Leightronix IncodeX Stream Quick guide

END-TO-END Solutions for
Broadcast & Streaming
Installation, Configuration, and Operation Instructions
PRODUCT MANUAL

©2018 LEIGHTRONIX, INC. All rights reserved.
The information in this manual is subject to change without notice.
IncodeX Stream and VieBit are trademarks of LEIGHTRONIX, INC.
LEIGHTRONIX, INC.
1125 N. Cedar Rd
Mason, MI 48854
Phone: [phone] or [phone]
Fax: [phone]
www.leightronix.com
Support
At LEIGHTRONIX, every customer gets free support for the life of their
product, at no extra charge. There are no service contracts, no annual
renewals, no allowances, no deductibles, and no exclusions.
In addition to a 5 year hardware warranty, benets include access to:
• Priority Toll-Free telephone support
• Email Support
• Online support, desktop to desktop via Webex®
• Software updates
• Firmware updates
• Assistance with updates
Phone: [phone]
Email: [email protected]

Table of Contents
PACKING LIST ................................................................................................................................ 1
REQUIREMENTS............................................................................................................................. 1
IMPORTANT SAFETY INSTRUCTIONS ......................................................................................... 1
FRONT PANEL ................................................................................................................................ 2
BACK PANEL .................................................................................................................................. 2
Connectors ...................................................................................................................... 2
On/Off Switch .................................................................................................................. 2
SETTING UP THE INCODEX STREAM .......................................................................................... 3
1. Install it. ....................................................................................................................... 3
2. Plug it in....................................................................................................................... 3
3. Congure Your Network Settings................................................................................. 4
Automatic Network Conguration ........................................................................................... 4
Manual Network Conguration ............................................................................................... 4
4. Congure Your Firewall. .............................................................................................. 6
UPDATING/CHANGING INCODEX STREAM SYSTEM SETTINGS .............................................. 7
Specify Audio/Video Input and Encoding Settings........................................................... 7
Change Network Settings................................................................................................ 8
Obtain UDP Port Number................................................................................................ 8
Update Firmware............................................................................................................. 8
SPECIFICATIONS.......................................................................................................................... 10
PRODUCT WARRANTY ................................................................................................................ 12
DECLARATION OF STANDARDS CONFORMITY ....................................................................... 12
TABLE OF CONTENTS

2018-05-18 Page 1
IncodeX Stream
HD/SD Live Streaming Encoder
Thank you for purchasing the IncodeX Stream HD/SD live streaming encoder. The IncodeX Stream™
live streaming encoder combined with the subscription-based VieBit™ streaming service allows you
to create your own affordable, high quality live streaming channel.
The IncodeX Stream encoder captures a live video/audio signal from a LEIGHTRONIX server or other
video source and converts the signal into an outbound, HD or SD H.264 digital video stream. The
outbound stream is directed to the VieBit streaming service’s web servers and then simultaneously
distributed to local and worldwide viewers.
(1) IncodeX Stream HD/SD Live Streaming Encoder
(1) IncodeX Stream HD/SD Live Streaming Encoder Manual
(1) VieBit Streaming Solutions Manual
(1) Part #10-0311, AC Power Cord, 6 ft.
(1) Part #10-4856, CAT 5e Ethernet Cable, 7 ft.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the grounding-type plug. A grounding-type plug has two blades and a third grounding
prong. The third prong is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. When the apparatus is turned off, certain components in the power supply and system board remain energized. In order to
remove all electrical power from the apparatus, unplug the power cord from the MAINS socket outlet.
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
This apparatus must be connected to a MAINS socket outlet with a protective earthing
connection.
IMPORTANT SAFETY INSTRUCTIONS
PACKING LIST
REQUIREMENTS
• VieBit streaming service annual subscription
• Sustained outbound/upload bandwidth for transferring live stream to the Internet should roughly total the selected
video bit rate plus the audio bit rate plus 64 kb/s for overhead
• See “Table 1, Firewall Port Numbers Needed for Streaming” on page 6 for port numbers that need to be
opened between the IncodeX Stream encoder and domain names/IP addresses specied in the table

