Leightronix LabVault-SD Quick guide

PRODUCT MANUAL
Installation, Configuration, and Operation Instructions
SPECIALIZED
Video Solutions

©2011-2018 LEIGHTRONIX, INC. All rights reserved.
The information in this manual is subject to change without notice.
NEXUS®and PEG Central®are registered trademarks of LEIGHTRONIX, INC.
LABvault-SD™, PEGcasting™, UltraNEXUS™, UltraNEXUS-SDI™, LGX-SVOD™, and ePRO-BUS™ are
trademarks of LEIGHTRONIX, INC.
LEIGHTRONIX, INC.
1125 N Cedar Rd
Mason, MI 48854
Phone: (800) 243-5589 or (517) 694-8000
Fax: (517) 694-1600
www.leightronix.com
Support
At LEIGHTRONIX, every customer of our standard product line
receives technical support at no extra charge. There are no service
contracts, no annual renewals, no allowances, no deductibles, and
no exclusions.
In addition to a 5 year hardware warranty, benets include access to:
• Priority Toll-Free telephone support
• Email Support
• Online support, desktop to desktop via Webex®
• Software updates
• Firmware updates
• Assistance with updates
Phone: (800) 243-5589
Email: [email protected]

Table of Contents
ABOUT THIS MANUAL................................................................................................................... 1
PACKING LIST ................................................................................................................................ 1
IMPORTANT SAFETY INSTRUCTIONS ......................................................................................... 2
FRONT PANEL ................................................................................................................................ 3
KEYPAD.................................................................................................................................................................... 3
LEDS......................................................................................................................................................................... 3
DISPLAY ................................................................................................................................................................... 3
BACK PANEL .................................................................................................................................. 4
ORIGINAL LABVAULT-SD BACK PANEL................................................................................................................. 4
VERSION 2 OF THE LABVAULT-SD BACK PANEL................................................................................................. 4
SYSTEM INSTALLATION................................................................................................................ 5
INSTALLING THE LABVAULT-SD ............................................................................................................................ 5
ENTERING NETWORK SETTINGS INTO LABVAULT-SD....................................................................................... 6
WEB INTERFACE............................................................................................................................ 8
OPENING AND LOGGING IN................................................................................................................................... 8
UNDERSTANDING STATUS INDICATORS ON “SYSTEM DASHBOARD” SCREEN............................................. 9
ENTERING LABVAULT-SD SETTINGS.................................................................................................................. 10
Site Name and Location ................................................................................................................................... 10
LABvault-SD System Time ............................................................................................................................... 10
Web Interface Usernames and Passwords .......................................................................................................11
ePRO-BUS Setting ........................................................................................................................................... 12
Serial Port Setting............................................................................................................................................. 12
SETTING UP FILE TRANSFER DESTINATION(S)................................................................................................ 13
NEXUS Series Server (NEXUS/UltraNEXUS/UltraNEXUS-SDI) ..................................................................... 13
LEIGHTRONIX Streaming Video-on-Demand Web Site .................................................................................. 14
LGX-SVOD Server ........................................................................................................................................... 15
Server with FTP Capabilities ............................................................................................................................ 15
RECORDING .......................................................................................................................................................... 16
Record Settings ................................................................................................................................................ 16
Recording from the Web Interface.................................................................................................................... 17
PLAYING FILES...................................................................................................................................................... 18
“MPEG Player” Left Column Controls............................................................................................................... 18
“MPEG Engine Control” Panel.......................................................................................................................... 19
MANAGING FILES ................................................................................................................................................. 20
Rename Files on Internal Hard Drive ............................................................................................................... 20
Delete Files from Internal Hard Drive/Transfer Queue ..................................................................................... 20
Manually Transfer Recorded Files.................................................................................................................... 21
Change File Transfer Destinations ................................................................................................................... 21
TABLE OF CONTENTS

