LEM SWING14P User manual

The lighting flash with arrowshad symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltages” within the
product’s enclosure, that may be of sufficient magnitude to
constitute a risk of electric schok to persons.
The exclamation point within an equilater triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanyng the appliance.
IMPORTANT SAFETY INSTRUCTIONS
INSTRUCTIONS PERTAINING A RISK OF FIRE, ELECTRIC SHOCK OR INJURY A PERSONS
WARNING - When using electric products, basic precautions should always be followed, including the fol-
lowing.
1. Read all the SAFETY INSTRUCTIONS before using the product.
2. A reduce the risk of injury, close supervision is necessary when the product is used near children.
3. Do not use this product near water - for example, near a bathtub, washbowl, kitchen sink, in a wet base-
ment or near a swimming pool or the like.
4. This product in combination with an amplifier, may be capable of producing sound levels that could cause
permanent hearing loss. Do not operate for a long period of time at high volume level or at level that is
uncomfortable. If you experience any hearing loss or ringing in the ears, you should consult an audiologist.
5. This product should be located so that its location or position does not interfere with its proper ventilation.
6. This product should be located away from heat sources such as radiators, heat register or other product
that produce heat.
/. The product may be connected a power supply only of the type described on the operating instructions or
as marked on the product.
8. The product may be equipped with a polarized line plug (one blade wider then the other). This is a safety
feature. If you are unable a insert the plug into the outlet, contact an electrician a replace your obsolete
outlet. Do not defeat the safety purpose of the plug.
9. The power-supply cord of the product should be unplugged from the outlet when left unused for a long
period of time. When unplugging the power-supply cord, do not pull on the cord, but grasp it by the plug.
10. Care should be taken so that object do not fall and liquid are not spilled into the enclosure through
openings.
11. The product should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the product; or
C. The product has been exposed to rain; or
D. The product does not appear to operate normally or exhibits a marked change in performance; or
E. The product has been dropped or the enclosure damaged.
12. Do not attempt to service the product beyond that described in the user-maintenance instructions.
All other servicing should be referred to qualified service personnel.
13. WARNING - Do not place objects on the product’s power cord or place it in a position where anyone
could trip over, walk on or roll anything over it. Do not allow the product to rest on or to be installed over
power cords of any type. Improper installations os this type create the possibility of fire hazard and/or per-
sonal injury.
SAVE THESE INSTRUCTIONS

1
Instructions and installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
MONO input channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
STEREO input channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MASTER section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connection cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connection example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Schema a blocchi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Contents
Contents / Instructions and installation
Instructions and installation
✔ ✔
✔ ✔
✔ Connecting the mixer to the mains supply.
Before connecting the amplifier to the mains socket, always make certain that:
- the electric system and mains socket have an adequate grounding, compatible with the safety norms (if you’re
uncertain, consult specialized personnel);
- the mains voltage corresponds to that shown on the rear of the unit (an allowance of up to ±10% is accepted);
- the power cord is not damaged and has no bare wires;
- the on/off switch is in the OFF position.
Make sure the mixer is also off before disconnecting the power cord from the mains socket. It is best to lower (or better still
close) the output levels and switch off any amplifiers connected to the line output of the mixer before switching the mixer on
or off: this avoids annoying and sometimes dangerous (particularly for the speaker cabinets) signal peaks.
✔ ✔
✔ ✔
✔ Connection and prevention or identification of possible disturbances.
First of all, check that the mixer is installed in a place free from industrial or RF (radio frequency) interference. Avoid installing your
equipment very near radio or TV sets, mobile phones, etc., as these can cause noisy interference. When connecting the other
components of your sound system, watch out for the so-called “ground loops”, which could cause hum and jeopardize the mixer’s
excellent Signal-to-Noise and low distortion characteristics. The best way (even if not always feasible) to avoid ground loops is to
connect the electric ground of all the equipment to a single central point (the so-called “star” system). In this case, the central point
in sound systems is the mixer.
✔ ✔
✔ ✔
✔ Protection and maintenance.
Do not force knobs, switches or faders: they have been designed to respond to a light touch and could be damaged if treated
with excessive force. Take care of the connector cables, always holding them by the connectors and avoiding pulling the wire
and avoid knots and twists when coiling them: this gives the advantage of increasing their life and reliability, which is always
to your advantage. Periodically check that your cables are in good condition and are correctly wired and that all their contacts
are perfect: a great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable
or faulty cables.
Avoid exposing the mixer to direct sun, strong heat, intense vibrations, very dusty or damp surroundings, or even worse, rain:
this will avoid eventual malfunction, deterioration or even electric shocks and fires. Any dust on the mixer should be removed
using a soft dry cloth or a brush; never use alcohol, acetone or solvents.
✔ ✔
✔ ✔
✔ In the event of breakdown
All user-adjustable parts are external and easily accessible. Never open the amplifier: you could run the risk of serious electric
shocks. In the event of breakdown, contact the nearest GENERALMUSIC/LEM Assistance Centre
✔ ✔
✔ ✔
✔ Conservation of documents and packing.
Keep this manual for future consultation. On this subject, remember a golden rule: equipment always gets a better price on
the secondhand market if it has all its original documentation and packing as well as being well kept.

