Lec+ R5006W User manual

USER GUIDE
R5006W
R5006W 13/4/06 9:19 am Page 1

Introduction
Thank you for buying this high quality fridge!
This handbook is designed to help you through each step of owning your new
fridge, from installation, to use.
Please read through all of this guide carefully before you start using your fridge,
as we have endeavoured to answer as many questions as possible, and provide
you with as much support as we can.
If, however, you should find something missing, or not covered, please contact
the Lec Customer Care team who will be only too happy to assist you on:
0870 458 4386
Our policy is one of constant development and improvement, therefore we
cannot guarantee the strict accuracy of all of our illustrations and specifications
changes may have been made subsequent to publishing.
R5006W 13/4/06 9:19 am Page 2

Contents
For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
About your product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing your appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Using your appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Care & cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Reversing the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Changing the plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Service record and Customer Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover
R5006W 13/4/06 9:19 am Page 3

For Your Safety
Disposal of old appliances
Before disposing of an old appliance, make sure that you
have broken off, or disabled any locking mechanisms to
prevent children becoming accidentally locked inside.
Remove any plugs and power leads to ensure that the
appliance is inoperative.
Please note: The refrigeration system contains
insulating gases and refrigerant which will require
specialist disposal. Most components can be recycled.
Always contact your local authority for information
regarding the correct disposal/removal of old appliances,
do not dispose of with household waste.
Warning: When disposing of an old appliance make sure
that the pipe work does not become damaged.
Packaging
All of the packaging supplied with your appliance can be
recycled, or disposed of without any harm to the
environment.
Cardboard may be crushed, or cut into smaller pieces if
required for recycling or disposal. The polythene and
polystyrene included contain no CFC’s, and are
environmentally friendly.
For further information on recycling, contact your local
council or authority.
Before installing and using your new appliance
lRead through the instructions supplied with your
appliance - failure to install or use this appliance in
accordance with the instruction book may invalidate
any warranty.
lThe manufacturer does not accept any liability for
damage caused through improper use, or incorrect
installation.
lDo not install this appliance if it has been damaged
during transportation. This includes the plug and
power supply cord.
lAlways install this appliance in line with these
instructions.
1
R5006W 13/4/06 9:19 am Page 4

For Your Safety
When using your appliance
lWarning: Do not allow the refrigerant circuit to
become damaged while using or installing. Should it
become damaged, do not use the appliance until you
are instructed to do so by a service engineer.
Refrigerant can ignite or cause damage to the eye
when leaking.
lAlways remember to unplug the appliance before
cleaning. When disconnecting from the electricity
supply, pull the plug, not the power cord.
lDo not use any electrical appliance inside the food
storage area - unless they are recommended by the
manufacturer.
lAll electrical repairs must be carried out by a qualified
electrician. Inadequate repairs may result in in a
major source of danger for the user and invalidate any
warranty.
lNever store anything dangerous inside the appliance,
such as combustibles, explosives, strong acid and alkali
etc. Alcoholic beverages must be stored upright in an
air tight container in the refrigerator. Never store
alcohol in a freezer.
lWhen defrosting the appliance, never use sharp or
pointed metal implements. Always use a plastic
scraper. (see Defrosting for more information).
lAlways keep any ventilation openings clear of
obstruction. Should they become blocked, clear them
straight away.
lDo not allow children to play, sit or hang onto any part
of the appliance.
lThis appliance is intended for domestic use only, for
food refrigeration and making ice.
lMake sure that the plug is in an accessible place when
installation is complete and remove all packaging.
2
R5006W 13/4/06 9:19 am Page 5

About Your Product
Model Name: R5006W
lThis appliance operates at a voltage of:
220 - 240V ~ 50Hz
3
Technical Specification
Width (mm) 500
Depth ( mm) 510
Height (mm) 525
Useable volume (litres) 50
Actual volume (litres) 61
Energy Rating B
Climate Class N
Noise (dB (A) re 1 pW) 42
Refrigerant type R600a
1) Temperature regulator 2) Ice cube tray 3) Evaporator
4) Bottle rack 5) Shelf6) Water tray
7) Lock
R5006W 13/4/06 9:19 am Page 6

Installing Your Appliance
Before you start
lThis appliance must stand on a flat, even surface.
Do not install onto carpeted surfaces as this prevent
adequate ventilation.
lInstall the appliance in a well ventilated room. The
appliance should not be placed near to any heat heat
sources (cookers, heaters etc.) or in any unheated
rooms (garages, outhouses etc.) as the ambient
temperature affects the performance of the appliance.
lDo not expose the appliance to damp conditions, open
air or rain.
lDo not lift the appliance by the pipes or the door when
moving.
Should the appliance become damaged, contact Lec
Customer Care and do not use the appliance until you
are instructed to do so by a service engineer.
Installation clearances
lAllow 10cms on each side of the appliance and 10cms
over the top to ensure proper ventilation. The rear of
the appliance can go against a wall if necessary.
Getting started
Once you have installed your appliance in an appropriate
location, follow the start up procedure below:
lBefore you plug in the appliance, clean thoroughly the
inside, and any accessories with warm water and
bicarbonate of soda (0.5ml to 0.5 litres) and dry with a
soft cloth.
lLeave the appliance to stand for 30 minutes to allow
the refrigerant to settle following installation and
cleaning.
lOnce dry, plug the appliance into the socket.
lTurn the thermostat to the required setting.
lLeave the appliance for at least 4 hours before storing
any food inside to allow a sufficient temperature to be
reached.
4
10 cm 10 cm
R5006W 13/4/06 9:19 am Page 7

