LEDDOO LED Beam Cube 612 RGBW User manual

LED Beam Cube 612
RGBW

Merci d’avoir acheté le LED Beam Cube 612. Chaque LED Beam Cube 612 a été
rigoureusement testé en condition d’exploitation avant envoi. Vérifier soigneusement l’état
de l’emballage. Si le carton présente un choc, assurez-vous que l’appareil à l’intérieur est
intègre. Ne connectez jamais un appareil présentant un choc ou un défaut. En cas de
problème, contactez votre revendeur. Ne renvoyer jamais d’appareil sans avoir obtenu au
préalable l’accord de votre revendeur.
AVERSTISSEMENT Afin de réduire les risques d’électrocution ou de problèmes électriques, il
ne faut ni utiliser ni stocker cet appareil dans un environnement humide.
Cet appareil fonctionne en 230Volts. Vérifiez la tension d’alimentation source avant la mise
sous tension de l’appareil.
AVERTISSEMENT Ne jamais fixer longuement la source lumineuse de cet appareil.
Caractéristiques techniques :
Produit très compact et rapide
Alimentation 100V –240V 50/60 Hz
Consommation électrique 90 Watts
Source lumineuse 6 x 12 Watts RGBW OSRAM + 12*6 x SMD5050 RGB
Ouverture faisceau 10°
Canaux DMX 8/23/27/69
Pan 540° - Tilt illimité
Gradation fluide 0-100%
Stroboscope électronique
Dimensions 165 x 145 x 335 mm
Poids 5.7 Kg
Menu system

Modes DMX
Mode 8 canaux
Canaux
Valeur DMX
Fonction
1
000-255
DImmer Led rouge 10W
2
000-255
Led RGBW 10 W stroboscope
3
000-255
Dimmer Led rouge 5050
4
000-255
Led 5050 stroboscope
5
000-007
008-022
023-037
038-052
053-067
068-082
083-097
098-112
113-127
128-142
143-157
158-172
173-187
188-202
203-217
218-232
233-247
248-255
0
Mouvement Pan/Tilt 01
Mouvement Pan/Tilt 02
Mouvement Pan/Tilt 03
Mouvement Pan/Tilt 04
Mouvement Pan/Tilt 05
Mouvement Pan/Tilt 06
Mouvement Pan/Tilt 07
Mouvement Pan/Tilt 08
Mouvement Pan/Tilt 09
Mouvement Pan/Tilt 10
Mouvement Pan/Tilt 11
Mouvement Pan/Tilt 12
Mouvement Pan/Tilt 13
Mouvement Pan/Tilt 14
Mouvement Pan/Tilt 15
Mouvement Pan/Tilt 16
Mode musical
6
000-255
Vitesse mouvement (Lent->Rapide)

7
000-014
015-255
Couleurs
Enchainement couleurs
8
000-255
Vitesse d’enchainement (Lent->Rapide)
Mode 23 canaux
Canaux
Valeur DMX
Fonction
1
000-255
Pan 0°-540°
2
000-255
Vitesse (Rapide->Lent)
3
000-127
128-189
190-193
194-255
Tilt 0°-360°
Rotation horaire (Rapide->Lent)
Stop
Rotation anti-horaire (Rapide->Lent)
4
000-007
008-024
025-041
042-057
058-074
075-090
091-107
108-123
124-140
141-156
157-173
174-189
190-206
207-222
223-239
240-255
RGBW LED Blackout
RGBW LED1 R
RGBW LED1 G
RGBW LED1 B
RGBW LED1 W
RGBW LED1 R+G
RGBW LED1 R+B
RGBW LED1 R+W
RGBW LED1 G+B
RGBW LED1 G+W
RGBW LED1 B+W
RGBW LED1 R+G+B
RGBW LED1 R+G+W
RGBW LED1 R+B+W
RGBW LED1 G+B+W
RGBW LED1 R+G+B+W
5
000-255
RGBW LED2 Couleur
6
000-255
RGBW LED3 Couleur
7
000-255
RGBW LED4 Couleur
8
000-255
RGBW LED5 Couleur
9
000-255
RGBW LED6 Couleur
10
000-007
008-024
025-041
042-057
058-074
075-090
091-107
108-123
124-140
141-156
157-173
5050 LED Stripe 1 Blackout
5050 LED Stripe 1 Couleur 1
5050 LED Stripe 1 Couleur 2
5050 LED Stripe 1 Couleur 3
5050 LED Stripe 1 Couleur 4
5050 LED Stripe 1 Couleur 5
5050 LED Stripe 1 Couleur 6
5050 LED Stripe 1 Couleur 7
5050 LED Stripe 1 Couleur 8
5050 LED Stripe 1 Couleur 9
5050 LED Stripe 1 Couleur 10