CHECKING LOG FILES ......................................................................................................................................... 22
Open a Log File ................................................................................................................................................ 22
Search a Log File ............................................................................................................................................. 22
Delete a Log File .............................................................................................................................................. 23
MAINTAINING THE LABVAULT-SD........................................................................................................................ 25
Update Firmware .............................................................................................................................................. 25
Check Internal Hard Drive ................................................................................................................................ 25
Reboot/Shut Down ........................................................................................................................................... 25
CONTROL COMMANDS ............................................................................................................... 26
SPECIFICATIONS.......................................................................................................................... 31
PRODUCT WARRANTY ................................................................................................................ 33
DECLARATION OF STANDARDS CONFORMITY ....................................................................... 33
COPYRIGHT STATEMENTS ......................................................................................................... 34

LABvault-SD
About This Manual
Page 1 2018-06-08
Thank you for purchasing a LABvault-SD digital video player/recorder. With the LABvault-SD, anyone
can easily create and display industry standard MPEG-2 les with very little training. The LABvault-
SD includes a Web interface that can be used to operate the LABvault-SD’s record, playback, and
transfer features from any location while also providing administrative options for setting up le
transfer destinations, changing recording quality presets, managing les on the LABvault’s internal
hard drive, and accessing the system’s log les.
One of the most powerful features of the LABvault-SD is its ability to be controlled by a wide variety
of external sources. The most popular control interfaces include Crestron®and AMX®touch screen
technology, giving users an intuitive and simple way to record a video source, display the resulting
digital le on a connected television monitor, and then transfer the le to one or more destinations.
The LABvault-SD accommodates a variety of playback and storage destinations. For instance, users
may send les to an archive server and then later download the les to view on a PC, burn to a DVD,
or drag into an editing system timeline. Further options include sending each digital le from the
LABvault-SD to a LEIGHTRONIX NEXUS series server/controller (UltraNEXUS-SDI, UltraNEXUS, or
NEXUS) for scheduled or immediate broadcasting. The LABvault-SD can also be integrated with a
LEIGHTRONIX streaming video-on-demand application like the PEG Central Web service, with the
option to host les on the PEG Central web servers or in-house on an LGX-SVOD server.
(1) LABvault-SD Digital Player/Recorder
(1) Product Resource Disc, Including LABvault-SD Manual
(1) Part #10-0311, AC Power Cord, 6 ft.
(1) Part #10-4856, CAT 5e Ethernet Cable, 7 ft.
PACKING LIST
ABOUT THIS MANUAL
This manual describes how to install your LABvault-SD as well as use the included LABvault-SD
Web interface to set up and control the player/recorder. Instructions on using a touch screen or other
external control system with the LABvault-SD should be obtained from the third party provider. Refer
to the “CONTROL COMMANDS” on page 26 of this manual for a list of the commands needed to
program your external control system.

Page 2 2018-06-08
LABvault-SD
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the grounding-type plug. A grounding-type plug has two blades and a third grounding
prong. The third prong is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. When the apparatus is turned off, certain components in the power supply and system board remain energized. In order to
remove all electrical power from the apparatus, unplug the power cord from the MAINS socket outlet.
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
This apparatus must be connected to a MAINS socket outlet with a protective earthing
connection.
IMPORTANT SAFETY INSTRUCTIONS

