leahua LH-C070 User manual

www.leahualight.com
LH-C070 B-eyes 12x40W RGBW 4in1 zoom
wash pixel moving head light
User Manual
This manual contains important information.
Please read before operating fixture.

www.leahualight.com 1
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or injury
to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate
the dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light

www.leahualight.com 2
2 TECHNOLOGY REFERENCE
Input voltage: 110–240 V, 50/60 Hz
Power: 500W
Light source: 12pcs 40W, RGBW 4in1 mixing color
Working lifetime: About 50000 hours
IP rating: IP20
Working temperature:-20℃-40℃
Control mode: DMX 512, Auto, Master-slave, Sound
4Channel mode: STD/HSI/GUI/EXT (17/11/18/58CH)
Function: Dyeing, strobe, zoom, light beam effect
Pan: 540°(16bit) Electric correction
Tilt: 270°(16bit) Electric correction
Zoom range: 7°~ 70°
Dimmer: 0-100% dimmer
Display panel: Blue LCD screen
Housing material: Engineering plastics
Net weight: 15kg
MIN ZOOM-7°Beam Diameter
Distance(m)
3m
5m
7m
Beam Openning
0.60m
0.90m
xxm
Itensity(lux)
lux
lux
lux
Red
10920
4900
2140
Green
22100
9038
4296
Blue
25800
9953
4300
White
29820
12560
6000
R+G+B+W
92100
23560
11510

www.leahualight.com 3
MIN ZOOM-70°Beam Diameter
3 Board Instruction
Operate Menu
Menu
Item1
Item2
Item3
DmxAddr
001 - 512
Fixture
DMX Mode
STD/HSI/GUI/EXT
Run Mode
DMX/Sound/Host
Pan Invert
Close/Open
Tilt Invert
Close/Open
Manual
Pan
000 - 255
Pan Fine
000 - 255
Tilt
000 - 255
Tilt Fine
000 - 255
P/T Speed
000 - 255
Dim
000 - 255
Dim Fine
000 - 255
Srobe
000 - 255
Red
000 - 255
Green
000 - 255
Blue
000 - 255
Distance(m)
1m
3m
5m
Beam Openning
XX
XX
XX
Itensity(lux)
lux
lux
lux
Red
3536
518
198
Green
6343
855
335
Blue
6350
812
297
White
9248
1160
468
R+G+B+W
17580
2250
856

www.leahualight.com 4
Menu
Item1
Item2
Item3
White
000 - 255
Macro
000 - 255
CCT
000 - 255
Effect
000 - 255
Zoom
000 - 255
Reset
000 - 255
Infornation
Time
Current Time
xxxh
Total Time
xxxh
Power Count
xxx
Sensor
Pan
Ture/False
Tilt
Ture/False
Zoom
Ture/False
Temp
Ture/False
Fan
Ture/False
Temperature
Head Temp
xxx °C
Fan Speed
xxxx RPM
Software Version
Panel
V1.07
Motor
V1.03
Dimmer
V1.02
Network
Factory
Password
000 - 255
Pan
000 - 255
Tilt
000 - 255
Zoom
000 - 255
Red
000 - 255
Green
000 - 255
Blue
000 - 255
White
000 - 255

www.leahualight.com 5
Menu
Item1
Item2
Item3
FixReset
Motor Reset
Cance/Run
Factory
Cance/Run
Display
Language
EN/CH
DispFlip
Normal/Reverse
DispMode
Show/60s
Network
Protocol
ArtNet/sACN
KlingNet
Disable/Enable
Universe
000-255
IP Address
002.000.000.000
Subnet Mask
255.000.000.000
4 DMX CHANNEL SHEET
STD Mode:17CH
Channel
Function
DMX Value
Description
1
Pan
0-255
Pan rotation
2
Pan Fine
0-255
Pan fine
3
Tilt
0-255
Tilt rotation
4
Tilt Fine
0-255
Tilt fine
5
P/T Speed
0-255
P/T speed
6
Dim
0-255
Total dimmer 0-100%
7
Dim Fine
0-255
Dimmer
8
Strobe
0 - 3
No function
4-103
Strobe,from slow to fast
104 - 107
Open
108-207
Pulsation,from slow to fast