174-189
190-206
207-222
223-239
240-255
5050 LED Stripe 1 Couleur 11
5050 LED Stripe 1 Couleur 12
5050 LED Stripe 1 Couleur 13
5050 LED Stripe 1 Couleur 14
5050 LED Stripe 1 Couleur 15
11
000-007
008-255
Pas de fonction
5050 LED Stripe 2 Couleur
12
000-007
008-255
Pas de fonction
5050 LED Stripe 3 Couleur
13
000-007
008-255
Pas de fonction
5050 LED Stripe 4 Couleur
14
000-007
008-255
Pas de fonction
5050 LED Stripe 5 Couleur
15
000-007
008-255
Pas de fonction
5050 LED Stripe 6 Couleur
16
000-007
008-255
Pas de fonction
5050 LED Stripe 7 Couleur
17
000-007
008-255
Pas de fonction
5050 LED Stripe 8 Couleur
18
000-007
008-255
Pas de fonction
5050 LED Stripe 9 Couleur
19
000-007
008-255
Pas de fonction
5050 LED Stripe 10 Couleur
20
000-007
008-255
Pas de fonction
5050 LED Stripe 11 Couleur
21
000-007
008-255
Pas de fonction
5050 LED Stripe 12 Couleur
22
000-007
008-022
023-037
038-052
053-067
068-082
083-097
098-112
113-127
128-142
143-157
158-172
173-187
188-202
203-217
218-232
233-247
248-255
Pas de fonction
Pan/Tilt mouvement 01
Pan/Tilt mouvement 02
Pan/Tilt mouvement 03
Pan/Tilt mouvement 04
Pan/Tilt mouvement 05
Pan/Tilt mouvement 06
Pan/Tilt mouvement 07
Pan/Tilt mouvement 08
Pan/Tilt mouvement 09
Pan/Tilt mouvement 10
Pan/Tilt mouvement 11
Pan/Tilt mouvement 12
Pan/Tilt mouvement 13
Pan/Tilt mouvement 14
Pan/Tilt mouvement 15
Pan/Tilt mouvement 16
Mode musical
23
000-255
Vitesse d’enchainement (Lent->Rapide)

