LEGRAND 4 305 34 User manual

LE04246AA
• 36 x / Auto Focus ICR Camera
4 305 34

2
Indice
1 Safety precaution 3
2 Instroduction 4
3 Features 5
4 Packing list 6
5 Name and Function of Each Part 7
6 Installation 9
6.1 Connect to monitor 9
6.2 Connect the power 9
6.3 Connection layout 9
6.3.1 Connecting the keyboard 9
6.3.2 Connecting the alarm 10
7 Operation 13
7.1 Keyboard operation 13
7.1.1 Normal display mode 13
7.1.2 OSD setup menu mode 13
8 System Setup 13
8.1 Digital zoom operation 14
8.2 OSD (On Screen Display) Main Menu Description 14
8.2.1 Main menu display 14
8.2.2 Main menu setup 14
8.3 Sub Menu Description 14
8.3.1 FOCUS Setup 14
8.3.2 EXPOSURE Setup 15
8.3.3 DAY/NIGHT Setup 16
8.3.4 WHITE BALANCE Setup 17
8.3.5 PRIVACY Mask Setup 17
8.3.6 EFFECT Setup 18
8.3.7 MOTION DETECT Setup 20
8.3.8 COMMUNICATION Setup 20
9 Specications 21
The author assumes no responsability for any errors or omissions that may appear in this document nor does it
make a commitment to update the information herein.
ELPLTR DE GB NLIERU ESPT FR BELU CH

3
1. SAFETY PRECAUTIONS
- Please be extra careful not to shake the product and avoid places where frequent vibrations occur.
- Do not install the product in an environment where the humidity is high.
- Never keep the product to direct strong light or sunlight.
- Do not spill liquid of any kind on the product.
Alcohol or beverage can contain minerals that corrode the electronic components.
- Do not install the product in extreme temperature conditions.
Use the camera under conditions where temperatures are betweeen -10 °C and +50 °C. Be especially careful
to provide ventilation when operating under high temperatures.
- Minimum illumination cannot be archieved during low light (as shown below), please install appropriate light
xtures.
36 x (ICR) zoom auto-focus EX-view high resolution.
- The installation and calibration must be carried out by highly skilled personnel.
- Do not open there may be a risk of electric shock.
Use only for the following temperature conditions: from (+5) to (+50) °C.
Do not use with voltages different from the ones specied.
Warning
Safety instructions
This product should be installed in line with installation rules, preferably by a qualied electrician. Incorrect installation and use can lead to risk of electric shock or re.
Before carrying out the installation, read the instructions and take account of the product’s specic mounting location.
Do not open up, dismantle, alter or modify the device except where specically required to do so by the instructions. All Legrand products must be opened and repaired
exclusively by personnel trained and approved by Legrand. Any unauthorised opening or repair completely cancels all liabilities and the rights to replacement and gua-
rantees.
Use only Legrand brand accessories.
IEGB

4
2. INTRODUCTION
The 36x Auto-Focus ICR camera with WDR function, uses a high sensitive color 1/4” Sony interline reaching 550
TVL.
The camera is built-in with 36x Optical zoom lens spells added user convenience since there is no need for
eparate adjustment of the focal distance.
Current applications include highway trafc control, plus security surveillance in such locations as elevators and
parking lots.
The advanced DSP technology allows intelligent control for clearer, detailed pictures. Additionally, the user can
perform remote Zoom/Focus/Iris/White balance operations via either RS-422/RS-485.
In combination with a highly sensitive 1/4” CCD sensor, these features make the auto-focus camera is
particularly suitable for surveillance.

