Legendfires Garden Halo Operator's manual

‘Garden Halo’wood burning outdoor Fire
Users
Instruction
Manual
WARNING FOR YOUR SAFETY:
For Outdoor use, Only
1. Improper installation, assembly,
alteration or maintenance can
cause injury or property damage.
2. Read the installation, assembly,
operation and maintenance
instructions thoroughly before
assembly and use of this
appliance.
3. Failure to follow these instructions
could result in fire or explosion,
which could cause property
damage, personal injury or death.
Save these instructions for future
reference. If you are assembling this
appliance for someone else, give this
manual to them to read and save for
future reference.

Important Safeguards
IMPORTANT - PLEASE READ BEFORE USING YOUR PRODUCT
1. The ‘Garden Halo’is for OUTDOOR USE ONLY, and should NOT be used in a building, garage, or any
other enclosed area.
2. Do NOT use the ‘Garden Halo’for indoor heating. Toxic carbon monoxide fumes can accumulate and
cause asphyxiation.
3. The ‘Garden Halo’ is NOT for commercial use.
4. The ‘Garden Halo’ outdoor fire is NOT to be operated by children.
5. The ‘Garden Halo outdoor fire is NOT to be used in or on boats or other recreational vehicles.
6. When using the ‘Garden Halo’, exercise the same precautions you would with any open fire.
7. The use of alcohol, prescription or non-prescription drugs may impair the user’s ability to correctly
assemble or safely operate the ‘Garden Halo’ outdoor fire.
8. Do not use the ‘Garden Halo’outdoor fire without reading the entire “Manual”
9. The ‘Garden Halo’ outdoor fire is for use with dry, seasoned hardwood. It will burn hotter, more
completely and create less smoke.
10. Do NOT burn charcoal briquets, lump charcoal, driftwood, rubbish, leaves, paper, cardboard, plywood,
painted or stained or pressure treated wood. Avoid using softwoods such as pine or cedar that can
throw sparks out.
11. Do NOT alter the ‘Garden Halo’outdoor fire in any manner.
12. Do NOT use the ‘Garden Halo’outdoor fire until it is completely assembled.
13. Do NOT store or use any flammable liquids or vapours in the vicinity of the ‘Garden Halo’ outdoor fire.
14. Do NOT store or use an LP Gas cylinders within 10 feet (3.1M) of the ‘Garden Halo’outdoor fire while it
is in use.
15. Do NOT use the ‘Garden Halo’ outdoor fire near any Motor vehicle or recreational vehicle.
16. Do NOT use in an explosive atmosphere. Keep ‘Garden Halo’ outdoor fire area clear from combustible
materials.
17. Do NOT use the ‘Garden Halo’ outdoor fire under any overhead or near any unprotected combustible
constructions avoid using near or under overhanging trees or shrubs.
18. Always use the ‘Garden Halo’outdoor fire on a hard, level non-combustible surface, Asphalt may not be
acceptable for this. Do NOT use on Wooden decking.
19. Do NOT wear flammable or loose clothing when using the ‘Garden Halo’ outdoor fire.
20. Do NOT use petrol, kerosene, diesel, lighter fluid or alcohol to light or relight fires.
21. Keep all electrical cords, cables away from a Hot ‘Garden Halo’ outdoor fire.
22. All Surfaces of the ‘Garden Halo’outdoor fire are hot when in operation. To avoid burns, do NOT touch
outdoor fire until it has completely cooled unless you are wearing protective gear (heat-resistant gloves,
BBQ mittens etc.) Never touch ashes or logs to see if they are hot.

23. Do Not leave a lit ‘Garden Halo’ outdoor fire unattended, especially around children and pets.
24. Do NOT attempt to move or store the ‘Garden Halo’ outdoor fire until all ashes and coals are completely
extinguished.
25. Do Not remove ashes or logs until they are completely and fully extinguished.
26. Use heat-resistant gloves or tool when opening and closing door.
27. Use long, sturdy fire tongs when adding or removing logs.
28. Do NOT overload the ‘Garden Halo’ outdoor fire. Do NOT add additional logs until the fire burns down.
29. The ‘Garden Halo’ outdoor fire should be thoroughly inspected and cleaned on a regular basis.
30. Deaths, Serious injury or damage to property may occur if the above safeguard is not followed exactly.

ASSEMBLY INSTRUCTIONS
Dimensions of the Halo Diameter x height (760mmx 950mm) plus height of the flue
and cowl. NOTE: The only tool required for assembly is a cross head
screwdriver.
Base Section
Fire Body
Ash pan
Burner Plate 4-off
Burner Rack
500mm Flue Section
1000mm
Flue Section
Flue cowl
Door and Ash Pan Tool

Place the Fire Base in preferred suitable location and
adjust the feet to level fire as necessary. Ensuring that all
safeguard measures are complied with. slide ash box in
to base pedestal.
Lift and locate the fire body on to the base post.
Note the fire body is a heavy item and should be
lifted into position by two people. When in
position secure in place with M6 fixing screw.
Note location of inner Glass should be to each
side off the ashpan. This will mean that the sliding
outer glass will be on the same side as the
ashpan.
Fixing Screw 2-off
Ash Box
Base adjustable feet 4-off located
bellow, adjusted from bellow.