Mode 27 canaux
Canaux
Valeur DMX
Fonction
1
000-255
Pan 0°-540°
2
000-255
Vitesse (Rapide->Lent)
3
000-127
128-189
190-193
194-255
Tilt 0°-360°
Rotation horaire (Rapide->Lent)
Stop
Rotation anti-horaire (Rapide->Lent)
4
000-255
Dimmer LED RGBW
5
000-255
Stroboscope LED RGBW
6
000-007
008-024
025-041
042-057
058-074
075-090
091-107
108-123
124-140
141-156
157-173
174-189
190-206
207-222
223-239
240-255
RGBW LED Blackout
RGBW LED1 R
RGBW LED1 G
RGBW LED1 B
RGBW LED1 W
RGBW LED1 R+G
RGBW LED1 R+B
RGBW LED1 R+W
RGBW LED1 G+B
RGBW LED1 G+W
RGBW LED1 B+W
RGBW LED1 R+G+B
RGBW LED1 R+G+W
RGBW LED1 R+B+W
RGBW LED1 G+B+W
RGBW LED1 R+G+B+W
7
000-255
RGBW LED2 Couleur
8
000-255
RGBW LED3 Couleur
9
000-255
RGBW LED4 Couleur
10
000-255
RGBW LED5 Couleur
11
000-255
RGBW LED6 Couleur
12
000-255
Dimmer LED 5050
13
000-255
Stroboscope LED 5050
14
000-007
008-024
025-041
042-057
058-074
075-090
091-107
108-123
124-140
141-156
5050 LED Stripe 1 Blackout
5050 LED Stripe 1 Couleur 1
5050 LED Stripe 1 Couleur 2
5050 LED Stripe 1 Couleur 3
5050 LED Stripe 1 Couleur 4
5050 LED Stripe 1 Couleur 5
5050 LED Stripe 1 Couleur 6
5050 LED Stripe 1 Couleur 7
5050 LED Stripe 1 Couleur 8
5050 LED Stripe 1 Couleur 9

157-173
174-189
190-206
207-222
223-239
240-255
5050 LED Stripe 1 Couleur 10
5050 LED Stripe 1 Couleur 11
5050 LED Stripe 1 Couleur 12
5050 LED Stripe 1 Couleur 13
5050 LED Stripe 1 Couleur 14
5050 LED Stripe 1 Couleur 15
15
000-007
008-255
Pas de fonction
5050 LED Stripe 2 Couleur
16
000-007
008-255
Pas de fonction
5050 LED Stripe 3 Couleur
17
000-007
008-255
Pas de fonction
5050 LED Stripe 4 Couleur
18
000-007
008-255
Pas de fonction
5050 LED Stripe 5 Couleur
19
000-007
008-255
Pas de fonction
5050 LED Stripe 6 Couleur
20
000-007
008-255
Pas de fonction
5050 LED Stripe 7 Couleur
21
000-007
008-255
Pas de fonction
5050 LED Stripe 8 Couleur
22
000-007
008-255
Pas de fonction
5050 LED Stripe 9 Couleur
23
000-007
008-255
Pas de fonction
5050 LED Stripe 10 Couleur
24
000-007
008-255
Pas de fonction
5050 LED Stripe 11 Couleur
25
000-007
008-255
Pas de fonction
5050 LED Stripe 12 Couleur
000-007
008-022
023-037
038-052
053-067
068-082
083-097
098-112
113-127
128-142
143-157
158-172
173-187
188-202
203-217
218-232
233-247
248-255
Pas de fonction
Pan/Tilt mouvement 01
Pan/Tilt mouvement 02
Pan/Tilt mouvement 03
Pan/Tilt mouvement 04
Pan/Tilt mouvement 05
Pan/Tilt mouvement 06
Pan/Tilt mouvement 07
Pan/Tilt mouvement 08
Pan/Tilt mouvement 09
Pan/Tilt mouvement 10
Pan/Tilt mouvement 11
Pan/Tilt mouvement 12
Pan/Tilt mouvement 13
Pan/Tilt mouvement 14
Pan/Tilt mouvement 15
Pan/Tilt mouvement 16
Mode musical
23
000-255
Vitesse d’enchainement (Lent->Rapide)

