Lennox Elite series User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTALLATION
INSTRUCTIONS
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow your gas suppliers
instructions.
• Ifyourgassuppliercannotbereached,callthe
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
MODELS
POURVOTRESÉCURITÉ: Nepasentreposerniutiliser
d'essencenid'autrevapeursouliquidesinflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
•Ne pas tenter d'allumer d'appareil.
•Netouchezàaucuninterrupteur. Nepasvousservir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
•Evacuez la piéce, le bâtiment ou la zone.
•Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
•Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installationetservicedoitêtreexécutéparunqualifié
installeur,agencedeserviceoulefournisseurdegaz.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LESINSTRUCTIONSDONNÉDANSCETTENOTICEPOUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
B-VENT MULTI-OPEN
ELITE®SERIES
B-VENTED GAS FIREPLACES
P/N 850,008M REV. H 05/2004
This appliance may be installed in an aftermar-
ket permanently located, manufactured home
(USA only) or mobile home, where not prohib-
ited by local codes. This appliance is only for
use with the type of gas indicated on the rating
plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
sledoMtlovilliMsledoMcinortcelE
2-MNTSBE2-MNRCBE2-ENTSBE2-ENRCBE
2-MPTSBE2-MPRCBE2-EPTSBE2-EPRCBE
2-MNFPBE2-MNLCBE2-ENFPBE2-ENLCBE
2-MPFPBE2-MPLCBE2-EPFPBE2-EPLCBE
MNYABBEPNYABBEENYABBE
OTL Report No. 116-F-07-5
fire-parts.com

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Offset Venting
Vertical Venting
Figure 1
Millivolt Models -
Millivolt models come standard with the
manually-modulated gas valve; flame ap-
pearance and heat output can be con-
trolled at the gas valve. Input of millivolt
models is shown in the following table:
Electronic appliances are designed to operate
on natural or propane gas. An electronic inter-
mittent pilot ignition system provides safe,
efficient operation. External electrical power is
required to operate these units.
These appliances comply with National Safety
Standards and are tested and listed by Omni-
Test Laboratories (Report No. 116-F-07-5) to
ANSI Z21.50 - 2000 (in Canada, CSA 2.22 -
2000), and CAN/CGA-2.17-M91 in both USA
and Canada, as vented gas fireplaces.
These appliances may be used for bedroom
installations in the United States and are
listed accordingly. These units may not be
installed in bedrooms in Canada.
Installation must conform to local codes. In the
absence of local codes, installation must com-
ply with the current National Fuel Gas Code,
ANSI Z223.1. (In Canada, the current CAN-1
B149 installation code.) Electrical wiring must
comply with the National Electrical Code ANSI/
NFPA 70 - (latest edition). (In Canada, the
current CSA C22-1 Canadian Electrical Code.)
TABLE OF CONTENTS
Packaging ........................................ page 2
Introduction ..................................... page 2
General Information......................... page 2
Location .......................................... page 4
Appliance and Vent Clearances ....... page 4
Vent Termination Clearances ........... page 4
Typical Installation Sequence .......... page 4
Detailed Installation Steps ............... page 5
Step 1. Framing ............................. page 5
Step 2. Routing Gas Line ............... page 5
Step 3. Install the Venting System . page 5
Fireplace Specifications ................... page 6
Step 4. Field Wiring ....................... page 10
Step 5. Connecting Gas Line.......... page 11
Step 6. Outside Air Kit Installation . page 12
Step 7. Installing Logs ................... page 13
Step 8. Checking Unit Operation ..... page 13
Step 9. Installing Glass Enclosure
Panels.......................................... page 13
Step 10. Burner Adjustment ............ page 14
Step 11. Spillage Test and Safety
Limit Switch Operation ................ page 14
Step 12. Hood Installation ............... page 15
Finishing Requirements ................... page 15
Cold Climate Insulation.................... page 15
Gas Conversion Kits.................. page 16
TYPICAL INSTALLATION
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATIONANDLISTINGSOFTHISUNIT.
INTRODUCTION
Note: Installation and repair should be per-
formedby aqualifiedservice person.The appli-
ance should be inspected annually by a quali-
fied professional service technician. More fre-
quent inspections and cleanings may be re-
quired due to excessive lint from carpeting,
bedding material, etc. It is imperative that the
control compartment, burners and circulating
airpassage waysof theappliance bekeptclean.
S'assurerque lebrùleuret lecompartiment des
commandes sont propres. Voir les instruc-
tions d'installation et d'utilisation qui
accompagnent l'appareil.
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front, back and/or side viewing surfaces of
the appliance.
These appliances are designed to operate on
naturalorpropanegasonly.Theuseofotherfuels
or combination of fuels will degrade the perfor-
mance of this system and may be dangerous.
This installation manual will help you achieve a
safe, efficient and dependable installation for
your appliance and vent system.
Please read and understand these
instructions before beginning your
installation.
WARNING: THESE FIREPLACES ARE
VENTEDDECORATIVEGASAPPLIANCES.
DO NOT BURN WOOD OR OTHER MATE-
RIAL IN THESE APPLIANCES.
GENERAL INFORMATIONPACKAGING
The assembled vented gas fireplace is pack-
aged with:
1 -onelog set, with one plastic bag of vermicu-
lite, is packaged in a carton located within
the firebox.
2 - oneenvelopecontainingthe literaturepack-
age, which consists of the homeowner's
manual,installation instructions,warranty,
8 (EBST-2), 4 (EBPF-2, EBCR-2, EBCL-2
and EBBAY) nailing flanges; envelope is
located in the control area.
3 - two hoods (EBST-2, EBCR-2, EBCL-2), or three
hoods (EBPF-2, EBBAY) taped to the top of the
fireplace.
4-one plastic bag of glowing embers and one
plastic bag of decorative volcanic stone
is located in the bottom compartment.
These vented gas fireplaces are designed for
residential applications. They must be installed
with approved type-B, 6 in. double wall vent
pipesystemsroutedtotheoutsideatmosphere.
The millivolt appliances are designed to operate
on either natural or propane gas. A millivolt gas
controlvalve withpiezo ignitionsystem provides
safe, efficient operation. If any optional accesso-
ries which require electrical power are being
installed, the electrical power must be provided
at the time of appliance installation.
sledoMtlovilliM
enaporPdnalarutaN sledoMsaG )H/UTB(etartupnI detaludom-yllaunaM
,2-MNFPBE,2-MNTSBE ,2-MPFPBE,2-MPTSBE PNYABBE,MNYABBE 005,73OT000,03
,2-MNRCBE,2-MNLCBE 2-MPRCBE,2-MPLCBE 000,43OT000,62
fire-parts.com

