Leidos ProVision 3 User manual

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –ProprietaryPage 1 of 119
This item is subject to the U.S. Export Administration Regulations (15 CFR 730-774) and authorized for export only for certain
countries, parties, end-users, and end-uses. It may not be exported, resold, transferred, or otherwise disposed of without approval
under the EAR or as otherwise authorized by U.S. law and regulations.
© 2020 Leidos. All rights reserved
ProVision 3
Installation Manual
Model 1000-10004-PV

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 2 of 119
© 2020 Leidos. All rights reserved
Contents
Disclaimer .................................................................................................................................................8
1.0 Introduction.....................................................................................................................................12
1.1 Relevant Procedures....................................................................................................................12
1.2 Minimum Technical Qualifications.............................................................................................12
1.3 Contacting Customer Support .....................................................................................................12
2.0 Safety...............................................................................................................................................14
2.1 Electrical Safety Precautions.......................................................................................................14
Line Voltages.......................................................................................................................14
Voltage and High Current ...................................................................................................14
2.2 Lockout/Tagout Requirements and Procedure............................................................................15
2.3 Mechanical Safety Precautions....................................................................................................15
Mast Antenna.......................................................................................................................15
Belt Drive ............................................................................................................................15
2.4 Toxic Safety Precautions.............................................................................................................16
2.5 Fire Safety Precaution .................................................................................................................16
2.6 Safety Features ............................................................................................................................16
3.0 Tools List.........................................................................................................................................17
3.1 Tools in Installation Kit...............................................................................................................17
3.2 Additional Tools..........................................................................................................................17
4.0 Crate Unpacking..............................................................................................................................19
4.1 General Guidelines......................................................................................................................19
Installation Kit Crate ...........................................................................................................19
Scanner Crate.......................................................................................................................19
4.2 Scanner Crate Unpacking............................................................................................................21
4.3 Installation Kit Crate Unpacking.................................................................................................22
5.0 Genie Lift Assembly........................................................................................................................24
5.1 Genie Lift Components ...............................................................................................................24
5.2 Leg and Wheelie Bar Attachment ...............................................................................................25
5.3 Modified Cradle Fork Attachment ..............................................................................................27
6.0 Caster Operation..............................................................................................................................28
7.0 Removal from Scanner Crate ..........................................................................................................31
8.0 Movement to the Install Location....................................................................................................34
9.0 Upper Assembly Lift.......................................................................................................................36
9.1 Preparation of Assembly and Genie Lifts....................................................................................36
9.2 Upper Frame Assembly Lifting...................................................................................................41
9.3 Genie Lift Removal.....................................................................................................................44
10.0 Scanner Leveling and Alignment....................................................................................................45
10.1 Pre-leveling .................................................................................................................................45
10.2 Bolt-On Side Frames...................................................................................................................45
10.3 Isolation Footpads (optional).......................................................................................................47
10.4 Feet Lowered...............................................................................................................................47
10.5 Seismic Bracket Kit (optional)....................................................................................................47
10.6 Scanner Leveling.........................................................................................................................47
11.0 Scanner Assembly...........................................................................................................................48
11.1 Upper Frame Torque ...................................................................................................................48
11.2 Bottom Outer Window Angle Brackets.......................................................................................48
11.3 Floor Cover Trim.........................................................................................................................49
11.4 Mounting Brackets ......................................................................................................................50

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 3 of 119
© 2020 Leidos. All rights reserved
11.5 Top Window Angle Brackets......................................................................................................51
11.6 Motor Brake Release...................................................................................................................52
11.7 Power Cord..................................................................................................................................52
11.8 Swing Arm ..................................................................................................................................53
11.9 Antenna Masts.............................................................................................................................53
11.10 Mast Cables.............................................................................................................................54
11.11 Cosmetic Mast Wrap...............................................................................................................56
11.12 End Cap Top Bracket ..............................................................................................................57
11.13 Entrance/Exit End Cap ............................................................................................................58
11.14 Vibration Control Kit ..............................................................................................................58
11.15 Outer Window Scratch Guards................................................................................................58
11.16 Outer Windows........................................................................................................................59
11.17 Outer Window Bracket Supports.............................................................................................60
11.18 Outer Window Bracket Retainers............................................................................................60
11.19 Outer Window Screw Tightening Order .................................................................................61
11.20 Antenna Operation Verification ..............................................................................................61
E4.10.XX and SS5.1.XX.................................................................................................61
3.20.XXX ........................................................................................................................62
11.21 Housing Brace Brackets ..........................................................................................................64
11.22 Cabling Routes ........................................................................................................................64
11.23 Top Down Power.....................................................................................................................65
11.24 Power Input Box......................................................................................................................65
11.25 Router......................................................................................................................................66
11.26 Remote OCP............................................................................................................................66
11.27 Roof.........................................................................................................................................66
11.28 Top Side Covers......................................................................................................................67
11.29 Notch Delete............................................................................................................................69
11.30 Blank Plate and Cable Pass-Through Hole..............................................................................70
11.31 Middle OCP Cover..................................................................................................................71
11.32 Plain Middle Cover..................................................................................................................72
11.33 Middle Covers for Barrier Belt................................................................................................72
11.34 Upper/Lower Cover with Switch/Power Input........................................................................73
11.35 Plain Upper/Lower Covers......................................................................................................74
11.36 Label Kit..................................................................................................................................74
11.37 Top Entrance/Exit Covers .......................................................................................................74
11.38 Belt Barrier Assembly.............................................................................................................75
11.39 Operator Control Panel............................................................................................................75
11.40 Optional Resolution Station ....................................................................................................75
11.41 Inner Radome Top Angle Bracket...........................................................................................75
11.42 Inner Radome Base Flange Support Brackets.........................................................................76
11.43 Inner Radome Scratch Guards.................................................................................................76
11.44 Inner Radome Edge Support Brackets.....................................................................................77
11.45 Inner Radomes.........................................................................................................................77
11.46 Ceiling.....................................................................................................................................79
11.47 Entrance/Exit Ramp Supports and Ramp................................................................................80
11.48 Center Floor Board..................................................................................................................82
11.49 Floor Side Panels and Center Panel.........................................................................................83
11.50 Final Cover Fitting/Alignment ................................................................................................83
12.0 Scanner Power-Up...........................................................................................................................84
12.1 Pre-Power-Up Checks.................................................................................................................84

