User Guide
IdeaCentre Gaming5 17ACN7

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following
• Safety and Warranty Guide
• Generic Safety and Compliance Notices
• Setup Guide
First Edition (March 2022)
© Copyright Lenovo 2022.
LIMITED AND RESTRICTED RIGHTS NOTICE If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
Abo t this doc mentation . . . . . . . . iii
Chapter 1. Meet yo r comp ter . . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 2
Features and specifications . . . . . . . . . . . 3
USB specifications . . . . . . . . . . . . . . 3
Operating environment . . . . . . . . . . . . . 4
Chapter 2. Get started with yo r
comp ter . . . . . . . . . . . . . . . . . 7
Work with Windows . . . . . . . . . . . . . . 7
Windows help information . . . . . . . . . . 7
Chapter 3. Explore yo r comp ter . . . 9
Lock the computer . . . . . . . . . . . . . . 9
Lenovo Vantage. . . . . . . . . . . . . . . . 9
Set the power plan . . . . . . . . . . . . . 10
Transfer data . . . . . . . . . . . . . . . . 10
Connect to a Bluetooth-enabled device (for
selected models) . . . . . . . . . . . . 10
Purchase accessories . . . . . . . . . . . . 11
Chapter 4. CRU replacement . . . . . 13
CRU list . . . . . . . . . . . . . . . . . . 13
Remove or replace a CRU . . . . . . . . . . . 14
Power cord. . . . . . . . . . . . . . . 14
Computer cover . . . . . . . . . . . . . 14
Front bezel . . . . . . . . . . . . . . . 15
3.5–inch storage drive . . . . . . . . . . 16
Memory module . . . . . . . . . . . . . 17
M.2 solid-state drive . . . . . . . . . . . 18
Microprocessor heatsink and fan assembly . . 19
Coin-cell battery. . . . . . . . . . . . . 20
PCI-Express card, PCI-Express card holder,
PCI-Express card bracket and side system
fan . . . . . . . . . . . . . . . . . . 21
Power supply assembly . . . . . . . . . . 26
Chapter 5. Help and s pport . . . . . 29
Frequently asked questions . . . . . . . . . . 29
Self-help resources . . . . . . . . . . . . . 29
Call Lenovo . . . . . . . . . . . . . . . . 31
Before you contact Lenovo . . . . . . . . 31
Lenovo Customer Support Center . . . . . . 31
Purchase additional services. . . . . . . . . . 32
Appendix A. Notices and
trademarks . . . . . . . . . . . . . . . 33
© Copyright Lenovo 2022 i

ii User Guide

Abo t this doc mentation
• This guide applies to the Lenovo product models listed below. Illustrations in this guide may look slightly
different from your product model.
Model name Machine types (MT)
IdeaCentre Gaming5 17ACN7 90TQ
• For further compliance information, refer to the Generic Safety and Compliance Notices at https //
pcsupport.lenovo.com/docs/generic_notices.
• Depending on the model, some optional accessories, features, and software programs might not be
available on your computer.
• Depending on the version of the operating systems and programs, some user interface instructions might
not be applicable to your computer.
• Documentation content is subject to change without notice. Lenovo makes constant improvements to the
documentation of your computer, including this User Guide. To get the latest documentation, go to https //
pcsupport.lenovo.com.
• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.
As a result, some information in this documentation might become outdated. Refer to Microsoft resources
for the latest information.
© Copyright Lenovo 2022 iii

iv User Guide

Chapter 1. Meet yo r comp ter
Front
1. Power button 2. Headset connector
3. USB-C® connector (USB 3.2 Gen 1) 4. USB 3.2 connectors
5. Ventilation slots
Power indicator
Show the system status of your computer.
• Blinking for three times: The computer is initially connected to power.
• On: The computer is on.
• Off: The computer is off or in hibernation mode.
• Blinking rapidly: The computer is entering sleep or hibernation mode.
• Blinking slowly: The computer is in sleep mode.
Related topics
• “USB specifications” on page 3.
© Copyright Lenovo 2022 1

Rear
1. Audio line-out connector 2. HDMI™ 1.4 out connector
3. VGA-out connector 4. USB 2.0 connectors (4)
5. PCI-Express card area 6. Power cord connector
7. Ethernet connector (1G) 8. Security-lock slot
Related topics
• “USB specifications” on page 3.
• “Work with Windows” on page 7.
• “Lock the computer” on page 9.
2User Guide

