Lenovo IdeaCentre Gaming 5i User manual

User Guide
IdeaCentre Gaming 5i (17L,7)

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
follo ing:
• Safety and Warranty Guide
• Generic Safety and Compliance Notices
• Setup Guide
First Edition (December 2021)
© Copyright Lenovo 2021
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or soft are is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
About this documentation iii
Chapter 1 Meet your computer 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 2
Features and specifications . . . . . . . . . . . 3
USB specifications . . . . . . . . . . . . . . 3
Operating environment . . . . . . . . . . . . . 4
Chapter 2 Get started with your
computer 7
Work ith Windo s . . . . . . . . . . . . . . 7
Windo s help information . . . . . . . . . . 7
Chapter 3 Explore your computer 9
Lock the computer . . . . . . . . . . . . . . 9
Lenovo Vantage. . . . . . . . . . . . . . . . 9
Set the po er plan . . . . . . . . . . . . . 10
Transfer data . . . . . . . . . . . . . . . . 10
Connect to a Bluetooth-enabled device (for
selected models) . . . . . . . . . . . . 10
Purchase accessories . . . . . . . . . . . . 11
Chapter 4 CRU replacement 13
CRU list . . . . . . . . . . . . . . . . . . 13
Remove or replace a CRU . . . . . . . . . . . 14
Po er cord. . . . . . . . . . . . . . . 14
Computer cover . . . . . . . . . . . . . 14
Front bezel . . . . . . . . . . . . . . . 15
3.5–inch storage drive . . . . . . . . . . 16
Memory module . . . . . . . . . . . . . 17
M.2 solid-state drive . . . . . . . . . . . 18
Microprocessor heatsink and fan assembly . . 19
Coin-cell battery. . . . . . . . . . . . . 20
PCI-Express card, PCI-Express card holder,
PCI-Express card bracket and side system
fan . . . . . . . . . . . . . . . . . . 21
Po er supply assembly . . . . . . . . . . 26
Chapter 5 Help and support 29
Frequently asked questions . . . . . . . . . . 29
Self-help resources . . . . . . . . . . . . . 29
Call Lenovo . . . . . . . . . . . . . . . . 31
Before you contact Lenovo . . . . . . . . 31
Lenovo Customer Support Center . . . . . . 31
Purchase additional services. . . . . . . . . . 32
Appendix A Notices and
trademarks 33
© Copyright Lenovo 2021 i

ii User Guide

About this documentation
• This guide applies to the Lenovo product models listed belo . Illustrations in this guide may look slightly
different from your product model.
Model name Machine types (MT)
IdeaCentre Gaming5 17IAB7 90T0, 90T1
• For further compliance information, refer to the Generic Safety and Compliance Notices at https://
pcsupport.lenovo.com/docs/generic_notices.
• Depending on the model, some optional accessories, features, and soft are programs might not be
available on your computer.
• Depending on the version of the operating systems and programs, some user interface instructions might
not be applicable to your computer.
• Documentation content is subject to change ithout notice. Lenovo makes constant improvements to the
documentation of your computer, including this User Guide. To get the latest documentation, go to https://
pcsupport.lenovo.com.
• Microsoft® makes periodic feature changes to the Windo s® operating system through Windo s Update.
As a result, some information in this documentation might become outdated. Refer to Microsoft resources
for the latest information.
© Copyright Lenovo 2021 iii

iv User Guide

Chapter 1 Meet your computer
Front
1. Po er button 2. Headset connector
3. USB-C® connector (USB 3.2 Gen 1) 4. USB 3.2 connectors
5. Ventilation slots
Power indicator
Sho the system status of your computer.
• Blinking for three times: The computer is initially connected to po er.
• On: The computer is on.
• Off: The computer is off or in hibernation mode.
• Blinking rapidly: The computer is entering sleep or hibernation mode.
• Blinking slowly: The computer is in sleep mode.
Related topics
• “USB specifications” on page 3.
© Copyright Lenovo 2021 1

Rear
1. Audio line-out connector 2. HDMI™ 1.4 out connector
3. VGA-out connector 4. USB 2.0 connectors (4)
5. PCI-Express card area 6. Po er cord connector
7. Ethernet connector (2.5G) 8. Security-lock slot
Related topics
• “USB specifications” on page 3.
• “Work ith Windo s” on page 7.
• “Lock the computer” on page 9.
2User Guide