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 4 of 119
© 2020 Leidos. All rights reserved
12.2 Power Cable Routing...................................................................................................................85
12.3 Scanner Power-Up and Warm-Up...............................................................................................85
12.4 Date/Time Setting........................................................................................................................86
12.5 Scanner Calibration.....................................................................................................................86
Scanner Calibration E4.10.XX and SS5.1.XX....................................................................86
Auto Test Verification with Field Service Laptop ..............................................................90
13.0 Acronyms and Abbreviations..........................................................................................................91
14.0 Appendix A: ProVision 3 Control Kit Install Procedure.................................................................92
15.0 Purpose............................................................................................................................................92
16.0 Scope...............................................................................................................................................92
17.0 Applicable Documents ....................................................................................................................92
18.0 Definitions.......................................................................................................................................92
19.0 Requirements...................................................................................................................................92
19.1 Tools and Equipment...................................................................................................................92
20.0 Responsibilities ...............................................................................................................................93
21.0 Installation Overview ......................................................................................................................93
21.1 Installation Sequence...................................................................................................................93
21.2 Method 1......................................................................................................................................93
21.3 Method 2......................................................................................................................................94
22.0 Appendix B: End Cap Notch Delete Plate Installation Procedure ..................................................97
23.0 Purpose............................................................................................................................................97
24.0 Scope...............................................................................................................................................97
25.0 Applicable Documents ....................................................................................................................97
26.0 Definitions.......................................................................................................................................97
27.0 Requirements...................................................................................................................................97
28.0 Responsibilities ...............................................................................................................................97
29.0 Preparing System.............................................................................................................................98
30.0 Appendix C: Label Kit ..................................................................................................................103
31.0 Purpose..........................................................................................................................................103
32.0 Scope.............................................................................................................................................103
33.0 Requirements.................................................................................................................................103
33.1 Tools and/or Equipment............................................................................................................103
34.0 Responsibilities .............................................................................................................................103
35.0 Procedure.......................................................................................................................................104
36.0 Appendix C: OCP and Belt Barrier..............................................................................................106
37.0 Purpose..........................................................................................................................................106
38.0 Scope.............................................................................................................................................106
39.0 Applicable Documents ..................................................................................................................106
40.0 Definitions.....................................................................................................................................106
41.0 Requirements.................................................................................................................................106
42.0 Installation of Barrier Belt Option.................................................................................................107
42.1 Installation of Monitor Pole Mount Option...............................................................................108
42.2 Installation of Monitor Fixed Mount Option.............................................................................111
43.0 Appendix D: Installation Checklist...............................................................................................114
44.0 Appendix E: Genie Lift Pre-Use Inspection Form........................................................................117