Mode 69 canaux
Canaux
Valeur DMX
Fonction
1
000-255
Pan 0°-540°
2
000-255
Pan Fine
3
000-255
Vitesse Pan (Rapide->Lent)
4
000-127
128-189
190-193
194-255
Tilt 0°-360°
Rotation horaire (Rapide->Lent)
Stop
Rotation anti-horaire (Rapide->Lent)
5
000-255
Dimmer LED RGBW
6
000-255
Stroboscope LED RGBW
7/11/15/19/23/27
000-255
Dimmer rouge LED RGBW
8/12/16/20/24/28
000-255
Dimmer vert LED RGBW
9/13/17/21/25/29
000-255
Dimmer bleu LED RGBW
10/14/18/22/26/30
000-255
Dimmer white LED RGBW
31
000-255
Dimmer Led 5050
31
000-255
Strobe Led 5050
33/36/39/42/45/48/51/54
57/60/63/66
000-255
Dimmer rouge LED 5050
34/37/40/43/46/49/52
55/58/61/64/67
000-255
Dimmer vert LED 5050
35/38/41/44/47/50/53
56/59/62/65/68
000-255
Dimmer bleu LED 5050
69
000-199
200-209
210-239
240-255
Pas de fonction
Reset
Pas de fonction
Stand alone

LED Beam Cube 612
RGBW
Introduction

Unpacking: Thank you for purchasing the LED BEAM moving head wash, Every fixture has
been thoroughly tested and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during shipping. If the carton
appears to be damaged, carefully inspect your fixture for any damage and be sure all
accessories necessary to operate the unit has arrived intact. In the case damage has been
found or parts are missing, please contact the manufacturer or your dealer for further
instructions. Do not return this unit to your dealer without first contacting.
Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to
rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself; doing so will void your manufactures warranty. In the unlikely event your unit may
require service please contact the manufacturer or your dealer.
Features:Technical Specification
◇Extremely small, fast and powerful LED moving beam.
◇DMX Channels: 8/23/27/69ch
◇Pan: 540°, speed adjustable; Tilt: 360° continuous rotation
◇Each LED and LED stripe can be controlled individually
◇Electronic strobe with pulse and random effects
◇High efficiency, low power consumption
◇Super compact, low weight
◇Beam angle: 8°
Voltage: 100V~240V, 50/60Hz
Light source: 6*12W 4 in 1 RGBW OSRAM+12*6*5050SMD 3 in 1 RGB LED
Power: 90W
Dimension: 165X145X335 mm+(150mm³)
Net Weight: 6.0 kg

Set Up
Power Supply: Before plugging your unit in, be sure the source voltage in your area
matches the required voltage for your fixture, The model is workable in 100-240V/50~60Hz.
Please make sure your unit voltage matches the wall outlet voltage before attempting to
operate you fixture.
DMX Linking: To ensure proper DMX data transmission, when using several DMX fixtures
try to use the shortest cable path possible. The order in which fixtures are connected in a
DMX line does not influence the DMX addressing. For example; a fixture assigned a DMX
address of 1 may be placed anywhere in a DMX line, at the beginning, at the end, or
anywhere in the middle. When a fixture is assigned a DMX address of 1, the DMX controller
knows to send DATA assigned to address 1 to that unit, no matter where it is located in the
DMX chain.
LED display menu:
DMX address
DMX Address (1-512)
Channel mode
8/23/27/69CH
Slave mode
Master mode
Slave 1
Slave 2
Auto model
Auto 0—16(speed 0—9)
Show model
Show 0
Show 1--16
Sound active
On/off
Sound sense
0-100 from slow to fast
LED mode
ON/OFF
Pan Inversion
YES/NO
Test
testing
Hour
Fixture work hours 0---9999
Software version
Ver
Reset
DMX MODE:

8CH MODE:
Channel
DMX Value
Function
1
000-255
10W R LED Dimmer0%~ 100%
2
000-255
10W RGBW LED Strobe from slow to fast
3
000 - 255
5050 R LED Dimmer 0%~ 100%
4
000-255
5050 LED Strobe from slow to fast
5
000-007
0
008-022
Pan/Tilt Movement 01
023-037
Pan/Tilt Movement 02
038-052
Pan/Tilt Movement 03
053-067
Pan/Tilt Movement 04
068-082
Pan/Tilt Movement 05
083-097
Pan/Tilt Movement 06
098-112
Pan/Tilt Movement 07
113-127
Pan/Tilt Movement 08
128-142
Pan/Tilt Movement 09
143-157
Pan/Tilt Movement 10
158-172
Pan/Tilt Movement 11
173-187
Pan/Tilt Movement 12
188-202
Pan/Tilt Movement 13
203-217
Pan/Tilt Movement 14
218-232
Pan/Tilt Movement 15
233-247
Pan/Tilt Movement 16
248-255
Sound active
6
000-255
Movement Speed slow to fast
7
000-014
Color
015-255
Color Chase
8
000 - 255
Chase Speed slow to fast