Page 2 2018-05-18
IncodeX Stream
HD/SD Live Streaming Encoder
The IncodeX Stream front panel indicators provide status on your encoder’s power connectivity and encoding activity.
The red “Power” indicator lights up when your IncodeX Stream is connected to a power source and turned on. The
green “Active” light turns on when the IncodeX Stream is encoding.
A: 1 BNC HD/SD-SDI video input connector
B: 1 BNC composite video input connector
C: 2 RCA audio input connectors (left & right)
D: 1 RJ-45, 10/100 BASE-T Ethernet port with LED
status indicators
E: On/Off switch
F: Power cord connector
FRONT PANEL
BACK PANEL
Connectors
The IncodeX Stream back panel, includes, from left to right, top to bottom:
On/Off Switch
To turn on power to the IncodeX Stream, press the “–” symbol on the switch upward. The IncodeX Stream starts to en-
code when it is powered on. To turn off the IncodeX Stream, press the “o” symbol on the switch downward.
ABC D E F

2018-05-18 Page 3
IncodeX Stream
HD/SD Live Streaming Encoder
1. Install it.
The IncodeX Stream encoder may be left as a standalone, tabletop unit or mounted into a rack as follows:
a. Insert the IncodeX Stream into the rack, aligning the holes of the unit’s mounting bracket with those of the rack.
b. Secure the IncodeX Stream to the rack with user-supplied rack screws.
2. Plug it in.
Using a straight-through RJ-45 Ethernet cable,
connect the IncodeX Stream Ethernet port
directly to a cable or DSL modem or to a 10/100
BASE-T switch on your TCP/IP network. To
check your network connection, look at the Eth-
ernet LEDs above the Ethernet port and com-
pare to the table at left.
IncodeX Stream Ethernet LED Indicators
LED Position State Description
Left Off Connection speed is 10Mb/s
Blinking amber Connection speed is 100Mb/s
Right Off Ethernet link not established
Steady on green Ethernet link established.
Attach your network, power, and signal wiring to the IncodeX Stream according to the instructions below:
Connect the included power cable to the
power cord connector and then plug the
other end into an AC power source.
SETTING UP THE INCODEX STREAM
Leave empty rack spaces above and below the IncodeX Stream. The
IncodeX Stream should not have anything stacked on top of it.
If using, connect your
analog audio source to
the audio inputs.
LEIGHTRONIX strongly recommends the use of an uninterruptible power supply (UPS) with the IncodeX
Stream. Damage from power loss or spikes is not covered under warranty.
Once the IncodeX Stream encoder is installed, wired, and congured with network settings accord-
ing to the steps in this section, the encoder will automatically start converting the incoming video/
audio input signal into an H.264 video stream. As long as the IncodeX Stream is powered on and
has a connected video input, the encoder will continually output a video stream.
NOTE: For optimal performance, use a dedicated,
DSL Internet business connection with your
IncodeX Stream.
If using an analog video source,
connect your source to the com-
posite video input.
If using a digital video
source, connect your source
to the SDI video input.

Page 4 2018-05-18
IncodeX Stream
HD/SD Live Streaming Encoder
3. Congure Your Network Settings.
Automatic Network Conguration
The IncodeX Stream is shipped Dynamic Host Conguration Protocol (DHCP) enabled, meaning that if your network
uses a DHCP server, your encoder will automatically obtain an IP, subnet mask, and gateway address when it is con-
nected to a power source and your network. Skip to Step 4 on page 6.
NOTE: To quickly check if your network is connected to a DHCP server, go to a computer connected to your network
and see if it has been set to use DHCP.
Manual Network Conguration
If your network does not use a DHCP server, you will need to obtain a static IP, subnet mask, and gateway address for
your IncodeX Stream from your network administrator and then replace your IncodeX Stream’s default static network
addresses as follows:
a. Connect your IncodeX Stream’s Ethernet port to the Ethernet port on a laptop or PC with an Ethernet cable.
b. Change the IP address of your computer to a static 10.xx.xx.xx IP address that does not match the default static
IP address of your IncodeX Stream, 10.11.31.2. A good rule of thumb is to just add one to the last value in the
IncodeX Stream’s default static IP address, so you would use “10.11.31.3.”
c. Access the IncodeX Stream’s browser-based interface as follows:
i. Open an Internet browser on the computer connected to your IncodeX Stream.
ii. In the URL address line, enter the IncodeX Stream’s default static IP address, 10.11.31.2, and press enter.
You will be prompted to enter a username and password (see Illustration 1).
Illustration 1, IncodeX Stream Interface Login Box

