Toachievegooddriving
performances,it isimportanttoselectsupplyvoltageandoutputcurrentproperly.Generallyspeaking,
supplyvoltagedeterminesthehighspeedperformanceofthemotor,whileoutputcurrentdetermines
theoutputtorqueofthedrivenmotor(particularlyatlowerspeed).Highersupplyvoltagewillallow
highermotorspeedtobeachieved,atthepriceofmorenoiseand heating.Ifthemotionspeed
requirementislow,it sbettertouselowersupplyvoltagetodecreasenoise,heatingand improve
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
reliability.
RegulatedorUnregulatedPowerSupply
Bothregulatedandunregulatedpowersuppliescanbeusedtosupplythedriver.However,
unregulatedpowersuppliesarepreferredduetotheirabilitytowithstandcurrentsurge.Ifregulated
powersupplies(suchasmostswitchingsupplies.)areindeedused,itisimportanttohavelarge
currentoutputratingtoavoidproblemslikecurrentclamp,forexampleusing4Asupplyfor3A
motor-driveroperation. Ontheotherhand,ifunregulatedsupplyisused, onemayuseapowersupply
oflowercurrent ratingthanthatofmotor(typically50%～70%ofmotorcurrent).Thereasonisthat
thedriverdrawscurrentfromthepowersupplycapacitoroftheunregulatedsupplyonlyduringthe
ON duration ofthePWMcycle,butnotduringtheOFFduration.Therefore,theaveragecurrent
withdrawnfrompowersupplyisconsiderablyless thanmotorcurrent.Forexample,two3Amotors
canbewellsuppliedbyonepowersupplyof4Arating.
MultipleDrivers
Itisrecommendedtohavemultipledriverstoshareonepowersupplytoreduce cost, ifthesupply
hasenoughcapacity.Toavoidcrossinterference, DONOT daisy-chainthepowersupplyinputpins
ofthedrivers. Instead,pleaseconnectthem topowersupplyseparately.
Selecting Supply Voltage
ThepowerMOSFETSinsidethe3DM683canactuallyoperatewithin+20 ~+60VDC,including
powerinputfluctuationandbackEMFvoltagegeneratedbymotorcoilsduringmotorshaft
deceleration.Highersupplyvoltagecanincreasemotortorqueathigherspeeds,thushelpfulfor
avoidinglosingsteps.However,highervoltagemaycausebiggermotorvibrationatlowerspeed,and
itmayalsocauseover-voltageprotectionorevendriverdamage.Therefore, itissuggestedtochoose
onlysufficientlyhighsupplyvoltageforintendedapplications,and itissuggestedtousepower
supplieswiththeoreticaloutputvoltageof+20 ~+54VDC,leaving roomforpowerfluctuationand
back-EMF.
7. SelectingMicrostepResolutionand DriverOutputCurrent
Microstepresolutionsandoutputcurrentareprogrammable,theformercanbesetfrom200 to
102,400steps/revandthelattercanbesetfrom0.5Ato8.3A.See moreinformation about Microstep
ResolutionandOutputCurrentSetting inSection13.
However,whenit snotinsoftwareconfiguredmode,thisdriverusesan8-bitDIPswitchtoset

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
microstepresolution,andmotoroperatingcurrent, asshownbelow:
MicrostepResolutionSelection
Whenit snotinsoftwareconfiguredmode,microstepresolutionissetbySW5,6,7,8oftheDIP
switch asshowninthefollowingtable:
Steps/rev.(for1.2 motor) SW5 SW6 SW7 SW8
Default/Software configured,
（From200to102,400）ON ON ON ON
400 OFF ON ON ON
800 ON OFF ON ON
1600 OFF OFF ON ON
3200 ON ON OFF ON
6400 OFF ON OFF ON
12800 ON OFF OFF ON
25600 OFF OFF OFF ON
1000 ON ON ON OFF
2000 OFF ON ON OFF
4000 ON OFF ON OFF
5000 OFF OFF ON OFF
8000 ON ON OFF OFF
10000 OFF ON OFF OFF
20000 ON OFF OFF OFF
25000 OFF OFF OFF OFF
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
CurrentSettings
Foragivenmotor,higherdrivercurrentwillmakethemotortooutputmoretorque,butatthesame
timecausesmoreheatinginthemotoranddriver. Therefore, outputcurrentisgenerallysettobesuch
thatthemotorwill notoverheatforlongtimeoperation.Since paralleland serialconnectionsof
motorcoilswill significantlychangeresultinginductanceandresistance,it isthereforeimportantto
setdriveroutputcurrentdependingonmotorphasecurrent,motorleadsand connectionmethods.