www.leahualight.com 6
Channel
Function
DMX Value
Description
208 - 212
Open
231-225
Random slow strobe
226-238
Random medium strobe
239-251
Random fast strobe
252-255
Open
9
Red
0-255
LED off - LED on
10
Green
0-255
LED off - LED on
11
Blue
0-255
LED off - LED on
12
White
0-255
LED off - LED on
13
CCT
0-255
colour temperature adjusting
14
Macro
0-255
Macro color
15
Effect
0
Closed
1-100
Dream,gradual change from
slow to fast
101-200
Wave,from slow to fast
201-255
No function
16
Zoom
0-255
Wide beam- narrow beam
17
Reset
0-59
No function
60-99
Fixture reset
100-199
Auto program on
200-255
No function
HSI Mode:11CH
Channel
Function
DMX Value
Description
1
Pan
0-255
Pan rotation
2
Pan Fine
0-255
Pan fine

www.leahualight.com 7
Channel
Function
DMX Value
Description
3
Tilt
0-255
Tilt rotation
4
Tilt Fine
0-255
Tilt fine
5
P/T Speed
0-255
P/T speed
6
Strobe
0 - 3
No function
4-103
Strobe,from slow to fast
104 - 107
Open
108-207
Pulsation,from slow to
fast
208 - 212
Open
231-225
Random slow strobe
226-238
Random medium strobe
239-251
Random fast strobe
252-255
Open
7
Hue
0-255
Hue adjusting
8
Saturation
0-255
Saturation adjusting
9
Intensity
0-255
Intensity adjusting
10
Zoom
0-255
Wide beam- narrow beam
11
Reset
0-59
No function
60-99
Fixture reset
100-199
Auto program ON
200-255
No function
GUI Mode:18CH
Channel
Function
DMX Value
Description
1
Pan
0-255
Pan rotation
2
Pan Fine
0-255
Pan fine

www.leahualight.com 8
Channel
Function
DMX Value
Description
3
Tilt
0-255
Tilt rotation
4
Tilt Fine
0-255
Tilt fine
5
P/T Speed
0-255
P/T speed
6
Dim
0-255
Total dimmer 0-100%
7
Strobe
0 - 3
No function
4-103
Strobe,from slow to fast
104 - 107
Open
108-207
Pulsation,from slow to fast
208 - 212
Open
231-225
Random slow strobe
226-238
Random medium strobe
239-251
Random fast strobe
252-255
Open
8
Red
0-255
LED off - LED on
9
Green
0-255
LED off - LED on
10
Blue
0-255
LED off - LED on
11
White
0-255
LED off - LED on
12
Macro
0-255
Macro color
13
Shape
0
Closed
1-6
LED 1 shining
7-13
LED 2 shining
14-20
LED 3 shining
21-27
LED 4 shining
28-34
LED 5 shining
35-41
LED 6 shining
42-48
LED 7 shining
49-55
LED 8 shining
56-62
LED 9 shining

www.leahualight.com 9
Channel
Function
DMX Value
Description
63-69
LED 10 shining
70-76
LED 11 shining
77-83
LED 12 shining
84-90
3LEDs Pendulum static shape 1
91-97
3LEDs Pendulum static shape 2
98-104
3LEDs Pendulum static shape 3
105-111
4LEDs Pendulum static shape 1
112-118
4LEDs Pendulum static shape 2
119-125
4LEDs Pendulum static shape 3
126-132
3LEDs Inverted pendulum
static shape 1
133-139
3LEDs Inverted pendulum
static shape 2
140-146
3LEDs Inverted pendulum
static shape 3
147-153
3LEDs static patterns in the
middle 1
154-160
9LEDs static pattern in outer
ring
161-167
Windmill static pattern
168-174
Single LED Flow dynamic
effect
175-181
2LEDs Flow dynamic effect
182-188
3LEDs Flow dynamic effect
189-195
3LEDs Inverted pendulum flow
dynamic effect
196-202
4LEDs Pendulum flow
dynamic effect
203-209
3LEDs Pendulum flow

www.leahualight.com 10
Channel
Function
DMX Value
Description
dynamic effect
210-216
Wavy flow effect
217-223
Windmill rotation effect
224-230
Petal bloom dynamic effect
231-237
Color petal bloom effect
238-244
Color petal wave effect
245-251
Color petal rotation effect
252-255
Colorful rotation effect
14
Speed
0-255
Graphic effect speed selection
15
Shape Back
0-255
Graphic background color
selection
128-255
Complete reset
16
Back Dim
0-255
Background color brightness,
from bright to dark
17
Zoom
0-255
Wide beam- narrow beam
18
Reset/Prog
0-59
No function
60-99
Fixture reset
100-199
Auto program ON
200-255
No function
EXT Mode:58CH
Channel
Function
DMX Value
Description
1
Pan
0-255
Pan rotation
2
Pan Fine
0-255
Pan fine
3
Tilt
0-255
Tilt rotation
4
Tilt Fine
0-255
Tilt fine
5
P/T Speed
0-255
P/T speed
6
Dim
0-255
Total dimmer 0-100%

