leef Tovertafel User manual

1
Welcome to
Tovertafel
Original
User Guide

2
Contents:
• Pre-Installation Checklist
• Contents of Your Tovertafel Kit
• Mounting Instructions
• Table Comparing Height of Tovertafel With Size of Playing Surface
Mounting
Instructions

3
| Mounting Instructions
above the table. The box can be positioned closer
to the table using the extender.
(If necessary) Fix the extender to the ceiling
mount and set the required distance. Mount the
Tovertafel at the end of the extender and adjust
the height using the extender.
Insert the usb wifi-adapter in the usb socket on
top of the Tovertafel box. No wifi? Connect the
Tovertafel to the internet using a LAN cable.
The connection for the 220 volt power cable can
also be found on top of the box (see illustration
below)
CONTENTS
Check inclusion of all components:
•Tovertafel box (H 34 cm, L 38
cm and W 24 cm, weight 10 kg)
•220 volt power cable
•Ceiling mount
•Extender (27-57 cm)
•Screws and plugs
•Remote Control
•usb wifi-adapter (if ordered)
MOUNTING
Using the screws and plugs provided, connect the
ceiling mount directly above the (dining) table.
The ideal distance from the box to the surface of
the table depends on the size of the table.
The bigger the table, the higher the box needs to
be mounted to ensure full surface coverage. For a
rectangular, 6 to 8 person dining room table the
box needs to be 150 to 250 cm
SCREWS & PLUGS
CEILING MOUNT
EXTENDER
USB
WIFI-ADAPTER
REMOTE
CONTROL
220 V
POWER CABLE
MOUNTING INSTRUCTIONS
H
L
W
[email protected]
Pre Installation Checklist
FThere are no obstructions on
your ceilings where you wish to
position the Tovertafel unit(s).
FThe ceiling is made of concrete,
wood or plaster capable of
holding screws for the mounts.
FThe ceiling attachment is able
to securely hold the mount on
which the 10 kilos of Tovertafel
will hang with 4 screws.
FThere is no plumbing or piping
in the ceiling at 4 cm depth. (This
depth requirement is greater if
the Tovertafel is to be recessed).
FThere is sufcient space for the
table for Tovertafel use, and
walking/wheelchair circulation
around the table, directly below
the proposed mounting place.
FThere is a power point available
or have a point installed for the
Tovertafel to connect to (connect to
power circuit not lighting circuit).
FThere are no hanging lighting xtures
obstructing the projection eld.
FThere are no smoke detectors within
a 1 metre radius – heat from the
projector may impact the detectors.
FThere is WIFI or a LAN-connection to
connect the Tovertafel for available
updates wirelessly or directly
to internet. Phone hotspot will
sufce. (Only required for updates
and uploads of new games)
FThere is a suitable table available
a lighter surface shows the colours
most clearly but woodgrain or black
also create interesting effects.

4
above the table. The box can be positioned closer
to the table using the extender.
(If necessary) Fix the extender to the ceiling
mount and set the required distance. Mount the
Tovertafel at the end of the extender and adjust
the height using the extender.
Insert the usb wifi-adapter in the usb socket on
top of the Tovertafel box. No wifi? Connect the
Tovertafel to the internet using a LAN cable.
The connection for the 220 volt power cable can
also be found on top of the box (see illustration
below)
CONTENTS
Check inclusion of all components:
•Tovertafel box (H 34 cm, L 38
cm and W 24 cm, weight 10 kg)
•220 volt power cable
•Ceiling mount
•Extender (27-57 cm)
•Screws and plugs
•Remote Control
•usb wifi-adapter (if ordered)
MOUNTING
Using the screws and plugs provided, connect the
ceiling mount directly above the (dining) table.
The ideal distance from the box to the surface of
the table depends on the size of the table.
The bigger the table, the higher the box needs to
be mounted to ensure full surface coverage. For a
rectangular, 6 to 8 person dining room table the
box needs to be 150 to 250 cm
SCREWS & PLUGS
CEILING MOUNT
EXTENDER
USB
WIFI-ADAPTER
REMOTE
CONTROL
220 V
POWER CABLE
MOUNTING INSTRUCTIONS
H
L
W
[email protected]
above the table. The box can be positioned closer
to the table using the extender.
(If necessary) Fix the extender to the ceiling
mount and set the required distance. Mount the
Tovertafel at the end of the extender and adjust
the height using the extender.
Insert the usb wifi-adapter in the usb socket on
top of the Tovertafel box. No wifi? Connect the
Tovertafel to the internet using a LAN cable.
The connection for the 220 volt power cable can
also be found on top of the box (see illustration
below)
CONTENTS
Check inclusion of all components:
•Tovertafel box (H 34 cm, L 38
cm and W 24 cm, weight 10 kg)
•220 volt power cable
•Ceiling mount
•Extender (27-57 cm)
•Screws and plugs
•Remote Control
•usb wifi-adapter (if ordered)
MOUNTING
Using the screws and plugs provided, connect the
ceiling mount directly above the (dining) table.
