Lenovo IdeaCentre A310 User manual

1. Unpack
2. Computer instructions 3. Computer stand 4. Carry the computer
1
4
2
3
5
6
7
2 3 4 5 6 78 9107
1
Do not put any fluid container on the
base stand.
The buttons at the bottom of the screen
are touch buttons. When you touch
these, the indicator lights turn on.
1
2
1
2
Connect the power cords properly to
grounded electrical outlets.
Connect the
keyboard cable to
the appropriate
keyboard connector
(USB connector).
Connect the mouse
cable to the
appropriate mouse
connector (USB
connector).
Adjust the angle for the best viewing
experience. It can be rotated from
horizontal or vertical.
The stand provides stability to the
computer; it is not a removable part.
Hold the computer tightly when you carry it.
10
10
318
TV
Adjust the panel angle
for the best viewing
from the vertical.
Do not only use one
hand to adjust the panel
angle to avoid the
computer falling over.
Adjust the panel angle
for the best viewing
from the horizontal.
TV
TV
TV
TV
Version: 2.0
Connecting the wired keyboard and
mouse to your computer
(Selected models only)
Press the power button on the top of the
base stand to turn on the computer.
Camera
Built-in microphone
Hard Disk Drive Indicator
Bluetooth status indicator
WIFI status indicator
Menu/OK button
Direction buttons
1
8
4
2
7
3
5
6
9
10
Power button
TV tuner connector
(Selected models only)
Power connector
Ethernet connector
HDMI-OUT connector
(Selected models only)
HDMI-IN connector
(Selected models only)
USB ports (4)
Memory card reader
(Selected models only)
Microphone connector
Headphone connector
Bluetooth connect button
Mode switch button
(Selected models only)
The computer stand must
remain installed at all
times to ensure maximum
system stability.
12
74 63 5
TV
31044361
31044361 IC A3 QR V2.0 (EN)(R).indd 1 2010-5-19 16:02:26

5. Wireless keyboard and mouse instructions (Only some models are equipped with wireless keyboard and mouse)
Method 2Method 1
13
Make sure the
power switch on
the back of the
mouse is in the
ON position (the
keyboard does
not have a power
switch).
CONNECT
LASER
OFF ON
Remove the battery tabs
from both the keyboard
and the mouse.
When the keyboard and mouse wireless indicator lights
blink green, turn the computer on immediately.
Once the wireless connection is successfully established,
the indicator lights on the keyboard and mouse will turn
off and they will work properly.
CONNECT
LASER
OFFON
CONNECT
OFF ON
CONNECT
Press the wireless connect
buttons on the right side of the
keyboard and the back of the
mouse for over 5 seconds.
2
If the wireless keyboard and mouse still do not work, do
the following:
Make sure the wireless indicator lights still blink. If they
stop blinking, press the connect buttons on the keyboard
and mouse again, then press the bluetooth connect button
on the base stand for over 5 seconds until the indicator
lights turn off and the wireless connection established.
If connection is not established successfully, refer to
“Wireless keyboard and mouse instructions” in the User
Guide.
Bluetooth
connect button
Mode switch
button
