Lemon 020-T User manual

Manual
Detailed Table of Contents 2
1. Safety Precautions 3
2. Control elements and connections 4
3. Remote Control 6
4. Connecting and o erating the receiver 7
5. Gra hical User Interface (Menus) 15
6. Trouble-shooting 27
Technical data 28
Index (A-Z) 30
Digital
Terrestrial Receiver
Lemon 020-T
Lemon 030-T
Lemon 020-T
Lemon 030-T

2
Table of Contents
1. Safety Precautions .........................................................................................................
2. Control elements and connections ..............................................................................
3. Remote Control ..............................................................................................................
4. Connecting and o erating the receiver .......................................................................
4.1 Connections .............................................................................................................................
4.2 On/Off switch ...........................................................................................................................
4.3 Programme selection ..............................................................................................................
4.4 Volume control/Mute switch ...................................................................................................
4.5 TV/Radio o eration ..................................................................................................................
4.6 Switching between various audio channels (soundtrack) and subtitling activation ........
4.7 Za ing .....................................................................................................................................
4.8 Free-to-air and encry ted rogrammes .................................................................................
4.9 Programme lists .......................................................................................................................
4.10 Teletext/Videotext ..................................................................................................................
4.11 Calling u the Main Menu......................................................................................................
5. Gra hical User Interface (Menus) .................................................................................
5.1 Installation/Setu .....................................................................................................................
5.2 Parental Lock function ............................................................................................................
5.3 Slee -Timer .............................................................................................................................
5.4 Creating a list of ersonal favourite rogrammes ...............................................................
5.5 Sorting channels .....................................................................................................................
5.6 Electronic Programme Guide (EPG) .....................................................................................
5.6.1 Current Programme (Now/Next) ..........................................................................................
5.6.2 Calling u the EPG ...............................................................................................................
5.7 Reset (returning to default settings) ......................................................................................
6. Trouble-shooting ............................................................................................................
Technical Data
Index (A-Z 40)
3
4
6
7
7
8
8
9
9
9
11
11
12
13
14
15
15
19
21
22
23
24
24
24
26
27
28
30

3
1. Safety Precautions
This set-top box has been manufactured in accordance with international safety standards.
For your own safety, you should read the notes on safety precautions carefully, and take note
of them, before operating your new receiver.
For your own safety, lease be sure to follow these safety recautions:
Mains ower su ly: onnect the unit only to a mains power supply that has the following characteristics:
90-260 V A , 50-60 Hz
Connection to the TV set and video recorder: Here, too, the receiver must be disconnected from the
mains power supply before using a Scart cable to establish connections to the TV set and video recorder.
O timum location: Set up your digital receiver indoors, in an area where it is protected from lightning,
rain water and direct sunshine.Ensure a minimum distance of 5 cm around the apparatus for sufficient
ventilation. Ensure that the ventilation is not impeded by covering the ventilation openings with items, such
as newspapers, table-cloths, curtains, etc…
Do not place naked flame sources, such as lighted candles on the apparatus. Do not expose the apparatus
to dripping or splashing. Do not place objects filled with liquids, such as vases on the apparatus.
Do not o en the unit:Never open the casing, as you are in danger of electrocution!
Protect from humidity: Ensure that no humidity, dampness or liquid can get into the unit. You should
therefore also not position any liquids near the receiver. Do not use any liquid detergents, as these may
damage the unit, and may subject you to high-voltage shock.
Prevent intrusion of foreign matter: The receiver is fitted with small ventilation slits on the top and along
the sides to assist in circulating air. Small objects could fall into these slits, so please do not put any objects
on top of the receiver.
Ensure adequate ventilation: Never cover the ventilation slits on the unit casing. When in operation, the
digital receiver should be placed on a straight and solid base. It should not be placed in direct sunshine
nor too close to a heater or radiator. Ensure there is sufficient free space around the unit for free air
circulation.Use the apparatus only in moderate climates (not in tropical climates).
Protection from lightning: In case of thunderstorms, switch off the receiver, disconnect from the main
power supply, and disconnect the antenna cable from the unit. This will prevent your appliances being
damaged when there is a thunderstorm in your area.
Use only original arts and accessories: Use only original parts, or parts recommended by a specialist
retailer, as other parts may cause damage to the appliance, or bear the risk of personal injury. Non-
observance of this warning cancels the unit guarantee. Any repairs should only be carried out by qualified
specialist personnel. Take attention to the environmental aspects of battery disposal.
Disconnecting ower during extended absence: If the appliance is to be unattended for an extended
period of time, e.g. when you go on holidays, you should disconnect it completely from the mains
power supply.
Retain original ackaging material: Please retain the original packaging, should it be necessary at some
stage to return the unit.
The manufacturer undertakes no res onsibility for damage or injury caused by non-observance
of these safety recautions, or by ina ro riate handling of the a liance.