Feat res and specifications
For detailed specifications of your computer, go to https //psref.lenovo.com.
Hardware To view the hardware information of your computer, type device manager in the
Windows search box and then press Enter.
Power s pply
• 300-watt automatic voltage-sensing power supply
• 310-watt automatic voltage-sensing power supply
• 380-watt automatic voltage-sensing power supply
• 500-watt automatic voltage-sensing power supply
Microprocessor To view the microprocessor information of your computer, type system
information in the Windows search box and then press Enter.
Memory Double data rate 4 (DDR4) dual in-line memory module (DIMM)
Storage device
To view the storage drive capacity of your computer, type disk management in the
Windows search box and then press Enter.
Note: The storage drive capacity indicated by the system is less than the nominal
capacity.
Expansion
• 3 SATA3.0 Port
• 2 DDR4 DIMM slots
• 2 M.2 solid-state drive slot (1 for WIFI and BT, 1 for PCIE SSD)
• 2 Storage drive bay (3.5-inch Storage drive bay)
• PCI Express slots PCIEx16 (1), PCIEx1 (1)
Network feat res
• Bluetooth
• Ethernet LAN
• Wireless LAN
USB specifications
Note: Depending on the model, some USB connectors might not be available on your computer.
Chapter 1.Meet your computer 3

Connector name Description
• USB 2.0 connector
• USB 3.2 connector Gen 1 / USB 3.2 connector
Gen 2
Connect USB-compatible devices, such as a USB
keyboard, USB mouse, USB storage device, or USB
printer.
• USB-C (3.2 Gen 1) connector
• USB-C (3.2 Gen 2) connector
• Thunderbolt 3 connector (USB-C)
• Thunderbolt 4 connector (USB-C)
• Charge USB-C compatible devices with the output
voltage and current of 5 V and 3 A.
• Connect to an external display
– USB-C to VGA 1900 x 1200 pixels, 60 Hz
– USB-C to DP 3840 x 2160 pixels, 60 Hz
• Connect to USB-C accessories to help expand your
computer functionality. To purchase USB-C
accessories, go to https //www.lenovo.com/accessories.
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 (USB-C) 40
Thunderbolt 4 (USB-C) 40
Operating environment
Temperat re
• Operating From 5°C (41°F) to 35°C (95°F)
4User Guide

• Storage or transportation
– For common desktop computers From -40°C (-40°F) to 60°C (140°F)
– For all-in-one desktop computers From -20°C (-4°F) to 60°C (140°F)
Relative h midity
• Operating 20%-80% (non-condensing)
• Storage 10%–90% (non-condensing)
Altit de
• Operating -15.2 m (-50 ft) to 3048 m (10,000 ft)
• Storage -15.2 m (-50 ft) to 12192 m (40,000 ft)
Chapter 1.Meet your computer 5

6User Guide

Chapter 2. Get started with yo r comp ter
Work with Windows
The following table contains Windows frequently used settings. You can learn the basics and start working
with Windows right away.
To configure settings, type the corresponding keywords in the Windows search box and select the best
match. Follow the on-screen instructions to customize settings.
Table 1. Basic settings
F nctions Descriptions Search by
keywords
Control Panel View or change Windows settings, including hardware and software setup
and configuration.
Control Panel
Connect to Wi-Fi
networks
For models with a wireless LAN module, you can connect your computer to
a Wi-Fi® network. Click the network icon in the Windows notification area,
and then select a network for connection.
Note: The wireless LAN module on your computer may support different
standards. For some countries or regions, use of 802.11ax may be disabled
according to local regulations.
Wi-Fi
Connect to wired
networks
For models with an Ethernet (RJ-45) connector, you can use an Ethernet
cable to connect your computer to a wired network.
—
Airplane mode Airplane mode is a convenient setting to turn all wireless communications of
your computer on and off. You may need to turn it on when boarding an
airplane.
Airplane mode
Windows
Updates
Microsoft periodically releases feature and security updates to the Windows
operating system. Updates that are applicable to your Windows version are
downloaded automatically when your computer is connected to the
Internet. When updates are downloaded, you are prompted to restart the
computer to install these updates. You can also manually check if there are
available updates for the installed version of Windows.
Attention: Only use Windows Update to download and install updates.
Updates downloaded from other sources may include security risks.
Windows Updates
Windows help information
If the on-screen instructions cannot solve your problem, refer to the following to get the online Windows help
information.
• Type Get Help or Tips in the Windows search box and then press Enter. When the app opens, type the
problem description and select the matched result.
• Visit Microsoft support Web site https //support.microsoft.com. Enter what you are looking for in the
search box and get search results.
© Copyright Lenovo 2022 7