The ideal distance from the box to the surface of
the table depends on the size of the table.
The bigger the table, the higher the box needs to
be mounted to ensure full surface coverage. For a
rectangular, 6 to 8 person dining room table the
box needs to be 150 to 250 cm
SCREWS & PLUGS
CEILING MOUNT
EXTENDER
USB
WIFI-ADAPTER
REMOTE
CONTROL
220 V
POWER CABLE
MOUNTING INSTRUCTIONS
H
L
W
[email protected]
Mounting Intructions
Using the screws and plugs provided,
connect the ceiling mount directly above
the (dining) table. The ideal distance
from the box to the surface of the table
depends on the size of the table.
The bigger the table, the higher the
box needs to be mounted to ensure
full surface coverage. For a rectangular,
6 to 8 person dining room table the
box needs to be 150 to 250 cm above
the table. The box can be positioned
closer to the table using the extender.
(If necessary) Fix the extender to the
ceiling mount and set the required
distance. Mount the Tovertafel at
the end of the extender and adjust
the height using the extender.
Insert the usb wi-adapter in the
usb socket on top of the Tovertafel
box. No wi? Connect the Tovertafel
to the internet using a LAN cable.
The connection for the 220 volt power
cable can also be found on top of
the box (see illustration below)
Contents
Check inclusion of all components:
• Tovertafel box (H 34 cm, L 38
cm and W 24 cm, weight 10 kg)
• 220 volt power cable
• Ceiling mount (4 per kit)
• Extender (27-57 cm)
• Screws and plugs
• Remote Control
• usb wi-adapter

5
TABLE COMPARING HEIGHT OF TOVERTAFEL
WITH SIZE OF PLAYING SURFACE
This table states the relationship between the
height at which the Tovertafel is hung and the
maximum size of the playing surface.
The higher the Tovertafel is hung, the bigger the
playing surface is. The playing surface can be made
smaller than is stated in this table, in either
dimension, but cannot be made bigger.
0.0m
0.25m
0.60m
0.95m
1.30m
1.65m
2.00m
2.35m
2.70m
3.05m
3.40m
0.0m
0.45m
0.90m
1.35m
1.80m
2.25m
2.70m
3.15m
3.60m
4.05m
4.50m
0.0m
0.6m
1.0m
1.5m
2.0m
2.5m
3.0m
3.5m
4.0m
4.5m
5.0m
0.43m
0.43m
distance from the
bottom of the
Tovertafel to the
table top
length of playing surface width of playing surface
[email protected]
Length of
playing
surface
Distance from
the bottom of
the tovertafel
to the table top
Diagram Comparing Height of Tovertafel
With Size of Playing Surface
Installation height determines the maximum size of the playing surface.
This diagram states the relationship between the height at which the
Tovertafel is hung and the maximum size of the playing surface.
The higher the Tovertafel is hung, the bigger the playing surface is.
The playing surface can be made smaller than is stated in this
diagram, in either dimension, but cannot be made bigger.

6
TABLE COMPARING HEIGHT OF TOVERTAFEL
WITH SIZE OF PLAYING SURFACE
This table states the relationship between the
height at which the Tovertafel is hung and the
maximum size of the playing surface.
The higher the Tovertafel is hung, the bigger the
playing surface is. The playing surface can be made
smaller than is stated in this table, in either
dimension, but cannot be made bigger.
0.0m
0.25m
0.60m
0.95m
1.30m
1.65m
2.00m
2.35m
2.70m
3.05m
3.40m
0.0m
0.45m
0.90m
1.35m
1.80m
2.25m
2.70m
3.15m
3.60m
4.05m
4.50m
0.0m
0.6m
1.0m
1.5m
2.0m
2.5m
3.0m
3.5m
4.0m
4.5m
5.0m
0.43m 0.43m
distance from the
bottom of the
Tovertafel to the
table top
length of playing surface width of playing surface
[email protected]
TABLE COMPARING HEIGHT OF TOVERTAFEL
WITH SIZE OF PLAYING SURFACE
This table states the relationship between the
height at which the Tovertafel is hung and the
maximum size of the playing surface.
The higher the Tovertafel is hung, the bigger the
playing surface is. The playing surface can be made
smaller than is stated in this table, in either
dimension, but cannot be made bigger.
0.0m
0.25m
0.60m
0.95m
1.30m
1.65m
2.00m
2.35m
2.70m
3.05m
3.40m
0.0m
0.45m
0.90m
1.35m
1.80m
2.25m
2.70m
3.15m
3.60m
4.05m
4.50m
0.0m
0.6m
1.0m
1.5m
2.0m
2.5m
3.0m
3.5m
4.0m
4.5m
5.0m
0.43m 0.43m
distance from the
bottom of the
Tovertafel to the
table top
length of playing surface width of playing surface
[email protected]
TABLE COMPARING HEIGHT OF TOVERTAFEL
WITH SIZE OF PLAYING SURFACE
This table states the relationship between the
height at which the Tovertafel is hung and the
maximum size of the playing surface.