4
2. Control elements and connections
View of the front anel
Control elements on the front anel
Programme down key
Decreases the programme counter
Programme u key
Increases the programme counter
On/Off switch
Switches the receiver on or off
On/Off LED
Indicates whether the receiver is on or off
Infra-red sensor (Remote Control)
Receives signals from the remote control unit
Dis lay
Shows programme counter or time
1.
2.
3.
4.
5.
6.
Lemon 020-T
Lemon 030-T

View of the rear anel
Connections on the rear anel
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
VCR Scart
Facility for connecting a video recorder
TV Scart
For connection to TV set
Audio out uts (L/R)
inch analogue connections for connecting to a Hi-Fi system
RS-232 Data Interface
Serial interface for updates, etc.
ANTENNA IN
Terrestrial antenna input
RF LOOP OUT
Output of the terrestrial antenna signal -UHF channel for connection to the TV or to the RF LOOP
IN (recommended)
Mains ower connection
For connecting to domestic power supply (cable supplied)
Video connector
Digital audio out ut connector “coax”
Digital o tical Audio out ut
For connection to an HiFi system
RF LOOP IN
Input for a terrestrial antenna signal or connection to RF LOOP out (recommended)
RF OUT
Output of the terrestrial antenna signal -UHF channel
External ower su ly connection
For connecting to an external 10,5 – 14 V D , 1.0 A max power supply
5
Lemon 020-T
Lemon 030-T
DESIGNED AND DEVELOPED IN CE
Made in PRC
7
110
8913 3 4 11 12 5 6
1
8
9
734 56

EPG
Menu
TV
Exit
6
3. Remote Control
Function keys on the remote control unit
The keys on the remote control can be divided into groups:
-Function keys that directly control a specific function
(these keys have a double functionality according to the situation)
- Navigation keys
- Numeric keys 0-9
Batteries:
Batteries are required to operate the remote control unit (supplied with unit) To insert the batteries, open
the battery compartment cover on the rear of the remote control unit, insert the batteries (AA size, 2 x 1.5
Volt), and replace the compartment cover.
Spent batteries should not be discarded in your domestic refuse. In most countries, you are legally obliged
to ensure spent batteries are properly recycled. They can be disposed of either in special bins provided
in your community, or may be returned to any retailer who sells batteries.
Mute
Muting the loudspeakers (on/off)
Slee Timer
alls up the sleep timer switch
Teletext
This calls up the built-in teletext
decoder (only operational on TV
programmes providing teletext
or videotext)
Numeric keys 0-9
TV/red function key
Switch to TV reception, special
function in on-screen displays
Navigation (direction) keys
Used for navigating in the on-
screen displays (right, left, up,
down)
OK / Menu
onfirming a selection, calling
up the Main Menu
Last rogramme/yellow
function key
Direct jump back to last
programme viewed, special
function in on-screen displays
On/Off (Standby)
Switching the receiver on and off
Radio
Switch to radio reception
Audio - Subtitles A/B
Selecting audio channels
(language 1, language 2, etc.) or
activates the subtitles
EPG/green function key
alling up the electronic
programme guide, special function
in on-screen displays
Question mark/blue function key
Details about the active channel
1x press: programme information
2x press: detailed program
information
3x press: technical parameters
Exit
Quick exit from a menu page

7
4. Connecting and o erating the receiver
4.1 Connections
Your digital receiver provides a multitude of possible connections to other appliances. Here we list the
most important options available.
4.1.1 Connection to the terrestrial antenna
The digital receiver is connected directly to a terrestrial antenna on the ANTENNA IN connector (see page
4, connections on the rear panel item 8). , by means of a coaxial cable. This connection must be done
while the receiver is switched off.
4.1.2 Connection to the TV set
Digital receivers and TV sets are usually connected by means of a Scart cable. Simply connect the two
ends of the cable with the main socket on the TV set and with the TV socket on the receiver, respectively.
The Scart connection ensures that audio and video signals are transmitted to the TV set in optimum quality.
If your TV set is not equipped with a Scart socket: the receiver is also optionally obtainable fitted with a
built-in HF modulator. In this case, use an antenna (coaxial) cable to connect the RF output of the receiver
(socket “RF OUT”) with the antenna input socket of the TV set. In this case, it is also necessary to connect
together the RF LOOP OUT connector to the RF LOOP IN connector using a coaxial cable.
The digital TV programme currently being received is converted in the receiver to a UHF channel (channel
selectable via the installation menu), and is transmitted to the TV set via the antenna cable. The antenna
cable previously connected to the TV set should now be connected to the ANTENNA input socket of the
receiver (socket “ANTENNA IN“). In this way, the terrestrial antenna connection is looped through the
receiver. If you also have a video recorder connected to the terrestrial antenna cable, this terrestrial antenna
connection should run first from the receiver to the video recorder, and only from there to the TV set. As
in this case the audio and video signals have to be modulated for high-frequency transmission on a UHF
channel, signal quality is a little worse than when connection is made via a Scart cable.
4.1.3 Connection to a video recorder
Just as the TV set, the video recorder is connected to the receiver via a Scart connection. Use the “V R“
socket for this purpose.
4.1.4 Connection to a hi-fi system
The audio quality of digital TV and radio programmes can be enjoyed even more when reproduced through
a hi-fi system. To do this, use a R A cinch stereo cable to connect the sockets marked “Audio L/R“ on
the receiver to one of the inputs of your hi-fi system marked either “Line“, “Aux“, “Spare“ or “Extra“.
The receiver is also equipped with optical and electrical digital audio outputs, “Optical Digital Output” and
“Video/electrical digital audio” connectors. These can be used in order to connect the receiver to hi-fi
system supporting digital audio inputs.

4.2 On/Off switch
Press the On/Off key (Standby), on the remote control. The receiver is now ready for operation.
Now switch on your TV set, if it is not already switched on, and set it to an “AV“ programme
slot (“EXT“,”AV“, “External Source“, or similar).
When you have completed connecting the digital receiver to the terrestrial antenna and the TV set, as well
as to the video recorder and hi-fi system where applicable, you can now proceed to switch it on for the
first time. In order to do this, press the On/Off (Standby) key on the remote control. The receiver will now
be switched on. The receiver is now ready for operation.
To switch the unit off, press the Standby key.
4.3 Programme selection
4.3.1 Using the directional U /Down keys
You can move up or down the programme list one slot at a time by using the two
Up/Down keys on the remote control unit.
4.3.2 Using the numeric keys
If you want to select a programme directly, and you know its programme number,
then it is easiest to enter the programme by means of the numeric keys. As the
receiver is equipped to store several hundred programme, the programme number
always has three digits. However, you can also enter a number consisting of only
one, two digits. In this case, press the „OK/Menu“ key when you have entered the
number, in order to speed up the selection process.
4.3.3 Using the rogramme list
Press either the “TV“ or “Radio“ keys, depending on which programme category
you wish to choose. A programme list will now be displayed on-screen.
Use the up/down directional keys to navigate through
this list one programme slot at a time, backward or
forward.
Use the left/right directional keys to skip through the
list one page at a time, forward or backward. Press
the “OK/Menu“ key to view the selected programme.
The now/next program guide is shown under the
Mini TV when available.
The list can be dynamically sorted using the yellow
function of the remote (toggle between A..Z and
1..9 sorting).
8
Main TV
ZDF
ZDF-doku
ZTF Theaterkanal
3sat
Kika
Euros ort
EuroNews
CNBC
Nr
1
2
3
4
5
6
7
8
- Move √ - select Exit: Quit
Main TV List
Mini TV
Sort 123/ABC
now: Friends
16:30: The tonight show
TV
Menu

4.6 Switching between various audio channels (Soundtrack) and subtitling activation
Some TV broadcasters provide several audio channels or subtitles information, carrying
commentary in various European languages, to accompany the TV image. To use this facility,
press the “Audio - Subtitles A/B“ key.
A screen will be displayed with the ”Soundtrack”
and ”Subtitles” lists.
hoose the desired Audio Language and subtitle
and press ”OK/Menu” to select.
9
Main TV
ZDF
ZDF-doku
ZTF Theaterkanal
3sat
Kika
Euros ort
EuroNews
CNBC
Nr
1
2
3
4
5
6
7
8
- Move √ - select Exit: Quit
Main TV List
Mini TV
Sort 123/ABC
now: Friends
16:30: The tonight show
Switch List
Select Language
Audio
Soundtrack 1
Subtitle
None
4.4 Volume control/ Mute switch
The sound volume can be adjusted either using the remote control of your TV set,
or the remote control of your receiver (in the latter case, use the left/right
directional keys).
Use the “Mute“ key to switch off the sound temporarily. Press the key again to return
to the same sound level as set before.
4.5 TV/ Radio o eration
The DVB standard allows you to enjoy both TV and radio programmes in digital
quality. For ease of use these are listed separately in the receiver in the programme
lists “Radio“ and “TV“.
Press the “Radio“ key to switch to radio reception.
A programme list showing available radio
programmes will be displayed on screen.
Press the “TV“ key to return to viewing TV
programmes. A programme list showing available
TV programmes will be displayed on screen.
Menu
TV

4.6.1 Switching between various audio channels (Soundtracks)
Select the ”Soundtrack” list after pressing the
“Audio - Subtitles A/B“ key. Use the Up/Down
directional keys to select a specific audio channel,
and confirm by pressing the “OK/Menu“ key.
Press “Exit“ to exit this menu.
Unfortunately only very few TV programmes provide
additional audio channels, most are broadcasting a
stereo signal in one language only.
4.6.2 Activate/Deactivate a subtitle
Select the ”Subtitles” list after pressing the
“Audio - Subtitles A/B“ key. Use the Up/Down
directional keys to select a specific subtitling
language, and confirm by pressing the
“OK/Menu“ key.
Press ”Exit“ to exit this menu.
To deactivate a subtitling, choose the option “None”.
Unfortunately only very few TV programmes provide subtitling, most are broadcasting without any subtitling.
10
Switch List
Select Language
Audio
Soundtrack 1
Subtitle
None

11
14:35 - 15:29
15:30 - 15:54
15:04
126
Reallty TV
scrambled
BAator tluzoltAok
furcsa jAargAanyok
√ - Select Exit: Quit
Tuner Information
Exit
Signal Strength
Signal Quality
Program Namber 001
Program Name BBC TWO
Channel 69
Frequency (kHz) 858000
Tx Mode 2k
Guard Interval 1/32
4.7 Za ing
Various options exist to facilitate quick switching between programmes:
a) Fast za ing using the directional keys U /Down:
Press the directional Up key to select the next higher programme in the programme
list, or the directional key Down to select the next lower programme in the list.
b) Direct selection using the numeric keys:
As soon as a numeric key has been pressed, a small display field appears on
screen, which will display the selected channel number. A channel number may
consist of up to three digits. After a digit has been entered, the receiver will wait to
see whether any more digits are going to be entered. If no additional digits are
entered, the receiver will switch to the programme slot selected. This waiting period
can be avoided by pressing the “OK/Menu“ key immediately after the last digit has
been entered.
Exam le 1: You wish to select channel 1
Press “1“ on the remote control
The receiver will wait for 1 second to find out whether any more digits are to be entered
The receiver will then switch to channel 1
Exam le 2: You wish to select channel 12
Enter “1“ on the remote control, followed by “2“ within no more than 1 second of the first digit
The receiver will wait for 1 second to find out whether any more digits are to be entered
The receiver will then switch to channel 12.
4.8 Free-to-air and scrambled rogrammes
Whenever you switch to a different channel, programme
information will be displayed on the screen for a few
seconds. (Go to the Main Menu and the heading
“Installation/Setup“ then choose “Display settings” and the
item “Popup time“ allows to setup for how long this
information should be displayed.)
Where the channel provides EPG (TV guide) information,
you will also see on screen the name of the current as well
as the following programme. A bar graph will indicate what
portion of the current programme has already elapsed.
If there is no reception, in the top left-hand corner of the
screen “No Signal” is displayed.
Some digital TV and radio programmes are broadcast in
encrypted, or scrambled form. Where a programme cannot
be viewed either because the signal is encrypted, the
comment “scrambled“ will be displayed on screen.
You can get to the same on-screen menu by pressing the
“?“ key. Pressing this key again (second and third press)
will display more detailed information regarding the
programme currently selected. Press ”Exit“ to close this
window again.
Menu

12
Main TV
ZDF
ZDF-doku
ZTF Theaterkanal
3sat
Kika
Euros ort
EuroNews
CNBC
Nr
1
2
3
4
5
6
7
8
- Move √ - select Exit: Quit
Main TV List
Mini TV
Sort 123/ABC
now: Friends
16:30: The tonight show
4.9 Programme lists
In order to help you find your way around the several hundred TV and radio programmes available,
the programmes found during a hannel Search are stored in memory, and organized as
Programme Lists, with separate lists for TV and radio programmes. In order to view these lists,
press either the “TV“ or “Radio“ keys on the remote control, as appropriate. The relevant list will
then be displayed on screen.
Use the directional up/down keys to move from one programme to the next in these lists, then
press “OK/
Menu“ to switch to the selected channel.
You may use the directional left/right keys to move
forward or backward one page at a time in the
programme list. Press the “OK/Menu“ key to view
the selected programme.
TV

4.10 Teletext/Videotext
The teletext or videotext feature familiar from analogue TV programmes is also broadcast on
many digital TV programmes. The digital receiver is equipped to decode the teletext/video text
signal internally, and to display it on the TV screen.
Press the ”Teletext“ key to display the videotext or teletext of the programme
currently being viewed.
The teletext/video text will be displayed as an overlay on the screen over the
current TV image.
In order to view a specific page of teletext/video text, use the numeric keys to
enter the three-digit page number. The receiver is capable of storing a large
number of videotext pages in a temporary memory, which reduces waiting times
when calling up a new page. Enter “100“ at any time to return to the home page
of the teletext/video text pages of the TV programme being viewed.
You may use the directional keys Up/Down to page quickly through the complete
teletext/video text section of a particular TV programme. The benefit of the
temporary page storage function is of particular benefit when using this function
for fast page scanning.
13
Menu

14
4.11 Calling u the Main Menu
The receiver can now be individually configured, using
the on-screen menu display.
Press the ”OK/Menu“ key on the remote control. The
Main Menu will be displayed.
Now use the directional keys to select the line
“Installation/Setup“, and confirm by pressing the
“OK/Menu“ key.
In the sub-menu “Installation/Setup“ select the entry
“Display Settings“, and confirm by pressing the
“OK/Menu“ key.
17:00
9-4-02
Installation / Setu
Slee Timer
Parental Lock
Channel list Manager
TV Guige
Default Settings
Exit
Main Menu
Main Menu