Features and specifications
For detailed specifications of your computer, go to https://psref.lenovo.com.
Hardware To vie the hard are information of your computer, type device manager in the
Windo s search box and then press Enter.
Power supply
• 300- att automatic voltage-sensing po er supply
• 310- att automatic voltage-sensing po er supply
• 380- att automatic voltage-sensing po er supply
• 500- att automatic voltage-sensing po er supply
Microprocessor To vie the microprocessor information of your computer, type system
information in the Windo s search box and then press Enter.
Memory Double data rate 4 (DDR4) dual in-line memory module (DIMM)
Storage device
To vie the storage drive capacity of your computer, type disk management in the
Windo s search box and then press Enter.
Note: The storage drive capacity indicated by the system is less than the nominal
capacity.
Expansion
• 3 SATA3.0 Port
• 2 DDR4 DIMM slots
• 2 M.2 solid-state drive slot (1 for WIFI and BT, 1 for PCIE SSD)
• 2 Storage drive bay (3.5-inch Storage drive bay)
• PCI Express slots: PCIEx16 (1), PCIEx1 (1)
Network features
• Bluetooth
• Ethernet LAN
• Wireless LAN
USB specifications
Note: Depending on the model, some USB connectors might not be available on your computer.
Chapter 1.Meet your computer 3

Connector name Description
• USB 2.0 connector
• USB 3.2 connector Gen 1 / USB 3.2 connector
Gen 2
Connect USB-compatible devices, such as a USB
keyboard, USB mouse, USB storage device, or USB
printer.
• USB-C (3.2 Gen 1) connector
• USB-C (3.2 Gen 2) connector
• Thunderbolt 3 connector (USB-C)
• Thunderbolt 4 connector (USB-C)
• Charge USB-C compatible devices ith the output
voltage and current of 5 V and 3 A.
• Connect to an external display:
– USB-C to VGA: 1900 x 1200 pixels, 60 Hz
– USB-C to DP: 3840 x 2160 pixels, 60 Hz
• Connect to USB-C accessories to help expand your
computer functionality. To purchase USB-C
accessories, go to https:// .lenovo.com/accessories.
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device ill vary and ill be slo er than the data rate listed
belo for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 (USB-C) 40
Thunderbolt 4 (USB-C) 40
Operating environment
Temperature
• Operating: From 5°C (41°F) to 35°C (95°F)
4User Guide

• Storage or transportation:
– For common desktop computers: From -40°C (-40°F) to 60°C (140°F)
– For all-in-one desktop computers: From -20°C (-4°F) to 60°C (140°F)
Relative humidity
• Operating: 20%-80% (non-condensing)
• Storage: 10%–90% (non-condensing)
Altitude
• Operating: -15.2 m (-50 ft) to 3048 m (10,000 ft)
• Storage: -15.2 m (-50 ft) to 12192 m (40,000 ft)
Chapter 1.Meet your computer 5

6User Guide

Chapter 2 Get started with your computer
Work with Windows
The follo ing table contains Windo s frequently used settings. You can learn the basics and start orking
ith Windo s right a ay.
To configure settings, type the corresponding key ords in the Windo s search box and select the best
match. Follo the on-screen instructions to customize settings.
Table 1. Basic settings
Functions Descriptions Search by
keywords
Control Panel Vie or change Windo s settings, including hard are and soft are setup
and configuration.
Control Panel
Connect to Wi-Fi
net orks
For models ith a ireless LAN module, you can connect your computer to
a Wi-Fi® net ork. Click the net ork icon in the Windo s notification area,
and then select a net ork for connection.
Note: The ireless LAN module on your computer may support different
standards. For some countries or regions, use of 802.11ax may be disabled
according to local regulations.
Wi-Fi
Connect to ired
net orks
For models ith an Ethernet (RJ-45) connector, you can use an Ethernet
cable to connect your computer to a ired net ork.
—
Airplane mode Airplane mode is a convenient setting to turn all ireless communications of
your computer on and off. You may need to turn it on hen boarding an
airplane.
Airplane mode
Windo s
Updates
Microsoft periodically releases feature and security updates to the Windo s
operating system. Updates that are applicable to your Windo s version are
do nloaded automatically hen your computer is connected to the
Internet. When updates are do nloaded, you are prompted to restart the
computer to install these updates. You can also manually check if there are
available updates for the installed version of Windo s.
Attention: Only use Windo s Update to do nload and install updates.
Updates do nloaded from other sources may include security risks.
Windo s Updates
Windows help information
If the on-screen instructions cannot solve your problem, refer to the follo ing to get the online Windo s help
information.
• Type Get Help or Tips in the Windo s search box and then press Enter. When the app opens, type the
problem description and select the matched result.
• Visit Microsoft support Web site: https://support.microsoft.com. Enter hat you are looking for in the
search box and get search results.
© Copyright Lenovo 2021 7