Phasecurrentratingsuppliedbymotormanufacturerisimportantinselectingdrivercurrent,however
theselectionalsodependsonleadsand connections.
Whenit snotinsoftwareconfiguredmode,thefirstthreebits(SW1,2, 3)oftheDIPswitchareused
tosetthedynamiccurrent.Selectasettingclosest toyourmotor srequiredcurrent.
Dynamiccurrentsetting
PeakCurrent RMSCurrent SW1 SW2 SW3
Default/Software configured(0.5to8.3A) OFF OFF OFF
3.2A 2.3A ON OFF OFF
4.0A 2.9A OFF ON OFF
4.9A 3.5A ON ON OFF
5.7A 4.1A OFF OFF ON
6.4A 4.6A ON OFF ON
7.3A 5.2A OFF ON ON
8.3A 5.9A ON ON ON
Notes: Duetomotorinductance,theactualcurrentinthecoil maybesmallerthanthedynamic
currentsetting,particularlyunderhighspeedcondition.
Standstillcurrentsetting
SW4isusedforthispurpose.OFFmeaningthatthestandstill currentissettobehalfoftheselected
dynamiccurrent,andONmeaningthatstandstillcurrentissettobethesameastheselecteddynamic
current.
Thecurrentautomaticallyreducedto60%oftheselecteddynamiccurrentonesecond afterthelast
pulse.Theoretically,thiswillreduce motorheatingto36%(duetoP=I2*R)oftheoriginalvalue.If

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
theapplicationneedsadifferentstandstill current, pleasecontact Leadshine.
8. WiringNotes
lInordertoimproveanti-interferenceperformanceofthedriver,itisrecommendedtouse
twistedpairshieldcable.
lTopreventnoiseincurredinPUL/DIRsignal,pulse/directionsignalwiresandmotorwires
shouldnotbetieduptogether.Itisbettertoseparatethembyatleast10cm,otherwisethe
disturbingsignalsgeneratedbymotorwilleasilydisturbpulsedirectionsignals,causingmotor
positionerror,system instabilityand otherfailures.
lIf apowersupplyservesseveraldrivers,separatelyconnectingthedriversisrecommended
insteadofdaisy-chaining.
lItisprohibitedtopullandplugconnectorP2whilethedriverispoweredON,becausethereis
highcurrentflowingthroughmotorcoils(evenwhenmotorisatstandstill).Pullingorplugging
connectorP2withpoweronwill causeextremelyhigh back-EMFvoltagesurge,whichmay
damagethedriver.
9.TypicalConnection
Acompletesteppingsystemshouldincludesteppingmotor,steppingdriver,powersupplyand
controller(pulsegenerator).Atypical connection isshownasfigure9.
Figure 9:Typicalconnection
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
10. SequenceChartofControlSignals
Inordertoavoidsomefaultoperationsanddeviations,PUL,DIRandENAshouldabidebysome
rules,shownasfollowingdiagram:
Figure 10:Sequence chartofcontrolsignals
Remark:
a) t1:ENAmustbeaheadofDIRbyatleast5µs.Usually,ENA+and ENA-areNC(not
connected).See “ConnectorP1Configurations”formoreinformation.
b) t2:DIRmustbeaheadofPULactiveedgeby5µstoensurecorrectdirection;
c) t3:Pulsewidthnotlessthan2.5µs;
d) t4:Lowlevelwidthnotlessthan2.5µs.