3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
* Each model has two burners. Each burner contains one
oftheseorifices.
sledoMcinortcelE
enaporPdnalarutaN sledoMsaG )H/UTB(etartupnI etaRdexiF
,2-ENFPBE,2-ENTSBE ,2-EPFPBE,2-EPTSBE ENYABBE 005,73
,2-ENRCBE,2-ENLCBE 2-EPRCBE,2-EPLCBE 000,43
ledoM .oN
*ezisecifirO noitavelE )sretem(teeF
.taN.porP
2-TSBE 2-FPBE YABBE 44#55# 0054-0 )2731-0(
2-RCBE 2-LCBE 74#"50.0
Table 1
Test gage connections are provided on the
front of the millivolt gas control valve (iden-
tified IN for the inlet and OUT for the mani-
fold side). A ¹⁄₈" NPT test gage connection is
provided at the inlet and outlet side of
the electronic gas control valve.
Minimum inlet gas pressure to these appliances
is5.0 incheswatercolumn(1.24kPa)fornatural
gasand 11.0incheswatercolumn(2.74 kPa)for
propane for the purpose of input adjustment.
Maximum inlet gas supply pressure to these
appliances is 10.5 inches water column (2.61
kPa) for natural gas and 13.0 inches water
column (3.23 kPa) for propane.
Donotusetheseappliancesifanyparthasbeen
under water. Immediately call a qualified, pro-
fessional service technician to inspect the ap-
pliance and to replace any parts of the control
system and any gas control which have been
under water.
Themillivoltappliancesaremanuallycontrolled
and feature a spark ignitor (piezo) that allows
theappliance'spilot gastobelitwithouttheuse
of matches or batteries. This system will still
function in the event of a power outage.
Installations at Altitudes of 0 to 4500 ft.-
Unitsare testedandapproved forelevations
of 0 to 4500 feet (0 to 1372 meters).
Installations at Altitudes above 4500 ft.-
For elevations above 4500 feet (1372
meters), install the unit according to the
regulations of the local authorities having
jurisdictionand,intheUSA,thelatestedition
ofthe NationalFuel GasCode(ANSI Z223.1)
or, in Canada, the latest edition of the
CAN1-B149.1 and .2 codes.
Table 1 shows the units' gas orifice size for
the elevations indicated.
WARNING: FAILURE TO COMPLY WITH
THEINSTALLATIONANDOPERATING IN-
STRUCTIONS PROVIDED IN THIS DOCU-
MENT WILL RESULT IN AN IMPROP-
ERLY INSTALLED AND OPERATING AP-
PLIANCE,VOIDINGITSWARRANTY. ANY
CHANGE TO THIS APPLIANCE AND/OR
ITS OPERATING CONTROLS IS DANGER-
OUS. IMPROPERINSTALLATIONORUSE
OF THIS APPLIANCE CAN CAUSE SERI-
OUS INJURY OR DEATH FROM FIRE,
BURNS, EXPLOSION OR CARBON MON-
OXIDE POISONING.
These appliances must be isolated from the gas
supplypipingsystem (by closing theirindividual
manual shut-off valve) during any pressure test-
ing of the gas supply piping system at test
pressures equal to or less than ¹⁄₂ psig (3.5 kPa).
These appliances and their individual shut-off
valves must be disconnected from the gas
supply piping system during any pressure test-
ing of that system at pressures in excess of ¹⁄₂
psig (3.5 kPa).
These appliances must not be connected to
a chimney or flue serving a separate solid
fuel burning appliance.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
the flu with headaches, dizziness and/or
nausea. If you have these signs, obtain
fresh air immediately. Turn off the gas
supply to the appliance and have it ser-
viced by a qualified professional, as it may
not be operating correctly.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OFHIGHSURFACETEMPERATURES.USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS
ON OR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LES MEUBLES, L'ESSENCE OU AUTRES
LIQUIDESÀVAPEUR INFLAMMABLES À
COTE DE L'APPAREIL.
Electronic Models -
Electronic models have a fixed rate gas valve.
Input of electronic models is shown in the
following table:
All Models -
Maximum manifold pressure is 3.5 in. w.c.
(0.87 kPa) for natural gas and 10 in. w.c.
(2.49 kPa) for LP/Propane gas.
WARNING: B-VENTAPPLIANCESARENOT
DESIGNED TO OPERATE IN NEGATIVELY
PRESSUREDENVIRONMENTS(PRESSURE
WITHIN THE HOME IS LESS THAN PRES-
SURES OUTSIDE). SIGNIFICANT NEGA-
TIVELY PRESSURED ENVIRONMENTS
CAUSED BY WEATHER, HOME DESIGN,
OR OTHER DEVICES MAY IMPACT THE
OPERATION OF THESE APPLIANCES.
NEGATIVE PRESSURES MAY RESULT IN
POOR FLAME APPEARANCE, SOOTING,
DAMAGE TO PROPERTY AND/OR SEVERE
PERSONAL INJURY. DO NOT OPERATE
THESEAPPLIANCESINNEGATIVELYPRES-
SUREDENVIRONMENTS.PROVIDINGAD-
EQUATE VENTILATION TO THE APPIANCE
FORCOMBUSTIONAIRWILLELIMINATEA
NEGATIVE PRESSURE ENVIRONMENT.
This appliance may be installed in an af-
termarket permanently located, manufac-
tured home (USA only) or mobile home,
where not prohibited by local codes. This
appliance is only for use with the type of
gas indicated on the rating plate. This ap-
pliance is not convertible for use with
other gases, unless a certified kit is used.
Cetappareilpeutêtreinstallédansunmaison
préfabriquée (É.-U. seulement) ou mobile
déjàinstallée àdemeure si les réglements
locaux le permettent.
Cet appareil doit être utiliséuniquement avec
les types de gaz indiqués sur la plaque
signalétique. Nepasl'utiliseravecd'autresgaz
sauf si un kit de conversion certifiéest installé.
These appliances are equipped with an inte-
gral combustion air door and actuator arm.
Combustion air kits are optional.Install as
shown in Step 6 on page 12.
Ne pas se servir de cet appareil s'il a étéplongé
dans l'eau, complètement ou en partie. Appeler
untechnicienqualifiépourinspecterl'appareil et
remplacertoute partie dusystème decontrôle et
toute commande qui ont étéplongés dans l'eau.
fire-parts.com

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TYPICAL LOCATIONS
**See-Through
(EBST-2)
Corner - Left
(EBCL-2)
Corner - Right
(EBCR-2)
Peninsula
(EBPF-2)
*When See-Through (EBST-2) is
installed with one side flush
with a wall,opposite wall must
not extend beyond either
viewing side of the fireplace.
*See-Through(EBST-2) -
one side flush with a wall
**When See-Through (EBST-2) is
installed in the middle of a room,
do not extend side walls beyond
either viewing side of the fireplace.
Bay
(EBBAY)
KCAB )mm31(.ni2/1 srecaps)mm0(.ni0
SEDIS )mm31(.ni2/1 srecaps)mm0(.ni0
SRECAPSPOT )mm0(.ni0
ROOLF )mm0(.ni0
mottoBmorF ottinUfo gnilieC )mm6261(.ni46
TNEV )mm4.52(.ni1
SECNARAELCECIVRES
GNIWEIV -SEDIS KCAB,TNORF( )EDISRO
)sretem9.0(.teeF3
Figure 3
Figure 2
APPLIANCE AND VENT CLEARANCES
The appliance is approved with zero clearance to
combustible materials on all sides (as detailed in
Table2) ,with thefollowing exception:When the
unit is installed with one side flush with a wall,
the wall on the other side of the unit must not
extend beyond the front edge of the unit. In
addition,when theunit is installedin themiddle
of a room, the side walls surrounding the unit
must not extend beyond the front or rear edge
of the unit. See Figure 2 .
LOCATION
In selecting the location, the aesthetic and func-
tional use of the appliance are primary concerns.
However, vent system routing to the outside
atmosphere and access to the fuel supply are
alsoimportant. Considerationshould begiven to
trafficways,furniture,draperies,etc.,duetohigh
surface temperatures ( Figure 2 ). The location
should also be free of electrical, plumbing or
other heating/air conditioning ducting.
The appliance should be mounted on a fully
supported base extending the full width and
depth of the unit. The appliance may be located
on or near conventional construction materi-
als. However, if installed on combustible mate-
rials, such as carpeting, vinyl tile, etc., a metal
or wood barrier covering the entire bottom
surface must be used.
Table 2
Vertical Vent Termination Clearances
Gas Vent Rule –Gas vent caps are not permit-
ted within 8 feet (2.4 mm) of a vertical wall or
similar obstruction. Gas vent caps that are
located 8' or more from a portion of a building
which extends at an angle greater than 45°
upward from the horizontal may terminate in
accordance with (Figure 3 ) , provided that in
no case shall any discharge opening on the
capbe lessthan 2'(610 mm)horizontally from
the roof surface (National Fuel Gas Code ANSI
Z223.1 (NFPA 54) 7.6.2) (CAN/CGA B149).
Flat to 6/12 1' 0" 0.3
Over 7/12 to 9/12 2' 0" 0.6
Over 10/12 to 12/12 4' 0" 1.2
Over 13/12 to 16/12 6' 0" 1.8
Over 17/12 to 21/12 8' 0" 2.4
Roof Slope
Feet Meters
Minimum Height
from Roof to Lowest
Discharge Opening
Note: Venting terminals shall not be recessed
into a wall or siding.
Multiple Terminations –These appliances may
vent adjacent to and at the same level with any
other gas appliances (including direct-vent ap-
pliances) provided that there is at least 2 ft.
(0.6m) between the proximal edges of the vent
caps. These appliances may be vented adja-
cent to a chimney vent servicing a solid fuel
fireplace provided the B-vent cap is at least 2 ft.
(0.6m) away from the nearest point of the
chimney opening.
Theseinstructions shouldbe usedas aguide-
line and do not supersede local codes in any
way.
Roof Pitch is X/12
12
X
Minimum Height from Roof
to Lowest Discharge Opening
TYPICAL INSTALLATION SEQUENCE
The typical sequence of installation follows,
however, each installation is unique resulting
in variations to those described.
See the page numbers references in the fol-
lowing steps for detailed procedures.
Step 1. (page 5) Construct the appliance
framing. Position the appliance within the
framing and secure with nailing brackets.
Step 2. (page 5) Route gas supply line to
appliance location.
Step 3. (page 5) Install the vent system
and exterior termination.
Step 4. (page 10) Field Wiring
a. Millivolt Appliances –The operating con-
trol switch is factory installed.
b. Electronic Appliances –Connect 120 Vac
electrical power to the appliance receptacle.
Step 5. (page 11) Make connection to gas
supply.
Step 6. (page 12) OutsideAir KitInstallation
Step 7. (page 13) Install the log set, ver-
miculite and ceramic fiber chunks.
Step 8. (page 13) Checkout appliance op-
eration.
Step 9. (page 13) Install glass enclosure
panels.
Step 10. (page 14) Burner Adjustment.
Step 11. (page 14) Spillage Test and Safety
Limit Switch Operation.
Step 12. (page 15) Install the hoods.
fire-parts.com

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Top Radiant
Panel
Top Bustle
Bottom
Bustle Control
Compartment
Access Panel
Unit Parts Identification
Figure 4
Step 3. Install the Vent System & Exterior
Termination -
In the United States, vent installation must
conform with local building codes. In the ab-
senceoflocal codes,ventsmust beinstalledin
accordance with the current edition of the
National Fuel Gas Code (ANSI-Z223.1).
In Canada, vent installation must conform
with local building codes. In the absence of
local codes, vents must be installed in ac-
cordance with the current edition of the Na-
tional Standard of Canada CAN/CGA-B149.1
or B149.2 Installation Code.
This gas fireplace must be vertically vented
using listed 6 in. type-B, double-walled vent
pipe and a listed vent termination.
Slip the first 6 inch (152 mm) section of B-
Vent over the fireplace flue outlet and secure
with four sheetmetal screws (# 8 or larger),
and install the remainder of the B-Vent to the
outside. Minimum overall height of the vent
system and appliance must be 10' (2.54 m)
vertical - no offset
(see Figure 6 on page 6 );
or 12' (3.7 m) when an offset up to 60
degrees from the vertical is used - this offset
may start at the fireplace flue collar (see
Figure 7 on page 6 ). The maximum overall
height of the vent system and appliance
should not exceed 40 feet.
Install the B-vent system in accordance with
the vent manufacturer's instructions.
CAUTION: THIS APPLIANCE CANNOT BE
VENTED HORIZONTALLY.
Note: Refer to the vent manufacturers in-
stallation instructions for variations of vent-
ing techniques. If common venting of sev-
eral units is contemplated, it should be dis-
cussed with an architect and the local Build-
ing Department.
Donot placeinsulation materialswithin 1in.
of the gas vent system.
Iftheappliance istobe elevatedabovefloor level,
asolidcontinuousplatformmustbeconstructed.
Headers may be in direct contact with the appli-
ance top spacers but must not be supported by
themornotchedtofitaroundthem. Allconstruc-
tionabovetheappliancemustbeselfsupporting,
DONOT usetheappliance forstructural support.
Step 2. ROUTING GAS LINE
3- Open the control compartment access
panel, by actuating the spring-loaded mag-
netic catches securing the panel, gently de-
pressing the outer top corners of the panel
until the catches "pop" the panel free and
allowing it to swing out and down to open.
4- Remove the bottom control compartment
accesspanelbycompressingthespring-loaded
hinge pin on the left side until it disengages
from the left cabinet panel hole. Pull the panel
away from the fireplace. See Figure 22 on
page 12.
5- Remove the modesty panel by pulling the
bottom right corner of the modesty panel out
slightly to disengage the snap-fit feature; lift
the modesty panel by the tab on the panel's
right end, pull the right end of the panel away
from the cabinet and then pull the panel diago-
nally out of the left side cabinet panel slots. (In
the above procedure, reverse the words "left"
and "right" for EBCR-2 models). Remove the
modesty panel carefully, so that none of the
wires become loose or disconnected.
Side Nailing Flanges
Thefireplaceshould besecuredto theframingat
the side(s) and/or rear of the unit using the
factory-provided nailing flanges. Install the nail-
ing flanges - 8 (EBST-2), 4 (EBPF-2, EBCL-2,
EBCR-2 and EBBAY) - as shown in Figure 5
using the existing screws. Position the fireplace
within the framing. When required, the flanges
may be bent 90 degrees by hand or with the
assistance of a hammer. Use wood screws to
secure the nailing flanges to the framing. See
Table 2 on page 4 for clearances of framing
members to cabinet parts in the nailing flange
area. The nailing flange itself is exempt from
these clearances.
Figure 5
Step 1. FRAMING
Frame these appliances as illustrated in
Figures 8 (EBST-2), 9 (EBPF-2), 10
(EBCL-2), 11 (EBCR-2) or 12 (EBBAY) on
pages 6 and 7.
All framing details must
allow for a minimum clearance to com-
bustible framing members as shown
in
Table 2 on page 4 .
DETAILED INSTALLATION STEPS
The appliance is shipped with all gas controls
and components installed and pre-wired.
1 - Remove the shipping carton.
2- Removethetopradiantpanel;
seeFigure4.
Floor Nailing Tabs
Secure the fireplace to the floor as shown in
Figure 5.
All appliances are factory-equipped with a flex-
iblegaslineconnectorand ¹⁄₂ inchshutoffvalve.
(See step 5 on page 11).
6- Open the latch (located in the center of the
unitfrontopening,underthefireboxfloor)secur-
ing the glass enclosure panel. Remove the panel
bytilting itoutward atthe bottomand lifting itup.
Set the door aside protecting it from inadvertent
damage.
See Figure 22 on page 12.
Route a ¹⁄₂" (13 mm) gas line as shown in
Figure 8 (EBST-2), 9 (EBPF-2), 10 (EBCL-2),
11 (EBCR-2) or 12 (EBBAY) on pages 6 and 7 .
Gas lines must be routed, constructed and
made of materials that are in strict accordance
with local codes and regulations.
Turn tabs down and secure to the floor with
8d nails or other appropriate fasteners on all sides
of the unit which do not have viewing glass panels.
EBST-2 SHOWN
(EBPF-2 - NO NAILING FLANGES ON END WITH GLASS PANEL) EBCL-2 SHOWN (FOR EBCR-2 VIEW, INTERCHANGE SIDES)
Remove these two screws and use them
when installing the nailing flanges.
Nailing
Flanges
fire-parts.com

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 6 Figure 7
10 ft.
Minimum
12 ft.
Minimum
60 degrees
max.
FIREPLACE FRAMING SPECIFICATIONS
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
*41¹⁄₂
(1054)
41¹⁄₂
(1054)
*This dimension can be reduced to 41 inches (1041 mm). This results in 0 in. (0 mm)
clearance between framing and unit framing spacers. (The 41¹⁄₂ in. dimension permits
easier fireplace installation, if unit is installed after framing is erected.)
22³⁄₄**
(578)
EBST-2
(See-Through)
inches (millimeters)
6¹⁄₄
(159)
Minimum Framing
Stud size is 2 x 4
**Based on 5/8”drywall. Use 23”for 1/2”drywall.
*41¹⁄₂
(1054)
40¹⁄₈
(1019)
EBPF-2
(Peninsula)
inches (millimeters)
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
6¹⁄₄
(159)
Minimum Framing
Stud size is 2 x 4
*This dimension can be reduced to 41 inches (1041 mm). This results in 0 in. (0 mm)
clearance between framing and unit framing spacers. (The 41¹⁄₂ in. dimension permits
easier fireplace installation, if unit is installed after framing is erected.)
22³⁄₄**
(578)
**Based on 5/8”drywall. Use 23”for 1/2”drywall.
Figure 9
Figure 8
fire-parts.com

7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
*41¹⁄₂
(1054)
40¹⁄₈
(1019)
24
(610)
*This dimension can be reduced to 41 inches (1041 mm). This results in 0 in. (0 mm)
clearance between framing and unit framing spacers. (The 41¹⁄₂ in. dimension
permits easier fireplace installation, if unit is installed after framing is erected.)
EBCR-2 (Corner-Right)
inches (millimeters)
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
9⁷⁄₈
(251)
Minimum Framing
Stud size is 2 x 4
Figure 11
FIREPLACE FRAMING SPECIFICATIONS CONTINUED
*41¹⁄₂
(1054)
40¹⁄₈
(1019)
*This dimension can be reduced to 41 inches (1041 mm). This results in 0 in. (0 mm)
clearance between framing and unit framing spacers. (The 41¹⁄₂ in. dimension permits easier
fireplace installation, if unit is installed after framing is erected.)
24
(610)
EBCL-2 (Corner-Left)
inches (millimeters)
6¹⁄₄
(159)
9³⁄₄
(248)
Optional Gas Line
Location Center of gas line
is 3 in. (76 mm) up from floor.
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
Minimum Framing
Stud size is 2 x 4
Figure 10
Figure 12
*41¹⁄₂
(1054)
40¹⁄₈
(1019)
*This dimension can be reduced to 41 inches (1041 mm). This results in 0 in. (0 mm)
clearance between framing and unit framing spacers. (The 41¹⁄₂ in. dimension permits easier
fireplace installation, if unit is installed after framing is erected.)
EBBAY (Bay)
inches (millimeters)
7 ⁵⁄₈
(194)
Gas Line
Location Center of gas line
is 3 in. (76 mm) up from floor.
Minimum Framing
Stud size is 2 x 4
23¹⁄₄
(591)
fire-parts.com

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
EBST-2 (See-Through)
41
(1041)
37
(940)
40¹⁄₈
(1019)
6⁷⁄₈
(175)
12
(305)
12 (305)
20¹⁄₁₆
(510)
(70)
FRONT VIEW
RIGHT SIDE VIEWLEFT SIDE VIEW
TOP VIEW
3 (76)
4 (102)
¹⁄₂ (13)
GAS INLET
GAS INLET
40¹⁄₈
(1019)
3 (76)
ELECTRICAL
INLETS
A - 6 (152) DIA. FLUE OUTLET
FRAMING SPACERS
(Top and Both Sides)
24
(610)
CONTROL
COMPARTMENT
ACCESS PANEL
FINISH WALL BRACKET
(Front and back edge of unit top)
1/2
(13)
DETAIL OF
FINISH WALL BRACKET
¹⁄₂ (13) 2³⁄₄
ELECTRICAL
INLETS
B
A
B - 8 (203) DIA. FLUE COLLAR
6⁷⁄₈
(175)
4⁹⁄₁₆
(116) 4⁹⁄₁₆
(116)
OUTSIDE AIR
SHUTTER
EBPF-2 (Peninsula)
12 (305)
20¹⁄₁₆
(510)
TOP VIEW
40¹⁄₈
(1019)
FRAMING SPACERS
(Top and Side)
FINISH WALL BRACKET
(Front, back, and left edge of unit top)
6⁷⁄₈
(175)
12
(305)
(70)
RIGHT SIDE VIEW
LEFT SIDE VIEW
3 (76)
(13)
DETAIL OF
FINISH WALL BRACKET
2³⁄₄
¹⁄₂
4⁹⁄₁₆
(116)
OUTSIDE AIR
SHUTTER
A - 6 (152) DIA. FLUE OUTLET
B - 8 (203) DIA. FLUE COLLAR
B
A
24
(610)
41
(1041) 37
(940)
¹⁄₂
(13)
FRONT VIEW
4 (102)
GAS INLET
ELECTRICAL
INLETS
CONTROL COMPARTMENT
ACCESS PANEL
Figure 13
Figure 14
FIREPLACE SPECIFICATIONS
fire-parts.com

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
EBCL-2 (Corner-Left)
41
(1041)
37
(940)
6⁷⁄₈
(175)
12
(305)
12 (305)
(13)
(70)
FRONT VIEW RIGHT SIDE VIEW
LEFT SIDE VIEW
TOP VIEW
3 (76)
4 (102)
40¹⁄₈
(1019)
GAS INLET
ELECTRICAL
INLETS
FRAMING SPACERS
(Top, Side and Back) (13)
DETAIL OF
FINISH WALL BRACKET
FINISH WALL BRACKET
(Front and left edge of unit top)
CONTROL COMPARTMENT
ACCESS PANEL
¹⁄₂
¹⁄₂
2³⁄₄
20¹⁄₁₆
(510)
OUTSIDE AIR
SHUTTER
4⁹⁄₁₆
(116)
B
A
A - 6 (152) DIA. FLUE OUTLET
B - 8 (203) DIA. FLUE COLLAR
(13)
¹⁄₂
24
(610)
6⁷⁄₈
(175)
12
(305)
2³⁄₄
(70)
3 (76)
(13)
41
(1041)
37
(940)
24
(610)
12 (305)
FRONT VIEW
LEFT SIDE VIEW
TOP VIEW
4 (102)
40¹⁄₈
(1019)
GAS INLET
ELECTRICAL
INLETS
FRAMING SPACERS
(Top, Side and Back)
(13)
DETAIL OF
FINISH WALL BRACKET
RIGHT SIDE VIEW
EBCR-2 (Corner-Right)
FINISH WALL BRACKET
(Front and right edge of unit top)
¹⁄₂
¹⁄₂
CONTROL COMPARTMENT
ACCESS PANEL
20¹⁄₁₆
(510)
OUTSIDE AIR
SHUTTER
A - 6 (152) DIA. FLUE OUTLET
B - 8 (203) DIA. FLUE COLLAR
B
A
Figure 15
Figure 16
FIREPLACE SPECIFICATIONS CONTINUED
fire-parts.com

10 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 17
FIREPLACE SPECIFICATIONS CONTINUED
Step 4. FIELD WIRING
Refer to Section A for millivolt appliances and
Section B for electronic appliances. The gas
valve is set in place and pre-wired at the
factory on both models.
A. Millivolt Wiring
(See Figure 18 ) –
1. Appliance-mounted ON/OFF burner control
switch (rocker switch) is factory installed in
the modesty panel. Optional wall-mounted
switch, thermostat, or one of the optional
remote control kits may also be used.
2. Ifwall-mounted ON/OFF controlor thermo-
stat is selected, mount it in a convenient
location on a wall near the fireplace.
Figure 18
Thermopile
TH
TP TH
TP
White
White
Black
Millivolt Wiring Diagram
If any of the original wire as supplied must be replaced,
it must be replaced with Type AWM 105°C –18 GA. wire.
*OPTIONAL WALL-MOUNTED ON/OFF
SWITCH OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
*Turn the appliance-mounted ON/OFF burner control
switch to the OFF position if an optional
control switch is installed.
Factory Wired
Field Wired
Schematic Representation Only
APPLIANCE-MOUNTED ON/OFF SWITCH
LIMIT SWITCH
3. Wire the control switch within the millivolt
control circuit using the 15 feet of 2 con-
ductor wire supplied with the unit.
Note: The supplied 15 feet of 2 conductor
wire has one end of each conductor con-
nectedtothe gas valve circuitandthe other
end of each conductor placed loose inside
the lower compartment of the unit.
Caution: do not connect the optional wall
switch to a 120V power supply.
4. If an optional control switch is installed,
turntheappliance-mountedON/OFFburner
control switch to the OFF position.
EBBAY (Bay)
12 (305)
20¹⁄₁₆
(510)
TOP VIEW
40¹⁄₈
(1019)
FRAMING SPACERS
(Top and Side)
FINISH WALL BRACKET
(Front, back, and left edge of unit top)
7¹⁄₄
(184)
12¹⁄₂
(317) (70)
BACK VIEW
LEFT SIDE VIEW
(RIGHT SIDE OPPOSITE)
3 (76)
2³⁄₄
5³⁄₄
(146)
OUTSIDE AIR
SHUTTER
A - 6 (152) DIA. FLUE OUTLET
B - 8 (203) DIA. FLUE COLLAR
B
A
(13)
DETAIL OF
FINISH WALL
BRACKET
¹⁄₂
24
(610)
41
(1041) 37
(940)
¹⁄₂
(13)
FRONT VIEW
4 (102)
GAS INLET
ELECTRICAL
INLETS
CONTROL COMPARTMENT
ACCESS PANEL
fire-parts.com

