LEM 825 Parts list manual
THE L EADER IN G A ME PRO C E S SING
professional
french fry cutter
USE & MAINTENANCE
825
1 YEAR
WARRANTY
Revised November 20, 2015
IMPORTANT WARRANTY INFORMATION PLEASE READ
FILL OUT AND RETURN ENCLOSED WARRANTY CARD
THIS WARRANTY COVERS:
LEM Professional French Fry Cutter #825
THE WARRANTY IS EXTENDED TO THE ORIGINAL PURCHASER ONLY
WARRANTY DURATION: This product is warranted to the original purchaser for a period of one (1) year from the original
purchase date. EACH UNIT COMES WITH A WARRANTY CARD, WHICH MUST BE FILLED OUT COMPLETELY AND
RETURNED IMMEDIATELY, WITH A COPY OF THE PURCHASING RECEIPT. FAILURE TO RETURN YOUR WARRANTY CARD
WILL LIMIT WARRANTY TO 90 DAYS WITH PROOF OF PURCHASE.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship.The warranty is void if the
product has been damaged by accident, misuse, neglect, modication or improper service or repairs by unauthorized personnel. It
is also void if damaged in shipment or by other causes not arising out of defects in the materials or workmanship.This warranty
does not extend to any units which have been in violation of written instructions furnished. This warranty covers only the product
and its specic parts, not food or other products processed in it.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied, and no representative or person is
authorized to assume any other liability in connection with the sale of our products. There shall be no claims for defects or failure of
performance under any theory of sort, contract or commercial law including, but not limited to negligence, gross negligence, strict
liability or breach of contract.The manufacturer declines all responsibility for damage to persons, things or animals arising from the
failure to comply with the norms contained in this manual.The manufacturer reserves the right to make modications at anytime
to the models while maintaining the main characteristics described herein.The manufacturer also declines all responsibility for any
errors in compiling this manual.
WARRANTY PERFORMANCE: During the above one year warranty period, a product with a defect will either be repaired or
replaced after the product has been inspected by an LEM Service Technician. LEM RESERVES THE RIGHT TO REFUSE WARRA-
NTY PERFORMANCE OR PRODUCT EVALUATION UNLESS THE ORIGINAL SALES RECEIPT OR THE WARRANTY CARD IS ON
FILE. The repaired product will be in warranty for the balance of the one year warranty period. No charge will be made for such
repair or replacement.
IMPORTANT NOTICE: If any parts are missing or defective, please contact our Customer Service Department for assistance at
877-536-7763 (M-F 8:30am to 4:30pm EST). DO NOT RETURN TO THE STORE WHERE THE PRODUCT WAS PURCHASED.
LEM PRODUCTS MERCHANDISE RETURN POLICY WARRANTY SERVICE: To obtain service under terms of this warranty,
please contact us at 877-536-7763 to obtain authorization prior to returning the merchandise. No merchandise will be accepted
without prior authorization. Please return the product prepaid in the original packaging if possible, enclose a copy of your receipt,
(keep a copy of your proof-of-purchase for your records) and include a written explanation of the issue. Ship to LEM Products, 4440
Muhlhauser Road, Suite 300,West Chester, OH 45011. LEM Products is not responsible for damage incurred in shipping, make
certain to pack product properly. Return shipping charges are the responsibility of the purchaser. Packages returned to LEM should
be insured for the value of the product to cover any damages that may occur during shipping.
LEM Products • West Chester, OH 45011 •1-877-536-7763 • lemproducts.com
LEM Products • West Chester, OH 45011 • 1-877-536-7763 • lemproducts.com
PROFESSIONAL FRENCH FRY CUTTER
MODEL #825
#DESCRIPTION QTY # DESCRIPTION QTY
1Wing Nut 311 Push Rod Bolt 2
2½" Cutting Plate with Frame 112 Push Rod 2
3 " Cutting Plate with Frame 113 Handle 1
4 " Push Plate 114 Guide Rod Nut 3
5½" Push Plate 115 Back Stand 1
6Front Stand 116 Guide Rod 3
7Push Plate Base 117 Base 1
8Thumb Screw with Washer 218 Handle Bolt & Nut 2
9Push Rod Mount 119
20
Suction Cup Feet (not shown)
Shaft
4
1
10 Push Rod Mount Screw 2
CARE:
• Thoroughly wash and rinse the unit with hot soapy water before use.