11. ProtectionFunctions
Toimprovereliability,thedriverincorporatessomebuilt-inprotectionfunctions.The3DM683
usesoneREDLEDtoindicatewhatprotectionhasbeenactivated. TheperiodictimeofREDis3
s(seconds),and howmanytimestheREDturnsonindicateswhatprotectionhasbeenactivated.
BecauseonlyoneprotectioncanbedisplayedbyREDLED, sothedriverwilldecidewhaterrorto
displayaccordingtotheirpriorities.See thefollowing ProtectionIndications tablefordisplaying
priorities.
Over-currentProtection
Over-currentprotectionwill beactivatedwhencontinuouscurrentexceedstheupperlimitorincase
ofshortcircuitbetweenmotorcoilsorbetweenmotorcoil andground,and REDLEDwillturnon
oncewithineachperiodictime(3s).

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Over-voltageProtection
Whenpowersupplyvoltageexceeds62±1VDC,protection will beactivatedandREDLEDwill
turnontwice withineachperiodictime(3s).
PhaseErrorProtection
Motorpowerlineswrong&notconnectedwill activatethisprotection.REDLEDwill turnon four
timeswithineachperiodictime(3s).
Attention: Whenaboveprotectionsareactive,themotorshaftwill befreeortheLEDwill turnred.
Resetthedriverbyrepoweringit tomakeitfunctionproperlyafterremovingaboveproblems.Since
thereisnoprotection againstpowerleads(﹢,﹣)reversal, itiscriticaltomakesurethatpower
supplyleadscorrectlyconnectedtodriver.Otherwise,thedriverwill bedamagedinstantly.
ProtectionIndications
Priority
Time(s)ofON Sequence wave ofREDLED Description
1st 1 Over-currentprotection
2nd 2
Over-voltageprotection
3rd 4 Phase errorprotection
12. FrequentlyAskedQuestions
Intheeventthatyourdriverdoesn toperateproperly, thefirst stepistoidentifywhethertheproblem
iselectricalormechanicalinnature. Thenextstepistoisolatethesystemcomponentthatiscausing
theproblem. Aspart ofthisprocess youmayhavetodisconnecttheindividual componentsthatmake
up yoursystemandverifythattheyoperateindependently.Itisimportanttodocumenteachstepin
thetroubleshootingprocess.Youmayneedthisdocumentationtoreferbacktoatalaterdate,and
thesedetailswill greatlyassistourTechnicalSupportstaffindeterminingtheproblemshouldyou
needassistance.
Manyoftheproblemsthataffectmotioncontrolsystemscanbetracedtoelectricalnoise,controller
softwareerrors, ormistakeinwiring.
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
ProblemSymptomsand PossibleCauses
Symptoms PossibleProblems
Nopower
Microstepresolutionsettingiswrong
DIPswitchcurrentsettingiswrong
Fault condition exists
Motorisnotrotating
Thedriverisdisabled
Motorrotatesinthewrongdirection
Motorphasesmaybeconnectedinreverse
DIPswitchcurrentsettingiswrong
Thedriverinfault Somethingwrongwithmotorcoil
Control signal istoo weak
Control signal isinterfered
Wrongmotorconnection
Somethingwrongwithmotorcoil
Erraticmotormotion
Current settingistoo small, losingsteps
Current settingistoo small
Motorisundersizedfortheapplication
Accelerationissettoo high
Motorstallsduringacceleration
Powersupplyvoltagetoo low
Inadequateheatsinking/cooling
Automaticcurrentreductionfunction not beingutilized
Excessivemotorand driverheating
Current issettoo high

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
13. ProfessionalTuningSoftwareProTuner
Introduction
Thissectionwillprovideanoverviewofconnectionand basicsetup instructionsforLeadshine s
digitalsteppingDriver3DM683usingthe ProTuner software.Theseinstructionswillwalkyou
throughthefollowingstepsnecessarytostartupyourDriverandmotor.Thissectionisintendedfor
settinguptheDriverwiththe ProTuner.