23 CH MODE:
Channel
DMX Value
Function
1
000 - 255
Pan 0°~ 540°
2
000 –255
Speed fast to slow
3
000 - 127
128 - 189
190 - 193
194 - 255
Tilt 0°~ 360°
clockwise Rotation fast to slow
Stop
anticlockwise Rotation slow to fast
4
000 - 007
RGBW LED1--Blackout
008 - 024
RGBW LED1--R
025 - 041
RGBW LED1--G
042 - 057
RGBW LED1--B
058 - 074
RGBW LED1--W
075 - 090
RGBW LED1--R + G
091 - 107
RGBW LED1--R + B
108 - 123
RGBW LED1--R + W
124 - 140
RGBW LED1--G + B
141 - 156
RGBW LED1-- G + W
157 - 173
RGBW LED1--B + W
174 - 189
RGBW LED1--R + G + B
190 - 206
RGBW LED1--R + G + W
207 - 222
RGBW LED1--R + B + W
223 - 239
RGBW LED1--G + B + W
240 - 255
RGBW LED1--R + G + B + W
5
000 - 255
RGBW LED2--Color
6
000 - 255
RGBW LED3--Color
7
000 - 255
RGBW LED4--Color
8
000 - 255
RGBW LED5--Color

9
000 - 255
RGBW LED6--Color
10
000 - 007
5050 LEDs Strip1-- Blackout
008 - 024
5050 LEDs Strip1 --color1
025 - 041
5050 LEDs Strip1--color2
042 - 057
5050 LEDs Strip1--color3
058 - 074
5050 LEDs Strip1--color4
075 - 090
5050 LEDs Strip1--color5
091 - 107
5050 LEDs Strip1--color6
108 - 123
5050 LEDs Strip1--color7
124 - 140
5050 LEDs Strip1--color8
141 - 156
5050 LEDs Strip1--color9
157 - 173
5050 LEDs Strip1--color10
174 - 189
5050 LEDs Strip1--color11
190 - 206
5050 LEDs Strip1--color12
207 - 222
5050 LEDs Strip1--color13
223 - 239
5050 LEDs Strip1--color14
240 - 255
5050 LEDs Strip1--color15
11
000 - 007
Blackout
008-255
5050 LEDs Strip2--Color
12
000 - 007
Blackout
008-255
5050 LEDs Strip3--Color
13
000 - 007
Blackout
008-255
5050 LEDs Strip4--Color
14
000 - 007
Blackout
008-255
5050 LEDs Strip5--Color
15
000 - 007
Blackout
008-255
5050 LEDs Strip6--Color
16
000 - 007
Blackout
008-255
5050 LEDs Strip7--Color
17
000 - 007
Blackout
008-255
5050 LEDs Strip8--Color
18
000 - 007
Blackout
008-255
5050 LEDs Strip9--Color
19
000 - 007
Blackout
008-255
5050 LEDs Strip10--Color
20
000 - 007
Blackout
008-255
5050 LEDs Strip11--Color
21
000 - 007
Blackout
008-255
5050 LEDs Strip12--Color