The higher the Tovertafel is hung, the bigger the
playing surface is. The playing surface can be made
smaller than is stated in this table, in either
dimension, but cannot be made bigger.
0.0m
0.25m
0.60m
0.95m
1.30m
1.65m
2.00m
2.35m
2.70m
3.05m
3.40m
0.0m
0.45m
0.90m
1.35m
1.80m
2.25m
2.70m
3.15m
3.60m
4.05m
4.50m
0.0m
0.6m
1.0m
1.5m
2.0m
2.5m
3.0m
3.5m
4.0m
4.5m
5.0m
0.43m
0.43m
distance from the
bottom of the
Tovertafel to the
table top
length of playing surface width of playing surface
[email protected]
Width of
playing
surface
Distance from
the bottom of
the tovertafel
to the table top

7
Contents:
• Manual
• Turning On the Tovertafel
• Turning Off the Tovertafel
• Pausing a Game
• Playing with the Tovertafel
Set Up & Manual
TURNING ON THE TOVERTAFEL
Once installed leave switch on the base of the
unit "ON". Check whether the red LED light on the
Tovertafel enclosure is burning. If it’s not, make
sure the Tovertafel is connected to a power source.
Turn on the Tovertafel with the ON/OFF button (1)
(on the remote), after which the red LED light will
start to blink. After a while, you will hear a single
beep: the Tovertafel is booting up.
NOTE: Don’t press the ON/OFF button on the
remote control more than once. The Tovertafel
needs a few minutes to boot up. As long as the
red LED light is blinking, don’t press any other
button!
After the boot sequence, one of the games will
launch automatically. The games will be played in
random order for 5 minutes each.
To select a game, press "Home" (house icon) to
see all the menu of all loaded games.
MANUAL
TURN OFF THE TOVERTAFEL
Are you done with playing? Turn off the Tovertafel
with the ON/OFF button (1) on the remote control.
NOTE: The Tovertafel needs to cool down before it
can be turned on again or discon–nected from the
power source. When the Tovertafel has cooled
down suffi ciently, you will hear two beeps.
PAUSING A GAME
Do you want to pause a game to discuss or look at
something? You can do so by pressing the MODE
(2) button on the remote control.
This icon will appear on the projection.
Want to resume the game? Press the MODE (2)
button on the remote again and resume playing!
1. ON/OFF
Turn the Tovertafel on or off
2. MODE
Pause
3. RECTANGLE
no function
4. NAVIGATION
Change game or navigate through the menu
5. BACK
Go a step back
6. HOME
Go (back) to the main menu
7. VOLUME UP
Turn the volume up
8. VOLUME DOWN
Turn the volume down
1. ON/OFF
Turn the Tovertafel on or off
2. MODE
Pause game
3. RECTANGLE
no function
4. NAVIGATION
Change game or navigate
through the menu
5. BACK
Go a step back
6. HOME
Go (back) to the main menu
7. VOLUME UP
Turn the volume up
8. VOLUME DOWN
Turn the volume down
1.
2.
3.
6.
4.
7.
5.
8.
• Internet & Update Guide
• Connect with an Internet
Cable (Utp Cable)
• Connect with the Wi-Fi Dongle
• Connect with a Hotspot Via
Your Tablet or Smartphone
(IOS and Android)
• Install Update
• Tips for You or Your
Network Manager
Tovertafel Remote

8
Turn Off The Tovertafel
Are you done with playing? Turn
off the Tovertafel with the ON/OFF
button (1) on the remote control.
NOTE: The Tovertafel needs to cool
down before it can be turned on again
or disconnected from the power source.
When the Tovertafel has cooled down
suf ciently, you will hear two beeps.
Pausing A Game
Do you want to pause a game to
discuss or look at something? You
can do so by pressing the MODE (2)
button on the remote control.
This icon will appear on the
projection.
Want to resume the game? Press
the MODE (2) button on the remote
again and resume playing!
TURNING ON THE TOVERTAFEL
Once installed leave switch on the base of the
unit "ON". Check whether the red LED light on the
Tovertafel enclosure is burning. If it’s not, make
sure the Tovertafel is connected to a power source.
Turn on the Tovertafel with the ON/OFF button (1)
(on the remote), after which the red LED light will
start to blink. After a while, you will hear a single
beep: the Tovertafel is booting up.
NOTE: Don’t press the ON/OFF button on the
remote control more than once. The Tovertafel
needs a few minutes to boot up. As long as the
red LED light is blinking, don’t press any other
button!
After the boot sequence, one of the games will
launch automatically. The games will be played in
random order for 5 minutes each.
To select a game, press "Home" (house icon) to
see all the menu of all loaded games.