SoftwareInstallation
The ProTuner iswindowsbasedsetup softwarefortuningall theLeadshine sdigitalDriversincludes
steppingDriver3DM683.Itcanruninwindowssystems,includingWin95/Win98/WindowsNT/
Windows2000/WindowsXP.And theselectedPCshouldhave1serialportatleastfor
communicatingwiththeDriver.
Doubleclick “ProTuner_All_Setup_V1.0.exe”tobegininstallingthe ProTuner.SeeFigure11.
Click Next toenterthe “LicenseAgreement”window. SeeFigure12.
Figure 11:Begintoinstall the ProTuner
Note:ProTuner_All_Setup_V1.0.exe canbeusedforallLeadshinedigitaldrives.Usercan
getitfromeitherLeadshineCDorwebsite.Pleasegetthelatestversionfrom
http://www.leadshine.com.
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 12:License agreement
Choose “Iagree tothetermsofthislicenseagreement”andclick Next tocontinueinstallation.The
usercanenteruser sinformationinthefollowingwindow.SeeFigure13.Afterenteringtheuser s
information, click Next toselectinstallationfolder,whereyouwouldliketoinstall the ProTuner.See
Figure14.
Figure 13:User sinformationsettings

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 14:Installation foldersettings
Figure 15:Shortcutfoldersetting
Setthe “ShortcutFolder”inFigure15andcontinuetoinstallthe ProTuner byfollowingFigure16
andFigure17.An InstallationSuccessful windowwillappearifthe ProTuner isinstalled
successfully. SeeFigure18.
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 16:Installation informationsummarization
Figure 17:Installing the ProTuner

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 18:Finishinstallation
ConnectionsandTesting
ConnectthesteppingsystemaccordingtothecontentsinprevioussectionsandconnectthePCtothe
driverasthefollowingfigure.
RS232 InterfaceConnection
Figure 19:RS232interface connection
Testing theStepping System
Turnonthepowersupply,thegreen(Power)LEDwilllight.The3DM683 hasdefaultparameters
storedinthedriver.Ifthesystemhasnohardwareandwiringsproblem,themotorshouldbelocked
and thedrivershouldbeready.
If theredLEDimmediatelyturnson (flickers),thencheckpowersupply,themotor,motorwirings
3DM683
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
and tryagain.Openthetuningsoftware ProTuner andcheckdriverstatusbyclicking Err_check.If
it s PhaseError,checkthemotor,motorwiringsandtryagain.Ifitstill doesn tworkafteryou
followedall oftheprevioussteps,pleasecontactusat [e-mail].
If theREDLEDisoffand themotorisnormal,thenyoucanstarttotunetheservo with ProTuner.
However, werecommend youseethefollowingcontentsbeforestartingtuning.
SoftwareIntroduction
ProTuner MainWindow
Figure 20:ProTuner
ØOption
Theusercanchoosethree drop-downmenusbyclicking “Option”,including ComConfig,
SaveToDriver and Exit.
lComConfig:ConfigureComcommunicationinterface.
lSaveToDriver: Downloadthecurrentparametersettingstothedriver.
MenuBar
StatusBar

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
lExit: Exit the ProTuner.
ComConfigWindow
Figure 21:RS232communication configurationwindow
Serial Port: Selecttheserial communicationporttowhichthedriverisconnected. Thefactorydefault
settingisCOM1.
BaudRate: Selectthecommunication baudrate. Thefactorydefaultsettingis38400.