LABvault-SD
Front Panel
Page 3 2018-06-08
KEYPAD
The four LABvault-SD arrow keys are used to display status information as well as for the entry of TCP/IP network
addresses. If you hold down an arrow key for more than one second, it begins to scroll through all of the available
options. Release the key when the desired option is displayed.
The front panel keypad also turns the LABvault-SD on/off. Note that the LABvault-SD automatically turns on when the
unit is plugged in. When held for four seconds, the red “X” button turns off
the LABvault-SD. If the LABvault-SD has been turned off, press the green
check push button for two seconds to turn the unit back on.
LEDS
The LABvault-SD front panel has two status, light-emitting diodes (LEDs)
for at-a-glance feedback. The red “Record” LED lights up when the LABvault-SD is encoding. The blue “Play” LED
lights up when playback on the LABvault is activated.
DISPLAY
The LABvault-SD display shows status and password-protected TCP/IP address entry screens. Once the LABvault-
SD has been booted up, press the up or down arrows on the keypad to display the following status screens:
11/03 12:00:00PM
SN:B923D1 V01.00
Serial Number & Firmware Version
Firmware Date IP Address
LABvault-SD Identication
11/03 12:00:00PM
FW Blt:10/31/08
11/03 12:00:00PM
IP:10.9.0.1
11/03 12:00:00PM
ID:LABvault-SD
MPEG Recorder Status
11/03 12:00:00PM
Recorder Stopped
Bios Date
11/03 12:00:00PM
Bios:02/14/08
FRONT PANEL
BEFORE unplugging or
removing power from the
LABvault-SD, shut down the
unit from its front panel.
Transfer Status
11/03 12:00:00PM
NX: 0.8591GB 2%
Indicates le transfer destination and progress.
If more than one destination is selected for
a transfer, the screen only shows the rst
destination to which the LABvault-SD sends the
le. Changes to “Send Idle” when there are no
active le transfers.
Processor Temperature
11/03 12:00:00PM
Temp: 42°C
PStat Firmware Version
11/03 12:00:00PM
PStat Ver:66.03
Displays the rmware version for the
front panel status LEDs.
MPEG Player Status
11/03 12:00:00PM
MPEG Player Stop
Build Number
11/03 12:00:00PM
Bld Num:427

Page 4 2018-06-08
LABvault-SD
Back Panel
A: Power cord connector
B: 1 RS-232 Serial Port for External Control System
C: 1 RJ-45, 10/100 BASE-T Ethernet port with corre-
sponding LED indicators
D: 1 BNC video input connector
E: 1 BNC video output connector
F: 2 RCA audio input connectors (left & right)
G: 2 RCA audio output connectors (left & right)
BACK PANEL
The LABvault-SD back panel, includes, from left to right, top to bottom:
ABCDE
FG
Not Used
ORIGINAL LABVAULT-SD BACK PANEL
A: Power cord connector
B: not used
C: 9-pin male RS-232 DTE connector for control by
a compatible third party system, such as a AMX or
Crestron touch screen
D: 1 RJ-45, 10/100/1000 BASE-T Ethernet port with cor-
responding LED indicators
E: 1 BNC video input connector
F: 1 BNC video output connector
G: 2 RCA audio input connectors (left & right)
H: 2 RCA audio output connectors (left & right)
The LABvault-SD back panel, includes, from left to right, top to bottom:
Not Used
VERSION 2 OF THE LABVAULT-SD BACK PANEL
A
B
C D
EF
GH
There are two versions of the LABvault-SD, which have different back panels, supported network connectivity speeds,
and internal hard drive sizes. The original LABvault-SD, no longer available, has a back panel matching the rst of the
pictures shown below, supports 10/100 BASE-T Ethernet, and has a 120 GB internal hard drive. The current LABvault-SD
model, version 2, has a back panel matching the second picture below, supports 10/100/1000 or gigabit BASE-T Ethernet,
and has a 250 GB internal hard drive.