www.leahualight.com 11
Channel
Function
DMX Value
Description
7
Dim Fine
0-255
Dimmer
8
Strobe
0 - 3
No function
4-103
Strobe,from slow to fast
104 - 107
Open
108-207
Pulsation,from slow to
fast
208 - 212
Open
231-225
Random slow strobe
226-238
Random medium strobe
239-251
Random fast strobe
252-255
Open
9
Red 1
0-255
LED Red1
10
Green 1
0-255
LED Green 1
11
Blue 1
0-255
LED Blue 1
12
White 1
0-255
LED White 1
13
Red 2
0-255
LED Red 2
14
Green 2
0-255
LED Green 2
15
Blue 2
0-255
LED Blue 2
16
White 2
0-255
LED White 2
17
Red 3
0-255
LED Red 3
18
Green 3
0-255
LED Green3
19
Blue 3
0-255
LED Blue 3
20
White 3
0-255
LED White 3
21
Red 4
0-255
LED Red 4
22
Green 4
0-255
LED Green 4
23
Blue 4
0-255
LED Blue 4
24
White 4
0-255
LED White 4
25
Red 5
0-255
LED Red 5

www.leahualight.com 12
Channel
Function
DMX Value
Description
26
Green 5
0-255
LED Green 5
27
Blue 5
0-255
LED Blue 5
28
White 5
0-255
LED White 5
29
Red 6
0-255
LED Red 6
30
Green 6
0-255
LED Green 6
31
Blue 6
0-255
LED Blue 6
32
White 6
0-255
LED White 6
33
Red 7
0-255
LED Red 7
34
Green 7
0-255
LED Green 7
35
Blue 7
0-255
LED Blue 7
36
White 7
0-255
LED White 7
37
Red 8
0-255
LED Red 8
38
Green 8
0-255
LED Green 8
39
Blue 8
0-255
LED Blue 8
40
White 8
0-255
LED White 8
41
Red 9
0-255
LED Red 9
42
Green 9
0-255
LED Green 9
43
Blue 9
0-255
LED Blue 9
44
White 9
0-255
LED White 9
45
Red 10
0-255
LED Red 10
46
Green 10
0-255
LED Green 10
47
Blue 10
0-255
LED Blue 10
48
White 10
0-255
LED White 10
49
Red 11
0-255
LED Red 11
50
Green 11
0-255
LED Green 11
51
Blue 11
0-255
LED Blue 11
52
White 11
0-255
LED White 11
53
Red 12
0-255
LED Red 12

www.leahualight.com 13
Channel
Function
DMX Value
Description
54
Green 12
0-255
LED Green 12
55
Blue 12
0-255
LED Blue 12
56
White 12
0-255
LED White 12
57
Zoom
0-255
Wide beam- narrow beam
58
Reset/Prog
0-59
No function
60-99
Fixture reset
100-199
Auto program ON
200-255
No function
5 DIFFICULTY RESOLUTION
The following is a list of problems and resolution, and other
malfunction preparing work should be professionally qualified staff to
deal with.
1. Bulb not working
a) Check whether approaching the service life of light bulbs, then
change it
b) Check whether bulbs circuitry leak, loss or connect poorly
2. Beam appears bleak
a) The bulbs maybe approach the service life, then change it, or
the optical components are unclean.
b) Bulbs have accumulation of dust, so the bulbs and other parts
inside the lamp should be cleaned and maintained in regular
period.
3. Computer lamp work intermittently

www.leahualight.com 14
a) Check whether the fan process naturally and become dirty
b) Check inner temperature-response control plug is off
c) Check whether the circuitry is good
4. The computer lamp not controlled by controller during lighting
a) Check numeral starting address and the connection of
communication control circuit
b) The corresponding channel button of controller is open or not
c) Check whether the fuse on power supply input jack is broken
off
6 AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill
in the related content and feedback us the problems timely, as
well as we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：(customers）

www.leahualight.com 15

Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product
in normal state, you can made under the provisions of the warranty, show the warranty card
and purchase bills(copy), and enjoy free maintenance service in a specific service center or
the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
End User
Company Name:
Add:
Sale Store
Link man:
Tel: Stamp

www.leahualight.com 16
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the
statement containing data may have changed, and will not notice the
change any more. Company retains its right to change specifications
related when product is improved. Thanks for your understanding.