2
Introduction
Congratulations for having chosen SWING 14P!
SOLO
100
100100
100100
TAPE IN
LEVEL
PEAK PEAK PEAK PEAK PEAK PEAK PEAK PEAK
SOLOSOLOSOLOSOLOSOLOSOLOSOLOSOLO
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
AUX 1
PRE/POST
100
PAN
RL
PAN
RL
PAN
RL
PAN
RL
PAN
RL
PAN
RL
BAL BAL
RRLL
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
INSERT INSERT INSERT
LINE LINE LINE
MIC/LINE MIC/LINE MIC/LINE
MIC MIC MIC
MIC
LINE
1
MIC
LINE
2
MIC
LINE
3
MIC
LINE
4
MIC
LINE
5
MIC
LINE
6
MONITOR DSP MIX L&R MONO
MIC
LINE
1
MIC
LINE
2
MIC
LINE
3
MIC
LINE
4
MIC
LINE
5
MIC
LINE
6
LO-CUT
75 Hz
LO-CUT
75 Hz
LO-CUT
75 Hz
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
MID
+12-12
MID
+12-12
MID
+12-12
FREQ
8k
100
FREQ
8k
100
FREQ
8k
100
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
80 Hz
LOW
+15-15
12 kHz
HIGH
+15-15
12 kHz
HIGH
+15-15
12 kHz
HIGH
+15-15
12 kHz
HIGH
+12-12
2.5 kHz
MID
+12-12
2.5 kHz
MID
+12-12
2.5 kHz
MID
+12-12
2.5 kHz
MID
+12-12
2.5 kHz
MID
+15-15
12 kHz
HIGH
+15-15
12 kHz
HIGH
+15-15
12 kHz
HIGH
+15-15
12 kHz
HIGH
+15-15
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
100
POST-FADER
AUX 2
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
LEVEL
SOLO
100
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
LEVEL
SOLO
100
FOOTSWITCH
PHONES
STEREO
LINE
7/8
STEREO
LINE
11/12
STEREO
LINE
13/14
STEREO
LINE
9/10
RIGHT RIGHT
AMP
IN
AMP MODE
LEVEL LEVEL
LEFT
(MONO)
LEFT
(MONO)
7/8 9/10
+4dB
-10dB
+4dB
-10dB
MIX L&R
L+R / MONITOR
1
2
LEFT
LEFT
(MONO)
RIGHT
RIGHT
AUX SENDS TAPE
IN
TAPE
OUT
MONO
OUTPUT
MIX
OUTPUTS
MONITOR OUT
AUX INPUTS
L
L
R
R
+48V PWR
PROTECT
LEVEL
SET
OUTPUT/SOLO
LEVEL
CLIP
LR
30
20
10
7
4
2
0
2
4
7
10
12563 250 8k 16k
+12+12
-12-12
00
4k2k1k500
BAND GRAPHIC EQSTEREO 9
OFF
ON
OFF
ON
OFF
ON
125 Hz
SUB-WOOFER
LPF
18
7
6
5
4
3
2
1
8
7
6
5
4
BRIGHT REVERSE
1. REVERB REGEN
2. AMBIENT
3. ECHO + REVERB
4. BOUNCE DELAY
5.TAP DELAY
6. PAN DELAY
7. MULTITAP DELAY
8. BYPASS
DARK S/HALL
BRIGHT GATE
DARK L/HALL
BRIGHT PLATE2
DARK S/ROOM
BRIGHT PLATE1
DARK L/ROOM
BRIGHT L/ROOM
STEREO DELAY1
BRIGHT S/ROOM
STEREO DELAY2
BRIGHT L/HALL
MONO DELAY
BRIGHT S/HALL
MULTIEFFECT
(see below)
3
2
SOLO
ACTIVE
PHONES SOURCE DSP TO MONITOR PHONES LEVEL
MONITOR
MIX L&R
MONO
AFL
PFL
PEAK
SOLO MODE
1 SHORTER
2
3
4
5
6
7
8 LONGER
VARIATIONS
PRESETS
11/12 13/14
MULTIEFFECT
PRESETS
SWING 14P is an extremely versatile amplified mixer able to offer a great number
of functions in a really compact format. Fitted with a powerful built-in amplifier and high-
quality DSP, SWING 14P has been designed to make its transport, installation and use
as easy as possible and are the ideal solution for anyone requiring (for work or enjoyment
purposes) a practical, reliable powered mixer as well as excellent sound quality.
SWING 14P is equipped with 6 MONO MIC channels, 2 STEREO LINE channels
and 2 AUXILIARY STEREO channels, for a total of 14 INPUTS. The inputs channels offer
highly advanced features, such as LO-CUT FILTER, INSERT point and 3-band EQ with
sweep mid. The master section includes an internal DSP with 128 high quality REVERB
and DELAY effects and a 9-band GRAPHIC EQ. The powerful 250+250 WATTS built-
in amplifier provides high efficiency and sound quality and includes a complete protection
system for the maximum reliability.
Introduction