Using Your Appliance
About the thermostat
lThe thermostat is located in the upper left part of the
appliance.
lThe reduce the temperature inside the appliance, turn
the thermostat clockwise.
lTo increase the temperature inside the appliance turn
the thermostat anticlockwise.
lDepending on the ambient temperature of the room
the appliance is in, you may need to adjust the
thermostat accordingly.
In summer months the thermostat may need to be set
at a lower temperature.
Thermostat guide
In some cases food inside the refrigerator may become
frozen, common causes of this are:
lThermostat is set too high - you will need to adjust
the setting to a more suitable temperature.
lThe ambient temperature has dropped suddenly (i.e.
during winter) and this makes the refrigerator even
colder.
5
Thermostat
setting
Season /
best use
Ambient
temperature (˚C)
1 - 2 Summer 25 - 35
2 - 4 Spring / Autumn 15 - 25
4 - 5 Winter 5 - 15
6 - 7 Fast refrigeration or
making ice
n/a
(remember to re-set after
24 hours to the previous
setting)
Low /
Warmest Off
High /
Coldest
R5006W 13/4/06 9:19 am Page 8

Using Your Appliance
Tips for using this appliance
lBefore storing cooked foods in the refrigerator, allow
them to cool to room temperature.
lTo maintain adequate air circulation, do not over fill
the appliance. If there is too much food inside, the
compressor does not work as effectively.
lDo not open the door any more than necessary - this
will keep the temperature as cold as possible inside.
lIf you are storing any frozen food in the freezer
compartment, make sure that you follow the food
manufacturers guidelines.
lIces and water ices should not be consumed straight
from the freezer - this can cause ice burns to the
tongue and hands.
lNever touch the inside of the appliance, or any frozen
items with wet hands. This can cause injury to your
hands if they stick to cold surfaces.
lWrap or cover foods well before storing. Always make
sure that any packaging is air tight and suitable for
use inside a fridge.
lCooked meats and raw meats should be stored on
separate shelves, and raw meat should not be allowed
to drip onto other foods.
Making ice cubes
lFill the ice cube tray 3/4 full with water and place into
the fridge.
lSet the thermostat to ‘7’.
lOnce the water has frozen, return to thermostat to the
previous setting.
lTo remove ice cubes, twist the try or place under
running water for a few seconds to loosen.
lDo not use sharp, pointed or metal implements to
remove the ice cube tray if it becomes frozen to the
fridge.
6
R5006W 13/4/06 9:19 am Page 9

Using Your Appliance
Defrosting your appliance
Your appliance will need defrosting periodically.
Ice forms on the inside of the appliance while it is in use,
this is normal, however if the ice becomes too thick
(between 4 - 6mm) it reduces efficiency and increases
energy consumption. Defrosting the appliance will help
to ensure the best performance possible.
To defrost:
lUnplug the appliance and set the thermostat to the
‘off’ position.
lLeave the appliance to defrost. You can accelerate
defrosting by placing a bowl of warm (not hot) water
inside the appliance on a piece of cardboard.
lDo not use sharp, pointed or metal implements to
scrap ice from the inside of the appliance. Use a
plastic scraper.
lDo not use mechanical devices (hair dryer etc.) to
accelerate the defrosting process.
lOnce defrosting is completed, make sure that the
inside of the appliance is dry and clean, plug in the
appliance and switch the thermostat to the required
temperature.
If there is any food in the appliance at the time of
defrosting, remove it from the appliance wrap it well and
store in a cool, dry place. Alternatively you can store it in
a different freezer if possible.
In the event of a power cut
If the power failure is 3 hours or less, food can remain
inside the appliance. Keep the door closed to maintain
the temperature inside.
If the power cut is longer than 3 hours, remove all food,
wrap well and store in a cool dry place.
Important: Be aware that the storage life of the food will
have been reduced. Use up this food as soon as possible
or discard. Do not re-freeze food which has thawed,
either consume or cook and re-freeze if appropriate.
7
R5006W 13/4/06 9:19 am Page 10