5
3. FEATURES
High resolution
CCD Sensor provides high resolution reaching 550 TVL with advanced and clear picture quality.
Excellent sensitivity
High sensitivity, low smear, high anti-blooming and high S/N ratio.
Wide Dynamic Range (WDR)
High-quality WDR functions, perfectly shows the image details between dark and light.
Newly added environment dynamic detection switch, enhancing WDR image efciency.
Digital Noise Reduction (DNR)
2D/ 3D DNR, realize the clear image at low light environment, clear picture quality saving hard disk storage size
of DVR when using MPEG/MPEG4/H.264 compression after noise reduction.
Day & Night
Mechanic IR cut-lter driving unit with AE provides change from color to B&W mode automatically for day and
night 24-hour surveillance.
Selectable between manual Day & Night control or from external input signal Day & Night control.
Digital Slow Shutter (DSS)
Improve the low light performance.
When in low light, reducing the image frame refresh rate and increase the sensitivity of the camera.
Privacy mask
Privacy image masking with free position, support up to 15 areas of privacy masking zone.
Privacy area enlarges with digital zoom-in function.
Motion detection
Camera-site takes the initiative in providing motion detection alert for a more comprehensive monitoring and
careful editing of motion detection area.
When there are changes within the detection area, the camera immediately issues a warning.
Extra connection
Control the camera easy by keyboard via RS-485.
Connect the extra alarm out to combine with the Motion Detection function.
OSD
OSD (On Screen Display) Setup Menu.
Camera title setup of up to 16 alphanumeric letters.
Image Control
Performance: 36x Optical zoom lens and 16x digital zoom (total 576x zoom), freeze image, positive/negative
image, mirror function (left/right).
Application
All function can be operated from OSD: AES (Automatic Electronic Shutter), AI (Auto Iris), GC (Gain Control),
WB (White Balance), BLC (Back Light Compensation) and provides the ickerless mode, and line-lock function.

6
Check and make sure all of the items shown below are included in your product package.
If something is missing, contact your dealer as soon as possible.
PACKING LIST
Item description Item picture
Camera (box type)
Power adaptor
User’s manual
Caméra ICR à mise au point automatique / 36 x
36 x / ICR Camera met automatische scherpstelling
36 x / Auto Focus ICR Camera
36 x / Auto Focus ICR-Kamera
Cámara IRC Auto Focus 36 x
36 x / Câmara ICR de Focagem Automática
Κάμερα ICR αυτόματης εστίασης / 36 x
ICR-камера с 36-кратной автофокусировкой
36 x/Kamera Auto Focus ICR
36 x / Otomatik Odaklı ICR Kamera
Accessories

7
Front view
5. NAME and FUNCTION of EACH PART
Side view
Rear View
1 Mouting base Mouting base for installing the camera
2 Power input Dc 12V, 7 mA or AC 24V
3 Video Output Video output: composite video 1 Vp-p, 75 Ohms, BNC
4 Audio Output Composite video 1 Vp-p, 75 Ohms, RCA
5 5 Keys control Name Function
Tele/ Zoom tele or up ( )
Wide/ Zoom wide or down ( )
Near/+ Focus near or increase (+)
Far/- Focus far or decrease (-)
Menu Enter or exit setup menu
6 Remote controller Not used
7 Function Input/output - Day & Night
Control
Name Function
DNO
(Day & Night output)
5V/10 mA: IR LED ON (Night)
0V: IR led off (Day)
DNI
(Day & Night external input)
Open contact: Day
Close contact: (close to GND):
Night
AL (Alarm) Motion detection alarm output
1

8
Day & Night Output
This function will turn on the external IR LED lamp according to the position of IR cut lter.
5V/10 mA: IR LED ON (night)
0V: IR led off (Day)
Day & Night external input
When Day & Night mode is set to “External” on the OSD menu of the camera, this function will be
switched to Day mode or Night mode according to the Day & Night signal from the external light sensor
or the IR Led Lamp.
Open contact: Day
Close contact: (close to GND): Night
- Camera Control 2.4K / 4.8K / 9.6K / 19.2k / BPS (please refer to OSD setup
menu)
Optional: RS-422/RS-485.
Name Function
R+, R-, T+, T- Use for RS-422/RS-485 control

9
Connect the video-out port on the rear panel of the camera to a monitor.
6. INSTALLATION
6.1 Connect to monitor
Since the power specication supports both AC and DC, you may connect an AC 24V, 500 mA adaptor or a DC
12V, 500mA adaptor.
6.2 Connect the power

10
To connect the keyboard and alarm, please follow the setup guide shown below:
6.3 Connection layout
6.3.1. Connecting the Keyboard
T-
R-
T+
R+
T-
T+
RS-485 2 wires
to keyboard
Keyboard
Monitor
Camera

11
Installation with joystick
- RS-485 interface is used to communicate with the keyboard.
Connect R+ of the camera to T+ of the keyboard. Connect R- of the camera to T- of the keyboard.
- User could adjust camera ID via rear panel keys or via remote commands.
Protocol, speed and parity should only be adjusted via rear panel keys.
Communication Setting
Camera ID 0 ~ 253 for P protocol
1 ~ 254 for D protocol
Speed 2 400, 4 800, 9 600, 19 200, 38 400, 57 600, 115 200
Parity None
The speed of camera should be the same as the speed of the keyboard.
Adjusted function is only effective, after exiting the OSD Setup menu.
Note: Maximum cable distance for RS-485 communication over 24-gauge wire is 4,000 feet (1 219 m).
Recommend using shielded twisted pair cable that meets the basic requirements for EIA RS-485
applications.
6.3.2. Connecting the Alarm
Light Sensor installation
Connect DNI and GND of the camera to the DNI and GND of the light sensor.
AL
GND
DNO
GND
DNI
Camera
IR Illuminator (light sensor)
Camera
IR Illuminator
(Light sensor)
IR Illuminator
(Light Control)
Alarm