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 5 of 119
© 2020 Leidos. All rights reserved
List of Figures
Figure 1: Hazardous Voltage and High Current Labels..............................................................................14
Figure 2: Belt-Drive Safety Labels..............................................................................................................16
Figure 3: Electrical Power Switch (Two Options)......................................................................................16
Figure 4: Masts and Other Items on Top Shelf ...........................................................................................21
Figure 5: Scanner Crate with Top Shelf to Be Removed............................................................................21
Figure 6: Column Screws to Be Removed ..................................................................................................22
Figure 7: Screws/Bolts and Brackets to Be Removed.................................................................................22
Figure 8: Installation Kit .............................................................................................................................23
Figure 9: Genie Lift Components................................................................................................................24
Figure 10: Spring-Loaded Pin and Crank Handle (Rotated from In to Out)...............................................25
Figure 11: Spring-Loaded Pin and Crank Handle and Carriage Lock Bar..................................................26
Figure 12: Wheelie Bars (at Right) .............................................................................................................26
Figure 13: Fork Support Tubes....................................................................................................................27
Figure 14: Modified Cradle Forks with Rings in Place...............................................................................27
Figure 15: Caster Assembly ........................................................................................................................28
Figure 16: Caster Positions..........................................................................................................................28
Figure 17: Caster Orientation......................................................................................................................29
Figure 18: Caster Caution Area...................................................................................................................29
Figure 19: Caster Pivot Lock.......................................................................................................................30
Figure 20: Ramps Attached.........................................................................................................................31
Figure 21: Caster End Plate Installation......................................................................................................31
Figure 22: Caster Attachment to Caster End Plate......................................................................................32
Figure 23: Electrical Enclosure End of Upper/Lower Frame Assembly.....................................................34
Figure 24: Grip Point for Rotating Casters..................................................................................................35
Figure 25: Bolts to Remove from Shipping Legs........................................................................................36
Figure 26: Lifting Bracket with Quick-Release Pin Being Inserted............................................................37
Figure 27: Lifting Bar Inserted Through Lifting Bracket and Pinned in Place...........................................37
Figure 28: Column Head Clamp..................................................................................................................37
Figure 29: Left and Right Columns.............................................................................................................38
Figure 30: Orientation of Columns..............................................................................................................38
Figure 31: Columns Attached with Bolts and Column Head Clamps.........................................................39
Figure 32: Genie Lift Position.....................................................................................................................39
Figure 33: Modified Cradle Fork and Lifting Bar Secured with Quick-Release Pin..................................40
Figure 34: Wheel Chock..............................................................................................................................40
Figure 35: Shipping Leg with Two Remaining Lower Bolts Removed......................................................40
Figure 36: Stop Bolt in Upper Bolt Hole.....................................................................................................41
Figure 37: Column Bolt Direction...............................................................................................................42
Figure 38: Bolts 1–3 Torqued on Left (Top) and Right (Bottom) Columns...............................................42
Figure 39: Cross Braces Between Shipping Legs .......................................................................................43
Figure 40: Bolt Through L Bracket into Swing Arm ..................................................................................43
Figure 41: Leveling Foot.............................................................................................................................45

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 6 of 119
© 2020 Leidos. All rights reserved
Figure 42: Bolt-On Side Frames..................................................................................................................46
Figure 43: U-clip Installed on Frame ..........................................................................................................46
Figure 44: Cross-Level Check.....................................................................................................................47
Figure 45: Other Column Screws/Bolts Torqued........................................................................................48
Figure 46: Bottom Outer Radome Angle Bracket.......................................................................................49
Figure 47: Floor Cover Trim and Install Detail...........................................................................................49
Figure 48: Mounting Bracket Installed on Column.....................................................................................50
Figure 49: Top Outer Radome Angle Bracket with Bolt Inserted (Right)..................................................51
Figure 50: Motor Brake Release Cable and Detail Showing Jumper Connected........................................52
Figure 51: Power Input Box........................................................................................................................52
Figure 52: Power Switch in the On Position...............................................................................................53
Figure 53: Swing Arm in Calibration Position............................................................................................53
Figure 54: Antenna Mast Being Attached to Swing Arm ...........................................................................54
Figure 55: Cables Routed Through Swing Arm Hole.................................................................................54
Figure 56: Corrugated Tube ........................................................................................................................55
Figure 57: Connectors on ISU and Cables from Mast Connected to ISU...................................................55
Figure 58: Cosmetic Mast Wrap Protective Film Being Removed.............................................................56
Figure 59: Cosmetic Mast Wrap Installation...............................................................................................56
Figure 60: Push-In Rivets Inserted..............................................................................................................57
Figure 61: Nut Plate ....................................................................................................................................57
Figure 62: Right Entrance/Exit Cover –Top (Left) and Bottom (Right)....................................................58
Figure 63: Scratch Guard Film Being Removed.........................................................................................58
Figure 64: Outer Windows..........................................................................................................................59
Figure 65: Outer Window Bracket Support –Top (Left) and Bottom (Center)..........................................60
Figure 66: Outer Window Bracket Retainer: Overall and Upper and Lower Closeups..............................60
Figure 67: Floor Center Panel .....................................................................................................................62
Figure 68: Housing Brace Brackets.............................................................................................................64
Figure 69: Cabling Route with Power Input Box, OCP, and Other Cables Together .................................65
Figure 70: Power Input Box in the Lower (Electrical Enclosure End) Position .........................................66
Figure 71: Roof Middle Holes.....................................................................................................................67
Figure 72: Roof Middle Holes (Viewed from Motor/Pulley End)..............................................................67
Figure 73: Top Side Cover and Clip-On Panel Nuts...................................................................................68
Figure 74: Top Side Cover Sliding into Entrance/Exit Cover.....................................................................69
Figure 75: Blank Plate and Cable Pass-Through Hole................................................................................70
Figure 76: Middle OCP Cover ....................................................................................................................71
Figure 77: Plain Middle Cover....................................................................................................................72
Figure 78: Middle Covers for Barrier Belt..................................................................................................73
Figure 79: Upper/Lower Cover with Switch/Power Input in Lower Position.............................................74
Figure 80: Top Entrance/Exit Cover ...........................................................................................................75
Figure 81: Inner Radome Top Angle Rail and Attachment Point...............................................................75
Figure 82: Inner Radome Base Flange Support Bracket and Guide Pin .....................................................76
Figure 83: Scratch Guard Film Being Removed.........................................................................................76
Figure 84: Placement of Inner Radome Edge Support Brackets.................................................................77