3
PEAK
SOLO
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
PAN
RL
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
INSERT
MIC/LINE
MIC
LINE
1
MIC
LINE
1
LO-CUT
75 Hz
3
10
20
30
40
5
0
MID
+12-12
FREQ
8k
100
80 Hz
LOW
+15-15
12 kHz
HIGH
+15-15
100
POST-FADER
AUX 2
PEAK
SOLO
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
PAN
RL
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
LINE
MIC
MIC
LINE
6
MIC
LINE
6
3
10
20
30
40
5
0
80 Hz
LOW
+15-15
+12-12
2.5 kHz
MID
12 kHz
HIGH
+15-15
100
POST-FADER
AUX 2
MONO input channel
MIC INPUT
Balanced XLR connector: this input is for use with microphones,
but can also accept a wide range of balanced or unbalanced low
impedance signals. Do not connect keyboards, recorders or other
equipment with a line signal, as the signal level would be too high
and probably distorted.
LINE INPUT
Balanced JACK connector: can receive balanced or unbalanced
high-impedance signals from equipment with a high-level output
(all instruments excluding microphones). Do not connect a
microphone to this input: the signal would not be sufficiently
amplified and will probably be poor and disturbed.
CHANNEL INSERT
STEREO JACK connector: allows to use an external device
(equalizer, compressor, etc.) to process the signal of the channels
1, 2 and 4. The INSERT connectors have the signal SEND on
the JACK TIP and the signal RETURN on the JACK RING (see
CONNECTOR CABLES).
LO-CUT
HI-PASS filter: allows to reduce the frequencies below 75 Hz with
a 18 dB / Oct. slope. Thanks to this filter it’s possible to eliminate
unwanted subsonic frequencies, like, for examples the
microphones rumble due to the stage resonance.
GAIN
Gain control: regulates the amplification of external signals
(microphones, instruments, etc.) fed into the channel.
HIGH
HIGH frequency control: gives a 15dB boost or cut at 12 kHz
with a “SHELVING” curve.
MID
MID frequency control: gives 15dB boost or cut from 100 Hz
to 8 kHz (channels 1-3) or at 2.5 kHz (channels 4-6) with a
“PEAKING” curve.
LOW
LOW frequency control: gives 15dB boost or cut at 80Hz with
a “SHELVING” curve.
MONO input channel

