LEDDOO LED SQUARE BAR 144 User manual

LED SQUARE BAR 144
User Manual

Keep This Manual For Future Need
Introduction
Unpacking: Thank you for purchasing this fixture, every fixture has been
thoroughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred
during shipping. If the carton appears to be damaged, carefully inspect your
fixture for any damage and be sure all accessories necessary to operate the
unit has arrived intact. In the case damage has been found or parts are
missing, please contact the manufacturer or your dealer for further
instructions. Do not return this unit to your dealer without first contacting.
Warning! To prevent or reduce the risk of electrical shock or fire, do not
expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt
any repairs yourself; doing so will void your manufactures warranty. In the
unlikely event your unit may require service please contact the manufacturer
or your dealer.
DMX-CONTROLLED OPERATION
You can control the devices individually via your DMX-controller.The device has
six different DMX channel modes. The Control Board allows you, as described
below, to assign the DMX channel mode.
Addressing the device and DMX Channel Selection
The Control Board allows you to assign the DMX fixture address, which is defined
as the first channel from which the device will respond to the controller.
To set the desired starting address press the MODE button until the display shows
“Addr”. Press ENTER to confirm.
You can now set the desired address via the UP or DOWN buttons. Press ENTER
once again to confirm.
Now you can start operating the LED PIX-144 RGB Bar via your lighting controller.
To select the desired DMX Channel
Mode(3CH/5CH/6CH/12CH/24CH/48CH)press the MODE button until the display
shows “Chnd”. Press ENTER to confirm.
Choose the desired DMX Channel Mode via the UP/DOWN-buttons and again
press ENTER to confirm.
Press the MODE button in order to return to the main menu.
Please see the following DMX protocol graphic for the respective channel values.

Please, be sure that you don’t have any overlapping channels in order to
control each device correctly and independently from any other fixture on the
DMX chain. If several LED PIX-144 RGB Bars are addressed similarly, they
will work synchronically.
Controlling:
After having addressed the LED PIX-144 RGB Bar, you may now start
operating it via your lighting controlling.
The LEDs of the device are organized into LED segments, each of which can
be individually controlled with the following DMX-protocol.
e MENU button about one second or wait for one minute to exit the menu
mode
.

Display
DMX MODE:
3CH MODE:
Channel DMX Value Function
1 000-255 RED Dimmer 0%~ 100%
2 000-255 Green Dimmer 0%~ 100%
3 000-255 Blue Dimmer 0%~ 100%
5CH MODE
Channel
DMX Value
Functi
on
1
000
-
255
RED Dimmer 0%~ 100%
2
000
-
255
Green Dimmer 0%~ 100%
3
000
-
255
Blue Dimmer 0%~ 100%
4
000
-
255
Master dimmer 0
-
100%
5
000
-
255
No function
001
-
005
Sound control(7color)
006
-
010
No function
011-255 Strobe with increasing speed
6CH MODE:
Channel
DMX Value
Function
1
000
-
255
Master dimmer 0
-
100%
2
000
-
255
Strobe with increasing speed
3
000
-
255
RED Dimmer 0%~ 100%
4
000
-
255
Green Dimmer 0%~ 100%
5
000
-
255
Blue Dimmer 0%~ 100%
6
000
-
015
No function
016
-
255
Auto program R
-
G
-
B wit
h increasing
12CH MODE:

24CH MODE:
48CH MODE:
