Lennox MiniAir 10 Installation guide

Providing indoor climate comfort
MINIAIR / MINIAIR +
MINIAIR-IOM-0507-E
Installation, operating
and maintenance

IOM / MINIAIR-0507 1
SYMBOLOGY
ATTENTION
DANGER
a) HIGH RISK OFELECTRIC SHOCK
b) ATTENTION: AUTHORIZED PERSONNEL ONLY

2 IOM / MINIAIR-0507
INDEX
MiniAir
SECTION 1–PRESENTATION
1.1 Manual Presentation page 4
1.2 Unit Identification page 4
SECTION 2–TECHNICAL CHARACTERISTICS
2.1 Unit dimensions page 5
2.2 Unit technical data page 6
SECTION 3–TRANSPORTATION
3.1 Packing page 6
3.2 Transportation page 6
3.3 Checklist page 6
3.4 Storing page 6
SECTION 4–INSTALLATION &CONNECTION
4.1 Definition page 7
4.2 Safety Regulations page 7
4.3 Preliminary operations page 8
4.4 Choosing installation position page 8
4.5 Connecting accessories page 8
4.6 MINIAIR unit positioning page 9
4.7 Duct connection page 10
4.8 Hydraulic connection page 10
4.9 Electrical connections page 11
SECTION 5–PRE START CHECKLIST
5.1 Checks prior to initial Start-up page 12
SECTION 6–STANDARD MAINTENANCE
6.1 Monthly maintenance page 12
6.2 Yearly maintenance page 13
SECTION 7–TROUBLESHOOTING
7.1 Finding faults page 13
SECTION 8–SPARE PARTS
8.1 Spare part order page 14
SECTION 9–MATERIAL DISPOSAL
9.1 Material disposal page 14
MiniAir +
SECTION 10 –PRESENTATION
10.1 Manual presentation page 15
10.2 Machine identification page 15
SECTION 11 –TECHNICAL CHARACTERISTICS
11.1 General characteristics page 15
11.2 Accessories page 15
11.3 Packing dimensions page 16
11.4 Unit technical data page 17
11.5 Accessories technical data page 18
11.6 Possible positioning page 19
11.7 By-pass for de-frosting or free-cooling page 21

IOM / MINIAIR-0507 3
SECTION 12 –TRANSPORTATION
12.1 Packing page 21
12.2 Transportation page 22
12.3 Checklist page 22
12.4 Storing page 22
SECTION 13 –INSTALLATION &CONNECTION
13.1 Definition page 22
13.2 Safety regulations page 22
13.3 Preliminary operations page 23
13.4 Choosing place of installation page 23
13.5 Machine positioning page 24
13.6 Duct connection page 25
13.7 Hydraulic connection page 26
13.8 Electrical connection page 27
13.9 Installation of CVU & PCU accessories page 27
SECTION 14 –ELECTRICAL SCHEMES
14.1 MINIAIR+ 03-06 direct connection page 29
14.2 MINIAIR+ 03-06 connection with CVU speed control page 29
14.3 MINIAIR+ 03-06 connection with SKE & PCU control panel page 30
14.4 MINIAIR+ 10-14-19-25 direct connection page 30
14.5 MINIAIR+ 10-14-19-25 connection with CVU speed control page 31
14.6 MINIAIR+ 10-14-19-25 connection with SKE & PCU control panel page 31
14.7 MINIAIR+ 30 direct connection page 32
14.8 MINIAIR+ 30 connection with CVU speed control page 32
14.9 MINIAIR+ 30 connection with SKE & PCU control panel page 33
14.10 MINIAIR+ 40 direct connection page 33
14.11 MINIAIR+ 40 connection with CVU speed control page 34
14.12 MINIAIR+ 40 connection with SKE & PCU control panel page 34
SECTION 15 –PRE-START CHECKLIST
15.1 Checks prior to initial start-up page 35
SECTION 16 –STANDARD MAINTENANCE
16.1 Monthly maintenance page 35
16.2 Yearly maintenance page 36
SECTION 17 –TROUBLESHOOTING
17.1 Localisation of breakdowns page 37
SECTION 18 –MATERIAL DISPOSAL
18.1 Material disposal page 37