22
000-007
0
008-022
Pan/Tilt Movement 01
023-037
Pan/Tilt Movement 02
038-052
Pan/Tilt Movement 03
053-067
Pan/Tilt Movement 04
068-082
Pan/Tilt Movement 05
083-097
Pan/Tilt Movement 06
098-112
Pan/Tilt Movement 07
113-127
Pan/Tilt Movement 08
128-142
Pan/Tilt Movement 09
143-157
Pan/Tilt Movement 10
158-172
Pan/Tilt Movement 11
173-187
Pan/Tilt Movement 12
188-202
Pan/Tilt Movement 13
203-217
Pan/Tilt Movement 14
218-232
Pan/Tilt Movement 15
233-247
Pan/Tilt Movement 16
248-255
Sound active
23
000-255
Movement Speed slow to fast
27 CH MODE:
Channel
DMX Value
Function
1
0-255
Pan 0°~ 540°
2
0-255
Pan Speed fast to slow
3
000 - 127
Tilt 0°~ 360
128 - 189
Tilt clockwise rotation fast to slow
190 - 193
Stop
194 - 255
Tilt anticlockwise rotatiojn slow to fast
4
0-255
10W RGBW LED Dimmer 0%~ 100%
5
000-007
008-255
Stroboscope
(Speed 0 - 100%)
10W RGBW LED Strobe slow to fast
6
000 - 007
10W RGBW LED1--Blackout
008 - 024
10W RGBW LED1--R
025 - 041
10W RGBW LED1--G
042 - 057
10W RGBW LED1--B

058 - 074
10W RGBW LED1--W
075 - 090
10W RGBW LED1--R + G
091 - 107
10W RGBW LED1--R + B
108 - 123
10W RGBW LED1--R + W
124 - 140
10W RGBW LED1--G + B
141 - 156
10W RGBW LED1--G + W
157 - 173
10W RGBW LED1--B + W
174 - 189
10W RGBW LED1--R + G + B
190 - 206
10W RGBW LED1--R + G + W
207 - 222
10W RGBW LED1--R + B + W
223 - 239
10W RGBW LED1--G + B + W
240 - 255
10W RGBW LED1--R + G + B + W
7
0-255
RGBW LED2--Color
8
0-255
RGBW LED3--Color
9
0-255
RGBW LED4--Color
10
0-255
RGBW LED5--Color
11
0-255
RGBW LED6--Color
12
0-255
5050 LED- Dimmer 0%~ 100%
13
000-255
Strobe from slow to fast
14
000 - 007
5050 LEDs Strip1--Blackout
008 - 024
5050 LEDs Strip1--color1
025 - 041
5050 LEDs Strip1--color2
042 - 057
5050 LEDs Strip1--color3
058 - 074
5050 LEDs Strip1--color4
075 - 090
5050 LEDs Strip1--color5
091--107
5050 LEDs Strip1—color6
108 - 123
5050 LEDs Strip1 -color7
124 - 140
5050 LEDs Strip1 -color8
141 - 156
5050 LEDs Strip1 -color9
157 - 173
5050 LEDs Strip1 -color10
174 - 189
5050 LEDs Strip1 -color11
190 - 206
5050 LEDs Strip1 -color12
207 - 222
5050 LEDs Strip1--color13
223 - 239
5050 LEDs Strip1--color14
240 - 255
5050 LEDs Strip1--color15
15
000 - 255
5050 LEDs Strip2--Color
16
000 - 255
5050 LEDs Strip3--Color
17
000 - 255
5050 LEDs Strip4--Color
18
000 - 255
5050 LEDs Strip5--Color
19
000 - 255
5050 LEDs Strip6--Color
20
000 - 255
5050 LEDs Strip7--Color
21
000 - 255
5050 LEDs Strip8--Color
22
000 - 255
5050 LEDs Strip9--Color
23
000 - 255
5050 LEDs Strip10--Color
24
000 - 255
5050 LEDs Strip11--Color
25
000 - 255
5050 LEDs Strip12--Color
26
000-007
0
008-022
Pan/Tilt Movement 01
023-037
Pan/Tilt Movement 02