MANUAL
TURN OFF THE TOVERTAFEL
Are you done with playing? Turn off the Tovertafel
with the ON/OFF button (1) on the remote control.
NOTE: The Tovertafel needs to cool down before it
can be turned on again or discon–nected from the
power source. When the Tovertafel has cooled
down suffi ciently, you will hear two beeps.
PAUSING A GAME
Do you want to pause a game to discuss or look at
something? You can do so by pressing the MODE
(2) button on the remote control.
This icon will appear on the projection.
Want to resume the game? Press the MODE (2)
button on the remote again and resume playing!
1. ON/OFF
Turn the Tovertafel on or off
2. MODE
Pause
3. RECTANGLE
no function
4. NAVIGATION
Change game or navigate through the menu
5. BACK
Go a step back
6. HOME
Go (back) to the main menu
7. VOLUME UP
Turn the volume up
8. VOLUME DOWN
Turn the volume down
TURNING ON THE TOVERTAFEL
Once installed leave switch on the base of the
unit "ON". Check whether the red LED light on the
Tovertafel enclosure is burning. If it’s not, make
sure the Tovertafel is connected to a power source.
Turn on the Tovertafel with the ON/OFF button (1)
(on the remote), after which the red LED light will
start to blink. After a while, you will hear a single
beep: the Tovertafel is booting up.
NOTE: Don’t press the ON/OFF button on the
remote control more than once. The Tovertafel
needs a few minutes to boot up. As long as the
red LED light is blinking, don’t press any other
button!
After the boot sequence, one of the games will
launch automatically. The games will be played in
random order for 5 minutes each.
To select a game, press "Home" (house icon) to
see all the menu of all loaded games.
MANUAL
TURN OFF THE TOVERTAFEL
Are you done with playing? Turn off the Tovertafel
with the ON/OFF button (1) on the remote control.
NOTE: The Tovertafel needs to cool down before it
can be turned on again or discon–nected from the
power source. When the Tovertafel has cooled
down suffi ciently, you will hear two beeps.
PAUSING A GAME
Do you want to pause a game to discuss or look at
something? You can do so by pressing the MODE
(2) button on the remote control.
This icon will appear on the projection.
Want to resume the game? Press the MODE (2)
button on the remote again and resume playing!
1. ON/OFF
Turn the Tovertafel on or off
2. MODE
Pause
3. RECTANGLE
no function
4. NAVIGATION
Change game or navigate through the menu
5. BACK
Go a step back
6. HOME
Go (back) to the main menu
7. VOLUME UP
Turn the volume up
8. VOLUME DOWN
Turn the volume down
| Manual
Turning On The Tovertafel
Once installed leave switch on the base
of the unit "ON". Check whether the red
LED light on the Tovertafel enclosure
is burning. If it’s not, make sure the
Tovertafel is connected to a power source.
Turn on the Tovertafel with the ON/
OFF button (1) (on the remote), after
which the red LED light will start to
blink. After a while, you will hear a single
beep: the Tovertafel is booting up.
NOTE: Don’t press the ON/OFF button
on the remote control more than once.
The Tovertafel needs a few minutes to
boot up. As long as the red LED light is
blinking, don’t press any other button!
After the boot sequence, one of the
games will launch automatically.
The games will be played in random
order for 5 minutes each.
To select a game, press "Home" (6) to
see all the menu of all loaded games.

9
Playing With The Tovertafel
To the next game Set up the play surface
Press the left or right arrow (4)
to go to a different game.
Or choose a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose
a specic game in the games
menu. Pressing ‘OK’ launches the
chosen game. This game will
continue until you choose
a different game.
With ‘Set up play surface’ you
can customize the size & shape
of the play surface for your table.
Press the ‘menu’ (6) button
on the remote control
and press the ‘up arrow’ to
enter the settings menu.
PLAYING WITH THE TOVERTAFEL
To the next game
Press the left or right arrow (4) to
go to a different game. Or choose
a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose a
specifi c game in the games menu.
Pressing ‘OK’ launches the chosen
game. This game will continue until
you choose a different game.
Play in random order
Press ‘menu’ (6) and subsequently
press the ‘up arrow’ to enter the
settings menu. Choose ‘random’
here and press ‘OK’. Now the games
will change every 5 minutes.
Sound settings
Most of the Tovertafel games have
sound, you can change these
settings with the remote control.
With the sound buttons (7 and 8),
you can turn the sound up, down,
or off.
Set up the play surface
With ‘Set up play surface’ you can
customize the size & shape of the
play surface for your table.
Press the ‘menu’ (6) button on the
remote control and press the ‘up
arrow’ to enter the settings menu.
Go to ‘set up the play surface’ and press ‘OK’. A
green line will appear on or near the table. You
can use the arrow keys to move the green line so
that it hits the exact edge of the table. Press ‘OK’
and the next line turns green. Repeat the
previous step for all lines.
After the last line, press the menu
button on the remote control. This
saves the settings.