12
IR Illuminator Installation
Connect DNI and GND of the camera to the DNI and GND of the IR Illuminator.
AL
GND
DNO
GND
DNI
GND
INPUT
Camera
IR Illuminator (Camera control)
Output signal = 5V, 10 mA
Note: CAM must be set to AE mode light sensor to EXT mode.
Alarm Installation
Connect GND and AL of the camera to the GND and AL of the alarm.
AL
GND
DNO
GND
DNI
INPUT
GND
Camera Alarm
Output signal = 5V, 10 mA
Note: The alarm is triggered by motion sensor.

13
(1) Mount the camera on the mounting bracket by using the hole on the top or bottom of the camera or by using
the encloses 8 mm mounting block, furnished by 2 screws.
(2) Connect the video output to the monitor or other video device via a 75 Ohms type coaxial cable.
(3) Connect the power source, using the DC Jack (+12V DC in the jack center).
(4) Wait a while for the camera to power on and the zoom lens will resume to the previous power on position
automatically.
(5) Once the picture appears on the monitor, press the zoom tele, zoom wide, focus near, focus far
and setup menu key to obtain the best picture quality.
7.1 Keyboard operation
7.1.1 Normal display mode
Keyboard Camera function
Open Brightness (+)
Close Brightness (-)
Near Focus Near
Far Focus Far
Twist Joystick Clockwise (Zoom In) Zoom Tele
Twist Joystick Counter Clockwise (Zoom Out) Zoom Wide
Move Joystick Left X
Move Joystick Right X
Move Joystick Up X
Move Joystick Down X
Keyboard Camera function
Enter 95 ; Press Preset 5 s Access to OSD Main Menu
Enter a number (1-32 ; 35-82) ; Press Preset Call the Preset Point
Enter a number (1-32 ; 35-82) ; Press Preset 2 s Set the Preset Point
7.1.2 Main menu mode
Keyboard Camera function
Open Enter Sub Menu
Close Exit Sub Menu
Near Cursor Up
Far Cursor Down
Twist Joystick Clockwise (Zoom In) x
Twist Joystick Counter Clockwise (Zoom Out) x
Move Joystick Left Decrease (-)
Move Joystick Right Increase (+)
Move Joystick Up Cursor Up
Move Joystick Down Cursor Down
7. OPERATION

14
8.1 Digital zoom operation
The built-in 36x optical zoom lens is highly reliable and offfers auto focus and auto iris functions.
Users can monitor a scene from any desired angle of view, use (T)/ (W) button to control the optical zoom
1x ~ 36x and digital zoom 1x ~ 16x.
8.2 OSD (On Screen Display) main menu description
8.2.1 Main Menu Display
MAIN MENU
FOCUS <-->
EXPOSURE <-->
DAY/NIGHT <-->
WHITE BALANCE <-->
PRIVACY MASK <-->
EFFECT <-->
MOTION DETECT <-->
COMMUNICATION <-->
DEFAULT <-->
RETURN ON
8.2.2 Main Menu Setup
- In order to display the setup menu on the screen, set the menu command or press the button panel.
- Use (T)/ (W) control buttons to select each item.
- Use (-)/ (+) control buttons to change the data.
- Use Menu Control button to Enter/Exit the menu display.
8.3 Sub Menu description
8.3.1 Focus setup
FOCUS
FOCUS MODE PUSH AUTO
DISTANCE 1.5 M
ZOOM START X1
ZOOM END X576
ZOOM SPEED HIGH
TRACKING MODE AUTO
DEFAULT ON
RETURN
FOCUS MODE SET:
This function is for focus mode setting.
Set the mode to Auto, Manual, or Push Auto.
Note:
Auto: Select auto mode to enable automatic adjustment of the focus position.
Push Auto: Select push auto to adjust focus position TELE or WIDE, the preset value
becomes that for AF mode and returns to Manual Focus mode.
FOCUS DISTANCE SET:
This function is for selection of minimum shooting distance.
Set the focus distance mode to 10 cm, 50 cm, 1 m, 1.5 m, 3 m, 5 m or 10 m.
8. SYSTEM SETUP