4
MONO input channel
MONITOR
Control for the MONITOR send level.
The MONITOR send is PRE-FADER: this means than the signal
sent to the MONITOR is taken before the control of the channel
FADER, allowing a completely independent mix for the monitoring
respect to the main mix.
AUX1 & AUX2/DSP
Control for the EFFECT sends level.
The AUX1 and AUX2/DSP sends are both POST-FADER: this
means than the signal is taken after the control of the channel
FADER and therefore its level is effected by the fader’s setting.
The AUX1 sends the signal to the AUX SEND 1. The AUX2/DSP
sends the signal both to the AUX SEND 2 and to the internal DSP.
PAN
Centre-dented Pan pot for controlling the signal’s pan:
regulates stereo “position” of the signal with respect to the main
L&R outputs. If PAN is turned completely to the LEFT, the signal
will only be sent to MIX LEFT, if it’s turned completely to the
RIGHT, the signal will only be sent to MIX RIGHT. At intermediate
settings, the signal is sent to both MIX LEFT and RIGHT, but in
different proportions.
PEAK
PEAK LED indicator: lights up when the input signal is near to
the CLIPPING point. This control is POST-GAIN, POST-INSERT
and POST-EQ and, therefore, reacts to the signal already
processed by the internal EQ and by external units. Set the GAIN
control in such a way that the PEAK LED do not light up or only
do so occasionally.
SOLO
Button for PRE-LISTENING function: allows the channel signal
to be selected for the listening thru the HEADPHONES outputs
and the visualization on the LED BARGRAPHS. According to the
position of the SOLO MODE button the listening and the
visualization can be PRE or POST-FADER.
LEVEL
Fader for controlling channel level: regulates the level of each
channel sent to the MIX L&R main outputs.
PEAK
SOLO
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
PAN
RL
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
INSERT
MIC/LINE
MIC
LINE
1
MIC
LINE
1
LO-CUT
75 Hz
3
10
20
30
40
5
0
MID
+12-12
FREQ
8k
100
80 Hz
LOW
+15-15
12 kHz
HIGH
+15-15
100
POST-FADER
AUX 2
PEAK
SOLO
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
PAN
RL
GAIN
-10dB
MIC
LINE
+10dB
-60dB
0dB (LINE)
-40dB
LINE
MIC
MIC
LINE
6
MIC
LINE
6
3
10
20
30
40
5
0
80 Hz
LOW
+15-15
+12-12
2.5 kHz
MID
12 kHz
HIGH
+15-15
100
POST-FADER
AUX 2

5
PEAK
SOLO
PRE-FADER
MONITOR
100
AUX 1
PRE/POST
100
BAL
RL
3
10
20
30
40
5
0
80 Hz
LOW
+15-15
+12-12
2.5 kHz
MID
12 kHz
HIGH
+15-15
100
POST-FADER
AUX 2
STEREO
LINE
7/8
RIGHT
LEVEL
LEFT
(MONO)
7/8
+4dB
-10dB
STEREO input channel
STEREO input channel
STEREO INPUT
Balanced JACK connectors: receive the STEREO LINE input signal on the channel
(0dB). Inserting a single JACK connector on the LEFT socket this channel can be
used as a MONO channel.
LEVEL
Gain control: regulates the amplification of the signal connected to the L&R inputs.
The selectable values are +4 and -10 dB.
BAL
Centre-dented control of the balance of the signal on the main outputs.
The BAL control has a balancing effect on the levels of the two LEFT & RIGHT parts
of the STEREO signal and works as follows:
• turning to the LEFT lowers the RIGHT signal level on MIX RIGHT;
• turning to the RIGHT lowers the LEFT signal on MIX LEFT.
NOTE: the remaining features of the STEREO channel are the same as in the MONO
channel.