4 IOM / MINIAIR-0507
MINIAIR
SECTION 1–PRESENTATION
1.1 Manual Presentation
This instruction manual supplies the necessary information for the transportation, the installation, operation and
maintenance of the MINIAIR apparatus as supplied by the company LENNOX (from this point named as the supplier).
It supplies the user with as much information as is normally useful for a correct and secureinstallation of the unit.
Lack of observation of the details found within this manual, and an inadequate installation of the MINIAIR may cause the
withdrawal of the warranty supplied with the equipment.
Furthermore, the Supplier will not respond to any eventual damage, whether direct or indirect, caused by the incorrect
installation, or for damages caused by the installation being effectuated by inexperienced or unauthorised personnel.
Verify, upon acquisition, that the apparatus is complete and supplied as described.
Any eventual disputes must be presented in writing within 8 days from the reception of the goods.
1.2 Unit Identification
The MINIAIR Unit is provided with identification plate listing the following:
-Address of Constructor;
-“CE” Mark;
-Model;
-Serial Number;
-Maximum absorbed current “A”;
-Power supply voltage “V”;
-Power supply frequency “Hz”;
-Number of phases “Ph”;
-Date of fabrication;
-Unit Code.

IOM / MINIAIR-0507 5
SECTION 2–TECHNICAL FEATURES
2.1 Unit Dimensions
Model 10 20 25 30 40 50 60
2) W 710 1070 1400 1400 1680 1780 2000
L 390 390 390 390 390 480 480
H 850 850 850 850 850 960 960
 2 R ¾” ¾” ¾” ¾” ¾” 1” 1”
4 R ¾” ¾” 1” 1” 1” 1 ¼” 1 ¼”
6 R ¾” 1” 1” 1” 1 ¼” 1 ¼” 1 ¼”
1 20 20 20 20 20 20 20
X1 240 306 240 240 306 306 306
3) Y1 216 270 216 270 270 270 270
X2 - - 318 318 418 435 -
X3 - - - - - - 285
A1 670 1030 1360 1360 1640 1720 1940
A2 350 350 350 350 350 420 420
X 235 382 301 301 325 366 256
Y 136 82 136 82 82 160 160
Weight 5260 6070 7588 7890 96110 101120 120140

6 IOM / MINIAIR-0507
2.2 Unit technical data
Model 10 20 25 30 40 50 60
Airflow rate m3/h 1040 2150 2740 3360 3950 5070 6450
External static pressure () Pa 150 150 150 150 150 150 150
1 m sound pressure level dB (A) 52 55 55 57 58 57 59
Motor power W 147 350 2 x 350 2 x 350 2 x 350 2 x 420 3 x 420
Max. current A 1,9 3,0 2 x 3,0 2 x 3,0 2 x 3,0 2 x 3,8 3 x 3,8
Fan speeds 3 3 3 3 3 3 3
Protection grade IP 20 55 55 55 55 20 20
Isolation Class B F F F F B B
Electrical power supply V/ph/Hz 230 / 1 / 50
Model 10 20 25 30 40 50 60
N° G3 filter cells (356x293x48) 2 3 4 4 5 5 6
N° F6 filter cells (356x293x320) 2 3 4 4 5 5 6
() 4 row coil version at nominal airflow rate
SECTION 3–TRANSPORTATION
3.1 Packing
The MINIAIR units and their accessories are provided with adequate packing, that must stay intact until the moment of
installing.
The materials that are not required for technical motives are supplied in fitted packing fixed externally and internally to
the unit.
3.2 Transportation
For the lifting and transportation of the unit, use adequate equipment, according to the 89/391/CEE regulations and
successive modifications.
Each individual machine weight is listed in this manual.
Avoid any uncontrolled rotation.
3.3 Checklist
Upon reception of the apparatus, we suggest that a complete control is carried out, to verify that the unit is intact and
complete, and no damage has been sustained during transport. Any eventual damage revealed must be communicated
to the carrier, demonstrating the reserve clause within the transport documents, specifyingthe type of damage.
3.4 Storing
In case of long term storage, the apparatus must be kept free from dust, and away from areas susceptible to heat and
vibration.
The manufacturer declines any responsibility for any damage as a result of negligence or lack of protection from
atmospheric agents.

IOM / MINIAIR-0507 7
SECTION 4–INSTALLATION &CONNECTION
4.1 Definition
CLIENT–The client is the person, activity or the society, that has bought or hired the apparatus, and intends to utilise the
machinery for its intended use.
USER / OPERATOR –The User or Operator, is the actual person that has been authorised by the client to utilise the
apparatus.
TECHNICIAN –Defined as the person who has followed a relevant/specific course of study, and so is able to understand
the dangers derived from the use of the apparatus, and in turn, due to this, are capable of solving major dilemmas.
4.2 Safety Regulations
Qualified personnel must carry out the installation.
During the installation operation, use protective clothing, for example: glasses, gloves, etc. as indicated by
686/89/CEE and successive regulations.
During the installation operate in absolute security, pollution free air and in an area free of obstructions.
Respect the regulations in force in the country in which the apparatus is being installed. Specifically relative to
its use, and to the disposal of packing and products used for the cleaning and maintenance of the unit. Respect
the recommendations given by the producers of such products.
Before placing in function the unit, check the perfect connection of the various components and the internal
parts of the system.
Avoid at all costs human contact with moving parts and contact with the parts themselves.
Do not commence with servicing or cleaning of the unit, before the unit has been disconnected from the
main supply.
The maintenance and the substitution of damaged or consumed parts must be carried out only by specialised
personnel, following the indications found within this manual.
The Manufacturer declines any responsibility for
failure to respect the Safety Regulations, and the
prevention as described below.
Furthermore, the manufacturer declines any
responsibility for damage caused by the improper
use of the unit and/or modifications carried out
without proper authorisation.
Min 400 mm
Min 100 mm

8 IOM / MINIAIR-0507
Spare parts must correspond to the requirements specified by Manufacturer.
In case of dismantling of the unit, respect the anti-pollution regulations in force.
N.B. The installer and the user of the apparatus must take into account, and solve problems, connected with any other
type of risk that may occur to the unit. For example, risks derived from the entrance of foreign bodies, or risks due to the
presence of flammable or toxic gas.
4.3 Preliminary Operations
Check the perfect condition of the various components of the unit.
Control that contained within the packing, there are the installation accessories, and documentation.
Transport the packed section as close as is possible to the intended place of installation.
Do not place tools or weight on top of the packed unit.
4.4 Choosing installation position
Position the unit on a solid structure, that will not vibrate, and is capable supporting the weight of the machine.
Position the unit in a point where the condensation discharge may occur easily.
Do not position the unit in an area in which flammable gases, acidic or corrosive substances are present. They
may damage various components in an irreparable manner.
Allow a minimum amount of free space as indicated in the figure. This permits ease of installation and
maintenance.
4.5 Connecting accessories
1. Fix the angular fixing clamp
2. Place together the fixing modules
3. Pass the M8 x 25 screws through the adjacent holes and necessary washers (see diagram)
4. Screw the nut by hand
5. Tighten with an Allen key

IOM / MINIAIR-0507 9
4.6 MINIAIR unit positioning
The unit is equipped with anti-vibration support plates.
As follows are indications the various sequence of assembly:
1. Carry out the drilling of the ceiling, and fit the four M8 threaded bolts as indicated in the diagram.
2. Position the unit on the four bolts using the supplied fixing plates.
3. Block the unit tightening the fixing bolts.
i. Dimensions 10 20 25 30 40 50 60
A 745 1105 1435 1435 1715 1820 2040
B 820 820 820 820 820 922 922
To aid the regular flow of the condensation, it is advised to install the unit with a 3mm inclination towards the
condensation outlet.