11
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Note:The gasvalve ON/OFFswitch isshown in
Figure20onpage11.Itisintegral withthegas
valve and should be set to the ON position.
B. Electronic Wiring
(also see figure 20 on page 11 )
Note: The electronic appliance must be con-
nected to the main power supply.
1. Route a 3-wire 120Vac 60Hz 1ph power
supply to the appliance junction box.
2. Open the control compartment access
panel, by actuating the spring-loaded
magnetic catches securing the panel,
gently depressing the outer top corners
of the panel until the catches "pop" the
panel free and allowing it to swing out
and down to open.
3. Removethe bottomcontrol compartment
access panel by compressing the spring-
loaded hinge pin on the left side until it
disengages from the left cabinet panel
hole. Pull the panel away from the fire-
place.
See Figure 22 on page 12.
4. Remove the modesty panel by pulling the
bottom right corner of the modesty panel
out slightly to disengage the snap-fit fea-
ture; lift the modesty panel by the tab on
the panel's right end, pull the right end of
the panel away from the cabinet and then
pull the panel diagonally out of the left
side cabinet panel slots. (In the above
procedure, reverse the words "left" and
"right" for EBCR-2 models). Remove the
modesty panel carefully, so that none of
the wires become loose or disconnected.
5. Removethe outletreceptacle by removing
the two securing screws. See
Figure 19.
(The left and right designations used here
are reversed in EBCR-2 applications.)
6. Install a field-provided strain relief in the
cabinet knockout opening for the protec-
tion of the power supply wires.
7. Connect the power supply wires to the
receptacle as shown in Figure 20 on
page 11.
8.Connect the ground supply wire and the
green wire attached to the outlet
receptacle's green ground screw.
9. Appliance-mounted ON/OFF burner con-
trol switch (rocker switch) is factory in-
stalled in the modesty panel. Optional
wall-mounted switch,thermostat, or one
of the optional remote control kits may
also be used.
10. Ifwall-mounted ON/OFFswitchor thermo-
stat is to be used, mount it in a convenient
location on a wall near the fireplace.
11. If the wall-mounted ON/OFF switch is to be
used, wire it to the the low voltage circuit
as shown in
Figure 20 on page 11.
Note: The supplied 15 feet of 2 conductor wire
has one end of each conductor connected to
the gas valve circuit and the other end of each
conductor placed loose inside the lower com-
partment of the unit.
12. After wiring is complete, reinstall the out-
let receptacle; install the field-provided
the metal junction box cover plate; rein-
stall the modesty panel.
OUTLET RECEPTACLE INSTALLATION
Figure 19
IMPORTANT: Ground supply wire must be
connected to the green wire attached to
theoutletreceptacle'sgreengroundscrew.
See
Figure 20 on page 11 . Failure to do so
will result in a potential safety hazard. The
appliance must be electrically grounded
in accordance with local codes or, in the
absence of local codes, the National Elec-
tricalCode,ANSI/NFPA70-(latestedition).
(In Canada, the current CSA C22-1 Cana-
dian Electrical Code.)
EBST-2, EBPF-2
AND EBCL-2 OUTLET RECEPTACLE SHOWN.
EBCR-2 HAS THE OUTLET RECEPTACLE LOCATED IN
THE LEFT CORNER OF THE UNIT
EBBAY OUTLET RECEPTACLE LOCATED IN
THE REAR LEFT CORNER OF THE UNIT
VIEW OF RIGHT BOTTOM CORNER OF UNIT
OUTLET RECEPTACLE
JUNCTION BOX
OUTLET RECEPTACLE
BOX SECURING SCREW
CABINET
RIGHT SIDE
PANEL
FIREBOX BOTTOM
Step 5. CONNECTING GAS LINE
Make gas line connections. All codes require a
shut-off valve mounted in the supply line.
Figure 21 on page 12 illustrates two methods
for connecting the gas supply. The flex-line
method is acceptable in the U.S., however,
Canadian requirements vary depending on lo-
cality. Installation must be in compliance with
local codes.
Figure 20
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA.
wire.
2. 120V, 60Hz –Less than 3 amps.
BK
Junction Box
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
R
WT
BL
G
W
120
VAC.
BK
W
Gas Valve
B
APPLIANCE-MOUNTED ON/OFF SWITCH
R
IGNITER
PILOT
ASSEMBLY
BK
G
Outlet Box Green
Ground Screw
Hot side of Outlet
Schematic Representation Only
*ON/OFF Switch (Integral
with Gas Valve)
White Wire
To Opposite
Side
**OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE
RECEIVER
*Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
**Turn the appliance-mounted ON/OFF burner control switch to
the OFF position if an optional control switch is installed.
LIMIT SWITCH
WT
G
fire-parts.com

12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 22
Figure 21 - GAS CONNECTION
These appliances are equipped with a gas flex
lineforuse(wherepermitted) inconnectingthe
unit to the gas line. A gas flex line is provided to
aid in attaching the B-vent appliance to the gas
supply.Thegas flexlinecan onlybeusedwhere
local codes permit. See
Figure 21 for flex line
description. The flex line is rated for both natu-
ral and propane gas. A manual shut off valve is
also provided with the flex line.
The gas control valve is located in the lower
control compartment. To access the valve
proceed as follows:
1- Openthecontrolcompartmentaccesspanel,
(Figure 22) by actuating the spring-loaded
magnetic catches securing the panel, gently
depressingtheoutertopcornersofthepanel
until the catches "pop" the panel free and
allowing it to swing out and down to open.
2- Remove the bottom control compartment
access panel by compressing the spring-
loaded hinge pin on the left side until it
disengagesfromtheleftcabinetpanel hole.
Pull the panel away from the fireplace. See
Figure 22.
3- Remove the modesty panel by pulling the
bottom right corner of the modesty panel
out slightly to disengage the snap-fit fea-
ture; lift the modesty panel by the tab on
the panel's right end, pull the right end of
the panel away from the cabinet and then
pullthe panel diagonallyout of theleft side
cabinet panel slots. (In the above proce-
dure, reverse the words "left" and "right"
for EBCR-2 models). Remove the mod-
esty panel carefully, so that none of the
wires become loose or disconnected.
Secure all joints tightly using appropriate
tools and sealing compounds (ensure pro-
pane resistant compounds are used in pro-
pane applications).
Step6. OutsideAir Kits–Optional outside make-
up air kits, Model FOAK-4 or FAOK-4LD, may be
used with these appliances. Refer to the installa-
tion instructions packaged with the air kits for
specific installation information. If used, the out-
side air kit must be installed before the fireplace is
framed and enclosed in the finished wall.
Outside air drawn into the fireplace supplies
air to the fire for combustion. Only one outside
air duct is necessary, if installed. See the
Figures on pages 8, 9 and 10 for the location
of the units outside air inlet.
If additional length of duct is necessary, pur-
chase locally available U.L. Class 0 or Class 1
metallic ducting. The duct may extend up to 50'
(15.24 m) in any direction.
Note: When installing the air duct vertically,
DO NOT terminate the duct closer than 3'
below the chimney top.
Outside combustion air ducting may be run
upwards or vertically through framing and
ceiling joists, with the hood installed through
an outside wall and 3' (1 m) below the termi-
nation. Ducting may also be run downward
through floor Joists and under the home to a
ventilated crawlspace not considered part of
the living area of the home.
Note: Do not terminate outside air kit in attic
space under any circumstances.
The millivolt control valve has a ³⁄₈"
(10 mm) NPT thread inlet port. The electronic
control valve has a ¹⁄₂" (13 mm) NPT thread inlet
port and is fitted with a ¹⁄₂" x ³⁄₈" (13 mm x
10 mm) NPT fitting.
Turn on gas supply and test for gas leaks using
a soapy water solution. Never use an open
flame to check for leaks.
A. Mix a 50% dish soap, 50% water solution.
B. Light the appliance (refer to the lighting
instructionsprovidedinthe Homeowner'sCare
and Operation Instructions).
C. Brush all joints and connections with the
soapy water solution to check for leaks. If
bubbles are formed, or gas odor is detected,
turn the gas control knob to the “OFF”posi-
tion. Either tighten or refasten the leaking
connection and retest as described above.
D. When the gas lines are tested and leak free,
observe the individual tongues of flame on the
burner. Make sure all ports are open and
producing flame evenly across the burner. If
any ports are blocked, or partially blocked,
clean out the ports.
CAUTION: NEVER LOCATE INLET WHERE IT
CAN BE BLOCKED BY SHRUBS, SNOW
DRIFTS, ETC. NEVER LOCATE INLET IN GA-
RAGE OR ANY AREA WHERE THERE IS AN-
OTHERFUELBURNINGAPPLIANCEORPROD-
UCTSEMITTING COMBUSTIBLEGASES SUCH
AS PAINT, GASOLINE, ETC. IN COLD CLI-
MATES, IT IS RECOMMENDED THE COMBUS-
TION AIR DUCT BE INSULATED.
The hand operated outside air control lever is
locatedon the right side(EBST-2, EBPF-2, and
EBCL-2) or left side (ECBCR-2) of the fire-
place opening.
See Figure 23 on page 13.
To open the outside air shutter, open the bottom
controlaccesspanel, reachintothe gapbetween
the firebox bottom and the modesty panel, and
pull the outside air control lever all the way out.
After completing the installation of the op-
tional outside air vent system, the outside air
control lever must be put in service and tested
to ensure proper operation before completing
any enclosure around the firebox. Failure to
do so may result in extensive and costly re-
work. Before the operation of the vent system
can be tested, the lever securing screw must
be removed. See Figure 23 on page 13.
Gas Stub
¹₂" x
³₈" Flare
Shut-Off Valve
³₈ Flex Tubing
³₈" NPT ₂ ³₈
Flare Fitting
³₈" Nipple
³₈"
Union
³₈" Close Nipple
³₈" Shut-Off Valve ¹₂
x ³₈ "
Reducer
Gas
Valve
Gas Flex Line Connector
Piezo Ignitor
Gas Valve
Modesty Panel
Control
Compartment
Access panel
ON/OFF
Switch
Hinge
Pin
fire-parts.com