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor doesn’t
register all hand movements. The overview
below shows will movements do and which
don’t work.
Press ‘menu’ (6) and subsequently
With ‘Set up play surface’ you can
PLEASE NOTE: Ensure that people near the
Tovertafel are not annoyed by the sounds!
Tovertafel creates moments of happiness in
residential care. Games have been developed
specifically for people living with dementia or
people with learning disabilities. We feel that
everybody has the right to play!
Do you have questions, suggestions, or feedback?
Let us know.
[email protected]
PLAYING WITH THE TOVERTAFEL
To the next game
Press the left or right arrow (4) to
go to a different game. Or choose
a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose a
specifi c game in the games menu.
Pressing ‘OK’ launches the chosen
game. This game will continue until
you choose a different game.
Play in random order
Press ‘menu’ (6) and subsequently
press the ‘up arrow’ to enter the
settings menu. Choose ‘random’
here and press ‘OK’. Now the games
will change every 5 minutes.
Sound settings
Most of the Tovertafel games have
sound, you can change these
settings with the remote control.
With the sound buttons (7 and 8),
you can turn the sound up, down,
or off.
Set up the play surface
With ‘Set up play surface’ you can
customize the size & shape of the
play surface for your table.
Press the ‘menu’ (6) button on the
remote control and press the ‘up
arrow’ to enter the settings menu.
Go to ‘set up the play surface’ and press ‘OK’. A
green line will appear on or near the table. You
can use the arrow keys to move the green line so
that it hits the exact edge of the table. Press ‘OK’
and the next line turns green. Repeat the
previous step for all lines.
After the last line, press the menu
button on the remote control. This
saves the settings.
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor doesn’t
register all hand movements. The overview
below shows will movements do and which
don’t work.
Press ‘menu’ (6) and subsequently
With ‘Set up play surface’ you can
PLEASE NOTE: Ensure that people near the
Tovertafel are not annoyed by the sounds!
Tovertafel creates moments of happiness in
residential care. Games have been developed
specifically for people living with dementia or
people with learning disabilities. We feel that
everybody has the right to play!
Do you have questions, suggestions, or feedback?
Let us know.
[email protected]
PLAYING WITH THE TOVERTAFEL
To the next game
Press the left or right arrow (4) to
go to a different game. Or choose
a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose a
specifi c game in the games menu.
Pressing ‘OK’ launches the chosen
game. This game will continue until
you choose a different game.
Play in random order
Press ‘menu’ (6) and subsequently
press the ‘up arrow’ to enter the
settings menu. Choose ‘random’
here and press ‘OK’. Now the games
will change every 5 minutes.
Sound settings
Most of the Tovertafel games have
sound, you can change these
settings with the remote control.
With the sound buttons (7 and 8),
you can turn the sound up, down,
or off.
Set up the play surface
With ‘Set up play surface’ you can
customize the size & shape of the
play surface for your table.
Press the ‘menu’ (6) button on the
remote control and press the ‘up
arrow’ to enter the settings menu.
Go to ‘set up the play surface’ and press ‘OK’. A
green line will appear on or near the table. You
can use the arrow keys to move the green line so
that it hits the exact edge of the table. Press ‘OK’
and the next line turns green. Repeat the
previous step for all lines.
After the last line, press the menu
button on the remote control. This
saves the settings.
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor doesn’t
register all hand movements. The overview
below shows will movements do and which
don’t work.
Press ‘menu’ (6) and subsequently
With ‘Set up play surface’ you can
PLEASE NOTE: Ensure that people near the
Tovertafel are not annoyed by the sounds!
Tovertafel creates moments of happiness in
residential care. Games have been developed
specifically for people living with dementia or
people with learning disabilities. We feel that
everybody has the right to play!
Do you have questions, suggestions, or feedback?
Let us know.
[email protected]
PLAYING WITH THE TOVERTAFEL
To the next game
Press the left or right arrow (4) to
go to a different game. Or choose
a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose a
specifi c game in the games menu.
Pressing ‘OK’ launches the chosen
game. This game will continue until
you choose a different game.
Play in random order
Press ‘menu’ (6) and subsequently
press the ‘up arrow’ to enter the
settings menu. Choose ‘random’
here and press ‘OK’. Now the games
will change every 5 minutes.
Sound settings
Most of the Tovertafel games have
sound, you can change these
settings with the remote control.
With the sound buttons (7 and 8),
you can turn the sound up, down,
or off.
Set up the play surface
With ‘Set up play surface’ you can
customize the size & shape of the
play surface for your table.
Press the ‘menu’ (6) button on the
remote control and press the ‘up
arrow’ to enter the settings menu.
Go to ‘set up the play surface’ and press ‘OK’. A
green line will appear on or near the table. You
can use the arrow keys to move the green line so
that it hits the exact edge of the table. Press ‘OK’
and the next line turns green. Repeat the
previous step for all lines.