8User Guide

Chapter 3 Explore your computer
Lock the computer
Note: Lenovo makes no comments, judgments, or arranties about the function, quality, or performance of
the locking device and security feature. You can purchase computer locks from Lenovo.
Kensington-style cable lock
Lock your computer to a desk, table, or other fixtures through a Kensington-style cable lock.
Lenovo Vantage
The preinstalled Lenovo Vantage is a customized one-stop solution to help you maintain your computer ith
automated updates and fixes, configure hard are settings, and get personalized support.
Access Lenovo Vantage
Type Lenovo Vantage in the search box and then press Enter.
To do nload the latest version of Lenovo Vantage, go to Microsoft Store and search by the app name.
Key features
Lenovo Vantage enables you to:
• Kno the device status easily and customize device settings.
• Do nload and install UEFI BIOS, firm are and driver updates to keep your computer up-to-date.
© Copyright Lenovo 2021 9

• Monitor your computer health, and secure your computer against outside threats.
• Scan your computer hard are and diagnose hard are problems.
• Look up arranty status (online).
• Access User Guide and helpful articles.
Notes:
• The available features vary depending on the computer model.
• Lenovo Vantage makes periodic updates of the features to keep improving your experience ith your
computer. The description of features might be different from that on your actual user interface.
Set the power plan
For ENERGY STAR® compliant computers, the follo ing po er plan takes effect hen your computers have
been idle for a specified duration:
• turn off the display: After 10 minutes
• put the computer to sleep: After 25 minutes
To a aken the computer from Sleep mode, press any key on your keyboard.
To change or customize a po er plan:
1. Type po er plan in the Windo s search box and then press Enter.
2. Customize a po er plan of your preference.
Transfer data
Quickly share your files using the built-in Bluetooth technology among devices ith the same features. You
also can install a disc or media card to transfer data.
Connect to a Bluetooth-enabled device (for selected models)
You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a
smartphone, or speakers. To ensure that the connection is successful, place the devices 10 meters (33 feet),
at most, from the computer.
10 User Guide

1. Click the action center icon in the Windo s notification area. Enable the Bluetooth feature.
2. Click the bluetooth options to add a bluetooth device, and then follo the on-screen instructions.
Purchase accessories
Lenovo has a number of hard are accessories and upgrades to help expand the capabilities of your
computer. Options include memory modules, storage devices, net ork cards, po er adapters, keyboards,
mice, and more.
To shop at Lenovo, go to https://pcsupport.lenovo.com/ arrantyupgrade.
Chapter 3.Explore your computer 11

12 User Guide

Chapter 4 CRU replacement
Customer Replaceable Units (CRUs) are parts that can be upgraded or replaced by the customer. Lenovo
computers contain the follo ing types of CRUs:
• Self-service CRUs: Refer to parts that can be installed or replaced easily by customer themselves or by
trained service technicians at an additional cost.
• Optional-service CRUs: Refer to parts that can be installed or replaced by customers ith a greater skill
level. Trained service technicians can also provide service to install or replace the parts under the type of
arranty designated for the customer’s machine.
If you intend on installing the CRU, Lenovo ill ship the CRU to you. CRU information and replacement
instructions are shipped ith your product and are available from Lenovo at any time upon request. You
might be required to return the defective part that is replaced by the CRU. When return is required: (1) return
instructions, a prepaid shipping label, and a container ill be included ith the replacement CRU; and (2) you
might be charged for the replacement CRU if Lenovo does not receive the defective CRU ithin thirty (30)
days of your receipt of the replacement CRU. For full details, see the Lenovo Limited Warranty
documentation at:
https:// .lenovo.com/ arranty/ll _02
CRU list
The follo ing is the CRU list of your computer.
Self-service CRUs
• Po er cord
• Computer cover
• Keyboard *
• Mouse *
• Front bezel
• Memory modules
• M.2 solid-state drive
• 3.5–inch storage drive
• HDD bracket
• Thumbscre kit
Optional-service CRUs
• Microprocessor heatsink and fan assembly
• Coin-cell battery
• Po er supply assembly
• PCI-Express card
• PCI-Express card holder
• PCI-Express card bracket
• Side system fan
* for selected models
© Copyright Lenovo 2021 13

Remove or replace a CRU
This section provides instructions on ho to remove or replace a CRU.
Power cord
Prerequisite
Before you start, read Generic Safety and Compliance Notices, and print the follo ing instructions.
Before you remove the po er cord, turn off the computer and ait several minutes until the computer is cool.
For access, do the follo ing: Turn off the computer and remove all connected devices and cables.
Removal steps
Computer cover
Prerequisite
Before you start, read Generic Safety and Compliance Notices, and print the follo ing instructions.
Before you open the computer cover, turn off the computer and ait several minutes until the computer is
cool.
For access, do the follo ing:
1. Turn off the computer and remove all connected devices and cables.
14 User Guide