2018-05-18 Page 5
IncodeX Stream
HD/SD Live Streaming Encoder
iii. In lowercase, enter “admin” into the “User name” eld and ”stream” as the password. Click “Ok” to open the
IncodeX Stream interface in your Internet browser window (see Illustration 2).
iv. Stop the IncodeX Stream from encoding by clicking “Stop Encoder.”
v. Select the “Static” mode from the rst “Network Settings” drop down eld.
vi. Enter the IP, subnet mask, and gateway addresses you have obtained from your network administrator into the
corresponding elds.
NOTE: Be sure to write down your static IP address in a known location so that it is available if needed, as this
information will be needed to access your IncodeX Stream’s interface in the future.
vii. When you have nished entering in your network settings, click the “Apply Settings” button. Your IncodeX
Stream will automatically reboot to apply the network address changes. The IncodeX Stream will resume encod-
ing once it restarts.
viii. Detach the IncodeX Stream’s Ethernet port from your computer or laptop and then connect the encoder to your
network.
Illustration 2, IncodeX Stream Interface

Page 6 2018-05-18
IncodeX Stream
HD/SD Live Streaming Encoder
4. Congure Your Firewall.
In order for the VieBit service to receive a video stream from your IncodeX Stream, open the rewall ports shown in
Table 1 between your IncodeX Stream’s media access control (MAC) address and the domain names and IP address
also specied in Table 1.
NOTE: Your IncodeX Stream’s MAC address is its 12 character serial number.
Table 1, Firewall Port Numbers Needed for Streaming
Port Number Port Function Domain Name/
IP Address
80 HTTP for access of your VieBit
subscription information license.leightronix.com
53 DNS for domain name resolution 67.227.136.122
123 NTP for clock synchronization between the
IncodeX Stream and VieBit servers time.leightronix.com
Check the IncodeX Stream’s web
interface for the specic port number
your encoder is using (see “Obtain
UDP Port Number” on page 8) or
open on all ports
UDP for the delivery of the IncodeX Stream’s
video stream to the VieBit servers harbor.pegstream.com