LABvault-SD
System Installation
Page 5 2018-06-08
SYSTEM INSTALLATION
INSTALLING THE LABVAULT-SD
While installing the LABvault-SD, refer to the labeled back panel on page page 4 that matches your LABvault-
SD’s back panel. Perform the following installation steps:
1. The LABvault-SD may be left as a standalone, tabletop unit or mounted into a rack as follows:
a. Insert the LABvault-SD into the rack, aligning the holes of the unit’s mounting bracket with those of the rack.
b. Secure the LABvault-SD to the rack with user-supplied rack screws.
2. Connect the included power cable to the LABvault-SD’s power cord connector and then plug the other end into an
AC power source.
3. Using a straight-through RJ-45 Ethernet cable, connect the LABvault-SD Ethernet port to a hub or switch on your
TCP/IP network. The original LABvault-SD supports 10/100 BASE-T Ethernet, while version 2 of the LABvault-SD
supports 10/100/1000 (gigabit Ethernet). To check your network connection, look at the Ethernet LEDs above the
Ethernet port and compare to the table below that corresponds to your LABvault-SD’s back panel.
4. Connect your video/audio signal wiring to the LABvault-SD as follows:
a. Video/Audio Source: this is the resource or signal the LABvault-SD will record. Connect your video source
wiring to the LABvault-SD’s BNC video input and stereo RCA audio inputs.
b. Video/Audio Destination: connect a television monitor to the LABvault-SD’s BNC video output and stereo RCA
audio outputs to review your recorded digital les. The LABvault-SD supports simultaneous playback and
recording, allowing you to watch other les during recording.
5. If your external control system has not been congured for network connectivity and supports RS-232
communication, connect the control system (such as AMX or Crestron touch screen) directly to the LABvault’s RS-
232 control port. For LABvault control protocol details, refer to the “CONTROL COMMANDS” on page 26.
Version 2 LABvault-SD Ethernet LED Indicators
LED Position State Description
Right Off Connection speed is 10Mb/s
Green Connection speed is
100Mb/s
Orange Connection speed is
1000Mb/s
Left Slow blinking
yellow
Ethernet link not established
Fast blinking
yellow
Ethernet link established.
LABvault-SD is transmitting
on the network.
NOTE: The LABvault requires the following network ports:
•23 Telnet
• 21 FTP Control Connection
• 20 FTP Data (if using third party FTP client in passive mode)
• 80 for the LABvault-SD Web interfaces
• 2000 UDP for ePRO-BUS Control
Leave empty rack spaces above and below the LABvault-SD. The LABvault-SD should not have
anything stacked on top of it.
LEIGHTRONIX strongly recommends the use of an Uninterruptible Power Supply (UPS) with
the LABvault-SD. Damage from power loss or spikes is not covered under warranty.
Original LABvault-SD Ethernet LED Indicators
LED Position State Description
Left Off Connection speed is 10Mb/s
Green Connection speed is
100Mb/s
Right Off Ethernet link not established
Steady on yellow Ethernet link established.
PEGvault-SD is not trans-
mitting on the network.
Blinking yellow Ethernet link established.
PEGvault-SD is transmitting
on the network.

Page 6 2018-06-08
LABvault-SD
System Installation
ENTERING NETWORK SETTINGS INTO LABVAULT-SD
CONFIG MENU
Edit unit address
a. Power up the LABvault-SD by pressing the green check button on
the front panel for at least two seconds.
b. From the front panel, enter your password by pressing the right arrow button to display the password entry
screen and then the right arrow key ve times. If the password is entered correctly, the LABvault-SD’s
conguration menu will be displayed (see below).
If the password is entered incorrectly, the front panel display returns to the status screens.
c. Either enter your LABvault-SD network addresses manually or use DHCP to automatically congure the addresses
according to the following steps:
• Automatic Network Addressing: enable DHCP on your LABvault-SD according to the table below. When
enabled, DHCP will congure your LABvault with an IP, subnet mask, and gateway network addresses.
•
• Manual Network Address Entry
Obtain an IP address, subnet mask, and a gateway for your LABvault-SD from your network administrator.
Repeat the network conguration steps below to enter your IP, subnet, and gateway network addresses.
DHCP Conguration Steps Corresponding Screen Displays
i. From the “CONFIG MENU” screen, press “↑” or “↓“ to
proceed to the “Edit DHCP” screen.
ii. Press “→“ to select the screen.
iii. Press “↑ “ or “↓ “ to toggle the eld value from
“DISABLED” to “ENABLED.”
iv. Press “→“ to enter the next screen.
v. Either press “→“ again to save your changes or “←“ to
abort changes.
The LABvault-SD must be powered down and then powered back up to apply any DHCP changes
(press the red “X” button for four seconds to turn the unit off and then press the green check
button for two seconds to return power).
ENABLE DHCP:
ENABLED
Press ~ to
confirm DHCP
CONFIG MENU
Edit DHCP
Network Address Conguration Steps Corresponding Screen Displays
i. From the “CONFIG MENU” screen, press “↑” or “↓“ to
proceed to the desired address screen.
ii. Press “→“ to select the screen.
iii. Press “→“ or “←“ to position the underscore beneath the
editable elds and press “↑“ or “↓“ to edit the values.
iv. Press “→“ past all of the editable elds to enter the next
screen.
v. Either press “→“ again to save your changes or “←“ to
abort changes.
The LABvault-SD must be powered down and then powered back up to apply any network address
changes (press the red “X” button for four seconds to turn the unit off and then press the green
check button for two seconds to return power).
Enter address
255. 0. 0. 0.
CONFIG MENU
Edit unit address
Press ~ to
confirm address
Default Front Panel Password:
ve right arrow keys

