LEGRAND CM7020 User manual

User Manual
CM7020
OUTDOOR DOME IP CAMERA
1308244 Rev. A

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 2xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
OUTDOOR DOME IP CAMERA
This is a 1/3” CMOS Sensor IP camera with a built-in web server.
The user can view real-time video via IE browser. It supports
H.264, and M- JPEG video compression, providing smooth and
high video quality. The video can be stored in Micro SD card and
playback remotely.
With a user friendly interface, it is an easy-to-use IP camera
which is designed for security application.

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 3xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK DO
NOT OPEN
CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED TO THEIR
RESPECTIVE COMPANIES.
Warnings, Cautions and Copyright

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 4xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
Hardware
CPU
Multimedia SoC
RAM
512MB
Flash
32MB
Image Sensor
1 / 3” Megapixel CMOS Sensor
Sensitivity
Color: 0.15 Lux (AGC ON) B/W:
0.08 Lux (AGC ON)
Lens Type
2.8-8mm 2.8x motorized zoom lens@ F1.8
View Angle
50.25°~99.1° (H), 28.21°~52.37°(V)
ICR
IR cut Filter Mechanism
I/O
N/A
Power over Ethernet
Yes
Video Output
N/A
Audio
N/A
Power Consumption
DC 12V Max: 5.52W(IR ON); 3.48W(IR OFF) PoE
Max: 6.12W(IR ON); 4.32W(IR OFF)
Operating Temperature
-20°C ~ 50°C [*IR OFF]
*IR ON: 45°C
Dimensions
Weight
450g
IR LEDs
LEDs
10 LEDs, 850nM
IR Distance
15M
Network
Ethernet
10/ 100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE 802.1X,
RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, 3GPP,
SAMBA, Bonjour
Product Specifications

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 5xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
System
Video Resolution[16:9]
2688x1520@30fps, 1920x1080@30fps, 1280x720@30fps,
640x360@30fps
Video Adjust
Brightness, Contrast, Hue, Saturation, Sharpness, AGC, Night Mode,
WDR, Flip, Mirror, Noise Reduction, Day&Night Adjustable
Triple Streaming
Yes
Image Snapshot
Yes
Full Screen Monitoring
Yes
Privacy Mask
Yes, 3 different areas
Compression Format
H.264/ M-JPEG
Video Bitrates Adjust
CBR, VBR
Motion Detection
Yes, 3 different areas
Triggered Action
Mail, FTP, Save to SD card, SAMBA
Security
Password protection, IP address filtering, HTTPS encrypted data
transmission, 802.1X port-based authentication for network protection,
QoS/DSCP
Firmware Upgrade
HTTP mode, can be upgraded remotely
Simultaneous Connection
Up to 10
Micro SD Card Management (Optional)
Recording Trigger
Motion Detection, IP check, Network break down (wire only),Schedule
Video Format
AVI, JPEG
Video Playback
Yes
Delete Files
Yes
Web Browsing Requirement
OS
Windows 10, Windows 7, XP, Microsoft IE 6.0-11.0 or Firefox
Mobile Support
iOS 4.3 or above, Android 1.6 or above
Hardware Suggested
Intel Dual Core 2.53G,RAM: 1024MB, Graphic card: 128MB
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION.

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 6xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1. Right-Click on the desktop. Select Properties
2. Change color quality to highest (32bit).
Monitor Settings

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 7xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1. Use the software IP Installer to assign the IP address of the IP Camera. The software
is in the software CD attached to the product’spackage.
2. There are 3 kinds of IP configuration.
a. Fixed IP (Public IP or VirtualIP) –Also known as static assignment.
b. DHCP (Dynamic IP) –The IP address is assigned from the primary router on the
network automatically.
c. Dial-up (PPPoE) –The IP address is dynamically assigned by the service provider.
3. Execute IP Installer
4. For Windows XP SP2 or above, a Windows Security Alert may pop up. Please click on
Allow access.
IP Assignment

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 8xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
5. IP Installer configuration:
6. IP Installer will search for all the IP Cameras connected on the LAN. The user can click
Search Device to search again.
NOTE: The camera must be connected to the same router as the computer for the
camera to be discovered.
7. Click one of the IP Cameras listed on the left side. The network configuration of this IP
camera will be shown on the right side. You can change the name of the IP Camera to
your preference (e.g.: Office, warehouse). Change the parameters and click Submit, then
click OK, it will apply the changes and reboot the device.

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 9xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
8. Please make sure the subnet of the PC IP address and the IP Camera IP address are the
same.
The same Subnet:
IP Camera IP address: 192.168.1.200 PC IP
address: 192.168.1.100
Different Subnets:
IP Camera IP address: 192.168.2.200 PC IP
address: 192.168.1.100
Generally, the PC IP address will always be in the same subnet as long as it
connected to the same router as the CM7020 Outdoor Dome IP Camera.
9. A quick way to access remote monitoring is to left-click the mouse twice, on a selected IP
Camera, listed on the Device list of IP Installer. A new browser window will be opened.
10. Then, key-in the default user name: admin and password:admin.

301 Fulling Mill Road, Suite G
Middletown, PA 17057
[phone]
©Copyright 2016 by Legrand, Inc All Rights Reserved.
www.legrand.us
Page | 10xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1. For users of IE 6.0-11.0:
When viewing the camera video for the first time via IE (Internet Explorer), the browser will ask you to
install the ActiveX component.
Choose ‘Allow’,
Then choose ‘Install’.
Start installing the ActiveX component.
If the installation fails, please check the security settings in the IE browser.
Go to Start-Up Menu on the lower left corner of the Windows, select Control Panel
then Double-click on to access to Internet Properties settings.
Starting from Internet Properties, proceed to step A and B:
Install ActiveX control