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 7 of 119
© 2020 Leidos. All rights reserved
Figure 85: Inner Radome Fastened in Place................................................................................................78
Figure 86: Inner Radome Slotted Hole and Screw Sticking Out.................................................................78
Figure 87: Ceiling........................................................................................................................................79
Figure 88: Ramp Support............................................................................................................................80
Figure 89: Bolt Cover..................................................................................................................................80
Figure 90: Ramp Assembly.........................................................................................................................81
Figure 91: Floor Center Panel .....................................................................................................................82
Figure 92: Floor Side Panel.........................................................................................................................83
Figure 93: Cover Fitting to Eliminate Gaps ................................................................................................83
Figure 94: Power Input Receptacle .............................................................................................................84
Figure 95: Field Service Tool Connect Page...............................................................................................87
Figure 96: Field Service Tool Testing, Diagnostics....................................................................................87
Figure 97: SVDiagnostics............................................................................................................................88
Figure 98: Calibration Window...................................................................................................................88
Figure 99: Pre-cal and VCO Cal .................................................................................................................89
Figure 100: Pre-cal and VCO Cal ...............................................................................................................90
Figure 101: Using Template to the Locate Foam Block .............................................................................93
Figure 102: End Cap Measurements ...........................................................................................................94
Figure 103: Foam Block..............................................................................................................................95
Figure 104: Foam Block Placement ............................................................................................................95
Figure 105: Barcode Label Above Block....................................................................................................96
Figure 106: Top Down View.......................................................................................................................96
Figure 107: Fiberglass Panel Removal........................................................................................................98
Figure 108: Clean Area with Wipe..............................................................................................................99
Figure 109: Clean Surface........................................................................................................................100
Figure 110: Apply Tape Strip....................................................................................................................100
Figure 111: Peel Paper Off........................................................................................................................101
Figure 112: Line Up Plate.........................................................................................................................101
Figure 113: Plate Alignment .....................................................................................................................102
Figure 114: End Cap Alignment...............................................................................................................102
Figure 115: Labeling for Bottom Power Entry..........................................................................................104
Figure 116: Labeling for Top Power Entry...............................................................................................105
Figure 117: Label position for Entrance/Exit Panel on Motor End..........................................................105
Figure 118: Barrier Belt.............................................................................................................................107
Figure 119: Receiver End..........................................................................................................................107
Figure 120: Belt End .................................................................................................................................108
Figure 121: Monitor Attached With Support Post.....................................................................................108
Figure 122: Monitor Mount Disassembly .................................................................................................109
Figure 123: Install Thumb Screws ............................................................................................................109
Figure 124. Monitor Support Post Assembly............................................................................................110
Figure 125: Monitor Attached With Fixed Riser.......................................................................................111
Figure 126: Screws and Spacers Installed.................................................................................................112
Figure 127: Riser Installed ........................................................................................................................112

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 8 of 119
© 2020 Leidos. All rights reserved
Disclaimer
Leidos Security Detection & Automation, Inc., (“Leidos SD&A”), has made all reasonable efforts to ensure the
information in this manual is accurate and complete. Leidos Security Detection & Automation shall not be held
liable for any technical or editorial errors or omissions contained herein, or for incidental, special, or consequential
damages concerning the furnishing or use of this manual. The information contained in this manual is subject to
change without notice. Any comments or proposed changes should be submitted, in writing, to Leidos Security
Detection & Automation, Inc. to the attention of Documentation Control, Document Comments.
Proprietary Information Notice
This manual contains proprietary information that is protected by copyright, and all rights are reserved. No portion
of this document may be copied, photocopied, reproduced by any means, or translated into another language without
the prior written consent of Leidos Security Detection & Automation, Inc.
Copyright Notice
Copyright © 2021 by Leidos Security Detection & Automation, Inc. All rights reserved. United States copyright
laws and international treaty provisions protect this document. It may not be reproduced or transmitted
electronically for the purpose of reproduction, either in whole or in part, without the prior, express, and written
consent of Leidos Security Detection & Automation, Inc.
Trademark
ProVision® is a registered trademark of Leidos Security Detection & Automation, Inc., in the United States and/or
other countries.
Classified Information Notice
For security reasons, the U.S. Federal Aviation Administration (FAA) and the U.K. Department for Transport (DfT)
have classified much of the information and data pertaining to the performance criteria, test results, and technical
aspects of Explosive Detection Systems. If additional information is required that is not part of Leidos Security
Detection & Automation proprietary documentation packages, qualified representatives of foreign governments and
aviation agencies should specifically request the information on letterhead. Leidos Security Detection & Automation
will make every effort to provide qualified individuals with detailed information in a manner consistent with the
Classifications Guide for FAA Explosive Detection Systems Information and Data in effect at the time of the
request. Contact Leidos Security Detection & Automation Customer Support for additional information.
Safety Disclaimer
Equipment that is used in a manner NOT specified by Leidos Security Detection & Automation may reduce any
protection provided by the system.
Warranty Disclaimer
Leidos Security Detection & Automation does not warrant that the operation of the Leidos Security Detection &
Automation products will be uninterrupted, error-free, or secure, that the Leidos Security Detection & Automation
products will comply with any rules or regulations applicable to the activities in which customers may employ the
Leidos Security Detection & Automation products, or that the Leidos Security Detection & Automation products
will operate to detect prohibited objects in all circumstances. You acknowledge that the real-world performance of
the Leidos Security Detection & Automation products may vary depending on your deployment, operation, and
application of the Leidos Security Detection & Automation product.