13
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure26 -InstallingtheGlassEnclosurePanel
Glass
Enclosure
Panel
Latch
Lower Compartment Door and Hinge
Front Glass
Enclosure Panel
Firebox Floor
Bottom Vee-flange
(Glass Enclosure
Panel Frame)
Top Flange
(Glass Enclosure
Panel Frame)
Modesty Panel
EBST-2 SHOWN
WARNING: NEVER OPERATE THE APPLI-
ANCE WITHOUT THE FRONT GLASS EN-
CLOSUREPANEL IN PLACE AND SECURE.
WARNING:HANDLETHEGLASSWITHEXTREME
CARE! TEMPERED GLASS IS SUSCEPTIBLE TO
DAMAGE (SCRATCHES, FOR EXAMPLE) –
HANDLE GLASS DOOR (GLASS ENCLOSURE
PANEL) GENTLY WHILE REINSTALLING IT.
Figure 24
Figure 25
The top ³⁄₈" (10 mm) at the pilot generator
(thermopile) and the top ¹⁄₈" min (tip) of the
quick drop out thermocouple should be en-
gulfed in the pilot flame. The flame should
project 1" (25 mm) beyond the hood at all three
ports
(Figure 24) .
Millivolt Appliance Checkout
The pilot flame should be steady and, not lifting
or floating. Flame should be blue in color with
traces of orange at the outer edge.
Step7.INSTALLINGLOGS,VERMICULITE,
DECORATIVE VOLCANIC STONE AND
GLOWING EMBERS
The log set, with one plastic bag of vermicu-
lite, is packaged in a carton located within the
firebox. One plastic bag of glowing embers
and one plastic bag of decorative volcanic
stone is located in the bottom compartment.
Refer to the Homeowner's Care and Operat-
ing Instructions for detailed placement in-
structions for the log set, vermiculite, decora-
tive volcanic stone and glowing embers.
Step 8. CHECKING APPLIANCE OPERATION
With gas line installed run initial system check-
out before closing up the front of the unit.
Follow the pilot lighting instructions provided
in the Homeowner's Care and Operation In-
structions.Forpiezo ignitorlocationsee Figure
22 on page 12 (millivolt appliances only).
Note: Lighting instructions may also be found
on the pull out lighting instruction labels
attached to the gas control valve.
Step 9. INSTALLING GLASS ENCLOSURE
PANELS
Electronic Appliance Checkout
To light the burner, turn ‘ON’the modesty
panelmountedON/OFFswitchand turnthegas
control switch to the “ON”position. Ensure the
ignitor lights the pilot. The pilot flame should
engulf the flame rod as shown in
Figure 25 .
Replace logs after pilot inspection.
To light the burner; turn “ON”the modesty
panel mounted ON/OFF switch and rotate the
gas valve control knob counterclockwise to
the “ON”position.
When first lighting the appliance, it will take
a few minutes for the line to purge itself of
air. Once purging is complete, the pilot and
burner will light and operate as indicated in
theinstruction manual.Subsequent lightings
of the appliance will not require such purg-
ing. Inspect the pilot flame (remove logs, if
necessary, handling carefully).
1. Visually inspect the gasket on the backside
of the panels. The gasket surface must be
clean, free of irregularities and seated firmly.
2. Position the glass enclosure panel in front
of the firebox opening at a 45 degree angle and
engage the top flange over the lip at the top of
the firebox opening.
See Figure 26.
3. Swing the glass enclosure panel down and
back. Ensure the gasket seats evenly as the
panel draws shut. Engage the Vee-flange at
the bottom of the panel with the latch; then
close the latch to secure the panel.
4. After installing the front glass enclosure
panel, reinstall the modesty panel by inserting
thetongues on theleft side ofit into theslots on
the left side cabinet panel. Swing the right side
of the modesty panel towards the unit. Engage
the hook on the right side of the modesty panel
with the right side cabinet panel slot. Gently
press the bottom right corner of the modesty
panel to engage the snap-fit feature.
(The left and right designations used here
are reversed in EDCR-2 applications.)
5. After reinstalling the modesty panel, reinstall
the bottom control compartment access panel
by inserting the right side locating pin into the
right side cabinet panel and then the left side
spring-loaded pin into the left side cabinet panel.
Figure 23
Operate the actuator through several cycles
including the closed position. Ensuring proper
operation and freedom of movement. Return
the actuator arm to the closed position.
Outside Air Control Lever
and Securing Screw Location
(EBST-2, EBPF-2 and EBCR-2 Units Shown)
Theoutsideairshuttershouldbefullyopenwhen
the fireplace is in use and completely closed
when the fireplace is not being used. Closing it
whennotinusewillpreventoutsidecoldairfrom
entering the dwelling.
To access the label, see the procedure on the
previous page described for accessing the gas
control valve.
MILLIVOLT
Thermocouple
Hood Ignitor Rod
³⁄₈" Min
(9 mm)
Thermopile
Pilot
Nozzels
ELECTRONIC
Proper Flame
Adjustment
Pilot
Nozzle
3/8 To 1/2 Inch
(9 mm to 13 mm)
Ground
Electrode
Flame Rod
Hot Surface
Igniter
Outside Air Control Lever with Stop Behind
Securing Screw
Outside Air Shutter in the
Closed Position
Control Compartment Access Panel
fire-parts.com

