Varytec Studio Par Mini User manual

User manual
Studio Par Mini

2 / 5
Table of contents
1. Safety instructions............................................................................................................................ 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Installation of the lamp ..................................................................................................................... 4
3. Technical data.................................................................................................................................. 4

3 / 5
1. Safety instructions
•This device is suitable for indoor use only.
•All modifications to the device will void the warranty.
•Repairs are to carry out by skilled personnel only.
•Use only fuses of the same type and original parts as spare parts.
•Protect the unit from rain and humidity to avoid fire and electric shocks.
•Make sure to unplug the power supply before opening the housing.
1.1.FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or ex ceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to
disconnect the plug from the receptacle
.

4 / 5
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Installation of the lamp
General the Mini Studio Par for Par 30 up to 75W lamps is for these lamps only!
The filterholder is included already and can be slipped into the frontside holders. In every case you
should prevent the filter holder from falling by using the bracket at the top side of the Studio Par.
Make sure that this side is installed always on top when you mount the Studio Par.
!!Attention!!
You can insert all Par30 lamps with max 75W and 230V, you shall never use different or bigger
lamps. One fitting lamp is included already.
Make sure to replace the lamp when it is damaged.
Make sure that the led lamp you are going to use is fitting your mains voltage!
Warning! The usage of this Studio par with too high or too low voltage can set down the
lifetime and destroys the lamp.
1. Disconnect the item from the mains, before you change the lamp.
2. Turn the lamp counter clockwise to take it out.
3. Take a Par 30 lamp with E27 socket and max 75W and turn it clockwise back in.
Warning! Non fitting lamps can cause a defect of the lamp or even of the socket!
3. Technical data
Voltage AC 240V/ 50Hz
Power consumption Up to 75W
Meassures d137 x L182mm
Weight 1,3Kg
Lamp Par 30 Lamp for E27 Socket 230V
(1 x included)
Ambient temperature Max -10°C – 40°C
Protection Class IP20
Cooling Convection cooled

5 / 5
Importer:
B & K Braun GmbH
Industriestraße 1
D-76307 Karlsbad
www.bkbraun.com
[e-mail]