15
The various on-screen displays available are described in detail in this chapter.
The actual on-screen displays generated by your receiver may differ slightly from
those shown here, as continuous updates of the software may alter the appearance
or even the structure of the displays.
Navigation within the on-screen dis lays is effected by means of the four
directional keys, by means of the “OK/Menu“ key, which is used to confirm
a selection, as well as in some cases by means of the colored function keys.
In each case you can exit from a age by ressing the ”Exit“ key.
Press the “OK/Menu“ key to call up the Main Menu. From here you can select the
various sub-menus:
5.1 Installation/Setu
This is the place to set the basic parameters of
your receiver.
5.1.1 Dis lay Settings
Dis lay Language: The on-screen display may be shown
in a variety of languages. Use the directional keys to
select the desired language, then confirm by pressing the
”OK/Menu“ key.
Dis lay Colour: If you would prefer to view the display
in a different colour, use the directional keys to select the
desired colour (Type 1, 2 or 3), and confirm by pressing
the “OK/Menu“ key.
Dis lay Trans arency: the transparency, too, can be
adjusted, i.e. the degree to which the TV image is visible
through the overlaid on-screen text display. Use the
directional keys to select the degree of transparency,
from 40% to 100%, then confirm by pressing the
“OK/Menu“ key.
Message Time: When switching between programmes,
for instance, a message is briefly displayed with
programme information. The duration of this message
being displayed can be set, from 1 to 9 seconds. Use the
directional keys to select the desired message time, then
confirm by pressing the “OK/Menu“ key.
5. Gra hical User Interface ( Menus)
17:00
9-4-02
Installation / Setu
Slee Timer
Parental Lock
Channel list Manager
TV Guide
Default Settings
Exit
Main Menu
Main Menu
Installation / Setu
Dis lay Settings
Audio / Video Settings
Time / Date
Channel Search
System information
Software u date
Exit
17:00
9-4-02
Exit
Dis lay Settings
Language Color Trans arency
English Ty e 1 10%
Deutsch Ty e 2 40%
Francais Ty e 3 60%
80%
Po u Time
1sec.
3sec.
6sec.
9sec.
- Move √ - select Exit: Quit
Preferred
Subtitle Subtitle
English
Deutsch
Francais
Nederlands
On
Off
Menu
Exit

16
5.1.2 Audio/Video Settings
Scart connectors: Depending on the type of
appliance connected, you can determine the type
of signal to be fed to the Scart connectors marked
”TV“. Use the directional keys to select from: VBS
( omposite/FBAS) or RGB (only for TV Scart connector) .
Screen size (as ect ratio): Use the directional keys
to select the appropriate picture format for your TV
set (4:3 or 16:9), then confirm by pressing the
“OK/Menu“ key.
Video/Audio out: The rear panel of the receiver
has got a inch connector which can be used either
to output a Video signal or a digital electrical audio
output signal. Activate the wanted output (see
connector 12 page 4).
Digital Audio out:The receiver is also equipped with two digital audio outputs (electrical and optical).
hoose one format, P M (normal stereo) or Dolby digital (A 3 ). When Dolby digital is chosen, the receiver
will automatically detect if A 3 sound is available and will activate it on the digital audio output, if no A 3
is available the digital Audio outputs will have a classic stereo P M signal.
RF Modulator (o tional): the receiver is also available equipped with a built-in RF modulator, which
provides the facility to output the currently selected TV programme via a UHF channel. Select the audio
frequency (5,5 MHz for PAL B/ /G/H, 6,0 MHz for PAL I as well as 6,5 MHz for PAL D/K/L). Then use the
numeric keys to enter the UHF channel on which the TV image is to be transmitted.
Test image (o tional): In order to find the optimum setting of the receiving channel at the TV set, a test
image can be generated.
Preferred Audio
Select in the lists the preferred Audio language, this will be automatically activated if available after
a zapping.
5.1.3 Time/Date
General Settings: If the “Automatic Time Setup“ (bottom right) is set to “On“, the receiver will receive the
digital clock time and date as broadcast by the digital TV programme providers, and will apply these. The
DVB standard will broadcast this in the GMT time zone. In order to display local time correctly, it may be
necessary to set a time offset, indicating the difference between local time and GMT (e.g. in Germany
daylight savings time in summer is + 2h, winter time s + 1h).
Clock mode: The time can be displayed in 12 or 24 hour format.
Automatic Time Setu : The receiver can either receive the current time via the digital TV programmes
(On), or it can calculate current time independently (Off). In this case, the current time must be selected
under “General Settings“ on this page use the “OK/Menu“ key), then the time must be entered manually
by using the directional keys.
- Move √ - select Exit: Quit
Exit
Audio / Video Settings
TV Scart Screen Video/Audio
out
CVBS 4 : 3
RGB 16: 9
RF Modulator
5.5 MHz
6.0 MHz
6.5 MHz
Channel 22
Digital
Audio Out
Stereo
Dolby
Digital
Video
Audio
size
Test Picture
On
Preferred
Audio
English
Deutsch
Francais
Nederlands

