Lem Elettronica SCF316/8 User manual

Versione. 1.1
SCF316/8
Optical Input Multiswitch
User manual
ITALY
MADE IN
MODEL SCF316/8
OPTICAL INPUT 1
RF OUTPUTS 8
OPTICAL
OPERATION WAVELENGTH nm 1310 - 1330 - 1550
INPUT POWER RANGE dBm -14... 0
INPUT CONNECTOR TYPE SC/APC
RETURN LOSS dB ≥40
SATELLITE
OUTPUT BANDWIDTH MHz 950... 2150
SCR/dCSS OUTPUT LEVEL dBµV 85 Low / 94 High
LEGACY OUTPUT LEVEL dBµV 75 Low / 80 High
SATELLITE OUTPUTS CONTROL STANDARDS LEGACY/EN50494/EN50607/SKY UK (AUTO-SWITCH)
AVAILABLE USER BAND FREQUENCY PLANS SKY ITALIA - SKY UK
TV TERRESTRIAL / FM / DAB
OUTPUT BANDWIDTH MHz 40... 790
MAXIMUM OUTPUT LEVEL dBµV 85
OUTPUT LEVEL ADJUSTABLE RANGE dB 0... -20
OTHERS
ISOLATION BETWEEN SATELLITE/TERRESTRIAL dB ≥ 40
ISOLATION V / H dB > 30
OUTPUT RETURN LOSS dB > 10
DC INPUT VOLTAGE RANGE V12... 20
MAXIMUM CONSUMPTION W16
OPERATING TEMPERATURE °C 0... 50
DIMENSIONS mm 237x118x3 8
8 Legacy/dCSS - DTT/DAB/FM outputs
Led monitor optical link
A.C.G. for each output
Selectable Low/High satellite output level
Level adjuster for TV terrestrial signal
118 mm
237 mm
39 mm

1. Read carefully these instructions
2. Keep these instructions
3. Heed all warnings
4. Follow all instructions
5. Do not expose this apparatus to extreme temperatures
6. Do not install this apparatus near water or expose to rain and moisture
7. Place the apparatus in a dry and well-aired location
8. Install the unit on a vertical wall, or in a waterproof cabinet with a minimum IP55
rating, and fix it safely using the provided fixing plugs
9. Do not install the unit lying flat or on its top
10. Connect the power adapter cord to a detachable power supply socket
11. Unplug the apparatus during lighting storms or when unused for long time
12. Only use accessories specified by the manufacturer
13. Do not remove the cover without disconnecting from the mains first
14. Ambient temperature should not be lower than 0°C and higher than 50°C
15. Please allow air circulation around the apparatus
Safety instructions
DESCRIPTION OF SYMBOLS AND ELECTRICAL SAFETY
The equipment complies with the CE requirements
The equipment is designed for indoor use only
Equipment grounding terminal
This symbol indicates that the equipment complies with the class II equipment safety
requirements
CAUTION To avoid the risk of electric shock, do not open the equipment.
The equipment is compliant with RoHS 2011/65EU
Dispose according to local authorities recycling processes

Minimum recommended distance
Place the apparatus and the power supplier in a dry and well-aired location
Install the unit on a vertical wall, or in a waterproof cabinet with a minimum IP55
rating, and fix it safely using the provided fixing plugs
Use only the power supplier YS25-1501250 provided with the amplifier.
The use of not-original power suppliers determines the not-compliance of the
product and can cause malfunctions and void the warranty
Installation warnings
20 cm 20 cm
20 cm
20 cm
PSU
SCF316/8
Optical Input
Legacy/SCR- dCSS
Multiswitch 8x16 User Band
Tap Freq.Range: 950... 2150MHz
SCR/dCSS Ouput Level: 85/94dBµV
Legacy Output Level: 75/80dBµV
Tap Freq.Range: 40... 790MHz
Output Level: 75... 95dBµV
LED OPERATING MODE
Off............. Receiver Off
Green................. Legacy
Blue.............. SCR/dCSS
Green blinking......... <9V
SATELLITE
Optical Wavelenghts: 1310 - 1330 - 1550nm
Input Level Range: -14...0dBm
Connector Type: SC/APC
OPTICAL
TV TERRESTRIAL
User Band
Freq. plan
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
Optical
Input
LOW
5
6
dCSS
Legacy
dCSS
Legacy
7
8
HIGH OUT
1
2
LOW
HIGH OUT
3
4
LOW
HIGH OUT
5
6
LOW
HIGH OUT
7
8
Optical
Link V
Optical
Link H
Optical
Link T V
0-20dB
TV Terrestrial