14 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
RENRUBNIAM GNITTESRETTUHSYROTCAF
sledoM saGlarutaN sehcni )mm(
enaporP saG sehcni )mm(
2-TSBE 2-FPBE 2-RCBE 2-LCBE YABBE
61/1)5.1(61/5)8(
Figure 27
Figure 28
*Note - Do Not Adjust the Factory-Set Position.
Each of the two air shutters (one for each
burner) are open the amount shown in
the table, below.
Orifice
*Air Shutter
Opening Burner
Venturi
Tube
Step 10. BURNER ADJUSTMENTS
Note - The air shutter for the burner primary air
openingis factory-set. Donot adjust thefactory-
setposition.Thefactory-setpositionisshown in
Figure 27.
Step 11. Spillage Test and Safety Limit
Switch Operation
Spillage Test
After appliance installation, perform this spillage
test to verify that proper venting conditions exist:
1- Place unit in its normally-operated con-
dition, that is, with the glass enclosure pan-
els in place.
2 - Close all doors and windows in the
room. Turn on all exhaust fans in the house.
3- Light the appliance.
4- Wait 15 minutes.
5- To check for venting action, start by
holding a smoke producing device within an
inch of one edge (side edge, not top or
bottom edge) of one glass enclosure panel.
The smoke should be drawn toward the edge
of the glass enclosure panel. Continue the
test by moving the smoke producing device
along the entire length of both side-edges of
the glass door. Repeat the test for all glass
enclosure panels.
6- If the smoke is not drawn towards the
edges of the glass door turn off the appli-
anceandcallaqualifiedservicetechnican.
Manually-Reset Safety Limit Switch
This appliance is equipped with a manually-reset blocked flue safety limit switch. Refer to Figure 28
for its location. If, during appliance operation, the flame goes out (independently of the burner on/
off wall switch), it may be due to the operation of this safety limit switch. First allow the appliance
to cool, then reset the safety switch by pushing the red reset button on the back of the switch.
To access the blocked flue safety limit switch
refer to Figure 28:
A - To access the blocked flue safety switch when top radiant panel is not covered with non-
combustible material:
1- Lift up and remove top radiant panel/eyebrow assembly on the control side of unit.
2 - Reach between the cabinet side and the firebox side wall and locate the blocked flue safety
switch.
3- Push the red reset button on the switch.
The applilance should then relight and remain lit. If this does not occur, turn off the appliance and
call a qualified service technician.
B - To access the blocked flue safety switch when top radiant panel is covered with non-
combustible material:
NOTE - This procedure should only be performed by a qualified service technician.
Important - Turn electrical power off before beginning this procedure.
1- Lower bottom hinged panel on the control side of the fireplace. Remove the modesty panel
and glass enclosure panel as described on page 5, Steps 3, 4, 5 and 6 under "Detailed Installation
Steps" heading.
2 - Remove the side baffle securing screws (5) and then remove the baffle.
3- Remove the safety switch bracket securing screws (2), and pull the switch/bracket assembly
through the side panel slot.
4- Push the red reset button on the switch.
5- Reinstall the switch/bracket assembly.
6- Reinstall the side baffle.
7- Reinstall front glass door.
8- Raise the bottom hinged panel.
The appliance should then relight and remain lit. If this does not occur, check unit for a blocked
flue condition.
SAFETY SWITCH LOCATION (EBCL-2 SHOWN) EBST-2 and EBPF-2 Safety Switch Location Also as Shown;
EBCR-2 Location on the Left End of the Fireplace, EBBAY Location on the Rear of the Fireplace.
MANUALLY-RESET
SAFETY LIMIT SWITCH
FIREBOX SIDE BAFFLE
FIREBOX SIDE BAFFLE SECURING SCREW
FIREBOX
SIDE WALL
CABINET
SIDE WALL
TOP RADIANT PANEL
AND EYEBROW
BRACKET
SECURING SCREW
SAFETY SWITCH
fire-parts.com

15
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
12 (305) MANTEL
10 (254) MANTEL
8 (203) MANTEL
6 (152) MANTEL
4 (102) MANTEL
4
(102)
14
(356) 12
(305) 10
(254) 2 (51) MANTEL
TOP OF
APPLIANCE
6
(152)
NOTE - Hood shown as positioned
in louvered front model. The hood
position in the flush faced front model
is lower than shown.
8
(203)
MANTEL CLEARANCES
Inches (mm)
*Note - The side walls of mantels may protrude
beyond the front face of the fireplace a maximum
of 5 inches (127mm) at 0 inch clearance to the
sides of the fireplace.
Figure 29
COLD CLIMATE INSULATION
If you live in a cold climate, seal all cracks
around your appliance with noncombustible
material and wherever cold air could enter the
room. It is especially important to insulate
outside chase cavity between studs and under
floor on which appliance rests, if floor is above
ground level.
A hearth extension is not required with this appliance. If a hearth extension is used, do not block the
control compartment access panel. Any hearth extension used is for appearance only and does not
have to conform to standard hearth extension installation requirements.
Note: Combustible wall finish materials and/or surround materials must not be allowed to
encroach the area defined by the appliance front face (black sheet metal). Never allow
combustible materials to be positioned in front of or overlapping the appliance front face. See
Figures 30.
Non-combustible materials, such as surrounds and other appliance trim, may be installed on the appliance
frontfacewiththeseexceptions: theymustnotcoveranyportion of theglass or louvers; they mustnotcover
any portion of the top radiant panel and the air gaps surrounding the top radiant panel.
Vertical installation clearances to combustible mantels vary according to the depth of the mantel.
(See Figure 29) . Mantels constructed of non-combustible materials may be installed at any height
above the appliance opening; however, do not allow anything to hang below the hood.
Figure 30
FINISHING REQUIREMENTS
Wall Details
Complete finished interior wall. To install the appliance facing flush with the finished wall, position
framework to accommodate the thickness of the finished wall ( Figures 30 ).
Step 12. HOOD INSTALLATION
All of these appliances must have hoods installed prior to operating on all sides with glass
enclosure panels.
Onall clean face units,slide the hoodsinto the slots onthe lower edgesof the radiant panels( Figure 30 ).
Combustible
Finished Wall
Materials May
Touch Top of
Unit
This Area Must Remain Clear
of Combustible Materials
Top of Appliance
1" Min
(25 mm)
Combustible
Wall Framing
Spacer
Clean Face Models
Top of Door Frame
Hood must be installed as shown.
Radiant panel
Combustible Wall
Framing
fire-parts.com

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
tiKnoisrevnoCsaGenaporPoTlarutaN
.oNsledoMepyTtinU.oNgolataC
2-TSBE 2-FPBE YABBE
tlovillim56L58
cinortcele97L58
tiKnoisrevnoCsaGenaporPoTlarutaN
.oNsledoMepyTtinU.oNgolataC
2-RCBE 2-LCBE
tlovillim24M91
cinortcele44M91
tiKnoisrevnoCsaGlarutaNotenaporP
.oNledoMepyTtinU.oNgolataC
2-TSBE 2-FPBE YABBE
tlovillim27L58
cinortcele68L58
tiKnoisrevnoCsaGlarutaNotenaporP
.oNledoMepyTtinU.oNgolataC
2-RCBE 2-LCBE
tlovillim34M91
cinortcele54M91
GAS CONVERSION KITS
In Canada:
THE CONVERSION SHALL BE CARRIED OUT
INACCORDANCEWITH THE REQUIREMENTS
OF THE PROVINCIAL AUTHORITIES HAVING
JURISDICTION AND IN ACCORDANCE WITH
THE REQUIREMENTS OF THE CAN1-B149.1
AND .2 INSTALLATION CODE.
LA CONVERSION DEVRA ÊTRE EFFECTUÉE
CONFORMÉMENTAUXRECOMMANDATIONS
DES AUTORITÉS PROVINCIALES AYANT
JURIDICTION ET CONFORMÉMENT AUX
EXIGENCESDUCODED'INSTALLATIONCAN1-
B149.1 ET.2.
Gas conversion kits are available to convert
your appliance from the use of one type of gas
to the use of another. These kits contain all the
necessary components needed to complete
the task including labeling that must be affixed
to ensure safe operation.
Kitpartnumbers arelisted hereandthe follow-
ing steps detail the conversion procedure.
WARNING: THIS CONVERSION KIT SHALL BE
INSTALLED BY A QUALIFIED SERVICE AGENCY IN
ACCORDANCE WITH THE MANUFACTURER'S IN-
STRUCTIONS AND ALL APPLICABLE CODES AND
REQUIREMENTS OF THE AUTHORIZED AGENCY
HAVING JURISDICTION. IF THE INFORMATION IN
THESE INSTRUCTIONS IS NOT FOLLOWED EX-
ACTLY, A FIRE, EXPLOSION OR PRODUCTION OF
CARBON MONOXIDE MAY RESULT CAUSING
PROPERTYDAMAGE,PERSONALINJURYORLOSS
OFLIFE. THE INSTALLATIONISNOTPROPERAND
COMPLETE UNTIL THE OPERATION OF THE CON-
VERTEDAPPLIANCEISCHECKEDASSPECIFIEDIN
THEOWNERINSTRUCTIONSSUPPLIEDWITH THE
KIT.THEQUALIFIEDSERVICEAGENCYPERFORM-
ING THIS INSTALLATION ASSUMES RESPONSI-
BILITY FOR THIS CONVERSION.
AVERTISSEMENT: CET ÉQUIPEMENT DE CONVERSION
SERA INSTALLÉPAR UNE AGENCE QUALIFIÉE DE SER-
VICE CONFORMÉMENT AUX INSTRUCTIONS DU
FABRICANT ET TOUTES EXIGENCES ET CODES
APPLICABLES DE L'AUTORISÉS AVOIR LA JURIDICTION.
SI L'INFORMATION DANS CETTE INSTRUCTION N'EST
PASSUIVIEEXACTEMENT,UNFEU,EXPLOSIONOUPRO-
DUCTIONDEPROTOXYDEDECARBONEPEUT RÉSULTER
LE DOMMAGES CAUSER DE PROPRIÉTÉ, PERTE OU
BLESSUREPERSONNELLEDE VIE. L'AGENCE QUALIFIÉE
DE SERVICE EST ESPONSABLE DE L'INSTALLATION
PROPRE DE CET ÉQUIPMENT. L'INSTALLATION N'EST
PAS PROPRE ET COMPLÉTE JUSQU'ÀL'OPÉRATION DE
L'APPAREIL CONVERTI EST CHÉQUE SUIVANT LES
CRITÈRES ÉTABLIS DANS LES INSTRUCTIONS DE
PROPRIÉTAIRE PROVISIONNÉES AVEC L'ÉQUIPEMENT.
b. Remove the bottom control compartment
access panel by compressing the spring-
loaded hinge pin on the left side until it
disengages from the left cabinet panel
hole. Pull the panel away from the fire-
place.
See Figure 22 on page 12.
c. Remove the modesty panel by pulling the
bottom right corner of the modesty panel
out slightly to disengage the snap-fit fea-
ture; lift the modesty panel by the tab on
the panel's right end, pull the right end of
the panel away from the cabinet and then
pullthe panel diagonallyoutof the leftside
cabinet panel slots. (In the above proce-
dure, reverse the words "left" and "right"
for EBCR-2 models). Remove the mod-
esty panel carefully, so that none of the
wires become loose or disconnected.
d. Locate the latch at the top of the control
compartment.Todisengagethelatch from
the bottom vee-flange of the glass enclo-
sure panel, reach for the handles located
towards the back of the latch and pull the
handl down toward the front of the unit.
e. Swing the bottom of the door out and raise
it slightly to lift the top flange of the door
frame away from the appliance.
Step 2. Carefully remove the logs. Exercise
care as not to break the logs.
Step 3. Referring to Figure 31 on page 17 ,
remove the two burners.
Step 1. Turn off the gas supply to the appliance.
a. Openthecontrolcompartmentaccesspanel,
by actuating the spring-loaded magnetic
catches securing the panel, gently depress-
ingtheoutertopcornersofthepaneluntilthe
catches"pop"thepanelfreeandallowing itto
swing out and down to open.
fire-parts.com

