INSTALLATION INSTRUCTIONS

LTSIU_F-5445_091118

Luminaires for Tunnel Applications

LUXTRAN™

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety precautions

should always be followed, including the following:

THIS PRODUCT MUST BE INSTALLED IN

ACCORDANCE WITH THE APPLICABLE

INSTALLATION CODE BY A PERSON FAMILIAR

WITH THE CONSTRUCTION AND OPERATION OF

THE PRODUCT AND THE HAZARDS INVOLVED.

CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE

CODE D’INSTALLATION PERTINENT, PAR UNE

PERSONNE QUI CONNAÎT BIEN LE PRODUIT

ET SON FONCTIONNEMENT AINSI QUE LES

RISQUES INHÉRENTS. DISCONNECT POWER TO ALL

CIRCUITSBEFOREWIRINGFIXTURE.INSTALLINACCORDANCE

WITH ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT

CONNECTTOANUNGROUNDEDSUPPLY.READALLFIXTURE

MARKINGSANDLABELSTOENSURECORRECTINSTALLATION

OFFIXTURE.SUPPLEMENTALINSTRUCTIONSMAYBELOCATED

ONTHEFIXTURE,INADDITIONTOTHISINSTRUCTIONSHEET,

REGARDING ORIENTATION, OR MOUNTING RESTRICTIONS.

SAVE THESE INSTRUCTIONS

INSTALLATION INSTRUCTIONS

LTSIU SERIES

1. Secure xture to wall or ceiling using user supplied hardware. Slots for 3/8 bolts are provided in the mounting

brackets. See Figure 1.

The LuxTran LTSIU series luminaires contains sensitive electronics. Take care to avoid damage by improper handling or

static electricity discharge (ESD). Either type of damage could render the system inoperable or cause latent failure.

NOTE: If the xture has directional optics, note the label indicating the direction of light and install appropriately.

Figure 1

.94

.44

10.0

25.5

9.75

Figure 1a

.91

.41

4.00

25.37

5.95

20°

Figure 1b

www.kenall.com |P: 800-4-Kenall |F: 262-891-9701 |10200 55th Street Kenosha, Wisconsin 53144, USA

This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents

INSTALLATION INSTRUCTIONS

LTSIU_F-5445_091118

SERVICE INSTRUCTIONS

2. Rotate latches and open door, which is retained by stainless steel cables.

3. Loosen wing nuts and remove Wiring Cover. See gure 2.

Figure 2

4. Connect weather tight electrical service to 7/8 dia. opening provided.

5. Connect electrical service:

Black- input line, 120-277VAC or 277-480VAC (refer to label for correct input voltage)

White- Neutral

Copper- ground

6. Replace Wiring Cover and secure with wing nuts.

7. Close door and secure rotating latches.

LTSIU series LED modules are not eld replacable.

LED module replacement may be done after the xture is removed from service.

Before beginning any service operation, be sure the power to the xture is off.

To replace an LED driver-

1. Open door, which is retained by stainless steel cables.

2. Loosen wing nuts and remove Wiring Cover.

See Figure 3.

3. Disconnect the driver to be replaced.

4. Remove the retaining strap which secures

the driver. See gure 3.

5. Install new driver and secure using

restraining strap.

6. Connect to LED modules following the

wiring diagram for the particular xture.

Figure 2

Figure 3

www.kenall.com |P: 800-4-Kenall |F: 262-891-9701 |10200 55th Street Kenosha, Wisconsin 53144, USA

This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents

INSTALLATION INSTRUCTIONS

LTSIU_F-5445_091118

To replace LED modules-

1. Open door, which is retained by stainless steel cables.

2. Loosen wing nuts and remove Wiring Cover. See Figure 2.

3. Remove reectors and disconnect LED module leads. See Figure 4.

4. Remove screws securing LED module.

5. Secure new LED module by re-installing removed screws.

6. Attach leads and secure reectors.

7. Re-install wiring cover and door.

Figure 4

Wiring Diagrams

Blue

Red

Blue

Red

Blue

LED Module

Blue

Red

Blue

Gray

Red

Green

White

Driver

Black

Purple

White

100L Wiring Diagram RED

BLUE

RED BLUE

GREEN

COPPER

WHITE

BLACK

DIMMING (+)

DIMMING (-)

100L Wiring