17
17:00
9-4-02
Channel Search
Channel Search
Auto Tune
Manual Tune
Exit
- Move - Change activate search Exit: Quit
Exit
Manual Tune
Channel 42
Frequency (kHz) 642000
Tx Mode 2k
Guard Interval 1/32
Auto mode YES
Signal Level / Strength
Signal Quality / Bit Error Rate
17:00
9-4-02
Auto Tune
Auto Tune
Add new services
Re lace existing services
Exit
5.1.4 Channel Search
New digital TV and radio programmes are added
sometimes, or existing programmes change their
frequency. If you wish to receive these programmes,
you must allocate them to specific programme slots in
the programme list, and store them in memory. The
hannel search functions are designed to assist you
in this activity, and there are various types of programme
search available.
Several procedures can be followed in order to initiate
a programme search. Press the “OK/Menu“ key to call
up the Main Menu, then using the directional keys select
the sub-menu “Installation Setup“, followed by “ hannel
Search“, confirming your selection in each case by
pressing the “OK/Menu“ key. Here you can decide
between the two options available, as described below.
5.1.4.1 Auto Tune
The Auto Tune scan function can be used to allow the
receiver to search for new programmes. In this case,
the entire frequency range is scanned.
Then, it is necessary to choose between “Add new
services” or “Replace existing services” options.
The “Add new services” deletes all the channels which
were in the memory and scan. The option “Replace
existing services” scans and add the new channels to
the existing list in the receiver.
5.1.4.2 Manual Tune
In case specific programmes cannot be found by means
of the automatic search, e.g. because the programme
broadcasting format does not comply with DVB
standards, you may employ a manual programme
search function.
In this on-screen display, you will have to specifically
input the broadcast channel/frequency, TX mode and
Guard interval if available (Auto mode field in mode
No). If the TX mode and guard interval are not known,
it is possible to setup Auto mode to Yes.
Press the yellow key on the remote control to activate
the search.

18
17:00
9-4-02
Tuner Information
Product Information
Exit
System Information
System Information
Product Information
Exit
√ - Select Exit: Quit
Product ID
Hardware Version
Software Version
Build Version
Software Build date
BootLoader Version
Tracing
7
3.0
1.2
606
20-02-2003
1.11.0
1441102115
√ - Select Exit: Quit
Tuner Information
Exit
Signal Strength
Signal Quality
Program Namber 001
Program Name BBC TWO
Service TV
Channel 69
Frequency (kHz) 858000
Tx Mode 2k
Guard Interval 1/32
5.1.5 System information
In the last category of the Installation/Setup display
you will find detailed technical information relating to
the programme currently being viewed, as well as to
the hardware and software of the receiver.
Tuner Information
The technical reception data of the programme currently
being received are displayed here:
Program Number: Number of the program in the
main list.
Program Name: Name of the program in the lists.
Service Ty e: Type of the program (TV, Radio or
Data Service).
Frequency: Frequency of the channel in kHz.
Tx Mode: Tx value of the channel (2k or 8k).
Guard Interval: The Guard interval value of the channel
(1/4, 1/8, 1/16 or 1/32).
Below this, you will see two bar graphs indicating
signal strength and signal quality.
Product Information
The sub-display “Product Information“ provides you
with all data relating to the hardware and software of
the receiver. Each unit has its own unique serial
number (Product ID). When making service calls it is
important to specify the hardware version applicable,
as the technician then knows exactly which
components, circuit boards, etc. have been used in
the unit.