2018-05-18 Page 7
IncodeX Stream
HD/SD Live Streaming Encoder
UPDATING/CHANGING INCODEX STREAM SYSTEM SETTINGS
Flexible and convenient, the IncodeX Stream includes a browser-based interface that allows you to change your system
settings and perform rmware updates.
To access the IncodeX Stream browser-based interface, perform the following:
1. You will need your IncodeX Stream’s IP address to access the encoder’s browser-based interface. If you are not sure
what your IncodeX Stream’s IP address is, you can obtain it using the set of steps below that correspond to your
network setup:
• DHCP Mode: if your IncodeX Stream automatically gets its network addresses from a DHCP server on your net-
work, you will need to install a third party program such as “Fast Resolver” on a PC connected to the same net-
work and scan for your IncodeX Stream’s MAC address. The IncodeX Stream’s MAC address is the same as its
serial number, which is identied on a sticker on the encoder’s back panel. Once the program nds your IncodeX
Stream, it will provide you with the encoder’s IP address. DHCP assigned network addresses do expire, so you
may need to re-scan your network for your IncodeX Stream the next time you need to access the encoder’s inter-
face.
• Static Mode: if your network does not use a DHCP server, use the IP address assigned by your network adminis-
trator to your IncodeX Stream to access the encoder’s interface. If your IncodeX Stream has not yet been con-
gured with the static addresses for your network, perform the steps in “Manual Network Conguration” on page
4.
2. Open an Internet browser on a computer connected to the same network as your IncodeX Stream.
3. In the URL address line, enter your IncodeX Stream’s IP address and press enter. You will be prompted to enter a
username and password.
4. Enter “admin” into the “User name” eld and “stream” as the password. Click “Ok” to open the IncodeX Stream inter-
face in your Internet browser window.
5. Once you are logged in, you may perform the steps in any of the following subsections.
Specify Audio/Video Input and Encoding Settings
Digital video encoding results are based on a combination of the encoding bit rate and the quality of the input source.
Video being fed to the encoder must have stable sync.
• Input Settings
The IncodeX Stream will accept either composite video with analog audio or HD/SD-SDI video with embedded or
analog audio. Along with connecting your video/audio sources to the correct inputs on the IncodeX Stream’s back
panel, you will also need to tell the IncodeX Stream which back panel input(s) to use during encoding as follows:
1. Stop the IncodeX Stream from encoding by clicking “Stop Encoder.”
2. Choose either “Composite” or “SDI” from the “Video Source” drop down menu to specify the type of video input
signal you will be encoding.
3. Use the “Audio Source” drop down menu to specify your audio encode source as follows:
► If your setup uses the composite video input, the audio selection cannot be changed from “Analog Stereo.”
► If you are choosing to encode a source connected to the HD/SD-SDI video input, you may select “Analog Ste-
reo” to encode analog audio along with it or if there is audio embedded in your HD/SD-SDI video signal, select
the corresponding embedded two-channel audio pair.
4. Click the “Apply Settings” button to make the change(s).
5. Restart the IncodeX Stream encoder by clicking the “Start Encoder” button.
• Encoding Settings
The IncodeX Stream’s video encoding settings are changed within the VieBit Web interface’s control panel. Refer to
the VieBit Streaming Solutions Manual for further instructions.

Page 8 2018-05-18
IncodeX Stream
HD/SD Live Streaming Encoder
Change Network Settings
You may switch your IncodeX Stream’s network mode to either of the following:
• Static Mode: while the IncodeX Stream ships DHCP enabled, you have the option of entering in your own static
network addresses. Perform steps iv–vii on page 5.
• DHCP Mode: perform the following steps:
1. Stop the IncodeX Stream from encoding by clicking “Stop Encoder.”
2. Select the “DHCP” mode from the rst “Network Settings” drop down eld.
3. Click the “Apply Settings” button. Your IncodeX Stream will automatically reboot to apply the network mode
change. The IncodeX Stream will resume encoding once it restarts.
Obtain UDP Port Number
The “Outgoing Port#” eld shows you the VieBit service port that receives the IncodeX Stream’s video stream. This is
useful if you wish to only unblock one port on your rewall for UDP trafc between the IncodeX Stream encoder and VieBit
delivery service.
Update Firmware
Download the latest IncodeX Stream rmware le from the LEIGHTRONIX Support Center website onto your network
connected computer and install the le as follows:
1. Click the “Settings” button on the menu bar to access the IncodeX Stream’s rmware update button (see Illustration
4).
2. Click the “Update” button.
Illustration 3, IncodeX Stream Interface Settings

2018-05-18 Page 9
IncodeX Stream
HD/SD Live Streaming Encoder
Illustration 4, IncodeX Stream Firmware Update Buttons
3. Click the “Choose le” button (see Illustration 5) and navigate to the location on your computer where you saved the
IncodeX Stream rmware update le. Open the le to add it to the web interface screen and close the navigation
window.
4. Click the “Upload and Update” button (see Illustration 5). Once the rmware le has been installed on the IncodeX
Stream, the encoder will reboot.