• For best results, DO NOT put unit in dishwasher.
CAUTION:
• KEEP OUT OF REACH OF CHILDREN.The blades are very sharp.
• Suction cups are not intended for use on pourous surfaces such as a wood- discoloration or possible marring may occur.
• When cutting brous vegetables such as yams, sweet potatoes and onions, use the large blade. Use a rm, quick pushing motion to
move the vegetables through the blades. Repeat as needed until the produce is through the blades.
• To produce the best strips, use fresh, rm fruits and vegetables such as carrots, cucumbers, zucchini, apples, yams, sweet potatoes,
onions, white, red and yellow potatoes.
USE:
1. To change the blade, remove the 3Wing Nuts (#1) on the front of the Cutting Plate (#2 or #3) Front Stand (#6).
2. Place the alternate blade on the unit and replace the wing nuts.
3. To change the Push Plate (#4 or #5), remove the two Thumb Screws andWashers (#8) from the Push Plate Base (#7) and mount
the alternate plate in place. Replace screws.
4. The unit can be mounted to a sturdy surface of wall.
OPTIONAL: To install Suction Cup Feet Kit (#19) place the bolt of each suction cup through the holes in the feet of the cutter. Thread
the nylock nut onto each bolt tightly. Press firmly down on the French Fry Cutter to create suction between the surface and the
cutter. Suction cups work best on smooth, horizontal surfaces.To create more suction, a damp cloth can be swiped across the suction
cup prior to adhering. Check stability of the cutter prior to using.
NOTE: The suction cups are not meant to be used on a vertical surface. Use the suction cups for horizontal mounting purposes only.
7 8 9 10 11
12
20
17 16
11
14
15
18
3
2
1
4
5
6
CAUTION
Before using the appliance for the rst time please make sure to read carefully
and thoroughly through these operating instructions and the safety advice.
Familiarize yourself completely with the functions of the appliance.
1. Always ensure that the appliance is properly assembled and safely set up before use.
2. CAUTION: This appliance is not recommended for use near or by children or persons with certain disabilities. Set up and
store the appliance out of reach of children. Store the device in a secure and dry place out of reach of children. DO NOT
allow children to operate the appliance.
3. CAUTION: Exposed sharp metal blades! Use Extreme Caution when handling and cleaning metal blades. Do not touch
sharp edge of the blades. It is recommended that cut resistant gloves be worn when handling the blades.
4. Thoroughly hand-wash all removeable parts with warm, soapy water prior to use. Do not soak. NOT DISHWASHER SAFE .
5. The appliance is designed exclusively for domestic use and not for commercial purposes.
6. Use the appliance with the supplied accessories only. WARNING: The use of attachments not recommended or sold
by the manufacturer may cause injury, damage to personal property, and may void your warranty.
7. WARNING: DO NOT use while under the inuence of alcohol or drugs (prescription or non-prescription) as these may
impair user’s ability to properly assemble or safely operate the appliance.
8. The manufacturer declines any responsibility in the case of improper use of this product. Improper use of this product
voids the warranty.
9. Tie back loose hair and clothing and roll up long sleeves before operating the appliance. Remove ties, rings, watches,
bracelets or other jewelry before operating the slicer.
10. Use appliance with appropriately sized food. DO NOT attempt to process foods other than potatos or other rm
vegetables and fruits that have pits removed.
11.
SAVE THESE INSTRUCTIONS
LEM Products • West Chester, OH 45011 • 1-877-536-7763 • lemproducts.com LEM Products • West Chester, OH 45011 • 1-877-536-7763 • lemproducts.com
23
ASSEMBLY & OPERATING INSTRUCTIONS
PARTS LIST
GENERAL WARNINGS AND SAFETY INFORMATION
