Lennox LGA Series Installation and operation manual

ã1998 LennoxIndustriesInc.
Litho U.S.A.
Page 1
Corp.9822-L12
LGA/LCA
Service Literature
3.0to6.0TON
10.5to21 kW
Revised 09/2001
LGA/LCA SERIES
TheLGA/LCA3,3.5,4,5and6ton(10.5,12.3,14,17.5and
21 kW)unitsareconfigureto orderunits(CTO)with a wide
selection of factoryinstalled options.The
LGA/042/048/060/072 gas/electricpackaged rooftop units
areavailablein78,000,92,000or125,000Btuh(22.85,27,or
36.6kW)heating inputs,withthe LGA036 available onlyin
78,000 heating input. Gasheatsectionsare designed with
Lennox’aluminized oroptionalstainless steeltube heatex-
changers.The LCAcooling packaged rooftop unitsare
equipped withthe samecooling sectionsasthe LGAunits.
Optionalelectricheatisfactory-orfield-installed in LCAunits.
Electricheatoperatesinsingle ormultiplestagesdepending
onthekWinputsize.7.0kWthrough30kWheatsectionsare
available.LGAand LCAunitshaveidenticalrefrigerantcir-
cuitswith 3,3.5,4,5 and 6 ton (10.5,12.3,14,17.5 and 21
kW)cooling capacities.LGA/LCAunitsutilize onecompres-
sor.
The LGAand LCAunitsare designed to acceptanyofsev-
eraldifferentenergymanagement thermostatcontrolsys-
temswithminimumfieldwiring.Factoryorfield provided
controloptions connect tothe unitwithjack plugs.When
”plugged in”the controlsbecome an integralpartof the unit
wiring.
Information contained inthismanual isintended foruse by
qualified servicetechniciansonly.Allspecificationsaresub-
ject tochange.Proceduresoutlined inthismanualare pre-
sented asarecommendation onlyand do notsupersede or
replacelocalorstatecodes.
If theunitmustbeliftedforservice,rig unitby attaching
fourcables totheholes locatedintheunitbase rail (two
holes ateachcorner).Refertotheinstallation instruc-
tionsfortheproper rigging technique.
Electric shock hazard.Cancause
injuryordeath.Before attempting to
performany service ormaintenance,
turnthe electricalpowerto unitOFF at
disconnectswitch(es).Unitmay have
multiplepowersupplies.
WARNING
!
LGA060 (5TON)SHOWN
LCA060 (5TON)SHOWN
Библиотека СОК 

Page 2
TABLEOFCONTENTS
Introduction Page 1...........................
SpecificationsPages3-4......................
ElectricalDataPages5-7......................
ElectricalHeatAccessoriesDataPage 8.........
BlowerDataPages9-11.......................
PartsArrangementPage 12....................
I-UNITCOMPONENTSPages14-32.............
ControlBoxComponentsPages14-16..........
Cooling ComponentsPages17-19..............
BlowerCompartmentPages19-22..............
GasHeatComponentsPages23-27............
ElectricHeatDataPages28-30.................
ElectricHeatComponentsPages31-32..........
II-PLACEMENTAND INSTALLATIONPage 33.....
III-CHARGINGPages33-34.....................
NormalOperating PressuresPages33-34.......
IV-STARTUP-OPERATIONPage 35-36............
Preliminaryand SeasonalChecks Page 35.......
Cooling Startup Page 35.......................
Heating Startup Page 36-37....................
SafetyorEmergency ShutdownPage 37.......
V-SYSTEMS SERVICECHECKSPages37-40.....
LGAHeating ServiceChecks Pages37-40.......
High Altitude Page 38.........................
Cooling ServiceChecks Page 40...............
VI-MAINTENANCEPages40......................
FiltersPage 40...............................
Lubrication Page 40..........................
SupplyAirBlowerWheelPage 40...............
Evaporatorand CondenserCoil Page 40.........
ElectricalPage 40............................
VII-ACCESSORIES Pages41-44...................
LARMFRoofMounting FramesPage 41.........
TransitionsPage 41...........................
Supplyand ReturnDiffusersPage 42............
LAOAD(M)OutdoorAirDampersPage 42........
LAREMDEconomizersPages42-43............
LAGED(H)GravityExhaustDampersPage 43....
LAPEFPowerExhaustFansPage 43...........
OptionalColdWeatherKitPages43-44..........
ControlSystemsPage 44......................
SmokeDetectorsPage 44.....................
BlowerProving SwitchPage 44.................
DirtyFilterSwitchPage 44.....................
IndoorAirQualitySensorPage 44..............
LP/Propane KitPage 44......................
VIII-WIRINGDIAGRAMS/OPERATIONSEQUENCE
LGA/LCA036/072 Pages45-48..............
LGA036/072 Pages49-50.....................
ThermostatPages51.........................
EconomizerPage 52..........................
ElectricHeatPages53-54.....................