6
SOLO
100
100100
TAPE IN
LEVEL
FOOTSWITCH
PHONES
AMP
IN
AMP MODE
MIX L&R
L+R / MONITOR
1
2
LEFT
LEFT
(MONO)
RIGHT
RIGHT
AUX SENDS TAPE
IN
TAPE
OUT
MONO
OUTPUT
MIX
OUTPUTS
MONITOR OUT
AUX INPUTS
L
L
R
R
11/12 13/14
MASTER section
MASTER section
AUX SENDS 1&2
Unbalanced JACK connectors: these connectors feed out the sum of the signals arriving from the relative
AUX sends of the input channels.
AUX INPUTS 11/12 & 13/14
Unbalanced JACK connectors: these are the connectors of the auxiliary stereo inputs. These inputs
can be used for the return signal from outboard effects or for connecting any instrument or equipment
with a line output (e.g. keyboards, cassette recorder or CD turntable).
TAPE IN L&R
Two RCA connectors: receive external signals from STEREO tape recorders, CD player, DAT, etc. These
inputs can be connected to the outputs of your equipment.
TAPE OUT L&R
Two RCA connectors: send out the signal taken from MIX and normally intended for STEREO recording.
These outputs can be connected to the inputs of a recorder.
TAPE IN LEVEL
Pot for controlling the level of the TAPE input.

7
TAPE IN SOLO
Button for PRE-LISTENING of the TAPE INPUT: allows the TAPE IN signal to be selected for the
listening thru the HEADPHONES outputs and the visualization on the LED BARGRAPHS. According to
the position of the SOLO MODE button the listening and the visualization can be PRE or POST-FADER.
MONITOR OUTPUT
Unbalanced JACK connector: this connector feeds out the sum of the signals arriving from the relative
MONITOR sends of the input channels.
MIX L&R OUTPUTS
Two unbalanced JACK connectors: these are the connectors of the mixer main outputs and send out
the main program from the MIX L&R.
MONO OUTPUT
Unbalanced JACK connector: sends out the sum of the MIX LEFT & RIGHT signals. This output can
be used for a sub-woofer or for a mono monitoring.
PHONES OUT
STEREO JACK headphone output connector: only stereo headphones with a minimum impedance of
200 Ohms should be connected to this output.
DSP FOOTSWITCH
JACK connector for the DSP FOOTSWITCH: allow a FOOTSWITCH to be used for MUTING of the
built-in DSP.
AMP IN
2 unbalanced JACK connectors: these two inputs can be used for connecting an external device (such
as, for example, another mixer or a musical instrument) directly to the LEFT & RIGHT GRAPHIC EQ and
POWER AMPLIFIER sections of the mixer. Inserting connectors into these jacks will disconnect the mixer
section from the GRAPHIC EQ and the POWER AMPLIFIER.
AMP MODE
Button for the selection of the POWER AMPLIFIER and GRAPHIC EQ working mode.
- MIX L&R mode: the two EQ and POWER AMP channels get the signal from the MIX LEFT & RIGHT.
The signal level is controlled by the MIX L&R fader.
- L&R / MONITOR mode: the LEFT EQ/POWER AMP channel receives the signal from the sum MIX
LEFT & RIGHT, while the RIGHT EQ/POWER AMP channel receives the signal form the MONITOR send.
The signal level is controlled respectively by the MONO fader and by the MONITOR fader. This mode
allows the built-in amp to be used also for the monitors amplification.
AMP LEVEL
Built-in POWER AMP input level controls.
If you need to use only the mixer section of the SWING 14P, is advisable to turn completely down both
the power amp input level controls.
MASTER section

8
MASTER section
MIX L&R
Fader for control of the
general volume: controls
the level of the signal
arriving from the input
channels and sent to the
main MIX L&R output, to the
TAPE OUT and to the built-
in amplifier.
MONO
Fader for control of the
MONO output level: this
control is POST-MASTER,
i.e. the level of the signal
depends on the position of
the MIX L&R fader.
NOTE: the MONO fader is
used also for the control
of the summed MIX L&R
signal sent to the POWER
AMP LEFT channel when L&R / MONITOR mode i selected. Also in this case, the MIX L&R fader
should be open.
SUBWOOFER LPF 75Hz
LOW-PASS FILTER ON/OFF switch: allows to insert a 75 Hz low-pass filter on the MONO output. The
LPF can be used when a sub-woofer without internal filtering is connected to the MONO output.
MONITOR
Fader for controlling the level of the MONITOR output.
DSP
Fader for controlling the level of DSP on the MIX L&R main outputs.
DSP TO MON
Pot for controlling the level of the DSP to the MONITOR output.
PHONES LEVEL
Pot for controlling the level of the HEADPHONES outputs.
MONITOR DSP MIX L&R MONO
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
3
10
20
30
40
5
0
OFF
ON
125 Hz
SUB-WOOFER
LPF
100100
DSP TO MONITOR PHONES LEVEL