LABvault-SD
System Installation
Page 7 2018-06-08
d. Optional: the LABvault-SD FTP buffer size setting helps to control the rate at which data is transferred to and
from the LABvault. The buffer size defaults to 16 kilobytes, but may be adjusted down to 4 KB or up to 64 KB. If
your network equipment can handle a higher rate, edit the setting to 32 or 64 KB for faster transfer times.
To change the FTP buffer size, peform the following:
Network Address Conguration Steps Corresponding Screen Displays
i. From the “CONFIG MENU” screen, press “↑” or “↓“ to
proceed to the “Edit FTP TCP Buf” screen.
ii. Press “→“ to select the screen.
iii. Press “→“ or “←“ to position the underscore beneath the
editable elds and press “↑“ or “↓“ to edit the values.
iv. Press “→“ again to apply change and enter reboot
message screen or “←“ to abort changes.
The LABvault-SD must be powered down and then powered back up to apply any FTP buffer size
changes (press the red “X” button for four seconds to turn the unit off and then press the green
check button for two seconds to return power).
CONFIG MENU
Edit FTP TCP Buf
TCP Buf size:
64 kbytes

Page 8 2018-06-08
LABvault-SD
Web Interface
Your LABvault-SD includes a Web interface, allowing any authorized user to conveniently set up
and check on your LABvault from a local area network connection or the Internet. The LABvault-SD
Web interface is compatible with Internet Explorer, version 8 and higher, Firefox, Safari, and Google
Chrome.
OPENING AND LOGGING IN
Type your LABvault-SD’s IP address into your Web brower’s address bar (i.e., http://10.255.14.175). Enter the LABvault-
SD “admin” username and password into the login prompt and click the “Login” button.
NOTE: The username is always “admin” and the factory-default password is the last six digits of your LABvault’s serial
number.
WEB INTERFACE
Login Screen

LABvault-SD
Web Interface
Page 9 2018-06-08
Site Information: customize the “Site Name”
and “Site Location” information for your system
from the “Site Information” tab on the “System
Management” screen. Refer to the “Edit
Site Name and Location from the ‘System
Management’ Screen” subsection on the
following page for further information.
Storage: indicates the total storage capacity
of your LABvault-SD’s internal hard drive for
the current le record quality preset, as well
as how much storage has been used and is
currently available on the internal hard drive.
This eld also shows how many recorded les
are currently on the hard drive.
MPEG Recorder Status:
shows the user-selected lename and
recording quality preset for the current
recording session as well as the record
time in hours:minutes:seconds:frames.
The “Auto Delete” eld indicates
whether or not your LABvault-SD has
been set up to automatically delete
transferred les from its internal
hard drive. The “Index Pointers” box
displays any video index points set for
LEIGHTRONIX streaming video-on-
demand applications during the current
LABvault record session.
File Transfers: shows which les are
currently being transferred, the transfer
destination(s), and the transfer rate.
Network Settings: shows the network
settings entered into your LABvault-SD’s
front panel.
Destination Conguration:
indicates the le destination(s) set
up for automatic/manual le transfers
and network settings entered for all
destinations.
“System Dashboard” Web Interface Screen
UNDERSTANDING STATUS INDICATORS ON “SYSTEM DASHBOARD” SCREEN
Click the “Dashboard” button to display the “System Dashboard” screen. The Dashboard displays all of the currently
congured settings for your LABvault-SD as well as the unit’s operational and storage status.
MPEG Player Status: shows the
lename and playback time of the video
currently being displayed