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 9 of 119
© 2020 Leidos. All rights reserved
Software License Agreement (Embedded Products)
You have acquired a device (“DEVICE”) that includes software licensed by Leidos Security Detection &
Automation from Microsoft Licensing Inc. or its affiliates (“MS”). Those installed software products of MS origin,
as well as associated media, printed materials, and “online” or electronic documentation (“SOFTWARE”) are
protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights
reserved.
IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO NOT USE THIS
DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT LEIDOS SECURITY DETECTION
& AUTOMATION FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND.
ANY USE OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL
CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS
CONSENT).
GRANT OF SOFTWARE LICENSE: This EULA grants you the following license:
You may use the SOFTWARE only on the DEVICE.
NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT.
NO WARRANTIES FOR THE SOFTWARE. The SOFTWARE is provided “AS IS” and with all faults. The
entire risk as to satisfactory quality, performance, accuracy, and effort (including lack of negligence) is with you.
Also, there is no warranty against interference with your enjoyment of the SOFTWARE or against infringement. If
you have received any warranties regarding the device or the SOFTWARE, those warranties do not originate from,
and are not binding on, MS.
Java Support
Note on Java Support. The SOFTWARE may contain support for programs written in Java. Java technology is not
fault tolerant and is not designed, manufactured, or intended for use or resale as online control equipment in
hazardous environments requiring fail-safe performance, such as in the operation of nuclear facilities, aircraft
navigation or communication systems, air traffic control, direct life support machines, or weapons systems, in which
the failure of Java technology could lead directly to death, personal injury, or severe physical or environmental
damage. Sun Microsystems, Inc. has contractually obligated MS to make this disclaimer.
Liabilities and Restrictions
No Liability for Certain Damages. EXCEPT AS PROHIBITED BY LAW, MS SHALL HAVE NO LIABILITY
FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM OR IN
CONNECTION WITH THE USE OR PERFORMANCE OF THE SOFTWARE. THIS LIMITATION SHALL
APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. IN NO EVENT SHALL MS BE
LIABLE FOR ANY AMOUNT IN EXCESS OF U.S. TWO HUNDRED FIFTY DOLLARS (U.S. $250.00).
Limitations on Reverse Engineering, Decompilation, and Disassembly. You may not reverse engineer,
decompile, or disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted
by applicable law notwithstanding this limitation.
SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS. You may permanently transfer rights
under this EULA only as part of a permanent sale or transfer of the Device, and only if the recipient agrees to this
EULA. If the SOFTWARE is an upgrade, any transfer must also include all prior versions of the SOFTWARE.
EXPORT RESTRICTIONS. You acknowledge that the SOFTWARE is of U.S. origin. You agree to comply with
all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export
Administration Regulations, as well as end-user, end-use, and country destination restrictions issued by U.S. and
other governments. For additional information on exporting the SOFTWARE, see
http://www.microsoft.com/exporting.

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 10 of 119
© 2020 Leidos. All rights reserved
FCC Compliance
Federal Communications Commission Radio Frequency Interference Statement
FCC Compliance Federal Communications Commission Radio Frequency Interference Statement This
equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at their own expense. MODIFICATIONS: System modifications or component
changes not expressly approved by Leidos Security Detection & Automation could void the user's
authority to operate the equipment under FCC regulations. SHIELDED CABLES: In order to meet FCC
requirements, only the cabling provided by or approved by Leidos Security Detection & Automation may
be used for system interconnects.
FCC Waiver Conditions
Accordingly, pursuant to the delegated authority in Sections 0.31 and 0.241 of the Commission's rules,
FCC waives the requirements of Sections 15.31(c), 15.35(b) and Section 15.205(a) of FCC rules to permit
the certification and marketing of the Next Gen ProVision device. This waiver is subject to the following
conditions:
All installations of the ProVision System imaging devices operated under this waiver shall be
restricted to indoor use only.
Leidos shall inform purchasers that ProVision (PV3) System imaging devices may not be resold
to third parties for use at another installation in the United States unless appropriate arrangements
are made to meet all of the conditions of this waiver.
This waiver shall apply to the Provision (PV3) System described herein will not have any major
changes made to the transmitter circuitry or to the transmitter housing and position of the antenna
masts within the system that would increase the devices radiated power or bandwidth.
Leidos shall coordinate operation of its Provision (PV3) System imaging devices with any radio
astronomy facilities within 50 kilometers that receive signals in the 20-40 GHz band, and shall
coordinate any installation which is within line of sight of the observatory at Kitt Peak.