Care & Cleaning
Before cleaning your appliance
You should always unplug this appliance before cleaning.
It is advisable to defrost the appliance before cleaning
(see previous page).
To clean your appliance
lOnce defrosted, remove the accessories inside and
clean the using warm water and a neutral detergent.
Do not place them in a dishwasher.
lClean the inside of the cabinet with warm water and a
neutral detergent, do not use harsh abrasives or
caustic cleaners.
lDry the inside of the cabinet with a soft, dry cloth.
Always make sure the inside of the appliance is dry
after cleaning.
lAvoid getting water into the electric components of the
appliance, or spilling water on the fridge.
lWhen cleaning the door seals, use only warm soapy
water. Please use a mild soap and avoid damaging the
door seal as this will affect the performance of your
appliance.
lClean the outside of the appliance with warm, soapy
water and dry with a soft cloth. Any accumulation of
dirt and dust should be removed from the back and
bottom of the appliance to maintain adequate
ventilation.
lIf the appliance is not in use for a long period of time,
you should defrost and clean the appliance as detailed.
Make sure that it is dry, then unplug and leave the
door open to prevent unpleasant smells inside.
Please note: Regular turning off may shorten the life of
this appliance.
8
R5006W 13/4/06 9:19 am Page 11

Troubleshooting
Before calling Lec Customer Care, please check the table
below to see if the problem can be solved without calling
for a Service engineer.
Please note: Any damage caused by not following the
instructions within this handbook may lead to a charge
for a service engineer visit and any repairs carried out.
9
Problem Solution
The fridge doesn’t work lCheck that the appliance is
switched on
lCheck that the plug is not
damaged
lCheck that the fuse has not
blown
lCheck that the voltage is correct
for the appliance
Unusual noises lCheck that the appliance is on a
flat, level surface.
lCheck that nothing is coming
into contact with the appliance.
The temperature inside the fridge is
not cold enough.
lCheck that there is not too
much stored in the appliance.
lCheck the frequency of door
openings. If opened too often
this can cause the compressor
to run for some time.
lCheck that the thermostat is set
to a suitable temperature.
lCheck that the appliance is not
is direct sunlight, or near a
heating source.
lCheck that the ventilation grille
has not become blocked.
The outer surfaces of the fridge are
wet
lCaused by condensation - dry
the outer of the appliance
carefully.
The inner surfaces of the fridge are
wet
lThe door is opened frequently,
or kept open too long.
lCaused by condensation - dry
the inside of the appliance
thoroughly.
R5006W 13/4/06 9:19 am Page 12

Reversing The Door
Reversible door
lDetach the plug (6) at the left upper corner and the
component (1) at the left lower corner.
lDetach the cover (5) of the hinge box at the right
upper corner to remove the upper hinge. Hold and lift
the door to take it out, place the door in a safe place
to prevent damage.
lDetach the lower hinge (2) and the component (3).
Insert component (3) to the left hole of the lower
hinge (2) and tighten.
lAssemble component (1) to the corresponding position
on the right side and tighten.
lAssemble the upper hinge (4) to the corresponding
position on the left side and tighten.
lAssemble the door from below on the hinge (4).
lAssemble the lower hinge (2) to the left side of the
door.
lInsert the plug (6) on the right upper corner.
lAfter reversal of the door, open and close several times
to check that the door moves freely with no unusual
noises or sticking, and that all of the screws and
hinges are tight.
10
R5006W 13/4/06 9:19 am Page 13

Changing the Plug 11
Connecting to the electricity supply
Warning - this appliance must be earthed.
lThe flexible mains lead is supplied connected to a BS
1363 fused plug, having a fuse of 13 amp capacity.
lIf this plug does not fit in the socket in your home, it
should be replaced by a suitable plug as outlined
below.
As the colours of the wires in the mains lead of the
appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
lThe wire which is green and yellow must be connected
to the terminal marked E(Earth) or coloured
green.
lThe wire which is coloured blue must be connected to
the terminal marked N(Neutral) or coloured black.
lThe wire which is coloured brown must be connected
to the terminal marked L(Live) or coloured red.
The plug and socket must be accessible after
installation.
Should the mains lead ever need replacing:
We recommend that this procedure is carried out by a
qualified electrician who will replace it with a lead of the
same size and temperature rating.
Important: ensure that you route all mains, electrical
cables and flexible tubing well clear of any adjacent heat
source.
E(Earth)
GREEN / YELLOW
L (Live)
BROWN
N(Neutral)
BLUE
Use a 3 amp fuse
in a 13 amp plug.
The wires in the mains lead
are coloured in accordance
with the following code:
Green and Yellow = Earth
Blue = Neutral
Brown = Live
R5006W 13/4/06 9:19 am Page 14

Service Record
Date of purchase Installers stamp / Printed name Date of installation
Place of purchase:
Date Part(s) replaced Engineers Stamp/
Printed Name
Model Number
Serial Number
Please record your model number and serial number in the space below.
Having these numbers to hand will help us to help you, quickly and more
efficiently.
When contacting us, please use the Customer Care number on the back
cover of this handbook
R5006W 13/4/06 9:19 am Page 15

Lec Refrigeration
Stoney Lane, Prescot, Merseyside, L35 2XW
Customer Care Centre: 0870 458 4386
www.lec.co.uk
Lec Refrigeration, a division of Glen Dimplex Home Appliances
08 26312 00 © 01.2006
R5006W 13/4/06 9:19 am Page 16