9
STEREO 9-BAND
GRAPHIC EQ
Nine mini-slider for the
GRAPHIC EQ control.
The GRAPHIC EQ can be
used to regulate the overall
mixer frequency response, in
order to control the tone of the
main sound system and/or the
recording. The nine mini-
sliders give 12dB boost or cut.
EQ ON/OFF
EQ ON/OFF SWITCH.
OUTPUT/SOLO LEVEL
12-LED BARGRAPHS.
Allows the visualization of the signal assigned to the HEADPHONES output by the SOLO buttons or by
the selection buttons (see point 28).
The LEDs are of three different colors:
• green = show the normal operative level of the signal (from -30 to +4 dB);
• yellow = show a high operative level of the signal (from +7 to +10 dB);
• red (CLIP) = show a too high signal level, near to the overload of the mixer output stage.
To ensure clean, distortion-free signals and to avoid damaging the components of your sound system,
try to avoid making the red LEDs lighting up repeatedly.
POWER LED
LED indicating when the mixer is switched on.
+48V LED
LED indicating when the +48V phantom power is switched
on: this LED lights up when the buttons on the connector panel
on the rear of the mixer are pressed.
PROTECT LED
Indicates the intervention of the built-in POWER AMP
protection system. The internal protection is activated to protect
the amplifier and the connected loudspeakers from damage due
to an electronic fault or improper usage. In this case, switch off
the mixer and check all the connections.
MASTER section
12563 250 8k 16k
+12+12
-12-12
00
4k2k1k500
BAND GRAPHIC EQSTEREO 9
OFF
ON
+48V PWR
PROTECT
LEVEL
SET
OUTPUT/SOLO
LEVEL
CLIP
LR
30
20
10
7
4
2
0
2
4
7
10
SOLO
ACTIVE
PHONES SOURCE
MONITOR
MIX L&R
MONO
AFL
PFL
SOLO MODE

10
PHONES SOURCE
Button for the selection of the signal sent to the HEADPHONES output when there are no SOLO
switches pressed on the input channels.
a) MIX L&R: select the MIX L&R signal.
b) MIX B: select the MIX B signal.
c) MONITOR: select the MONITOR signal.
SOLO MODE
Allows to select if the listening and the visualization of the channels selected with the SOLO
buttons are PRE-FADER (PFL) or POST FADER (AFL).
SOLO ACTIVE LED
Indicates when at least one SOLO button is pressed on the input channels.
LEVEL SET LED
This LED lights when one or more SOLO button are pressed and the PFL mode is selected. This
is the typical SOLO mode used to set the input level of the channels.
MASTER section

