Lec+ TF55207W User manual

说明书递交文档
设 计
DESIGN
林芳芳
2017.04.27
校 对
CO.BY 蒋卨敏 LEC TF55207W(CE-BCD275WM-SQ)
说明书
许岩
图号/物料编码 PART NO.
标准化
STANDARD
图纸名称 PART NAME
业务
seller
图样标记
REL
版本号
REV.NO.
重量(g)
WEIGHT
比例
scale
材料 MATERIAL
80g双胶纸
1111
0
批 准
A
UTHORIZE
共 页
TOTAL SHEETS
第 页
NO. OF SHEETS
美的冰箱事业部
MIDEA REFRIGERATION DIVISION
技术要求
标记
MARKER 变更内容 修改日期 签名
①
②
③
④
⑤
1. 尺寸：32K；
2. 说明书印刷颜色：单色；
3. 样板需送设计部门封样；
4. 制件必须满足QMB-J53.005 产品说明书及其它类似印刷件技术规范。
5. 需要符合美的冰箱事业的最新版《QMB-GC08.007 有害物质管理规定》的限值要求。
条码仅供参参考，实际扫码按正确的14位新物料编码生成(文字部份固定不变，前后无空格，黑色印刷）
码制与其它要求按冰箱事业部最新公文要求
SIZE:60*20mm
xxxxxxxxxxxxxx:14
说明书最后一页添加条码

TF55207W

Contents
Safety Warnings........................................................................................................................... 4
Unpacking.................................................................................................................................... 6
Installation ................................................................................................................................... 7
Location ..................................................................................................................................................................... 7
Levelling the Unit ................................................................................................................................................... 7
Free Space Requirements ................................................................................................................................... 7
Reversing the Door Swing................................................................................................................................... 8
Cleaning Before Use ............................................................................................................................................13
Before Using Your Unit........................................................................................................................................13
Product Overview...................................................................................................................... 14
Operation ................................................................................................................................... 15
Switching On Your Unit ......................................................................................................................................15
Adjusting the Temperature...............................................................................................................................15
Noises Inside the Unit!........................................................................................................................................16
Tips for Keeping Food in the Unit...................................................................................................................16
Preparations for Freezing...................................................................................................................................17
Defrosting Frozen Food......................................................................................................................................17
Cleaning ..................................................................................................................................... 18
Defrosting ...............................................................................................................................................................18
Cleaning the Interior and the Exterior of the Unit....................................................................................18
Maintenance .............................................................................................................................. 19
Changing the Internal Light .............................................................................................................................19
Care When Handling / Moving the Unit.......................................................................................................19
Servicing..................................................................................................................................................................19
........................................................................................................19
Condensation.........................................................................................................................................................19
Disposal...................................................................................................................................... 19

Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for use in Domestic situations only and should
not be used in commercial or other business applications.
It should be used in a dry indoor location not subject to sub-zero
temperatures.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
• Choose a location for your unit away from heat sources such as
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
•
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
4

• Do not store bottles or glass containers in the freezer compartment.
bottle and damage your freezer compartment. (If applicable)
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
which the unit is placed for a few minutes.)
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
5

Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Main Unit
Salad Bin Cover x 1
Salad Bin x 1
Fridge Glass Shelf x 3
Bottom Freezer Drawer
Upper Freezer Drawer x 3
Ice Tray
Egg Tray
Upper Balcony x 2 Bottom Balcony x 1
Thank you for purchasing your new LEC Fridge Freezer.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
Instruction Manual
Instruction
Manual
6
Door reversal accessory Rear spacers & screws
Freezer Flap

Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 43°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Free Space Requirements
When installing the unit, ensure that 25
mm of free space is left at both sides, 50
mm at the rear and 25 mm at the top
of the unit. The door can be opened to
the right or the left, depending on what
better suits the location.
Please ensure there is more than twice
the width and depth distance space
of the unit to fully open the door to a
maximum angle of 160°.
Max. 160°
Y mm
X mm
7
INSTALLATION
1. Remove the 2 rear spacers and the 4 screws from the accessory bag.
2. On the back of the appliance at the bottom on both sides of the compressor
area there are pre-drilled holes. Fix the 2 rear spacers to both sides of the
compressor area into these holes using the 4 screws that are provided.

Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• Ensure the unit is unplugged and empty.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
8
INSTALLATION
To reverse the door you will need to lt the appliance backward to access the
lower hinge which holds screws. Do not lt the appliance more than 45 degrees
and do not lay the appliance flat on its side.
For your own safety, a minimum of 2 people should lior lt this product.
Tools Required: Cross headed screwdriver, flat headed screwdriver and hexagonal
spanner.
1. Remove the 2 screw caps and screws from the top cover and slide the cover
away from the appliance. Slide the hinge covers from the top of the fridge door
2. Remove the screws from the hinge bracket, take it off(you may need to twist
the hinge before take the hinge away) and remove the fridge door by liing it up
and away.
Caps & screws
Hinge covers

before finally tightening the hinge.
9
INSTALLATION