038-052
Pan/Tilt Movement 03
053-067
Pan/Tilt Movement 04
068-082
Pan/Tilt Movement 05
083-097
Pan/Tilt Movement 06
098-112
Pan/Tilt Movement 07
113-127
Pan/Tilt Movement 08
128-142
Pan/Tilt Movement 09
143-157
Pan/Tilt Movement 10
173-187
Pan/Tilt Movement 12
188-202
Pan/Tilt Movement 13
203-217
Pan/Tilt Movement 14
218-232
Pan/Tilt Movement 15
233-247
Pan/Tilt Movement 16
248-255
Sound active
27
000-255
Movement Speed slow to fast
69CH MODE:
Channel
DMX
Value
Function
1
0-255
Pan 0°~ 540°
2
0-255
Pan fine
3
0-255
Pan Speed fast to slow
4
000- 127
Tilt 0°~ 360°
128- 189
Tilt clockwise Rotation fast to slow
190- 193
Tilt Stop
194- 255
anticlockwise Rotation slow to fast
5
0-255
10W RGBW LED- -Dimmer
6
0-255
10W RGBW LED- Strobe slow to fast
7/11/15/19/23/27
0-255
RGBW LED--Red dimmer0-100%
8/12/16/20/24/28
0-255
RGBW LED--Green dimmer0-100%
9/1317/21/25/29
0-255
RGBW LED--Blue dimmer0-100%
10/14/18/22/26/30
0-255
RGBW LED--White dimmer0-100%
31
0-255
5050 LED All dimmer 0-100%
32
0-255
5050 LED strobe slow to fast
33/36/39/42/45/48/51/54/57/
60/63/66
0-255
5050 LED--Red dimmer0-100%

34/37/40/43/46/49
52/55/58/61/64/67
0-255
5050 LED-Green dimmer0-100%
35/38/41/44/47/50
53/56/59/62/65/68
0-255
5050 LED-Blue dimmer0-100%
69
000-199
No function
200-209
Reset
210-239
No function
240-255
Sound active
White Balance
Select WHITE BALANCE ,press the ENTER button to confirm,present mode will blink on the
display.Use the DOWN and UP button to select the Red or Green or Blue button to change
the value (128-255),once the mode has been selected,press the Enter button to setup.go
back to the functions without any change press the MENU button again.hold and press the
MENU button about one second or wait for one minute to exit the menu mode.
Temperature
Press the ENTER button to when the Temperature test is blink on the display.Pressing Enter
button and the display will show the temperature of the unit.,To go back to the functions
without any change press the MENU button again.hold and press the MENU button about
one second or wait for one minute to exit the menu mode.
Pro defaults
Press the MENU button to show PRO Defaults on the display.Use the DOWN and UP button
to select the YES(run built-in program to set the fixture to Pro defaluts settings) or No.,Press
the ENTER button to setup.to go back to the functions without any change press the MENU
button again.hold and press the MENU button about one second or wait for one minute to
exit the menu mode.
How to control the unit
You can operate the unit in three ways.
1.Master/slave built-in preprogram function
2.Easy controller
3.Universal DMX controller
No need to turn the unit off when you change the DMX address ,as new DMX address
setting will be effect at once .Every time you turn the unit on.it will show CM-120 on the
display and move the motors to their position and you may hear some noises for about 20
seconds.after that the unit will be ready to receive DMX signal or run the built in programs

Sound sense
Select Sound sense ,press the enter button to confirm,present mode will blink on the
display.use the down and up button to change the sound sense from 0-100.once the mode
has been selected .press the ENTER button to setup,to go back to the functions without any
change the MENU button again.hold and press the MENU button about one second or wait
for one minute to exit the menu mode.
Pan Reverse
With this function you can reverse the Pan-movement.
Tilt Reverse
With this function you can reverse the Tilt-movement.
Importateur
Gemar Lumitec
Zone Industrielle
13 rue Alfred Kastler
67850 HERRLISHEIM
www.gemarlumitec.com