Click Open buttontoestablishaconnectionwiththespecifiedsettings.Whenconnecting,youcan
choose SaveToDrive todownloadthecurrentparametersettingstothedriver,ortouploadthestored
driversettingsintothe ProTuner byclicking Tuning > PositionLoop onthemenubar.
Tuning
Theusercanchooseoneortwodrop-downmenu(s)byclicking Tuning,including CurrentLoop and
SystemConfig.
lCurrentLoop:InCurrentTuningwindow,theusercantunethe Kp (ProportionalGain)and
Ki (IntegralGain) ofdriver scurrentlooptooptimizeresponseswithdifferentmotors.
Start/RestartaStepResponsetesttogetanoptimum response.
Kp:ProportionalGain.ProportionalGaindeterminestheresponseofthedrivertocurrentsetting
command.LowProportionalGainprovidesastablesystem(doesn toscillate),haslowstiffness,and
largecurrenterror,causingpoorperformancesintrackingcurrentsettingcommand ineachsteplike
Figure23.Too largeProportionalGainvalueswill causeoscillationsandunstablesystems.
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 22:CurrentTuningwindow
Ki: IntegralGain.IntegralGainhelpsthedrivertoovercomestaticcurrenterrors.Aloworzero
valuefortheIntegralGainmayhavecurrenterrorsatrest. IncreasingtheIntegralGaincanreducethe
error. IftheIntegralGainistoo large,thesystemsmay “hunt”(oscillate)about thedesiredposition.
Start button:TheusercanstartaStepResponsetestbyclickingthisbutton.Start/RestartaStep
ResponsetesttogetanoptimumresponselikeFigure22,andremembertosavethesettingstothe
driverwhenfinishtuning. SeeFigure24.
Figure 23:Kp=785, Ki=0(poorperformances)

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 24:Finishtuningandsavesetting tothe driver
Notes:
However,iftheuserdoesnotwanttotunethecurrentloopafterchangingadifferentsteppingmotor,
then Motorauto-identificationandparameterauto-configuration technologyofthe3DM683 can
replacemanualtuningthedriverwith ProTuner.JustchangesSW4twotimesin1second,andthen
thedriverwillauto-identifythenewmotorandauto-configurerelatedcontrol parametersforoptimum
responses. Recommend usethisfunctionafterchangingthedrivenmotor.
lSystemConfig:
In SystemConfig window,theusercanconfigurePeakCurrent,Microstep,Command Type,Active
Edge,andeliminatemotorresonance.Abuilt-inpulsegeneratorcanbeusedfortestduringtuning.
See Picture25.
PeakCur: PeakCurrent.Thevalueisthepeakcurrent totheselectedmotorandcanbesetfrom0.5
to8.3A.Theusercansetthepeakcurrentwith ProTuner orDIPswitches,seemoreinformation
aboutsettingoutputcurrentofthedriverinsection5 “ConnectingtheMotor”andsection7
“SelectingMicrostepResolutionandDriverOutputCurrent”.
MicroStep: MicrostepResolution.Thevalueisdriver smicrostepresolutionsettingandcanbeset
from1to512.Theusercansetthemicrostepwith ProTuner orDIPswitches,Seemoreinformation
aboutsettingoutputcurrentofthedriverinsection7 “SelectingMicrostepResolutionand Driver
OutputCurrent”.
ElecDamp:ElectronicDampingCoefficient.Theelectronicdampingrestrainresonanceofthe
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
systemand preventamplitudeoftheoscillationfromincreasingtotheextendthatit makesthemotor
out ofcontrol. Theoptimalvaluedependsonthesystem, andthedefaultvalueis3000.
Figure 25:SystemConfigwindow
CommandType:Command Type ofcontrolsignal,includingPUL/DIRand CW/CCW.Setthis
parameteraccordingto Command Type ofmotioncontroller.
ActiveEdge:ActiveEdge. Theusercansetthetriggerededgeofpulsecommand signal inthispanel.