15
ZOOM START SET:
This function is for selection of Zoom Start position.
Set the Zoom Start mode from 1 to 36.
FOCUS END SET:
This function is for selection of Zoom End position.
Set the Zoom End mode from 2 to 576.
FOCUS SPEED SET:
This function is for selection of zoom speed.
Set the Zoom Speed to slow, normal or high.
ZOOM TRACKING MODE SET:
This function is for selection of zoom tracking mode.
Set the Zoom Tracking mode to Auto or Manual.
Zoom Tracking means focused zooming state. Select Auto mode, during zoom changing, the system will
continue focusing and nd the right track of the observation. Otherwise, select Manual mode the system will
follow the focus distance previously set.
DEFAULT SET:
If initial mode set to ON, all focus function is changed to the factory setting.
RETURN:
Exit the Focus set of OSD menu and return to the main menu.
8.3.2 EXPOSURE setup
EXPOSURE
MODE WDR
BRIGHTNESS 6
BLC NA
AGC MAX LEVEL 157
SHUTTER
NOISE REDUCE NORMAL
DSS MAX MEDIUM
DEFAULT OFF
RETURN ON
MODE:
It consists of 2 types of mode: NORMAL / WDR (Default setup: WDR)
BRIGHTNESS:
Select the Brightness from 0 to 15.
BLC:
When the exposure mode is set to Normal mode, we can setup the BLC function. BLC consist of three types:
BLC OFF / BLC SMART / BLC MANUAL (Default setup: BLC OFF).
BLC AREA EDIT
MODE BLC OFF
BLC LEVEL 7
AREA NA
START X NA
END X NA
START Y NA
END Y NA
DEFAULT ON
RETURN

16
1. Smart Mode - System will auto detect its brightness and the backlight compensation is auto dened by
the system.
2. User Dened Mode - Compensation area can be manually setup by the users.
AGC MAX LEVEL:
Set AGC Mode to Auto, AGC Max setup range = 0 ~ 255. (Default setup: 157).
X SHUTTER:
Set ickerless, 1/250, 1/500, 1/1 000, 1/2 000, 1/4 000, 1/10 000, 1/20 000, 1/500 000, 1/1 000 000.
NOISE REDUCE:
Adjust three-dimension noise reduction level value “High/Medium/Low”.
Noise reduction is a function which reduces image noise in order to improve the image quality of the camera.
In particular, it reduces the noise which is generated under low-brightness shooting conditions and other
high-gain states (Default Setup: Medium).
DSS Max:
Low speed shutter control, offers optimal brightness level.
Therefore, in dark scene highter the value higher the brightness level, total of 25 levels: Off ~ 512 (Default
Setup: OFF).
Note: Adjust according to the environment, high DSS level results smear images.
DEFAULT:
Return to default setup.
RETURN:
Return to previous status.
8.3.3 DAY/NIGHT setup
DAY AND NIGHT
D/N MODE AE
DAY/NIGHT 11
NIGHT/DAY 63
DEFAULT OFF
RETURN
D/N MODE:
Four types of setups AE/DAY/NIGHT/EXT (Default: AE).
(1) AE: Setup according to DAY-NIGHT and NIGHT/DAY (threshold value), auto switches to color or B/W.
(2) DAY: Fixed to color mode.
(3) NIGHT: Fixed to B/W mode.
(4) EXT: External control mode Color or B/W.
DAY -> NIGHT
The threshold value of color change (from color to B/W) under AE mode. Switches to B/W when “Day/Night”
≥ “AE value” then switch to B/W (Default setup: 11).
(1) CENTER (2) TOPS (3) TOPL (4) BOTTOMS
(5) BOTTOML (6) LEFT (7) RIGHT
(8) Use function option
“START X/END X/ START Y /
END Y” to setup the size of
Exposure Area
(Default Setup: USER)