Page 10 2018-06-08
LABvault-SD
Web Interface
ENTERING LABVAULT-SD SETTINGS
Congure your LABvault-SD’s site identication, system time and time zone, login username(s) and password(s), and
more from the “System Management” screen as described in the following subsections:
Site Name and Location
Customize the “Site Name” and “Site Location” on your
“System Dashboard” screen for your system. Click the
“SYSTEM” button to display the “System Management”
screen and then click the “Site Information” tab. Enter
a new identication name for your site into the “Site ID”
eld and a location description in the “Site Location” eld.
Click “Apply Changes” to change the information on your
“System Dashboard” screen.
“Site Information” Tab on “System Management” Web Interface Screen
“Site Information” Window on “System Dashboard” Screen
LABvault-SD System Time
Click the “SYSTEM” button to display the “System Management” screen and then click the “Site Information” tab.
“LABvault-SD Time” shows the date and time currently on your LABvault-SD system. To change the LABvault-SD’s
date/time, perform one of the following:
• Sync your LABvault-SD system’s date and time to your computer’s current date and time by clicking the “Set”
button next to the “Computer Time” eld.
• Manually change the LABvault-SD system date and time by editing the “Manual” elds as follows:
1. Use the up/down arrows to adjust the time elds.
2. Click on the date eld and select a new date in the calendar that appears.
3. Click the “Set” button to make the changes.

LABvault-SD
Web Interface
Page 11 2018-06-08
Web Interface Usernames and Passwords
Control access to your LABvault-SD system settings and operation through the browser-based interface. Click the
“SYSTEM” button to display the “System Management” screen and then click the “Security” tab. Perform the following:
“Security” Tab on “System Management” Web Interface Screen
• “System User (admin)” Password: use these elds to change the password for the “admin” user account. The
“admin” user is able to access the main LABvault-SD browser-based interface to change system conguration
settings, activate the LABvault-SD recorder, add index points, modify le transfer settings, and view system log
les. To change the “admin” password, enter up to eight alphanumeric characters in both elds and then click the
“Change Password” button to save.
• “Front Panel Password”: protect access to the network settings entered into the front panel of your LABvault-
SD by clicking a combination of ve arrow buttons and then clicking the “Save” button to change the password or
“Clear” to remove your entry from the eld.
• “Remote Users”:remote user accounts allow users with supported third party systems to initiate, stop, and check
the status of recording on your LABvault-SD. Enter a username and password into the corresponding elds and
then click the “Submit” button to add the account. To delete a remote user account, single click on the user’s name
and then click the “Delete” button.

Page 12 2018-06-08
LABvault-SD
Web Interface
ePRO-BUS Setting
Click the “System” button to display the “System Management” screen and then click the “ePRO-BUS” tab. Click the
“Enable” button to allow the LABvault-SD to receive PRO-BUS control commands over your Ethernet network from
a NEXUS, UltraNEXUS, or UltraNEXUS-SDI server. Clicking “Disable” will prevent the LABvault-SD from receiving
ePRO-BUS commands.
NOTE: Any LABvault-SD and NEXUS series server using the ePRO-BUS feature must be assigned a static IP address
and made available for UDP on Port 2000.
“ePRO-BUS” Tab on “System Management” Web Interface Screen
Serial Port Setting
The serial port mode setting, accessed by clicking the “Serial Port” tab on the “System Management” screen, applies to
the bottom serial port on the back panel of the LABvault-SD chassis. “Host” mode allows the LABvault-SD to receive
serial control commands from supported, external devices connected to the bottom serial port. “Camera” mode is not
currently supported. Currently, the LABvault-SD is automatically congured in the “Host” mode.
“Serial Port” Tab on “System Management” Web Interface Screen