WhenthedriverworksinCW/CCWmode,nomatterwhatlevelisatfixedlevelterminal,thedriver
canworksproperly.
DirectionDef:DirectionDefinition. Relatethedefaultrunningdirectionto aHIGH levelinputin
DIRor Low level inputinDIR.ThispanelisusedforPUL/DIRcommand typeonly.Pleasenotethat
thedefaultdirectionisalsorelatedtomotorcoil connections.
Anti-ResonanceIntroduction
Stepmotorsarehighlyresonant, whichresultsinvibrationandringing.Theringingutilizesalarge
fractionofthemotor'savailabletorque –therebywastingperformance.Furthermore,atmid-range
velocities,theresonance canbecomesoseverethatthemotorloosessynchronizationandstalls.The

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
3DM683 driverprovidesrobustanti-resonancecontroltostopthevibrationsandmaintainequilibrium.
Thisfeaturerequiresthat thedriverbeconfiguredwithrespect tothetotal inertiainthesystem.Ifset
improperly, theeffectivenessofthefeaturemaybediminished.
Theusercaninvokeordisablethefeaturebysetting Amp and Phase valuesin SystemConfig
window. Amp and Phase valuesall zeroistodisablethefeature,otherwiseistoinvokethefeature.It
shouldbeenabledunlessthesystemconfigurationeitherdoesnotneeditorcannottolerateit.A
systemwithloosecouplingsorviscousloadinggenerallydoesnotneedthisfeature.Ifasystemhas
compliant(springy)couplingandisabsentappreciablyviscosity,itmaynotrespondwelltotheactive,
anti-resonantloopinthedrive.Theanti-resonantfeatureisnotdesignedtodampsucha4th order
system. Iftheapplication ofanti-resonanceresultsindegradationorinstability, it shouldbedisabled.
1
st ResonanceArea:Parametersfor1st resonancearea. Usuallybetween0.6rpsand2rps.
Amp1 isAmplitudeadjustmentfor1st resonance area.
Phase1 isPhaseadjustmentfor1st resonancearea.Theusercanenteravaluedirectlyinthetextbox
ormovethesliderbarbackandforthtogetanoptimumvalue.
InternalPulser: Thereisaninternalpulsegeneratordesignedfordriverself-testingand
anti-resonancetuning. You canissueamotionbythissimplecontroller.
Cycle checkbox:Themotorwillrunindoubledirectionifthisbox ischecked.
Reverse checkbox:Usedtoreversetheinitialrunningdirection..
Interval editbox:Holdingtimebetweeneachrepeat,unitis millisecond.
Repeat edit box:Total motionrepeats.
Length editbox:Journeyofeachmotion,unit is revolution.
Start/Stop button:TheusercanStart/Stopamotion testbyclickingthisbutton.
ProcedureforAchievingOptimumPerformance
Step1: Startthemotiontestbyclicking Start/Stop button.Findaresonancespeedbyslightlymoving
thesliderbarofinternalpulsegeneratorbackandforth.SeeFigure26.
Step2: Run themotorattheresonance speedand verifythemotorsmoothness.Youmayfindabetter
smoothingvaluebyslightlymovingthesliderbarsof AMP(s)and Phase(s)backandforth.
Itisveryimportanttomakethe AMP(s)and Phase(s)adjustmentsatthepropertestspeedswithan
unloadedmotor.Runningatanincorrecttestspeedwillnotexcitethemotoratitspeakresonance,
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
makingit moredifficult tofindproperadjustment values. Optimum AMP(s)and Phase(s)valuesmay
bealittledifferentbetweenrunningthetestswithanunloadedmotorandaloadmotor.
Pleaseremembertoclick SavetoDrive todownloadthefinalparametersettingstothedriverwhen
finishtuning.SeeFigure27.