17
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
FRONT OF FIREPLACE
REAR BURNER
FRONT BURNER
FIREBOX SUBFLOOR
BURNER POSITIONING
REAR BURNER
FRONT BURNER
PILOT
BURNER
Note: The burners are not identical. Position them so
that the circular burner ports run as shown. Note
especially the vertical run of ports relative to the pilot
burner. Bracket A on the rear burner will interfere
with the pilot burner if an attempt is made to install
the rear burner in the front burner’s position.
BRACKET A BURNER
PORTS
NOTE: INSTALL REAR BURNER FIRST,
THEN FRONT BURNER.
Pressure
Regulator
Remove
These
Components
Pilot
Orifice
Spring
Adjusting
Screw
Slotted
Cap
PSI
OFF
I
ON
CONTROL
IGNITE
Manifold
Pressure
Test Port
Inlet Pressure Test Port
Retaining
Clip
Ignitor
Assembly
Pilot
Assembly
Pilot
Orifice
Flare Nut
Figure 35
Figure 34
Figure 33
Figure 32
Figure 31
When reinstalling the ignitor assembly, use
extreme care to prevent damage and break-
age. Do not apply any leverage to the ignitor
assembly while restoring the retainer clip to
its original position.
Note: If the ignitor is damaged, a replace-
mentkit is available, orderCatalog Number
87L54.
Electronic Appliances
Step 7. Honeywell Electronic Valves - See
Figure 34 and the instructions provided with
the kit. Remove the slotted cap screw, o-ring,
pressure-regulating adjusting screw and
spring. Retain all parts for possible later use.
Install new components from the kit. Black
cap and red spring for propane gas units.
Silvercap andstainlesssteelspringfro natural
gas units. Before installing the cap, attach
manometer to the manifold side pressure test
fitting and adjust screw until pressure reads
3.5inches water column (0.87kPa) for natural
gas, and 10.0 inches water column (2.49 kPa)
for propane gas.
See
Figure 35 and replace the pilot orifice as
follows: Remove the ignitor assembly retainer
clip,and carefullyremove theignitor assembly.
Exercise extreme care to prevent damage to
or breakage of the ignitor assembly. Remove
the screw securing the pilot assembly to its
mounting bracket. Back off the flare nut at the
end of the pilot gas line to free the pilot assem-
bly from the gas line. Remove the pilot orifice
and replace it with the one provided with the
conversion kit. Reinstall the pilot assembly by
reversing the steps detailed here.
Step5. Attachmanometertothemanifoldside
pressure test fitting and verify manifold pres-
surereads 3.5 inches watercolumn (0.87 kPa)
for natural gas, and 10.0 inches water column
(2.49 kPa) for propane gas.
Step 6. Refer to
Figure 33 and remove the
pilot hood assembly to access the hexed pilot
orifice. Remove and replace the orifice with
the one provided with the kit.
Millivolt Appliances
Step 4. SIT Systems - Refer to
Figure 32 and
the instructions provided with the kit. Using a
Torx T20, remove and discard the three pres-
sure regulator mounting screws. Remove the
pressure regulator, spring, poppet, diaphragm
and bushing. Discard all removed compo-
nents. Ensure the rubber gasket installed on
the back of the replacement pressure regulator
is properly positioned and install the new pres-
sure regulator using the new screws supplied
with the kit. Tighten screws to 25 In. lb. torque.
fire-parts.com

18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 36
Step 9. Reassemble the remaining compo-
nents by reversing the procedures outlined in
the preceding steps. Use pipe joint compound
or Teflon tape on all pipe fittings before install-
ing (ensure propane resistant compounds are
used in propane applications, do not use pipe
joint compounds on flare fittings).
Step 10. Attach the conversion label provided
in the conversion kit to the rating plate on the
appliance. Figure37 shows allof thelabels for
all of the kits covered by this manual as shown
in the tables on page 17. Compare the label
provided in the kit being installed to the appro-
priate label shown in Figure 37 .
Step 11. Turn on the gas suply and test for
leaks as shown in
step 5 on page 11 .
* Each model has two burners. Each burner contains one
of these orifices.
Figure 37
THIS APPLIANCE HAS BEEN CONVERTED TO:
NATURAL GAS
Models: EDST-2,EDPF-2,EBBAY
INPUT BTU/HR –37,500
MANIFOLD PRESSURE –3.5"
ORIFICE SIZE –#44
Kit Catalog No.
85L72 and 85L86
Kit Catalog No.
85L65 and 85L79
THIS APPLIANCE HAS BEEN CONVERTED TO:
PROPANE/LPG
Models: EDST-2,EDPF-2,EBBAY
INPUT BTU/HR –37,500
MANIFOLD PRESSURE –10.0"
ORIFICE SIZE –#55
THIS APPLIANCE HAS BEEN CONVERTED TO:
NATURAL GAS
Models: EDCR-2,EDCL-2
INPUT BTU/HR –34,000
MANIFOLD PRESSURE –3.5"
ORIFICE SIZE –#47
Kit Catalog No.
19M43 and 19M45
Kit Catalog No.
19M42 and 19M44
THIS APPLIANCE HAS BEEN CONVERTED TO:
PROPANE/LPG
Models: EDCR-2,EDCL-2
INPUT BTU/HR –34,000
MANIFOLD PRESSURE –10.0"
ORIFICE SIZE –0.050 INCH
ledoM .oN
*ezisecifirO noitavelE teeF )sretem(
.taN.porP
2-TSBE 2-FPBE YABBE 44#55# 0054-0 )2731-0(
2-RCBE 2-LCBE 74#"05.0
All Models
Step 8.
(Refer to Figure 31)
A. Remove the orifice from the manifold
andreplaceitwiththeoneprovidedinthe
kit. See the following table for orifice
sizes for natural and propane models .
Figure 36 illustrates the orifice.
B. Install the burners as shown in
Figure 31 .
Theprimary airopening canbe adjustedby
removing the venturi tube air shutter se-
curingscrewandplacingitintheotherhole
provided nearby. The correct hole usage
forthis screwfor thegas beingused canbe
determinedbythe air shutter gap indicated
in
Figure 27 on page 14.
fire-parts.com

19
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
fire-parts.com

20 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Printed in U.S.A. © 2002 by LENNOX HEARTH PRODUCTS
P/N 850,008M REV. H 05/2004
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue •Orange, CA 92865
fire-parts.com