PIN Code in ut
**
19
Activate PIN Code
Change PIN Code
Exit
17:00
9-4-02
Parental Lock
Parental Lock
Activate PIN Code
Change PIN Code
Exit
Parental Lock
Old PIN code
**
Activate PIN Code
Change PIN Code
Exit
Parental Lock
5.2 Parental Lock function
Not all TV and radio programmes are suitable for
listeners or viewers of all age groups. The receiver
therefore provides an active parental control (lock)
function, allowing you to block specific menu settings
or individual channels by means of a four-digit security
code (PIN or Personal Identification Number). It also
makes sense to block menu settings if you want to
prevent the receiver from being incorrectly programmed
by unauthorised persons. The standard functions such
as receiving programmes, EPG, Sleep Timer etc.,
remain fully functional without a PIN having to be
entered.
If no PIN code is activated (default setting), all receiver
functions and operations can be utilized without any
restrictions.
5.2.1 Activating the PIN code
Press the “OK/Menu“ key to call up the Main Menu,
then select the sub-display “Parental Lock“. Now select
the line “Activate PIN code“, and confirm by pressing
the “OK/Menu“ key.
You can now enter a four-digit PIN code to be used
in future as a parental lock. Press the “OK/Menu“ key
to confirm this number.
If the receiver accepts this PIN entry, you must recon-
firm this by means of the green function key and the
“OK/Menu“ key respectively. If the number is not
accepted, you must repeat the entry of the PIN code.
From this point on, all the display (menus) are
accessible only when the PIN is entered (see illustration
right).
5.2.2 Changing the PIN code
If you wish to change the PIN code, go to the display
“Parental lock“, and select the line “ hange PIN code“.
You will now have to enter both the previous and the
new PIN code.
If the receiver accepts the altered PIN code, you must
then confirm this by pressing the green function key,
resp. the “OK/Menu“ key.

20
Disable PIN Code
Change PIN Code
Deactivate Channel Blocking
Exit
17:00
9-4-02
Parental Lock
Parental Lock
17:00
9-4-02
Installation / Setu
Slee Timer
Parental Lock
Channel list Manager
TV Guide
Default Settings
Exit
Main Menu
Main Menu
Exit
Channel List Manager
Main TV
ZDF
ZDF-doku
ZTF Theaterkanal
3sat
Kika
Euros ort
EuroNews
CNBC
Lock / Unlock
Move a channel
Sort
Move a block
ab- removes station from list
Nr
1
2
3
4
5
6
7
8
5.2.3 Blocking individual channels
As soon as a PIN code has been activated in the
“Parental lock“ display, it is automatically possible to
also block access to individual programmes. In the
display “Parental lock“ you will now also see a line
“Programme access“, which you can use at a later
stage to lift the channel restrictions again at a
later stage.
The default setting provides unrestricted access to
all TV and radio programmes.
How to block individual channels:
Press the “Exit“ key to exit from the display “Parental
control“. You will find yourself in the Main Menu. Use
the up/down directional keys to select the entry “ hannel
list“, and confirm by pressing the “OK/Menu“ key. As
the parental lock function is already active at this stage,
you must now enter the PIN code, and confirm by
pressing the “OK/Menu“ key.
On the following display page you must select the
programme list in which you wish to block individual
programmes. Use the directional keys to go to the
relevant programme in the main list (left), then block
access to this programme by pressing the red
function key.
For as long as the parental lock is active, this programme
can only be viewed if the PIN is entered immediately
after the programme has been selected.
The red function key is also used if you wish to
remove the block on this channel at a later stage.
General deactivation of channel restrictions:
In order to remove completely the restrictions on
individual channels and on-screen displays, go to the
display „Parental lock“, select the line “Deactivate
channel blocking“ and enter the PIN code.
General deactivation of arental lock function:
In order to remove completely the parental lock function
in any form, go to the display “Parental lock“, then
select the line “Disable PIN code“, enter the PIN code.
With immediate effect, no PIN code will be required for
any of the functions of the receiver.
