Lenovo IdeaCentre A300 User manual

1. Unpack
2. Computer instructions 3. Computer stand 4. Carry the computer
TV
1
4
2
3
5
6
7
8
9
TV
TV
12
84 73 5 6 9
2 3 4 5 6 8 89 10 117
1
Do not put any fluid container on the
base stand.
The buttons at the bottom of the screen
are touch buttons. When you touch
these, the indicator lights turn on.
1
2
1
2
Connect the power cords properly to
grounded electrical outlets.
Connect the
keyboard cable to
the appropriate
keyboard connector
(USB connector).
Connect the mouse
cable to the
appropriate mouse
connector (USB
connector).
Adjust the angle for the best viewing
experience. It can be rotated from
horizontal or vertical.
The stand provides stability to the
computer; it is not a removable part.
Hold the computer tightly when you carry it.
10
10
318
Adjust the panel angle
for the best viewing
from the vertical.
Do not only use one
hand to adjust the panel
angle to avoid the
computer falling over.
Adjust the panel angle
for the best viewing
from the horizontal.
Version: 1.0
Connecting the wired keyboard and
mouse to your computer
(Selected models only)
Press the power button on the top of the
base stand to turn on the computer.
Camera
Built-in microphone
Hard Disk Drive Indicator
Bluetooth status indicator
WIFI status indicator
HDMI-IN mode indicator
LCD light adjust button
Novo Vision button
LCD on/off and PC/HDMI-IN switch combo
1
8
4
2
7
3
5
6
9
10
11
Power button
TV tuner connector
(Selected models only)
Power connector
Ethernet connector
HDMI-IN connector
(Selected models only)
HDMI-OUT connector
(Selected models only)
IEEE 1394 connector
(Selected models only)
USB ports (4)
Memory card reader
(Selected models only)
Microphone connector
Headphone connector
Bluetooth connect button
Mode switch button
(Selected models only)
The computer stand must
remain installed at all
times to ensure maximum
system stability.
31041772

5. Wireless keyboard and mouse instructions (Only some models are equipped with wireless keyboard and mouse)
Method 2Method 1
Make sure the power switch on the back of the mouse is in
the ON position (the keyboard does not have a power switch).
1
2
14
3
When the keyboard and mouse wireless indicator lights
blink green, turn the computer on immediately.
Once the wireless connection is successfully established,
the indicator lights on the keyboard and mouse will turn
off and they will work properly.
CONNECT
LASER
OFFON
CONNECT
OFF ON
CONNECT
Make sure the power
switch on the back of
the mouse is in the ON
position (the keyboard
does not have a power
switch).
CONNECT
LASER
OFFON
Install the batteries into the
keyboard and mouse
battery compartments.
Install the batteries
into the keyboard
and mouse battery
compartments.
Press the wireless connect buttons on the right side of the
keyboard and the back of the mouse for over 5 seconds.
3
When the keyboard and mouse wireless indicator lights
blink green, turn the computer on immediately.
Once the wireless connection is successfully established,
the indicator lights on the keyboard and mouse will turn
off and they will work properly.
CONNECT
LASER
OFFON
CONNECT
OFFON
CONNECT
Press the wireless connect buttons on the right side of
the keyboard and the back of the mouse for over 5
seconds.
2
If the wireless indicator lights stop blinking,
press the connect buttons on the keyboard
and mouse again.
The process of searching for wireless devices
could take several minutes.
After entering the system, press the Bluetooth connect button
on the base stand for over 5 seconds to search for wireless
devices.
When the wireless mouse device is found, the driver will be
installed automatically.
When the wireless keyboard device is found, enter the PIN
code and press the Enter key to finish the pairing process.
Once the wireless connection has been successfully
established, the wireless keyboard and mouse will work
properly.
If the wireless keyboard and mouse do not work, do
the following:
Bluetooth
connect button
Mode switch
button