11
DSP
DSP
The SWING 14P is fitted with a built-in DSP, including
128 high-quality REVERB and DELAY effects able to
reproduce accurately different kinds of ambients and to
enrich not only the voice, but also any kind of instrument.
The 128 PRESETS can be selected by means of two
16-position encoders. The first encoder selects the
BANK, while the second one selects 8 DIFFERENT
PRESETS for each bank. A PEAK LED, which lights
up when the input signal is near to the CLIPPING point,
and an ON/OFF button are also available.
The following table includes the list and the main
parameters of the 128 PRESETS available in the
internal DSP.
OFF
ON
18
7
6
5
4
3
2
1
8
7
6
5
4
BRIGHT REVERSE
DARK S/HALL
BRIGHT GATE
DARK L/HALL
BRIGHT PLATE 2
DARK S/ROOM
BRIGHT PLATE 1
DARK L/ROOM
BRIGHT L/ROOM
STEREO DELAY 1
BRIGHT S/ROOM
STEREO DELAY 2
BRIGHT L/HALL
MONO DELAY
BRIGHT S/HALL
MULTIEFFECT
(see below)
3
2
PEAK
1 SHORTER
2
3
4
5
6
7
8 LONGER
VARIATIONS
PRESETS
Preset Bank REV TIME (s) Bank REV TIME (s) Bank REV TIME (s) Bank REV TIME (s)
10.5 1.2 0.3 1.5
20.8 2.0 0.5 2.5
31.0 3.5 0.8 3.0
41.2 5.0 1.0 4.0
51.5 6.0 1.2 4.5
61.8 7.0 1.5 5.0
72.5 8.0 1.8 7.0
83.0 15.0 2.0 8.5
10.2 1.0 0.2 0.1
20.3 1.5 0.3 0.2
30.5 2.0 0.4 0.25
40.8 2.5 0.6 0.3
51.0 3.0 0.15 0.35
61.2 5.0 0.25 0.4
71.5 5.5 0.35 0.45
81.8 7.5 0.45 0.5
10.5 1.2 0.3 1.5
20.8 2.0 0.5 2.5
31.0 3.5 0.8 3.0
41.2 5.0 1.0 4.0
51.5 6.0 1.2 4.5
61.8 7.0 1.5 5.0
72.5 8.0 1.8 7.0
83.0 15.0 2.0 8.5
Preset Bank F.B. (%) Bank F.B. (%) Bank DEL TIME (ms) Bank Type
160 50 50 Regen
260 50 100 Ambient
360 50 180 Echo + Rev
460 50 200 Echo Cross.
560 50 350 2 Tap Stereo
660 50 400 3 Tap Pan
760 50 500 Multi Tap
860 50 650 Bypass
STEREO
DELAY 1 STEREO DELAY 2 MONO DELAY MULTI EFFECT
BRIGHT
GATE BRIGHT REVERSE
BRIGHT
PLATE 1 BRIGHT PLATE 2
DARK
SMALL
HALL
DARK
LARGE
HALL
DARK
SMALL
ROOM
DARK
LARGE
ROOM
BRIGHT
SMALL
HALL
BRIGHT
LARGE
HALL
BRIGHT
SMALL
ROOM
PRESET LIST
BRIGHT
LARGE
ROOM

12
Rear panel
Mixer on/off switch.
Power cord
Main fuse holder
In the event of breaking, always replace the fuse with same type and rating.
+48V
+48V Phantom power supply button: this button switches on the +48V power supply for all the MIC inputs
(XLR-F connector) of the MONO input channels and allows condenser microphones to be used on them.
When the PHANTOM power supply is switched on make certain that cables with BALANCED XLR
connectors are ALWAYS used to connect the microphones: this precaution is extremely important for
avoiding damage in the event of both condenser and normal (dynamic) microphones being used
simultaneously. Switch on the phantom power supply only after having connected the condenser
microphone to the input and only with the channel fader closed to avoid output signal peaks.
POWERED OUTPUTS
POWER AMP outputs: connect these outputs to the loudspeaker enclosures.
Be careful that the overall impedance of the speakers connected is not below 4 Ohms, because in this
case the amplifier could protect himself. Only use “power”cables (speaker enclosure cables), not “signal”
cables (screened cables used for instruments and microphones).
Rear panel

13
Connection cables
Connection cables
Balanced XLR-M
Unbalanced XLR-M
JACK power connector
RCA PIN
Unbalanced JACK
Balanced JACK
INSERT
connector

14
Connection example
Connection example
LIVE SET
MINIDISC
PLAYER
CH 11/12
DAT RECORDER
from TAPE OUT
VOCAL MIC
CH1,2,3&4
BRASS
CH 5
STEREO GUITAR
CH 13/14
STEREO KEYBOARD
CH 7/8
MIDI EXPANDER
CH 9/10
BASS
CH 6
MAIN P.A.
from L&R POWER OUTPUTS
STEREO
COMPRESSOR
to/from INSERT 1&2
AMPLIFIED
MONITOR
from MON OUT