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 11 of 119
© 2020 Leidos. All rights reserved
Contact Information
Mailing Address
Telephone
FAX
North America
Leidos Security Detection & Automation,
Inc.
490 First Avenue South
St. Petersburg, FL 33701 USA
727-556-0270
727-556-0271
[e-mail]/
https://www.leidos.com/security-
detection
Leidos Security Detection & Automation,
Inc.
1 Radcliff Road
Tewksbury, MA 01876 USA
781-939-3800
781-939-3996
[e-mail]/
https://www.leidos.com/security-
detection
Latin America
Leidos Security Detection & Automation,
Inc.
1 Radcliff Road
Tewksbury, MA 01876 USA
781-939-3800
781-939-3996
[e-mail]/
https://www.leidos.com/security-
detection
Europe/MiddleEast/Africa (EMEA)
Leidos Security Detection & Automation
U.K. Ltd
Bedford Link Logistic Park
Kempston, Bedfordshire
United Kingdom
MK43 9SS
44 (0) 1234
413060
N/A
[e-mail]/
https://www.leidos.com/security-
detection
Asia and Pacific
Leidos Security Detection & Automation,
Inc. Singapore Pte Ltd
300 Tampines Ave 5
#05-04 Tampines Junction
Singapore 529653
65.6787.0118
65 6787 1127
[e-mail]/
https://www.leidos.com/security-
detection
Leidos Security Detection & Automation,
Inc. Hong Kong Ltd
Unit 2308, Nanyang Plaza
No 57 Hung To Road
Kwun Tong, Kowloon, Hong Kong
852 2587 1777
852 2587 1177
[e-mail]/
https://www.leidos.com/security-
detection
Leidos Security Detection & Automation,
Inc. Australia Pty Ltd
Unit 6
435 Williamstown Road
Port Melbourne, Victoria 3207, Australia
61.3.8645.4500
61.3.8645.4555
[e-mail]/
https://www.leidos.com/security-
detection

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 12 of 119
© 2020 Leidos. All rights reserved
1.0 Introduction
This manual details the installation steps for the ProVision®3 scanner, Model 1000-10002-PV.
1.1 Relevant Procedures
The following procedures are referenced in this installation manual and might be required to complete
movement or installation of certain components of the ProVision 3 scanner:
Document Title
Document No.
ProVision 2 Technical Manual
8100-23121-TM
ProVision 2 Installation Specification
8100-20571-00
ProVision 2 Isolation Footpad Procedure
8000-22070-IP
ProVision 2 Seismic Bracket Kit Installation
Procedure
8000-22056-IP
ProVision 2 Top Down Power Procedure
8600-28515-IP
ProVision 2 IP Router Installation Procedure
8000-23712-IP
ProVison 2 Remote OCP Installation Procedure
8000-27088-IP
ProVision 2 Belt Barrier and OCP
8000-21314-IP
ProVision 2 Power Panel Label Installation Procedure
8600-23942-IP
ProVision 2 System Mount Resolution Station
8600-26545-IP
1.2 Minimum Technical Qualifications
This manual assumes you are factory-trained by Leidos customer support personnel in the installation,
operation, maintenance and repair of the ProVision 3 scanner. It also assumes you have the following
minimum technical qualifications:
Associate’s Degree in Electronics, or 5 years of related job experience.
Full working knowledge of PC-type computer systems, using the Windows operating system.
Good working knowledge of complex digital and analog circuitry.
Some knowledge of complex mechanical systems.
Thorough familiarity with the use of test equipment, especially a DVM and oscilloscope.
1.3 Contacting Customer Support
As a qualified service technician, you are encouraged to contact Leidos Security Detection & Automation
customer support if you have any technical questions or require any additional information. It is Leidos
Security Detection & Automation In.’s responsibility to help you solve our customers’ problems as
professionally, efficiently, and safely as possible.
Do not spend an excessive amount of time troubleshooting unusually difficult or previously unknown
problems. If, after a few hours of professional, systematic troubleshooting techniques, you still cannot
locate the cause of the problem, contact Leidos customer support.

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 13 of 119
© 2020 Leidos. All rights reserved
The sole job of customer support is to help you serve customers. Be sure to have your specific problem
and the troubleshooting methods you have employed documented and the installation site information
available, especially the scanner location and serial number.
The U.S. Customer Support staff can be reached Monday through Friday, excluding company holidays,
from 9:00 AM to 5:00 PM EST / EDT (14:00 to 22:00 UT). Refer to Contact Information in this manual
for more information. After normal business hours, a voicemail system will automatically answer. After
the announcement, leave your name, return phone or FAX number and a brief message. An L-3 Security
& Detection Systems Customer Support representative will return your call as soon as possible.
Our U.K.-based Customer Support staff can be reached Monday through Friday, excluding company
holidays, from 9:00 AM to 5:00 PM UT. Refer to Contact Information in this manual for more
information. After normal business hours, a voicemail system will automatically answer. After the
announcement, leave your name, return phone or FAX number and a brief message. A Leidos Security
Detection & Automation Systems customer support representative will return your call as soon as
possible.
Asia-Pacific Customer Support can be reached Monday through Friday, excluding company holidays,
from 9:00 AM to 5:00 PM Local Time (UT + 8). Refer to Contact Information in this manual for more
information. After normal business hours, a voicemail system will automatically answer. After the
announcement, leave your name, return phone or FAX number and a brief message. A Leidos Security
Detection & Automation Systems customer support representative will return your call as soon as
possible.

