Lenovo Moto Mod HASSELBLAD TRUE ZOOM User manual
TRUE ZOOM
en-GB, fr, de, it, es
1Attach your Moto Mod™
Attach your Moto Mod™
Align the camera lens on the back of your phone
with the Hasselblad True Zoom Moto Mod, and
then align the sides and bottom of the phone with
the Moto Mod until they snap together.
Note:
make sure that the connectors are clean
and dry. Also, remove your phone case if you use
one.
Caution:
before using your device, please read
the safety, regulatory and legal information at
the back of this guide.
Moto Mod Connectors
True Zoom_GSG_EMEA_68018258002A.book Page 1 Friday, Augus
t
2 At a glance
At a glance
•Poweron:
press the Power button to turn on
the True Zoom Moto Mod and extend the lens
•Zoomin:
use the Zoom dial for up to 10x
magnification with no loss in resolution
•Snapit:
press the Shutter button
Tip:
press the Shutter button halfway to
auto-focus, and then press it all the way to
take the photo. Press and hold for burst mode
Flash
Microphones
Two-stage
shutter
button
Power
button
Zoom
dial
Hand grip
Auto focus
assist
10x optical zoom
lens
True Zoom_GSG_EMEA_68018258002A.book Page 2 Friday, Augus
t
3Meet your viewfinder
Meet your viewfinder
Options
Hasselblad
modes
Select a Hasselblad mode.
Timer
Set a timer to 3 seconds or
10 seconds.
Flash
Set
On
,
Off
or
Auto-flash
.
Switch to front camera.
Swipe right for more
settings. Swipe left for
your photos.
Tap for
settings.
Switch to video,
panorama or
professional mode.
True Zoom_GSG_EMEA_68018258002A.book Page 3 Friday, Augus
t
4 Adjust settings
Adjust settings
Tap in the camera screen for these options:
To find more settings, swipe the viewfinder right.
Options
Professional
mode
Control all camera settings
manually.
Panorama
Take a wide- a n gl e s h ot . U s e
the on-screen guide to
slowly pan while you are
taking the photo.
Video
Ta ke a v i d e o.
Take a photo.
Options
Shutter
sound
Turn the shutter sound on or
off.
Storage
Choose a storage location for
your photos and videos (
Phone
or
SD card
).
Quick
capture
Launch your camera with two
twists of your wrist.
Location
Turn on to tag photos with a
location.
Photo size
Set the photo resolution.
True Zoom_GSG_EMEA_68018258002A.book Page 4 Friday, Augus
t
5Remove it
Remove it
Press the Power button
to turn off your True
Zoom Moto Mod
completely before you
remove it from your
phone.
After the camera lens
closes, detach the Moto
Mod from your phone
by placing your finger in the notch at the bottom
of the Moto Mod and pulling it away from your
phone.
Shutter type
Set whether to tap or
anywhere on the screen to take
the photo. When off, you have
to press the Camera Mod's
Shutter button to take a photo.
Confirmation
after shot
Choose whether to show your
photo after you capture it.
Use digital
zoom
Set digital zoom on or off.
Video
resolution
(rear camera)
Set the video resolution.
Quick tutorial
Learn more about your camera.
Options
True Zoom_GSG_EMEA_68018258002A.book Page 5 Friday, Augus
t
6 Tips & tricks
Tips & tricks
Looking for more?
• Other apps:
use your True Zoom Moto Mod
with any other app that would normally use
your phone camera, such as Facebook live
streaming (with 1080p video), Snapchat and
more
•Poweringon
: you can also twist your wrist
twice to turn on your camera app, which also
activates the True Zoom Moto Mod
• Closing the lens:
if your camera lens is open
when you detach the Moto Mod from the
phone, reattach it to close the lens
•Carrycase:
your True Zoom Moto Mod comes
with a carry case for storing it
True Zoom_GSG_EMEA_68018258002A.book Page 6 Friday, Augus
t
7Help & more
Help & more
•EverythingMoto:
for tutorials and helpful tips,
visit
www.motorola.com/mymotomods
• Get more Moto Mods
: Moto Mods are sold
separately. View the complete collection at
www.motomods.com
. Or, visit us at
www.moto.com/motomodsmobileapp
•Softwareupdates:
for help and more on your
phone, tap Apps >
Settings
>
Moto Mods
>
About this Moto Mod
>
Software
updates
• Hasselblad download:
edit your images using
Hasselblad Phocus, a free download from
www.hasselblad.com
•Help:
for help and more on your phone, tap
Apps >
Settings
>
Moto Mods
>
Help
.
•News:
Get the latest news, apps, tips and
much more – join us on:
www.youtube.com/motorola
www.facebook.com/motorola
www.twitter.com/moto
True Zoom_GSG_EMEA_68018258002A.book Page 7 Friday, Augus
t