15
Technical specifications
Technical specifications
SECTION LEVELS & DATA CONNECTORS
MONO INPUTCHANNEL
MIC input sensitivity
impedance from-10 to -60dB
4 kOhms XLR-F balanced
LINE input sensitivity
impedance from+10 to -40dB
10 kOhms JACK balanced
LO CUT 75 Hz, 18 db/oct. (CH 1-3)
HIGH ±15dB, @ 12kHz SHELVING
MID ±15dB from100 Hzto 8kHzPEAKING (CH 1-3)
±15dB @ 2.5kHz PEAKING(CH 4-6)
LOW ±15dB @ 80Hz, SHELVING
INSERT (CH 1,2 &4) sensitivity +4dB Stereo JACK
STEREO INPUT CHANNEL
LINE input sensitivity
impedance +4 / -10 dB
10 kOhms JACK balanced
HIGH ±15dB, @ 12kHz SHELVING
MID ±15dB @ 2.5kHz PEAKING
LOW ±15dB @ 80Hz, SHELVING
MASTER SECTION
MIX output output level
impedance +4dB
150 Ohms JACK balanced
MONOoutput output level
impedance +4dB
150 Ohms JACK balanced
MONITOR output output level
impedance +4dB
150 Ohms JACK balanced
AUX sends output level
impedance +4dB
150 Ohms JACK balanced
AUX inputs sensitivity
impedance -10dB
10 kOhms JACK balanced
AMP inputs sensitivity
impedance -10dB
10 kOhms JACK balanced
TAPE IN
OUT -10dB
-10dB RCA phono
HEADPHONES minimum impedance
output level 200 Ohms
180 mW Stereo JACK
DSP
A/D converters bit 18
D/A converters bit 18
Internal dynamics bit 18
PRESETS number 128
Effects HALL REVERB, ROOM REVERB, PLATE REVERB, GATE REVERB,
REVERSE REVERB, STEREODELAY, MONODELAY, CUSTOM DELAY
POWER AMPLIFIER
EIA outputpower
(1 kHz, THD 1%) 4 Ohms
8 Ohms 250 + 250 W
170 + 170 W 2 x JACK
Harmonicdistortion (THD) <0.05% @ 1kHz
PROTECTIONS Shortcircuit, currentlimit, thermal protection, DC protection atspeaker outputs,
power ON/OFF transient
GENERAL SPECIFICATIONS
Frequency response 20Hz - 20kHz, +1 / -2 dB
Hum&Noise -128dB Equivalentinputnoise -70dB Residualoutputnoise (SP OUT)
-97dB Residualoutputnoise (MIX OUT)
Crosstalk 60dB @ 1kHz, adjacent channelinputs
60dB @ 1kHz, inputto output
Power supply see label on the apparatus
Weight kg 18
Dimensions mm (WxHxD) 462x405x140
EQ
EQ

16
Block diagram
Block diagram

FEDERAL COMMUNICATIONS COMMISSION
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference in which case the user will be required to correct the interference at his
own expense.
CAUTION: Changes or modifications to this product not expressly approved by the
manufacturer could void the user’s authority to operate this product.
Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia
non è assunta alcuna responsabilità per eventuali inesatezze.
Tutti i diritti sono riservati e in questo documento non può essere copiato, fotocopiato, riprodotto per intero
o in parte senza previo consenso scritto della GENERALMUSIC S.p.A.
GENERALMUSIC si riserva il diritto di apportare senza preavviso cambiamenti e modifiche estetiche,
funzionali o di design a ciascun proprio prodotto.
GENERALMUSIC non assume alcuna responsabilità sull’uso o sull’applicazione dei prodotti o dei circuiti
qui descritti.
STAMPATO IN ITALIA
The information contained in this publication has been carefully prepared and checked. However no
responsibility will be taken for any errors.
All rights are reserved and this document cannot be copied, photocopied or reproducted in part or
completely without written consent being obtained in advance from GENERALMUSIC S.p.A.
GENERALMUSIC reserves the right to make any aesthetic, functional or design modification to any of its
products without prior notice.
GENERALMUSIC assumes no responsibility for the use or aoolication of the products or circuits
described herein.
PRINTED IN ITALY

Sales Division: 47842 S.Giovanni in Marignano (RN) – Via delle Rose, 12 – tel. [phone] – fax [phone]
Internet: http://www.lemaudio.com