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 14 of 119
© 2020 Leidos. All rights reserved
2.0 Safety
The ProVision 3 scanner is designed for safe operation under a wide range of operating conditions. The
scanner uses a rotating swing arm/antenna structure to inspect for contraband items. As with all such
equipment, certain potential hazards exist if the scanner is operated improperly. The potential for injury
from mechanical trauma or electrical shock can be avoided through proper use of the scanner.
If the equipment is used in a manner not specified by the manufacturer, the protection provided by the
equipment may be impaired. Repair technicians must be properly trained and certified in the operation,
installation and maintenance/repair of the ProVision 3 scanner.
2.1 Electrical Safety Precautions
High voltages and electrical currents are present inside the equipment. Contact with these parts can cause
severe injury or death. Follow proper electrical safety precautions when working on the equipment.
As with any electrical equipment not designed for outdoor use, the scanner should not be operated after
being exposed to rain or standing water. If the scanner is exposed to water for any reason, an authorized
service engineer should check it prior to operation.
Line Voltages
The scanner can be operated on line voltages from 100 to 120 VAC at 50 Hz or 60 Hz and 220 to
240 VAC at 50 Hz or 60 Hz. Caution should be exercised when working at the main power input.
Always be sure the scanner is properly grounded. This system must be grounded (earthed) by a 3-wire
power cord at all times. Any replacement of the power cord must be conducted by a qualified service
person, and the same plug configuration must be utilized.
Voltage and High Current
Hazardous voltages and high current are used throughout the ProVision 3 scanner. Use caution when
performing maintenance in all areas.
Figure 1: Hazardous Voltage and High Current Labels

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 15 of 119
© 2020 Leidos. All rights reserved
2.2 Lockout/Tagout Requirements and Procedure
Lockout/tagout is applicable to all personnel, including contractors, involved with repairing, servicing,
cleaning, routine maintenance, troubleshooting, inspection, testing, modification, installation, and
disassembly of Leidos systems.
Refer to the Lockout Tagout Work Instruction (8400-10708-WI) for details on the Lockout Tagout
procedures.
Lockout/tagout procedures shall be used in all situations where unexpected startup, moving parts (mast,
motor, and belt) or release of stored energy could result in injury.
During activities described above, all Leidos personnel shall perform the following steps in performing a
lockout/tagout procedure:
1. Notification: Notify all affected and other employees that installation, service, or maintenance is
required on a system and that the system power must be shut down and locked out to prevent injury
from accidental re-start. This includes bagroom, baggage handling station, and checkpoint personnel;
contractors; and other Leidos employees.
2. Preparation for Shutdown: The authorized employee must be knowledgeable of the energy source and
its hazards. The employee must locate the main power cord for the system and follow shut-off
procedures outlined in this manual.
3. Shutdown/Isolation: Turn system off and unplug power cord.
4. Lockout/Tagout: Secure power cord at machine and apply Plug Lockout box (Grainger Item 5TB29
or equivalent). Fasten lock and tag to Plug Lockout box. Tag must indicate the name of the
authorized employee, and the reason and expected duration or date of the lockout.
5. Verification of Isolation of Equipment: Ensure that the equipment is disconnected from the energy
source by first checking that no personnel are exposed, then verify the isolation of the equipment by
operating the push button, switch or other normal operating control(s) or by testing to make certain
the equipment will not operate.
6. EQUIPMENT IS NOW LOCKED OUT: The lock and tag shall not be removed until all work
requiring lockout/tagout is completed.
2.3 Mechanical Safety Precautions
Mast Antenna
The ProVision 3 scanner has two antenna mast assemblies attached to a rotating swing arm that is belt-
driven by a motor. Contact with these moving parts can cause severe injury. Do not service any moving
part with power applied; always unplug the scanner and use the lockout/tagout procedure (see Section
2.2).
Belt Drive
The ProVision 3 scanner employs a motor-driven belt to move the two antenna masts mounted on the
swing arm. Pinch point labels (shown in the following figure) are used to identify the moving equipment
areas. Use caution not to get entrapped or pinched in these areas.

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 16 of 119
© 2020 Leidos. All rights reserved
Figure 2: Belt-Drive Safety Labels
2.4 Toxic Safety Precautions
The consumable materials listed below are toxic to the skin, eyes, and respiratory tract. Good hygiene
practice is recommended; wash your hands thoroughly after leaving your work area. Wear nitrile gloves
and safety glasses when handling the consumable materials:
Isopropyl alcohol
Electrostatic discharge (ESD) wipes [490-26003]
Material safety data sheets are available. Consult your local safety and health staff concerning any
questions about toxic hazards.
2.5 Fire Safety Precaution
In the event of a fire, a Halon fire extinguisher or comparable type is recommended to extinguish any fire
inside the ProVision 3 scanner. Any ABC dry chemical fire extinguisher can be used; however, it may
cause additional damage to the equipment.
2.6 Safety Features
The ProVision 3 scanner is specifically designed to prevent injury during operation or maintenance
procedures. Injury can be avoided by using the electrical power switch to remove power from the
scanner, as discussed in the following paragraph.
The power switch, located at either the lower left or upper right of the outer radome with the posing figure
(see following figure), removes all electrical power from the ProVision 3 scanner. In case of an electrical
emergency:
1. Press the portion of the power switch labeled “O”to remove all power from the scanner.
2. Unplug the power cord from the electrical outlet.
Figure 3: Electrical Power Switch (Two Options)