10 IOM / MINIAIR-0507
4.7 Duct connection
The Ducts must be the correct dimension based on the functions of system and the air diffusion characteristics
of the unit fans. A mistaken calculation of the ducting will cause power loss or the intervention of any eventual
devices present on the system.
To prevent the formation of condensation and cut down the sound level it is advised to use internally lined
Ducts.
To avoid the transmission of machine vibrations into the environment, it is advised to fit an anti-vibration joint
between the fans and Ducts. The electrical continuity must be guaranteed between the Ducts and the apparatus
via an earth cable.
4.8 Hydraulic connections
The installation and connecting of the piping is an operation that must be done correctly, otherwise it may
compromise the performance of the system. At worst it may cause irreversible damage to the machine. These
operations are to be effectuated by qualified personnel.
The MINIAIR units are supplied with “female” mounted, GAS threaded water coils.
Extreme caution must be taken during the installation operation, to avoid damage.
The tube path must be studied in such a way to not create obstacles should an eventual extraction of unit coil or
filter be required.
Water inlet and outlet must occur allowing the thermal exchange in counterflow: follow the indications found on
theWATER INLET andWATER OUTLET plate.
Supply a lower valve for the emptying of the water contained in the coil.
Fix securely the tubes to the outside of the unit, so as to avoid offloading the weight onto the coil headers.
Oncethe connection has been followed, fix the external rubber seals against the panel to avoid passing of air.
The lining must just rest on the panel, to avoid the risk of burning.
Supply an interception valve to isolate the coil from the rest of the circuit in case of extraordinary maintenance.
Should the installation of the apparatus occur in areas with particularly cold climates, empty the system prior to
an extended period of inutilization.
4.8.1 Condensation outlet connection
The stainless steel condensation drip tray is provided with 20 mm outlet diameter.
The system of drainage must provide an adequate trap.
The dimensions and execution of the trap must guarantee that H 50 mm.
IMPORTANT: IT IS IMPORTANT NOT TO PLACE
IN OPERATION THE UNIT IF THE FAN OUTLETS
ARE NOT DUCTED OR NOT PROTECTED BY A
SAFETY NET ADHERING WITH REGULATION
UNI 9219 OR SUCCESSIVE.

IOM / MINIAIR-0507 11
The trap must have a tap for correct cleaning of the lower part, and must allow an easy disassembly.
The path of the condensation drainage tube must always have a gradient toward external.
Insure that the condensation run-off tube does not interfere with discharge of the unit.
4.8.2 Water humidifier connection
The evaporative pack section is feeded by water public network (no water pump inside); the feeding system must provide
a valve (supplied by the installer) for the adjustment of the water flow; an excessive quantity may overflow the driptray
system present in the system.
For the drainage of the water and the realisation of the trap, see previous paragraph; furthermore it is recommended to
not reduce the diameter of the drainage tube till the sewer outlet, so as to avoid overflow and nasty odours.
4.9 Electrical connections
Qualified personnel according to the supplied schemes must carry out the electrical connections at the control
panel.
Insure that the voltage and the frequency shown on the technical plate correspond to the connecting power
supply.
For the general power supply of the unit and its accessories, the use of adapters, multiple plugs and extension
leads is to be avoided.
It is the responsibility of the installer to insure that the installation of the unit is as close as possible to
the mains power supply, or sufficiently close to protect the electrical parts.
Connect the unit to an efficient power point, using the correct screws as supplied with the unit.
Before starting any operation, insure
that the general power supply has
been switched off.
Connect the unit and its accessories using
adequate wiring for the used power while
respecting the country regulations. The
dimension of the wiring must be enough to
support a voltage drop in start up phase lower
than 3% of the nominal one.

12 IOM / MINIAIR-0507
1 2
The electrical wiring diagrams of the ordered unit are supplied with it when delivered and they are related to the
real accessory selection.
SECTION 5–PRE START CHECKLIST
5.1 Checks prior to Start-up
Before turning on the apparatus verify the following:
Fixing of unit to ceiling;
Connection of ducts;
Correct condensation run-off;
Connection of mains supply;
Closing of all electrical clamps.
SECTION 6–STANDARD MAINTENANCE
It is the responsibility of the user to carry out all types of maintenance operations.
Only personnel previously trained and qualified may carry out maintenance operations.
Should the apparatus require disassembly, hand protection is required
6.1 Monthly maintenance
6.1.1 Filter section check
If the filter is dirty, open the lower panel door, removethe screws as seen in figure 1, remove filter door and remove the
filter from below (figure 2). For cleaning, utilise a vacuum cleaner or wash with normal detergent in warm water, dry well.
Remember to always fit the filter before re-starting the apparatus.
BEFORE FOLLOWING ANY TYPE OF
MAINTENANCE OPERATION, BE CERTAIN THAT
THE APPARATUS MAY NOT CASUALLY OR
ACCIDENTALLY BE CONNECTED TO THE
ELECTRICAL MAINS SUPPLY. THERFORE IT IS
NECESSARY TO SHUTDOWN THE UNIT’S
POWER SUPPLYAD PRIOR TO MAINTENANCE.

IOM / MINIAIR-0507 13
6.1.2 Bag filter section check
The soft bag filters are high performance type and require periodical checking, as a marked deterioration may occur
during usage, especially at the point where they are attached to the main frame. This is due to the continuous
deformation, and for the weight of the dust caught.
These filters are not recyclable, and any cleaning may only be carried a few times by turning the filter upside down.
Should it become necessary to substitute the filters, verify the condition of the sealing, and proceed with the substitution.
The bags full of dust must be removed with great care, or to achieve a safer operation, cover the air inlet area. This will
avoid the over-spill of dust inside the apparatus.
6.1.3 Coil check
Check that the Coil exchanger is clean and in a perfect condition so as to guarantee correct performance.
6.1.4 Water humidifier section check
A periodical cleaning of the drip tray is recommended by using steam (high pressure or similar) or specific cleaning
products. Alternatively, replace the evaporation pack, efficient working of which is fundamental to guarantee the air
quality.
The pack must be replaced when limestone build-up is found.
The evaporative pack must be fitted in its correct position, controlling the air direction through the apparatus and the
water flow on the filter.
Always check the cleaning and the efficiency of the outlet and the inlet of the water section.
6.1.5 Power supply check
Control that the power supply voltage falls within the prescribed limits.
6.2 Yearly maintenance
Check that all the electrical equipment, in particular the fixing of the electrical connections.
Check the tightness of all nuts, bolts, flanges and hydraulic connections that the vibrations of the machine may have
loosened.
SECTION 7–TROUBLESHOOTING
7.1 Finding faults
ANOMALY POSSIBLE CAUSE
The motor does
not run
Power supply not present
The thermostat switches are
not in their exact functioning
position
Material/foreign bodies
blocking moving parts
Loose electrical connections
Loss of
performance after
a period of
satisfactory
working
The filter and coil are dirty
The system is not correctly
balanced
Air present in hydraulic
system. Release with specific
valve.
Obstruction present in ducts

14 IOM / MINIAIR-0507
SECTION 8–SPARE PARTS
8.1 Spare part order
In the following table there are the codes of the unit components that might be replaced; the Customer must refer to
these codes for the possible spare part order. See 2.2 paragraph for the used quantity in the specific model.
Model
ii.
Sp
ar
e
pa
rt
10 20 25 30 40 50 60
Direct driven fan 03305021 AMF0000097 03305028 AMF0000040 AMF0000097 03305063 03305063
2-row water coil 03420192 03420193 03420105 03420105 03420106 03420199 03420202
4-row water coil 03420169 03420170 03420100 03420100 03420171 03420198 03420201
6-row water coil 03420194 03420195 03420102 03420102 03420196 03420150 03420200
G3 filter AMF0002466
F6 bag filter AMF0001743
SECTION 9–MATERIAL DISPOSAL
9.1 Material disposal
At the end of the productive life cycle, the MINIAIR Unit must be dismantled and disposed of respecting the operational
regulations present in its country of installation.
The materials that the unit is constructed of are:
-Aluzink sheet metal;
-Zinc-plated sheet metal;
-Aluminium;
-Copper;
-Polyester;
-Polyethylene;
-Inox Stainless Steel;
-Plastic.
18.2

IOM / MINIAIR-0507 15
MINIAIR+
SECTION 10 –PRESENTATION
10.1 Manual presentation
This instruction manual supplies the necessary information for the transportation, the installation, operation and
maintenance of the MINIAIR+ apparatus as supplied by the company LENNOX (from this point named as the supplier).
It supplies the user with as much information as is normally useful for a correct and secureinstallation of the unit.
Lack of observation of the details found within this manual, and an inadequate installation of the MINIAIR+ may cause
the withdrawal of the warranty supplied with the equipment.
Furthermore, the Supplier will not respond to any eventual damage, whether direct or indirect, caused by the incorrect
installation, or for damages caused by the installation being effectuated by inexperienced or unauthorised personnel.
Verify, upon acquisition, that the apparatus is complete and supplied as described.
Any eventual disputes must be presented in writing within 8 days from the reception of the goods.
10.2 Machine identification
The MINIAIR+ Unit is provided with identification plate listing the following:
-Address of Constructor
-“CE” Mark
-Model
-Serial Number
-Maximum Current absorbed in “A”
-Power supply voltage in “V”
-Power supply frequency in “Hz”
-Number of phases indicated with “Ph”
-Date of fabrication
-Gross weight in “Kg”
SECTION 11 –TECHNICAL CHARACTERISTICS
11.1 General characteristics
Completely removable aluzink plate side panels.
Panel thermal and acoustic insulation by means of polyethylene/polyester panels with a medium thickness of 20
mm.
High efficiency aluminium plate static type heat recuperators, with air flows separated by special seals.
UE3 efficiency air filters, which may be easily removed from the sides allowing their periodic cleaning.
Fan bodies mounted on anti-vibrators.
Double inlet centrifugal fans (for MINIAIR+03 single inlet fans) which may be removed from the sides for
periodic maintenance.
Multi-speed directly coupled electric motors..
To aid the electrical connections and ventilator control, a terminal block with a relay board is fitted.
Stainless steel condensation collecting tray, with condensation drainage towards the lower part
11.2 Accessories
Electrical reheating SKE
Water coil for reheating SKW
Regulation damper SKR
Speed selector CVU
Apparatus Control Panel PCU
Pressure operated soiled filter cut-off switch PSTD
Servomotor for damper regulations SSE
Anti-freeze thermostat TEG

16 IOM / MINIAIR-0507
11.3 Packing dimensions
Model 03 06 10 14 19 25 30 40
A (mm) 990 990 1150 1350 1450 1700 1700 1700
B (mm) 750 750 860 900 900 1230 1230 1230
C (mm) 270 270 385 410 470 490 530 630
L (mm) 127 164 240 240 240 306 339 339
H (mm) 112 100 218 270 270 270 297 297
L1 (mm) 275 275 330 337 337 502 502 502
H1 (mm) 153 153 267 267 327 347 387 487
D (mm) - - 230 230 280 305 305 405
E (mm) 120 197 225 241 230 323 308 308
F (mm) 135 171 238 224 284 304 331 431
G (mm) 195 195 222 239 239 321 321 321
- - G ¾ G ¾ G ¾ G ¾ G ¾ G ¾

IOM / MINIAIR-0507 17
11.4 Unit technical data
Model MINIAIR+
03 MINIAIR+ 06 MINIAIR+ 10 MINIAIR+ 14 MINIAIR+ 19 MINIAIR+ 25 MINIAIR+ 30 MINIAIR+ 40
Air flow m3/h 290 550 1000 1400 1900 2500 3200 4000
Available static pressure Pa 60 65 90 140 120 110 170 170
Liv. Sound pressure dB (A)
53 54 54 59.5 58 57,5 60,5 62
Fans MINIAIR+
03 MINIAIR+ 06 MINIAIR+ 10 MINIAIR+ 14 MINIAIR+ 19 MINIAIR+ 25 MINIAIR+ 30
Section 1.02
INIAIR+
40
Absorbed power W 2 x 45 2 x 65 2x 147 2x 350 2x 350 2x 350 2x 550 2x 750
Poles n° 4 2 4 4 4 4 4 4
Max current A 1,32 1,6 3 5,8 6,2 6 11,4 6,2
N° fan speed 2 2 3 3 3 3 3 2
Protection 20 44 44 55 44 55 20 55
Insulation Class B F F F F F F F
Power supply V/ph/Hz
230 / 1 / 50 400/3/50
Thermal recuperator (*) MINIAIR+
03 MINIAIR+ 06 MINIAIR+ 10 MINIAIR+ 14 MINIAIR+ 19 MINIAIR+ 25 MINIAIR+ 30 MINIAIR+ 40
Efficiency % 52,3 54,6 53,4 52,1 51,8 57,6 56 55,6
Capaicty recovered kW 1,34 2,57 4,6 6,2 8,4 12,3 15,3 19,4
Outlet temp °C 8,1 8,7 8,3 8,0 7,9 9,4 9,0 8,9
Filters(*) MINIAIR+
03 MINIAIR+ 06 MINIAIR+ 10 MINIAIR+ 14 MINIAIR+ 19 MINIAIR+ 25 MINIAIR+ 30 MINIAIR+ 40
Efficiency G3 G3 G3 G3 G3 G3 G3 G3
Frontal air speed m/s 1,7 3,6 2,9 4,1 4,5 3,8 4,3 4,3
Size mm 300 178
48
300
178
48
356
293
48
356
293
48
363
353
48
528
373
48
528
413
48
628
413
48
(*) Size valued in the following hypothesis: Ting. External =-5°C; T ambient 20°C ; nominal air flow.

18 IOM / MINIAIR-0507
11.5 Accessories technical data
11.5.1 Water coil for reheating
Section 1.03Coil code SKW 10 SKW 14 SKW 19 SKW 25 SKW 30 SKW 40
Geometry 25 22 25 22 25 22 25 22 25 22 25 22
Tubes per row N ° 14 14 16 17 17 21
Rows N ° 3 3 3 3 3 3
Fin pitch mm 2.5 2.5 2.5 2.5 2.5 2.5
Capacity KW 9.4 13.4 16.6 23.9 28.4 36.2
Outlet temp ° C 36 36.6 34.1 36.6 34.5 34.3
Air pressure drop Pa 65 64 85 62 85 92
Water pressure drop kPa 8 16 10 11 15 27
Size valued in the following hypothesis:
Water 70/60°C;
Air entrance temperature 8°C;
Nominal air volume.
11.5.2 Electrical reheating
Coil code SKE 03 SKE 06 SKE 10 SKE 14 SKE 19 SKE 25 SKE 30 SKE 40
Electrical coil 1 stage kW 2 4 4.5 6 9 12 12 12
Power supply V 230 230 400 400 400 400 400 400
Phases n° 1 1 3 3 3 3 3 3
Stage n° 1 1 1 1 1 1 1 1
Absorbed current A 8.7 17.4 6.5 8.7 13 17.3 17.3 17.3
Outlet Air Temp (+) °C 28.4 27.8 21.3 20.7 22 22.2 19.5 17
(+) Size valued with Ting air = 8°C and nominal air capacity.