After the last line, press the menu
button on the remote control. This
saves the settings.
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor doesn’t
register all hand movements. The overview
below shows will movements do and which
don’t work.
Press ‘menu’ (6) and subsequently
With ‘Set up play surface’ you can
PLEASE NOTE: Ensure that people near the
Tovertafel are not annoyed by the sounds!
Tovertafel creates moments of happiness in
residential care. Games have been developed
specifically for people living with dementia or
people with learning disabilities. We feel that
everybody has the right to play!
Do you have questions, suggestions, or feedback?
Let us know.
[email protected]
Press ‘menu’ (6) and
subsequently press the ‘up
arrow’ to enter the settings
menu. Choose ‘random’ here
and press ‘OK’. Now the games
will change every 5 minutes.
Play in random order
Most of the Tovertafel games
have sound, you can change
these settings with the remote
control. With the sound buttons
(7 and 8), you can turn the
sound up, down, or off.
Sound settings
Go to ‘set up the play surface’ and press
‘OK’. A green line will appear on or
near the table. You can use the arrow
keys to move the green line so that it
hits the exact edge of the table. Press
‘OK’ and the next line turns green.
Repeat the previous step for all lines.
After the last line, press the
menu button on the remote
control. This saves the settings.
PLAYING WITH THE TOVERTAFEL
To the next game
Press the left or right arrow (4) to
go to a different game. Or choose
a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose a
specifi c game in the games menu.
Pressing ‘OK’ launches the chosen
game. This game will continue until
you choose a different game.
Play in random order
Press ‘menu’ (6) and subsequently
press the ‘up arrow’ to enter the
settings menu. Choose ‘random’
here and press ‘OK’. Now the games
will change every 5 minutes.
Sound settings
Most of the Tovertafel games have
sound, you can change these
settings with the remote control.
With the sound buttons (7 and 8),
you can turn the sound up, down,
or off.
Set up the play surface
With ‘Set up play surface’ you can
customize the size & shape of the
play surface for your table.
Press the ‘menu’ (6) button on the
remote control and press the ‘up
arrow’ to enter the settings menu.
Go to ‘set up the play surface’ and press ‘OK’. A
green line will appear on or near the table. You
can use the arrow keys to move the green line so
that it hits the exact edge of the table. Press ‘OK’
and the next line turns green. Repeat the
previous step for all lines.
After the last line, press the menu
button on the remote control. This
saves the settings.
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor doesn’t
register all hand movements. The overview
below shows will movements do and which
don’t work.
Press ‘menu’ (6) and subsequently
With ‘Set up play surface’ you can
PLEASE NOTE: Ensure that people near the
Tovertafel are not annoyed by the sounds!
Tovertafel creates moments of happiness in
residential care. Games have been developed
specifically for people living with dementia or
people with learning disabilities. We feel that
everybody has the right to play!
Do you have questions, suggestions, or feedback?
Let us know.
[email protected]
PLAYING WITH THE TOVERTAFEL
To the next game
Press the left or right arrow (4) to
go to a different game. Or choose
a game via the menu.
Press ‘menu’ (6) to subsequently
use the arrow keys to choose a
specifi c game in the games menu.
Pressing ‘OK’ launches the chosen
game. This game will continue until
you choose a different game.
Play in random order
Press ‘menu’ (6) and subsequently
press the ‘up arrow’ to enter the
settings menu. Choose ‘random’
here and press ‘OK’. Now the games
will change every 5 minutes.
Sound settings
Most of the Tovertafel games have
sound, you can change these
settings with the remote control.
With the sound buttons (7 and 8),
you can turn the sound up, down,
or off.
Set up the play surface
With ‘Set up play surface’ you can
customize the size & shape of the
play surface for your table.
Press the ‘menu’ (6) button on the
remote control and press the ‘up
arrow’ to enter the settings menu.
Go to ‘set up the play surface’ and press ‘OK’. A
green line will appear on or near the table. You
can use the arrow keys to move the green line so
that it hits the exact edge of the table. Press ‘OK’
and the next line turns green. Repeat the
previous step for all lines.
After the last line, press the menu
button on the remote control. This
saves the settings.
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor doesn’t
register all hand movements. The overview
below shows will movements do and which
don’t work.
Press ‘menu’ (6) and subsequently
With ‘Set up play surface’ you can
PLEASE NOTE: Ensure that people near the
Tovertafel are not annoyed by the sounds!
Tovertafel creates moments of happiness in
residential care. Games have been developed
specifically for people living with dementia or
people with learning disabilities. We feel that
everybody has the right to play!
Do you have questions, suggestions, or feedback?
Let us know.
[email protected]
To what type of movements does the
Tovertafel respond?
The Tovertafel’s movement sensor
doesn’t register all hand movements.
The overview below shows will
movements do and which don’t work.
NOTE:
Ensure that people near the Tovertafel
are not annoyed by the sounds!