Page 10 2018-05-18
IncodeX Stream
HD/SD Live Streaming Encoder
Dimensions 1.75”H x 19”W x 8.5”D
Weight, without carton
or cables
5lbs.
Front Panel Indicators Two light-emitting diodes (LEDs) provide status on power and encoding activity
Power Input Three-position IEC power input with removable power cord
Power Supply Internal 200W power supply with active P.F.C., which accepts 90-264VAC @ 47-
63Hz
Conguration Storage • Internal memory
• Data integrity veried
• Elements:
► IP address
► Subnet mask
► Gateway
► Video/Audio Input Settings
► User Information
Video Inputs The IncodeX Stream provides the two following video inputs:
• 1 BNC female, composite video input, terminated 75 ohms
• 1 BNC female, HD/SD-SDI video input (SMPTE 259M-C) with support for 2 chan-
nels of embedded digital audio (SMPTE 272M, audio pair selectable), terminated
75 ohms
Audio Inputs 2 RCA female, stereo audio, unbalanced, line level
Ethernet Network Host
Management
• Remote Support: Dial-Up Networking
• Network Support Interface:
► Eight-position, eight-conductor RJ-45 modular jack, 10/100 BASE-T, unshielded
twisted pair, Ethernet
► Ethernet_II frame type
► Protocol: TCP/IP
► Services: Web
Web Interface IncodeX Stream web interface provided for management of the encoder’s system
settings and rmware updates; compatible with popular web browsers, including
Chrome, Firefox, and Internet Explorer
Video Standard NTSC, high definition, 16x9 aspect ratio, and standard definition, 4x3 aspect ratio
HD Encoding H.264 High, Main, or Baseline Prole Level 4; 1080i or 720p; 1024, 1536, or 2048
kb/s bit rate encoding
SD Encoding H.264 High, Main, or Baseline Prole Level 3; 480i or 360i; 512, 768, or 1024 kb/s bit
rate encoding
Audio Encoding MPEG-1 layer II; 48 kHz audio sampling rate; 64, 128, or 192 kb/s audio bit rate
encoding
Compliance/
Certications
Certied and listed as:
• Audio, Video, and Similar Electronic Apparatus Safety Requirements ANSI/UL
60065, 7th edition
• Audio, Video, and Similar Electronic Apparatus Safety Requirements CAN/CSA
C22.2 No. 60065:03, 1st edition
In no event shall LEIGHTRONIX be liable for any damages whatsoever resulting from loss of use,
data, or prots, whether or not advised of the possibility of damage, and on any theory of liability, aris-
ing out of or in connection with the use or performance of the IncodeX Stream.
SPECIFICATIONS

2018-05-18 Page 11
IncodeX Stream
HD/SD Live Streaming Encoder
Digital Media Licensing Licensed under MPEG-LA® LL’s AVC/H.264 Patent Portfolio

Page 12 2018-05-18
IncodeX Stream
HD/SD Live Streaming Encoder
LEIGHTRONIX, INC. warrants this IncodeX Stream streaming media encoder against defective work-
manship or materials for a period of ve (5) years from the original date of purchase.
During this warranty period, any parts found to be defective will be replaced at no charge. Labor to
repair or replace defective parts will also be performed at no charge during the warranty period.
This warranty does not cover abuse, shipping damage, neglect, tampering by unauthorized person-
nel, acts of God, damage inadvertently caused by the user, preventive maintenance, or any product
whose serial number is removed or defaced.
The sole responsibility of LEIGHTRONIX shall be to repair or replace in accordance with this war-
ranty. The seller’s and manufacturer’s only obligation shall be to repair or replace such quantity of
the product proved to be defective.
The customer shall bear the cost of shipping products returned to LEIGHTRONIX for warranty repair.
The cost for return shipment to the customer will be assumed by LEIGHTRONIX and shipped via an
equal priority service shipper prepaid and insured.
Neither seller nor manufacturer shall be liable for any injury, loss or damage, direct or consequential,
arising out of the use of, or the inability to use the product. Before using, the user shall determine the
suitability of the product for his/her intended use, and user assumes all risk and liability whatsoever in
connection therewith.
The warranty and the obligations and liabilities thereunder shall replace all other warranties or guar-
antees, express or implied.
PRODUCT WARRANTY
FCC NOTICE
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful inter-
ference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference
at his own expense.
Changes or modications to this device not expressly approved by LEIGHTRONIX,
INC. could void the user’s authority to operate this device.
This equipment is intended to be installed in a controlled environment with restricted access.
DECLARATION OF STANDARDS CONFORMITY