Optical SC/APC input
1
Terrestrial signals output level adjuster
12
SCR/dCSS - Legacy output Led status
3
Terrestrial/SCR/dCSS - Legacy Outputs
4
Satellite High/Low level outputs (5) e (6) selector
5
16 DC input 12... 20 Volt
Satellite High/Low level outputs (1) e (2) selector
17 Satellite High/Low level outputs (3) e (4) selector
18
Equipotential bonding
19
Optical link Status Led
110
SCF316/6
Tap Freq. Range: 950... 2150MHz
SCR/dCSS Ouput Level: 85/94dBµV
Legacy Output Level: 75/80dBµV
Tap Freq. Range: 40... 790MHz
Output Level: 75... 95dBµV
LED OPERATING MODE
Off............. Receiver Off
Green................. Legacy
Blue.............. SCR/dCSS
Green blinking......... <9V
SATELLITE
Optical Wavelenghts: 1310 - 1330 - 1550nm
Input Level Range: -14... 0dBm
Connector Type: SC/APC
OPTICAL
TV TERRESTRIAL
User Band
Freq. plan
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
dCSS
Legacy
Optical
Input
5
6
LOW
HIGH OUT
1
2
LOW
HIGH OUT
3
4
LOW
HIGH OUT
5
6
1
4
10
8
7
5
6
9
2
3
Optical
Link V
Optical
Link H
Optical
Link TV
0-20dB
TV Terrestrial
DC Input
O= No power
Green= Power
Optical Link
O= No optical link
Green= Optical link
SCF316/8 DESCRIPTION
Content
01 Optical Multiswitch SCF316/8
01 Power supplier YS25-1501250 (Input: 100-240Vac 0,5A Max / Output: 15Vdc 1,25A Max)
08 6x30mm xing plugs with 4,5x40mm screws
01 User manual
The optical signal level at the input of the multiswitch SCF316/8 must lie between 0dBm e -14dBm.
Optical signals higher than 0dBm can irreversibly damage the SCF316/8 multiswitch.
In PON with less than 4 optical points add a proper optical attenuator.
Outputs
Multiswitch mode selected
O= any voltage from set-top-box
Green blinking= Voltage from set-top-box < di 9 Volt
Green= Legacy mode (auto-switch)
Blue= SCR/dCSS mode (auto-switch)
Quattro mode selected
Green for all outputs
MONITOR LED DESCRIPTION

PSUPSU
PSU PSU
PSU
V H
LNB
WIDE
BAND
PSU
TV Terr.
Radio
SAT/dCSS/Legacy
Test SAT V
TXWBT
DSP20
Test SAT H
Test TV Terr.
Optical Splitter 1x32 Optical Splitter 1x32
Optical
Splitter
SCF316/4 SCF316/8 SCF316/6
SCF316/2
Single-Mode
Fibre Optic
9/125
DC
Powering
Line
The TXWBT headend converts and transmits over a single-mode optical fibre the terrestrial
signals (DTT, FM, DAB) processed by the programmable terrestrial headend DSP20 and
all the transponders of a satellite received from a Wide Band LNB. The optical signals are
received by the optical multiswitch of the SCF316 series and converted into RF ready for a
single or multi-dwelling coaxial distribution. Each SCF316 series output provides terrestrial
and satellite signals supporting the legacy or SCR/dCSS standards (AUTO-SWITCH).

Label with serial and tracking data
Model Serial # Manuf.
Week
Manuf.
Year
HW
Rel.
FW
Rel.
USER BAND FREQUENCY PLAN
EN 50494 (SCR Standard) EN 50607 (SCD2 / dCSS)
UB1: 1210 MHz UB1: 1210 MHz
UB2: 1420 MHz UB2: 1420 MHz
UB3: 1680 MHz UB3: 1680 MHz
UB4: 2040 MHz UB4: 2040 MHz
UB5: 985 MHz UB5: 985 MHz
UB6: 1050 MHz UB6: 1050 MHz
UB7: 1115 MHz UB7: 1115 MHz
UB8: 1275 MHz UB8: 1275 MHz
UB9: 1340 MHz
UB10: 1485 MHz
UB11: 1550 MHz
UB12: 1615 MHz
UB13: 1745 MHz
UB14: 1810 MHz
UB15: 1875 MHz
UB16: 1940 MHz