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 17 of 119
© 2020 Leidos. All rights reserved
3.0 Tools List
3.1 Tools in Installation Kit
Reference the installation kit packing list for the materials included.
3.2 Additional Tools
In addition to the tools included in the installation kit, the following tools are required (Tables 2 and 3) or
optional (Table 3).
Table 1: Required Installation Tools
Quantity
Description
1
Cutter, wire, diagonal, cushion grip, 5-5/8" long
1
Screwdriver, slotted, 3/8" blade, 10.75" long
1
Screwdriver, Phillips, (#2), 8" long
1
Screwdriver, ratcheting, insert bit, 1/4" hex bits
1
Extension, 3/8" drive, 6" overall length
1
Wrench, adjustable, 8"
1
Knife, utility
1
Miniature flashlight
1
Multi-meter (digital recommended)
1
Ratchet, 3/8" drive
1
1/2" to 3/8" drive adapter
1
3/8" to 1/2" drive adapter
1
10mm wrench (reversible ratcheting optional)
1
13mm wrench (reversible ratcheting optional)
1
15mm wrench (reversible ratcheting optional)
1
19mm wrench (reversible ratcheting optional)
1
24mm wrench (reversible ratcheting optional)
1
Socket, square drive, 10mm, standard, 3/8" drive
1
Socket, square drive, 13mm, standard, 3/8" drive
1
Socket, square drive, 15mm, standard, 3/8" drive
1
Socket, square drive, 19mm, standard, 3/8" drive
1
Socket, square drive, 24mm, standard, 3/8" drive
1
Hex key set, 6 Keys, 2mm-6mm

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 18 of 119
© 2020 Leidos. All rights reserved
Quantity
Description
1
1.5mm hex key
1
10mm hex key
1
Hex Bits Set
1
Torque wrench, 3/8" square drive, 30–250 in-lb / 3.4–28.2 Nm
1
Torque wrench, 1/2" drive, 20–150 ft-lb / 27.1–203.4 Nm
1
3/8” impact socket
1
7/16” impact socket
1
9/16” impact socket
Table 2: Required Troubleshooting/Service Tools
Quantity
Description
1
Field service laptop
1
Long-nose electrical pliers
1
Locking pliers 130mm
1
Torque wrench, 5/16"
1
Ratchet, 1/4" drive
1
Screwdriver, slotted, narrow blade, 3mm tip width, 150mm long
Table 3: Optional Tools
Quantity
Description
1
Drill, driver, cordless, 14.4V, heavy duty, 1/2" (13mm) chuck, with charger and two
batteries
1
Square drive socket universal joint, 3/8" drive
1
Adapter, 1/4" hex to 3/8"square drive male, 2" length

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 19 of 119
© 2020 Leidos. All rights reserved
4.0 Crate Unpacking
4.1 General Guidelines
The area should be large enough to unpack and set aside the contents of the two crates until needed. The
installation kit arrives in one crate, and the scanner is in the second, larger crate:
Installation Kit Crate
Hardware kit, genie lifts, brackets, casters, ramps, calibration aids required to move and install the
ProVision 3 scanner (including additional brackets and hardware necessary to install other Leidos
products but not needed for the ProVision 3).
Scanner Crate
Upper/lower frame assembly with shipping legs (4) and power input box/cables attached
Columns (2 left and 2 right)
Column head clamps (4)
Bolt-on side frames (2)
Outer windows (1 plain and 1 with stance or two plain)
Outer windows angle brackets (2 top and 2 bottom)
Outer windows bracket supports (4)
Outer windows bracket retainers (4)
Inner radomes (2)
Inner radome top angle rails (2)
Inner radome base flange support brackets (2)
Inner radome edge support brackets (4)
Antenna masts (2)
Cosmetic mast wrap (2)
Entrance/exit covers (2 left and 2 right)
Middle OCP cover
Plain middle cover
Middle belt barrier covers (2)
Upper/lower cover with switch/power input w/ cover plate
Plain upper/lower covers (3)
Ceiling panel
Roof
Top side covers (2)
Top entrance/exit covers (2)
Middle cover brace brackets (12)
Housing brace brackets (2)
Floor cover trim pieces (2)
Floor side panels (2) and center panel
Entrance/exit ramp assemblies (2)

ProVision 3 Installation Manual
8100-35521-00
Rev. A1
Leidos Security Detection & Automation, Inc. –Proprietary Page 20 of 119
© 2020 Leidos. All rights reserved
Entrance/exit ramp supports (2)
OCP mounting brackets (3)
Operator control panel (OCP) and OCP mount pole
Belt barrier kit
Cable pass-through hole cover plate/grommet
Blank cover plate
Seismic bracket kit [optional]
Power cord
Hardware kit