Fit Flue pipe sections and flue cowl as shown these
are a push fit.
Cowl
Flue Pipe 500
Flue Pipe 1000

USER INSTRUCTIONS
Lighting
1. Slide Open Door
2. Stack logs as shown use logs that are no more than 350mm Long, do not stack the logs to high or
overload the ‘Garden Halo’.
3. Place kindling on top as shown.
4. Use a tapper or long match to light kindling.
5. Slide door closed once kindling is lit.
6. It will help with lighting if the ash box is opened slightly.
7. Close ash box immediately logs start to burn.
WARNING FOR YOUR SAFETY
Before using this Outdoor Fire, make sure you have read,
understand and are following all information provided in the
‘Important safeguards’ in the front of this manual. Failure to
follow those instructions can cause death, serious injury or
property damage.
Ash box
Kindling
Logs
Ash box

Tending
You may need to move or add logs for an ideal experience.
Reminders:
Always wear protective gloves or similar when tending fire.
Wait until glowing coals have developed before adding any additional logs.
Do NOT add petrol, diesel, lighter fuel or alcohol to relight or enhance an existing fire.
1. Carefully open Door with tool or Heat proof Glove.
2. While using a long-handled fireplace tool, carefully move logs and coals as required, if any logs fall
against the glass move the log as soon as possible as this will cause staining of the glass. See cleaning
section on how to clean Glass.
3. If additional logs are required, place on top of coals, taking care not to move the coals too much.
4. Close door with tool or a heat proof glove.
Extinguishing
1. Allow fire to burn itself out.
2. Do NOT use water to extinguish as this is dangerous and may cause glass to shatter causing serious
injury or damage to property and damage to the ‘Garden Halo’ outdoor fire.
Cleaning
The ‘Garden Halo’ outdoor fire should be cleaned on a regular base to promote a safer experience and longer
product life. NOTE: After repeated use, a slight discoloration of the finish may occur.
Do NOT attempt to clean the ‘Garden Halo’ until the fire is completely out and cold.
Do NOT use oven cleaner or abrasive cleaners as they will damage this product.
1. Brush of any soot from inside of glass with a soft brush.
2. Once the coals and ash are cold and ‘garden Halo’ is cool to touch, slide open door and lift out burner
rack, then brush all ash and coals into pedestal, replace burner rack and close door. Leave for a short
period to allow ash to settle in ash pan. Then remove ashpan and dispose of ashes in a suitable manor,
and re-fit ash pan.
3. For stubborn stains on glass remove glass (see detail on glass removal) and clean with kitchen cream
cleaner and rinse with clean water. Dry glass with a clean cloth.
4. Wipe exterior surfaces with a mild soap solution.

Glass Removal
To remove the glass panels first, lift one
of the outer glass panels to clear the
bottom rail then tilt glass out at the
bottom to clear rail and slowly with draw
the Glass from the fire. Repeat this
procedure for the other outer glass panel.
Once both outer panels are removed
repeat the process with the inner panels.
To refit the panels reverse the procedure
ensure that the inner panels engage in
the inner upper rail.

Storage
Do Not move or store the ‘Garden Halo’ until the fire is completely out.
1. Once the fire is out, ensure all coals and ash are removed as per cleaning instructions.
2. Store ‘Garden Halo’ assembled in a suitable location away from children and pets.
Note: if you do not use a cover, store the ‘Garden Halo’ in a dry location to maximize product life.

GUARANTEE
CONDITIONS OF WARRANTY
If this appliance should prove to be defective due to faulty design, materials or workmanship within 12 months of
purchase, the product will be repaired free, subject to the following conditions.
1. The ‘Garden Halo’ shall have been purchased and used solely within the UK for domestic purposes and in
accordance with the Users Operating instructions.
2. It is the purchaser’s responsibility to prove that the unit is under guarantee, e.g. receipt of purchase.
3. On discovery of a fault, the purchaser should contact the dealer from whom the product was purchased in
order to ascertain whether they or a service centre will carry out the repair. If problems are encountered the
purchaser may contact the service centre shown with this product. All transportation will be at the purchaser’s
expense and risk.
4. All guarantees will be invalidated if unauthorised repairs or modifications are made to the ‘Garden Halo’, or in
case of accident, misuse, or damage caused by improper installation, or to damage occurring during transit to or
from the repairer and altered or missing serial numbers.
5. Any parts, which have been replaced under this guarantee, shall become our property.
6. The company shall not be liable for any consequential loss or damage whatsoever, arising from or in
connection with this ‘Garden Halo’.
8. ‘No fault found’, service calls and installation errors are not covered under the Manufacturers guarantee and
will result in a charge being made for the call out by our appointed service engineer.
9. This guarantee is in addition to and does not affect the purchaser’s statutory rights of Consumers.
10. The company will arrange call-out requests within a mutually agreed time frame. If the companies appointed
engineer cannot gain access or receives no answer, a call-out charge will be incurred.
11. The company reserve the right to alter, change and amend or cancel any aspect of these terms & conditions
in whole or part without prior notice.
Unit 404
Glenfield Park Business Centre
Blakewater Road
Blackburn
Lancashire
BB1 5QH
Tel: [phone]
Fax: [phone]
Web: www.legend-fires.com
Email: [email protected]