10
| Internet & Update Guide
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l bacPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l ba cPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
To perform an update, the Tovertafel must be connected to the internet.
You can connect the Tovertafel to the internet in two ways: using
the Wi-Fi dongle or by plugging in an internet cable.
Top of the
Tovertafel
Connect With an Internet Cable
(UTP Cable)
Connect With the Wi-Fi Dongle
Check if the UTP cable is
plugged into the LAN port
on the top of the device.
In the menu, go to ‘Network’,
and the device will look
for a connection.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l ba cPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l ba cPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l ba cPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l ba cPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
If this is successful, you will see the
message ‘You are connected’.
Check the Wi-Fi dongle is
plugged into the device. It has
to be plugged into the USB
port on top of the Tovertafel.
In the menu, go to ‘Network’,
and the device will look
for a connection.
It is best to leave the dongle in place
ready for any future updates.
You will most likely need to select
a network, type in password using
remote controller then OK.
The message will display :
“There is an update available would
you like to download it now?”.
Press Ok.
The message will tell you
downloading is in progress, then
when it is complete, you then need
to “restart” the unit by selecting the
Qicon on the settings menu.
The unit will appear to turn off
then reboot and the updates (or
new games) will be present.
You Can Create a Hotspot Via
Your Tablet or Smartphone
If no suitable Wi-Fi or wired network is
available, you can make a Wi-Fi network
through most smartphones or tablets
using your mobile internet connection.
Check if your phone or tablet can
make a connection with your provider’s
mobile data network (for example by
switching off the Wi-Fi on your phone
and seeing if you can still use the
internet). Switch your mobile hotspot
on using “hotspot and tethering”.

11
• Open ‘Settings’ on your iPhone.
• Turn the Wi-Fi on your iPhone on
(also if there is no network available).
• Go back to ‘Settings’ and go
to ‘Personal hotspot’’.
• Fill in a password you have chosen
yourself for the Wi-Fi access.
• Switch ‘Personal hotspot’ on.
• Open ‘Settings’ on your phone
and go to ‘More’ > ‘Tethering and
mobile hotspot‘ (it is possible that
the menu options on your phone
have slightly different names).
• From ‘Tethering and mobile
hotspot‘, congure your hotspot
• Switch ‘Tethering and
mobile hotspot’ on.
In the Tovertafel menu, go
to ‘Network’, and the device
will look for a connection.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
If no suitable Wi-Fi or wired network is available,
you can make a Wi-Fi network through most
smartphones or tablets using your mobile inter-
net connection. Check if your phone or tablet can
make a connection with your provider’s mobile
data network (for example by switching off the
Wi-Fi on your phone and seeing if you can still
use the internet). Switch your mobile hotspot on
using “hotspot and tethering”.
P.t.o. for more information
CONNECT WITH AN INTERNET
CABLE (UTP CABLE)
deggu l ps ie l ba cPTUeh t f ik cehC
into the LAN port on the top of
the device.
dna, ’krowteN‘otog,unemehtnI
the device will look for a connec-
tion.
If this is successful, you will see the message
‘You are connected’.
CONNECT WITH THE
WI-FI DONGLE
s ie l gnodi F - iWeh tk cehC
plugged into the device. It has to
be plugged into the USB port on
top of the Tovertafel.
To perform an update, the Tovertafel must be
connected to the internet. You can connect the
Tovertafel to the internet in two ways: using the
Wi-Fi dongle or by plugging in an internet cable.
INTERNET & UPDATES
Top of the Tovertafel
It is best to leave it in place ready
for any future updates.
You will mostlikely need to select a network, type
in password using remote controller then OK.The
message will display “There is an update available
would you like to download it now?” Press Ok.
The message will tell you downloading is in
progress, then when it is complete, you then need
to turn off the unit using the remote – let it
completely switch off you will hear a loud “Beep”.
Then turn back on with the remote and the
updates (or new games) will be present.
You
Create a hotspot via your tablet or smartphone
ON IOS:
•Open ‘Settings’ on your iPhone.
•Turn the Wi-Fi on your iPhone on (also if
there is no network available).
•Go back to ‘Settings’ and go to
‘Personal hotspot’’.
•Fill in a password you have chosen yourself
for the Wi-Fi access.
•Switch ‘Personal hotspot’ on.
ON ANDROID:
•Open ‘Settings’ on your phone and go to
‘More’ > ‘Tethering and mobile hotspot‘ (it
is possible that the menu options on your
phone have slightly different names).
•From ‘Tethering and mobile hotspot‘,
configure your hotspot
•Switch ‘Tethering and mobile hotspot’ on.
otog,unemlefatrevoTehtnI
‘Network’, and the device will look
for a connection
If this is successful, you will see a menu.
From this menu, choose the name of your phone
or tablet, press ‘OK’ on theremote controland fill
in the password. Choose ‘OK’ in the projection on
the table (top left).
INSTALL UPDATE
Connected? Go to ‘update’ and press
[OK] on the remote. (Make sure your internet
connection is not interrupted while updating.)