17
NIGHT -> DAY
The threshold value of color change (from B/W to color) under AE mode.
Switches to Color when “Night/Day” ≤ “AE value” then switch to Color (Default setup: 63).
DEFAULT
Return to default setup.
RETURN
Return to previous status.
8.3.4 WHITE BALANCE Setup
WHITE BALANCE
WB MODE Auto
RED GAIN NA
BLUE GAIN NA
PUSH AUTO NA
DEFAULT ON
RETURN
WB MODE:
Five types of WB Mode: Auto, Indoor, Outdoor, Manual and Push auto (Default setup: Auto).
RED GAIN / BLUE GAIN:
It operates only when WB Mode is set to Manual, otherwise it is an NA (not available) item
(Default setup: NA).
PUSH AUTO:
When WB Mode is set to Push Auto:
- Push Auto ON: Enable auto tracing white balance.
- Push Auto OFF: Disable auto tracing white balance and record the current white balance value.
DEFAULT:
Return to default setup.
RETURN:
Return to previous status.
8.3.5 PRIVACY MASK Setup
PRIVACY MASK
AREA 1
MASK OFF
START X 48
END X 168
START Y 16
END Y 56
DEFAULT ON
RETURN
AREA:
Maximum Privacy Mask area setup is 15 (Default setup: 1).
MASK:
Set MASK to “ON” Mask Area becomes available for setup and is shown on the monitor.
Set Mask to “OFF”, “Mask Area” becomes an NA (Not Available) item (Default setup: OFF).
START X:
Horizontal start position (0 ~ 440).

18
END X:
Horizontal end position (40 ~ 480).
START Y:
Vertical start position (0 ~ 271).
END Y:
Vertical end position (20 ~ 291).
DEFAULT:
Return to default setup.
RETURN:
Return to previous status.
8.3.6 EFFECT Setup
EFFECT
DISPLAY <- ->
SHARPNESS 8
POSI/NEGA POSI
MIRROR OFF
FREEZE OFF
WIDE BURST OFF
SYNC INTERNAL
V PHASE NA
DEFAULT ON
RETURN
DISPLAY
DISPLAY
TITLE EDIT
USER TITLE DISP ON
CAMERA ID DISP ON
ZOOM RATIO DISP ON
MOTION ALM DISP ON
AE/AWB DISP ON
BRIGHTNESS DISP ON
LANGUAGE ENGLISH
DEFAULT ON
RETURN

19
Normal AWB
M
1 1 ZOOM CAMERA
Zoom ID Title
1. TITLE: You can enter up to 16 characters (‘~’ indicates blank space).
2. USER TITLE DISP: TITLE / ID / ZOOM /MOTION ALM / AE AWB / BRIGHTNESS title display
ON/OFF under llive display
(Default setup: ON).
3. LANGUAGE: Select English as your OSD language display.
4. DEFAULT: Return to default setup.
5. RETURN: Return to previous status.
SHARPNESS:
Video sharpness level setup: 0 ~ 15 (Default setup: 8).
POSI / NEGA
Images can be set to POSI (Positive image) or NEGA (Negative image) (Default setup: POSI).
MIRROR:
Four types of Mirror Mode: OFF / HORIZONTAL / VERTICAL / ROTATE (Default setup: Off).
FREEZE:
Set Freeze to “ON” to enable still field image (Default setup: Off).
WIDE BURST:
Select this option to transmit system image to distant places.
SYNC:
When using a DC 12V adaptor, the sync setting is set to internal sync (Default Setup: INT).
And to line-lock sync when using an AC 24V adaptor.
V PHASE:
When L/L mode is selected, you can adjust the desired phase (0 ~ 99), otherwise it is an NA (Not Available)
item (Default setup: NA).
DEFAULT:
Return to default setup.
RETURN:
Return to previous status.

20
8.3.7 MOTION DETECT Setup
MOTION DETECT
MOTION OFF
SENSITIVITY 5
DURATION 5S
ALARM OUT OFF
ZOOM RATIO OFF
DEFAULT ON
RETURN
MOTION:
Motion detection setup “ON/OFF” (Default setup: OFF).
SENSITIVITY:
Detection sensitivity can be set to range of 0 ~ 63 (Default setup: 5).
DURATION:
Alarm duration that arises after the motion alarm can be set to 5 s / 10 s / 15 s / 20 s / 30 s / 1 mn / 2 mn
/ 3 mn / 4 mn / 5 mn (Default setup: 5 s).
When an alarm has been triggered it sends out a high level 5V signal from the rear panel.
ALARM OUT:
Zoom in setup: when alarm occurs, whether or not to start zoom in function (Default setup: OFF).
ZOOM RATIO:
1.4x / 2x / 2.8x / 4x / 6x (Default setup is 1.4x).
DEFAULT:
Return to default setup.
RETURN:
Return to previous status.
8.3.8 COMMUNICATION Setup
COMMUNICATION
CAMERA ID 1
SPEED 9 600
PARITY NONE
RETURN