LABvault-SD
Web Interface
Page 13 2018-06-08
SETTING UP FILE TRANSFER DESTINATION(S)
Easily control where your recorded les are sent by clicking the “Destinations” button and using the “File
Destinations” screen tabs. Recorded les may be automatically or manually transferred to a NEXUS series
server/controller, LEIGHTRONIX streaming VOD Web site, LGX-SVOD, and/or third party server with FTP
capabilities, as outlined below. The settings apply to each recording session until you change them.
NOTE: If no destinations are enabled, the LABvault-SD will record and store your les on its internal hard
drive. Refer to ““Managing Files” on page 20 for instructions on transferring and deleting les off
the internal hard drive.
NEXUS Series Server (NEXUS/UltraNEXUS/UltraNEXUS-SDI)
Send your LABvault-SD les to any of the storage volumes attached to your NEXUS series server. Enter your NEXUS
server’s IP address, username, and password along with the name of the volume that you want to store the les. The
names of your storage volumes can be viewed in the WinLGX “Storage Manager” window. Complete the remaining
settings according to the labeled illustration below and click the “Apply Changes” button when you have nished.
“NEXUS/UltraNEXUS” Tab on “File Destinations” Web Interface Screen
“Enable”: check to select your NEXUS series system
as an automatic le transfer destination for le
recordings initiated from the LABvault-SD Web interface
as well as the manual le transfer destination for les
recorded from an external control system.
“Verify Connectivity”: after entering your NEXUS
series unit’s IP address, username, and password, click
the “Verify Connectivity” button to ensure your LABvault-
SD can connect to the server.
“Transfer Holdoff Schedule”: 24-hour timeline allows you
to decide which hours of the day your LABvault will transfer
les to your NEXUS series system. Single click each hour
segment on the timeline to toggle transfer capabilities on or
off (green = on, red = off).
“Enable Auto-Play CH”: if you have selected the
“PEGcasting” option on the “Settings” tab, you may choose to
have the transferring le stream automatically begin playing
on your NEXUS series system’s MPEG Player 1 and/or 2.
Select a “Playback Delay” of 2-60 minutes to specify how
long after the le stream is transferred that it should begin
playing on the selected channel(s).
1
1
2
2
3
3
4
4

Page 14 2018-06-08
LABvault-SD
Web Interface
LEIGHTRONIX Streaming Video-on-Demand Web Site
The “Internet VOD Streaming” option transfers les to a LEIGHTRONIX streaming video-on-demand Web site such as
PEG Central. Complete the settings according to the labeled illustration below and click the “Apply Changes” button
when you have nished.
“Internet VOD Streaming” Tab on “File Destinations” Web Interface Screen
“Transfer Holdoff Schedule”: 24-hour timeline allows
you to decide which hours of the day your LABvault will
transfer les to your LEIGHTRONIX streaming Web site.
Single click each hour segment on the timeline to toggle
transfer capabilities on or off (green = on, red = off).
2
1
2
“Enable”: check to select your LEIGHTRONIX streaming
Web site as an automatic le transfer destination for le
recordings initiated from the LABvault-SD Web interface
as well as the manual le transfer destination for les
recorded from an external control system.
1
NOTE: If you select “Internet VOD Streaming” as an automatic le transfer destination, your les will be
recorded at a VBR of 1.5-2.5 Mb/s for all enabled le transfer destinations.

