www.lectrosonics.com 9
4) Use the UP and DOWN arrow buttons to adjust the gain until the
–10 dB glows green and the –20 dB LED starts to icker red dur-
ing the loudest peaks in the audio.
5) Once the audio gain has been set, the signal can be sent through
the sound system for overall level adjustments, monitor settings,
etc.
6) If the audio output level of the receiver is too high or low, use
only the controls on the receiver to make adjustments. Always
leave the transmitter gain adjustment set according to these
instructions, and do not change it to adjust the audio output level
of the receiver.
Rollo (Low Frequency Roll-o)
The low frequency audio roll-o is adjustable to optimize performance
for ambient noise conditions or personal preference.
Low frequency audio content may be desirable or distracting, so the
point at which the roll-o takes place can be set to 20, 35, 50, 70, 100,
120 or 150 Hz.
Rolloff
70 Hz
Phase (Selecting Audio Polarity)
This setting allows for conguration for use with certain microphones,
or for setting custom parameters.
Phase
Normal
Invert
Xmit
Setting Frequency
Frequency (mHz and kHz) in can be set by using the MENU/SEL
button to choose mHz or kHz and the UP and DOWN arrows to adjust
frequency.