Figure 26:Anti-resonance tuning

3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
Figure 27:Finishing tuninganddownloadparametersettingstothe driver
ØErr_check
lErrorCheck:Thiswindowshowsboththepresentstatusofeacherroreventandtheirhistory.
Currenterrorevent(s)canberesetbyclicking EraseCurrentErr! button,andallerrorevents
canberesetbyclicking EraseAll! button.Listofthelasttendrivefaults.#0beingthemost
recent, #9istheoldest.SeeFigure28.
Figure 28:Errorcheckwindow
OverCurrent: Over-currentProtection.Protection willbeactivatedwhencontinuouscurrent
exceedstheupperlimit.
OverVoltage:Over-voltageProtection.Whenpowersupplyvoltageexceeds62±1VDC,protection
willbeactivated.
PhaseErr: PhaseErrorProtection.Motorpowerlineswrong&notconnectedwillactivatethis
3DM683DigitalSteppingDriverManualV1.0
Tel:[phone]WebSite: www.leadshine.com
protection.
ErrCounter: Displayscurrenterror(s)andcurrenterrorhistory.
EraseCurrentErr!:EraseCurrentErr button.Theusercanclearcurrenterror(s)byclickingthis
button.
EraseAll!: EraseAll! button.Theusercanclearallerror(s)includingerrorhistorybyclickingthis
button.
ØAbout
Theusercanchoosetwodrop-downmenusbyclicking “About”,including ProductInformation and
ContactUs.
lProductInformation window:Showssomeproduct information about ProTuner.
lContactUs window: Showssomecontactinformationabout Leadshine.
Figure 29:Productinformation
Figure 30:Contactinformation

3DM683MicrosteppingDriverManual V1.0
Tel:[phone] WebSite: www.leadshine.com
APPENDIX
TwelveMonthLimitedWarranty
LeadshineTechnologyCo., Ltd.warrantsitsproductsagainstdefectsinmaterialsand
workmanshipforaperiodof12monthsfromshipment outoffactory.Duringthewarrantyperiod,
Leadshinewilleither,atitsoption,repairorreplaceproductswhichprovedtobedefective.
Exclusions
Theabovewarrantydoesnotextendtoanyproduct damagedbyreasonsofimproperorinadequate
handlingsbycustomer,improperorinadequatecustomerwirings,unauthorizedmodificationor
misuse,oroperationbeyond theelectricalspecificationsoftheproductand/oroperationbeyond
environmentalspecificationsfortheproduct.
ObtainingWarranty Service
Toobtainwarrantyservice,areturnedmaterialauthorizationnumber(RMA)mustbeobtained
fromcustomerserviceate-mail: [e-mail] beforereturningproductforservice.
CustomershallprepayshippingchargesforproductsreturnedtoLeadshineforwarrantyservice,
and Leadshineshallpayforreturnofproductstocustomer.
Warranty Limitations
Leadshinemakesnootherwarranty,eitherexpressedorimplied,withrespecttotheproduct.
Leadshinespecificallydisclaimstheimpliedwarrantiesofmerchantabilityand fitnessfora
particularpurpose.Somejurisdictionsdonotallowlimitationsonhowlongandimpliedwarranty
lasts,sotheabovelimitationorexclusionmaynot applytoyou. However, anyimpliedwarrantyof
merchantabilityorfitnessislimitedtothe12-monthdurationofthiswrittenwarranty.
Shipping FailedProduct
If yourproductfailduringthewarrantyperiod,e-mailcustomerserviceat [e-mail] to
obtainareturnedmaterialauthorizationnumber(RMA)beforereturningproductforservice.
Pleaseincludeawrittendescriptionoftheproblemalongwithcontactnameandaddress.Send
failedproducttodistributorinyourareaor:LeadshineTechnologyCo., Ltd.3/F,Block2,Nanyou
TiananIndustrialPark,NanshanDist,Shenzhen,China. Alsoencloseinformationregardingthe
circumstancespriortoproductfailure.