LABvault-SD
Web Interface
Page 15 2018-06-08
LGX-SVOD Server
Enter your LGX-SVOD server’s IP address, username, and password and then complete the remaining settings
according to the labeled illustration below and click the “Apply Changes” button when you have nished.
“LGX-SVOD” Tab on “File Destinations” Web Interface Screen
“Transfer Holdoff Schedule”: 24-hour timeline allows
you to decide which hours of the day your LABvault will
transfer les to your LGX-SVOD. Single click each hour
segment on the timeline to toggle transfer capabilities on
or off (green = on, red = off).
3
“Verify Connectivity”: after entering your LGX-SVOD
server’s IP address, username, and password, click the
“Verify Connectivity” button to ensure your LABvault-SD
can connect to the server.
2
1
2
3
“Enable”: check to select your LGX-SVOD server as
an automatic le transfer destination for le recordings
initiated from the LABvault-SD Web interface as well
as the manual le transfer destination for les recorded
from an external control system.
1
Server with FTP Capabilities
Push your les to another LEIGHTRONIX or third party video server with FTP capabilities. Enter your server’s IP
address, username, and password along with the name of the destination path. Complete the remaining settings
according to the labeled illustration below.
“FTP Server” Tab on “File Destinations” Web Interface Screen
“Transfer Holdoff Schedule”: 24-hour timeline allows you to
decidewhich hours of the day your LABvault will transfer les to your
server. Single click each hour segment on the timeline to toggle
transfer capabilities on or off (green = on, red = off).
3
“Verify Connectivity”: after entering your FTP server’s IP
address, username, password and destination path, click the “Verify
Connectivity” button to ensure your LABvault-SD can connect to the
server.
NOTE:Obtain your destination path from your server’s administrator.
2
1
2
3
“Enable”: check to select your FTP server as an automatic le
transfer destination for le recordings initiated from the LABvault-SD
Web interface as well as the manual le transfer destination for les
recorded from an external control system.
1

Page 16 2018-06-08
LABvault-SD
Web Interface
RECORDING
Set up your LABvault-SD system for recording with the administrative interface’s record quality and automation settings
and then learn how to use the interface to activate the LABvault-SD’s record and index features through the following
subsections:
NOTE: Record sessions initiated from the external control system will use the le quality setting currently
selected in the Web interface.
Record Settings
Click the “DESTINATIONS” button and then select the “Record Settings” tab. Enter the following record settings and
then click the “Apply Changes” button to send the changes to your LABvault-SD or “Cancel” to abort. The settings will
be applied to every recording session until they are changed.
• “File Name”: in the “File Name” eld, enter up to 14 characters (letters, numbers, and underscores only—no
spaces). If you use the same lename for more than one recording session, the record date and start time will be
appended to the name of each additional recorded le as “yy/mm/dd-hh/mm/ss” (year/month/day-hours/minutes/
seconds).
NOTE: Alternatively, you may enter the new lename into the “File Name” box in the lefthand column of the
LABvault-SD Web interface. Click the “Save” button to make the change. The new name will appear in
the “File Name” eld on the “File Settings” tab.
• “Create Unique Files”: when this option is selected, the record date and start time will be appended to the lename
of every recorded le as “yy/mm/dd-hh/mm/ss” (year/month/day-hours/minutes/seconds).
• “Automatic Delete”: if you want your recorded les deleted from the LABvault’s internal hard drive after each
transfer, select the “Enable” “Automatic Delete” option. The “Disable” option will cause your recorded les to stay
on the hard drive until you manually delete them from the “File Management” screen (click the “Files” button).
NOTES: • If no destinations are enabled, the LABvault-SD will record and store your les on its
internal hard drive. Refer to “Managing Files” on page 20 for instructions on transferring
and deleting les off the internal hard drive.
“Record Settings” Tab on “File Destinations” Web Interface Screen
Table of contents
Other Leightronix Recording Equipment manuals