8User Guide

Chapter 3. Explore yo r comp ter
Lock the comp ter
Note: Lenovo makes no comments, judgments, or warranties about the function, quality, or performance of
the locking device and security feature. You can purchase computer locks from Lenovo.
Kensington-style cable lock
Lock your computer to a desk, table, or other fixtures through a Kensington-style cable lock.
Lenovo Vantage
The preinstalled Lenovo Vantage is a customized one-stop solution to help you maintain your computer with
automated updates and fixes, configure hardware settings, and get personalized support.
Access Lenovo Vantage
Type Lenovo Vantage in the search box and then press Enter.
To download the latest version of Lenovo Vantage, go to Microsoft Store and search by the app name.
Key feat res
Lenovo Vantage enables you to
• Know the device status easily and customize device settings.
• Download and install UEFI BIOS, firmware and driver updates to keep your computer up-to-date.
© Copyright Lenovo 2022 9

• Monitor your computer health, and secure your computer against outside threats.
• Scan your computer hardware and diagnose hardware problems.
• Look up warranty status (online).
• Access User Guide and helpful articles.
Notes:
• The available features vary depending on the computer model.
• Lenovo Vantage makes periodic updates of the features to keep improving your experience with your
computer. The description of features might be different from that on your actual user interface.
Set the power plan
For ENERGY STAR® compliant computers, the following power plan takes effect when your computers have
been idle for a specified duration
• turn off the display After 10 minutes
• put the computer to sleep After 25 minutes
To awaken the computer from Sleep mode, press any key on your keyboard.
To change or customize a power plan
1. Type power plan in the Windows search box and then press Enter.
2. Customize a power plan of your preference.
Transfer data
Quickly share your files using the built-in Bluetooth technology among devices with the same features. You
also can install a disc or media card to transfer data.
Connect to a Bl etooth-enabled device (for selected models)
You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a
smartphone, or speakers. To ensure that the connection is successful, place the devices 10 meters (33 feet),
at most, from the computer.
10 User Guide

1. Click the action center icon in the Windows notification area. Enable the Bluetooth feature.
2. Click the bluetooth options to add a bluetooth device, and then follow the on-screen instructions.
P rchase accessories
Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your
computer. Options include memory modules, storage devices, network cards, power adapters, keyboards,
mice, and more.
To shop at Lenovo, go to https //pcsupport.lenovo.com/warrantyupgrade.
Chapter 3.Explore your computer 11

12 User Guide

Chapter 4. CRU replacement
Customer Replaceable Units (CRUs) are parts that can be upgraded or replaced by the customer. Lenovo
computers contain the following types of CRUs
• Self-service CRUs: Refer to parts that can be installed or replaced easily by customer themselves or by
trained service technicians at an additional cost.
• Optional-service CRUs: Refer to parts that can be installed or replaced by customers with a greater skill
level. Trained service technicians can also provide service to install or replace the parts under the type of
warranty designated for the customer’s machine.
If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement
instructions are shipped with your product and are available from Lenovo at any time upon request. You
might be required to return the defective part that is replaced by the CRU. When return is required (1) return
instructions, a prepaid shipping label, and a container will be included with the replacement CRU; and (2) you
might be charged for the replacement CRU if Lenovo does not receive the defective CRU within thirty (30)
days of your receipt of the replacement CRU. For full details, see the Lenovo Limited Warranty
documentation at
https //www.lenovo.com/warranty/llw_02
CRU list
The following is the CRU list of your computer.
Self-service CRUs
• Power cord
• Computer cover
• Keyboard *
• Mouse *
• Front bezel
• Memory modules
• M.2 solid-state drive
• 3.5–inch storage drive
• HDD bracket
• Thumbscrew kit
Optional-service CRUs
• Microprocessor heatsink and fan assembly
• Coin-cell battery
• Power supply assembly
• PCI-Express card
• PCI-Express card holder
• PCI-Express card bracket
• Side system fan
* for selected models
© Copyright Lenovo 2022 13

Remove or replace a CRU
This section provides instructions on how to remove or replace a CRU.
Power cord
Prereq isite
Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
Before you remove the power cord, turn off the computer and wait several minutes until the computer is cool.
For access, do the following Turn off the computer and remove all connected devices and cables.
Removal steps
Comp ter cover
Prereq isite
Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
Before you open the computer cover, turn off the computer and wait several minutes until the computer is
cool.
For access, do the following
1. Turn off the computer and remove all connected devices and cables.
14 User Guide