You can find this in the Tovertafel’s info menu.
THESE TIPS CAN ALSO HELP
YOU (OR YOUR NETWORK
MANAGER):
a. Connect a phone/laptop/tablet/computer
to the same internet that the Tovertafel is
connected to.
b. Go to www.canyouseeme.org
eh tn i l l fi’ k ceh co t t r op ‘ xobeh tn I. c
number 80 and click on ‘check port’.
If you see ‘error’ then the Tovertafel is
potentially blocked. If you see ‘success’,
then this port is open.
d. Repeat this with the number 443.
yamrotar ts inimdametsysruoY
require the Tovertafel’s ‘mac-
address’.
If you are not able to make a connection, take
the device down from the ceiling and temporarily
connect to the internet somewhere else. As
soon as the software update has been installed,
you can put the device up again.
Sometimes using a ‘guest network’, will not work
and sometimes the internet connection is protect-
ed by a firewall.
For the Tovertafel, it is important that ports 80 and
443 are ‘open’. Your network manager can help with
this. If you want to know if this is possibly the
problem, you can take the following steps:
Please contact Leef if this is required.
If this is successful, you will see a menu.
From this menu, choose the name
of your phone or tablet, press ‘OK’
on the remote control and ll in
the password. Choose ‘OK’ in the
projection on the table (top left).
Install Update
Sometimes using a ‘guest network’, will
not work and sometimes the internet
connection is protected by a rewall.
For the Tovertafel, it is important that
ports 80 and 443 are ‘open’. Your network
manager can help with this. If you want
to know if this is possibly the problem,
you can take the following steps:
• Connect a phone/laptop/tablet/
computer to the same internet that
the Tovertafel is connected to.
• Go to www.canyouseeme.org
• In the box ‘port to check’ ll in the
number 80 and click on ‘check port’.
If you see ‘error’ then the Tovertafel
is potentially blocked. If you see
‘success’, then this port is open.
• Repeat this with the number 443.
Your system administrator
may require the Tovertafel’s
‘mac-address’.
The mac-address can be found
in the information section.
On IOS
On Android
If you are not able to make a connection,
take the device down from the ceiling
and temporarily connect to the internet
somewhere else. As soon as the
software update has been installed,
you can rehang the Tovertafel.
To order new games you need to
email [email protected]om.au and
tell us the serial number of the unit
you want the games on and which
games you wish to purchase.
Connected? Go to ‘update’
and press the download icon
and [OK] on the remote.
(Make sure your internet connection
is not interrupted while updating.)
Then restart the machine and the
update or new games will be visible.
ON IOS:
•Open ‘Settings’ on your iPhone.
•Turn the Wi-Fi on your iPhone on (also if
there is no network available).
•Go back to ‘Settings’ and go to
‘Personal hotspot’’.
•Fill in a password you have chosen yourself
for the Wi-Fi access.
•Switch ‘Personal hotspot’ on.
ON ANDROID:
•Open ‘Settings’ on your phone and go to
‘More’ > ‘Tethering and mobile hotspot‘ (it
is possible that the menu options on your
phone have slightly different names).
•From ‘Tethering and mobile hotspot‘,
configure your hotspot
•Switch ‘Tethering and mobile hotspot’ on.
otog,unemlefatrevoTehtnI
‘Network’, and the device will look
for a connection
If this is successful, you will see a menu.
From this menu, choose the name of your phone
or tablet, press ‘OK’ on theremote controland fill
in the password. Choose ‘OK’ in the projection on
the table (top left).
INSTALL UPDATE
Connected? Go to ‘update’ and press
[OK] on the remote. (Make sure your internet
connection is not interrupted while updating.)
You can find this in the Tovertafel’s info menu.
THESE TIPS CAN ALSO HELP
YOU (OR YOUR NETWORK
MANAGER):
a. Connect a phone/laptop/tablet/computer
to the same internet that the Tovertafel is
connected to.
b. Go to www.canyouseeme.org
eh tn i l l fi’ k cehco t t r op ‘ xobeh tn I. c
number 80 and click on ‘check port’.
If you see ‘error’ then the Tovertafel is
potentially blocked. If you see ‘success’,
then this port is open.
d. Repeat this with the number 443.
yamrotar ts inimdametsysruoY
require the Tovertafel’s ‘mac-
address’.
If you are not able to make a connection, take
the device down from the ceiling and temporarily
connect to the internet somewhere else. As
soon as the software update has been installed,
you can put the device up again.
Sometimes using a ‘guest network’, will not work
and sometimes the internet connection is protect-
ed by a firewall.
For the Tovertafel, it is important that ports 80 and
443 are ‘open’. Your network manager can help with
this. If you want to know if this is possibly the
problem, you can take the following steps:
Please contact Leef if this is required.
These Tips Can Also Help You (Or Your Network Manager):

12
[e-mail]
Your serial number is:
