Lenovo ThinkCentre M57e 6176 User manual

Personal Systems Reference
Lenovo®ThinkCentre Desktops
April 2009 - Version 354
Lenovo ThinkCentre M58p Eco Ultra Small
with ThinkVision 2440x Wide monitor
Visit www.lenovo.com/psref for the latest version

Lenovo ThinkCentre M57e Small
Lenovo ThinkCentre M57e Small
Lenovo ThinkCentre M57e Desktop
with Lenovo ThinkVision monitor
Lenovo ThinkCentre M57e Tower
Lenovo ThinkCentre M57e Desktop
Lenovo ThinkCentre M57e Small (9482), Desktop (9481), Tower (9439)
Lenovo ThinkCentre M57e Tower
with dual Lenovo ThinkVision monitors

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Stability and manageability for small and medium businesses
Intel®Pentium®Dual-Core Processor E2200 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo Processor E7200 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Duo Processor E8400 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, 1333MHz system bus, and 6MB L2 cache or
Intel Core 2 Quad Processor Q6600 with quad-core
(dual-core on dual-die), Intel 64 Technology,
Virtualization Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 8MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Italics: standard memory in both sockets; no sockets avail;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 6305-B1U 2x3 Pentium E2200 2.20 1MB Dual 1GB 160GB2 DVD GMA XP Pro None Jun 08
M57e 6305-B2U 2x3 Pentium E2200 2.20 1MB Dual 2GB 160GB DVD±RW GMA XP Pro None Jun 08
M57e 6305-B4U 2x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB DVD GMA XP Pro None Jun 08
M57e 6305-B3U 2x3 Core 2 Duo E7200 2.53 3MB Dual 2GB 160GB DVD±RW GMA XP Pro None Jun 08
M57e 6305-B5U 2x3 Core 2 Duo E8400 3.00 6MB Dual 2GB 160GB DVD±RW GMA XP Pro None Jun 08
M57e 6305-B6U 2x3 Core 2 Quad Q6600 2.40 8MB Quad 2GB 160GB DVD±RW GMA XP Pro None Jun 08
M57e 6305-B7U 2x3 Pentium E2200 2.20 1MB Dual 1GB 160GB DVD GMA Business32 Premium None Sep 08
M57e 6305-B8U 2x3 Pentium E2200 2.20 1MB Dual 2GB 160GB DVD±RW GMA Business32 Premium None Sep 08
M57e 6305-B9U 2x3 Core 2 Quad Q6600 2.40 8MB Quad 2GB 160GB DVD±RW GMA Business32 Premium None Sep 08
ThinkCentre®M57e Small (6305) - TopSeller
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics Core
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
☞US models announced August 19, 2008; previous models on June 24, 2008
© Lenovo
(MONA2-4) August 2008
Preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
RoHS-compliant
Preloaded operating system20
- Some: Microsoft®Windows® XP
Professional with Vista®COA
- Some: Microsoft Windows Vista
Business Edition (32-bit)
Preloaded applications5(all OSes; only
some listed)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•Norton Internet Security™
•Diskeeper®Home
• Microsoft Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD, DVD±RW)
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
USB 2.0 Lenovo Multimedia Headset 40Y8518
ThinkVision
®
L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
☞
☞
☞
• These small and medium business (SMB) models are part of the US TopSeller ™Program
• These models have a 3-year limited warranty1
Vista
logo

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Stability and manageability for small and medium businesses
Intel®Pentium®Dual-Core Processor E5200 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core™2 Duo Processor E7300 with dual-core,
1066MHz system bus, and 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 6305-BBU 2x3 Pentium E5200 2.50 2MB 2 1GB 160GB2 DVD GMA XP Pro Premium None Nov 08
M57e 6305-BCU 2x3 Pentium E5200 2.50 2MB 2 2GB 160GB DVD±RW GMA XP Pro Premium None Nov 08
M57e 6305-BEU 2x3 Core 2 Duo E7300 2.66 3MB 2 1GB 160GB DVD GMA XP Pro Premium None Nov 08
M57e 6305-BDU 2x3 Core 2 Duo E7300 2.66 3MB 2 2GB 160GB DVD±RW GMA XP Pro Premium None Nov 08
ThinkCentre®M57e Small (6305) - TopSeller (October 2008)
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics Cores
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
US models announced October 21, 2008
© Lenovo
(MONA3-4) October 2008
Preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
RoHS-compliant
Preloaded operating system20
- Microsoft®Windows®XP Professional
with Vista®COA
✧Disk-to-Disk Recovery (in hidden
protected area)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
•Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Multimedia Center for Think Offerings
(DVD, DVD±RW)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
•Corel WinDVD Creator (DVD±RW)
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
DVD-ROM DL SATA 1.5Gb/s 16-48X Max 41N5618
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
• These small and medium business (SMB) models are part of the US TopSeller ™Program
• These models have a 3-year limited warranty1
Vista
logo

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
SATA Combo
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2160 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB shared L2 cache or
Intel Core™2 Duo Processor E4500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB shared L2 cache or
Intel Core 2 Duo Processor E6550 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, 1333MHz system bus, and 4MB shared L2 cache or
Intel Core 2 Duo Processor E8200 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 6MB shared L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 9482-BGU 2x3 Pentium E2160 1.80 1MB Dual 1GB 160GB2 DVD GMA XP Pro 3-yr Mar 08
M57e 9482-BHU 2x3 Pentium E2160 1.80 1MB Dual 1GB 160GB Combo GMA XP Pro 3-yr Mar 08
M57e 9482-BKU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB DVD GMA XP Pro 3-yr Mar 08
M57e 9482-BJU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA XP Pro 3-yr Mar 08
M57e 9482-BLU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA XP Pro 3-yr K12 Mar 08
M57e 9482-BMU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA XP Pro 3-yr HE Mar 08
M57e 9482-BPU 2x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 160GB DVD GMA XP Pro 3-yr Mar 08
M57e 9482-BNU 2x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 160GB Combo GMA XP Pro 3-yr Mar 08
M57e 9482-DAU 2x3 Core 2 Duo E8200 2.66 6MB Dual 1GB 160GB Combo GMA XP Pro 3-yr Mar 08
ThinkCentre®M57e Small (9482)
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics Core
Avail
dateName Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
☞US models announced March 18, 2008; previous models on February 26, 2008
✂ US models withdrawn effective September 2008 or January 2009
© Lenovo
(MONA1-4) March 2008
Preload
✂
✂
✂
✂
✂
✂
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Limited
warranty1
RoHS-compliant
Preloaded operating system20
- Microsoft®Windows® XP Professional
with Vista®COA
✧Disk-to-Disk Recovery (in hidden
protected area)
Preloaded applications5(only some listed)
•Some (K12): K-12 education software
-VitalSource Library School Edition
-Adobe®Instructor Resource Center
-Adobe Digital School Collection
− Photoshop Elements 5 (and CD)
−Premier Elements 3 (and DVD)
− Acrobat 8 Professional (and CD)
− Contribute 4 (and CD)
•Some (HE): Higher education software
-VitalSource Library College Edition
-Adobe Instructor Resource Center
-Adobe Photoshop Elements 5 (and CD)
-Adobe Premier Elements 3 (and DVD)
•Rescue and Recovery™
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
☞

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2180 or E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo Processor E7200 or E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
All: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to
256MB), one analog VGA DB-15 connector
Some: ADD2 DVI-D Monitor Connection (HDCP), PCI Express®
adapter in PCIe x16 slot, provides DVI-D connector to
support second monitor, HDCP-compliant
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15, DVI-D in some models)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 9482-HJU 2x3 Pentium E2180 2.00 1MB Dual 1GB 160GB2 DVD GMA XP Pro 3-yr None Sep 08
M57e 9482-HKU 2x3 Pentium E2200 2.20 1MB Dual 1GB 160GB DVD GMA XP Pro 3-yr None Sep 08
M57e 9482-HLU 2x3 Pentium E2200 2.20 1MB Dual 2GB 160GB DVD±RW GMA XP Pro 3-yr None Sep 08
M57e 9482-HHU 2x3 Core 2 Duo E7200 2.53 3MB Dual 2GB 160GB DVD GMA XP Pro 3-yr None Sep 08
M57e 9482-HFU 2x3 Core 2 Duo E7300 2.66 3MB Dual 1GB 160GB DVD±RW GMA+ADD2 XP Pro 3-yr None Sep 08
M57e 9482-HGU 2x3 Core 2 Duo E7300 2.66 3MB Dual 2GB 160GB DVD GMA XP Pro 3-yr None Sep 08
ThinkCentre®M57e Small (9482) - August 2008
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics
Core
Avail
date
Name
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
US models announced August 19, 2008
© Lenovo
(MONA2-12) August 2008
Preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)*
Slot 2: Low Profile, 32-bit PCI 2.3
* used in some models
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Limited
warranty1
RoHS-compliant
Preloaded operating system20
- Microsoft®Windows® XP Professional
with Vista®COA
✧Disk-to-Disk Recovery (in hidden
protected area)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
•Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Multimedia Center for Think Offerings
(DVD, DVD±RW)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
•Corel WinDVD Creator (DVD±RW)
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
DVD-ROM DL SATA 1.5Gb/s 16-48X Max 41N5618
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
SATA Combo
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Celeron®Processor 420 or 430 with single-core,
Intel 64 Technology, EDBit, 800MHz bus, and 512KB L2 cache or
Intel Pentium®Dual-Core Processor E2160 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB shared L2 cache or
Intel Core™2 Duo Processor E4500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB shared L2 cache or
Intel Core 2 Duo Processor E6550 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 4MB shared L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
80GB or 160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 9482-AUU 2x3 Celeron 420 1.60 512KB Single 1GB 160GB2 DVD GMA Bus32 3-yr None Mar 08
M57e 9482-AAU 2x3 Celeron 430 1.80 512KB Single 1GB 80GB DVD GMA Bus32 3-yr None Mar 08
M57e 9482-ABU 2x3 Pentium E2160 1.80 1MB Dual 1GB 80GB DVD GMA Bus32 3-yr None Mar 08
M57e 9482-ACU 2x3 Pentium E2160 1.80 1MB Dual 1GB 80GB Combo GMA Bus32 3-yr None Mar 08
M57e 9482-AVU 2x3 Pentium E2160 1.80 1MB Dual 1GB 160GB DVD GMA Bus32 3-yr None Mar 08
M57e 9482-AWU 2x3 Pentium E2160 1.80 1MB Dual 1GB 160GB Combo GMA Bus32 3-yr None Mar 08
M57e 9482-ADU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 80GB DVD GMA Bus32 3-yr None Mar 08
M57e 9482-AEU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 80GB Combo GMA Bus32 3-yr None Mar 08
M57e 9482-B1U 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB DVD GMA Bus32 3-yr None Mar 08
M57e 9482-B2U 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA Bus32 3-yr None Mar 08
M57e 9482-AFU 2x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 80GB Combo GMA Bus32 3-yr None Mar 08
M57e 9482-AGU 2x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 80GB DVD±RW GMA Bus32 3-yr None Mar 08
M57e 9482-B6U 2x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 160GB DVD GMA Bus32 3-yr None Mar 08
M57e 9482-B5U 2x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 160GB Combo GMA Bus32 3-yr None Mar 08
ThinkCentre®M57e Small (9482) - Vista®
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics Core
Avail
dateName Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
US models announced February 19, 2008
✂ US models withdrawn effective September 2008 or January 2009
© Lenovo
(MONA1-1) February 2008
Vista
preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
✧Vista Basic logo
Preloaded applications5(only some listed)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•Norton Internet Security™
• Diskeeper®Home
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (combo, DVD±RW)
•Corel®WinDVD®(combo, DVD, DVD±RW)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Limited
warranty1
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
ThinkVision
®
L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Other accessories at lenovo.com/accessories
✂
✂
✂
✂
✂
✂
✂
✂

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
SATA Combo
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2180 or E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB shared L2 cache or
Intel Core™2 Duo Processor E4500 or E4600 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB shared L2 cache or
Intel Core 2 Duo Processor E8200 or E8400 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 6MB shared L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Italics: standard memory in both sockets; no sockets avail;
Non-italics: standard memory in one socket; one socket available
All: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to
256MB), one analog VGA DB-15 connector
Some: ADD2 DVI-I PCIe Connection Adapter, PCI Express®
adapter in PCIe x16 slot, provides DVI-I connector to
support second monitor, no DVI-to-VGA dongle
160GB or 250GB, SATA 3.0Gb/s 7200 rpm, vibration dampening
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15, DVI-I in some models)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 9482-B8U 2x3 Pentium E2180 2.00 1MB Dual 1GB 160GB2 DVD±RW GMA Stand Bus32 Basic Sep 08
M57e 9482-E9U 2x3 Pentium E2200 2.20 1MB Dual 1GB 160GB Combo GMA Stand Bus32 Basic Gbl Mar 08
M57e 9482-FLU 2x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA Stand Bus32 Basic Educ Apr 08
M57e 9482-FAU 2x3 Core 2 Duo E4600 2.40 2MB Dual 1GB 160GB Combo GMA+ADD2 Bus32 Basic Gbl Mar 08
M57e 9482-DBU 2x3 Core 2 Duo E8200 2.66 6MB Dual 1GB 160GB Combo GMA Stand Bus32 Basic Mar 08
M57e 9482-FBU 2x3 Core 2 Duo E8400 3.00 6MB Dual 2GB 250GB DVD±RW GMA+ADD2 Bus32 Prem Gbl Mar 08
ThinkCentre®M57e Small (9482) - Vista®(March 2008)
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics
Core
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
☞US model announced August 19, 2008; previous models on March 18 or March 25, 2008
✂ US model withdrawn effective September 2008
© Lenovo
(MONA1-8) August 2008
Vista
preload
✂
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
Preloaded applications5(only some listed)
•Some: Education software
-VitalSource Library College Edition
-Adobe®Instructor Resource Center
-Adobe Digital School Collection
− Photoshop Elements 6 (and CD)
−Premier Elements 4 (and DVD)
− Acrobat 8 Professional (and CD)
− Contribute 4 (and CD)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•Norton Internet Security™
• Diskeeper®Home
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (combo, DVD±RW)
•Corel®WinDVD®(combo, DVD±RW)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•Some: system floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)*
Slot 2: Low Profile, 32-bit PCI 2.3
* used in some models
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Vista
logo
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
Floor
stand
• These models have a 3-year limited warranty1
☞

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Core™2 Duo Processor E7200 or E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA8 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 9482-H1U 2x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB2 DVD±RW GMA Business32 Basic Jul 08
M57e 9482-F9U 2x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB DVD±RW GMA Business32 Basic Educ Jul 08
M57e 9482-HCU 2x3 Core 2 Duo E7300 2.66 3MB Dual 1GB 160GB DVD±RW GMA Business32 Premium Educ Sep 08
ThinkCentre®M57e Small (9482) - Vista®(June 2008)
GHzType-model Processor Memory8
SATA
disk
SATA
optical Graphics
Core
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
☞US model announced August 19, 2008; previous models on June 24, 2008
© Lenovo
(MONA2-1) August 2008
Vista
preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
Preloaded applications5
•Some: Education software
-VitalSource Library College Edition
-Adobe®Instructor Resource Center
-Adobe Digital School Collection
− Photoshop Elements 6 (and CD)
−Premier Elements 4 (and DVD)
− Acrobat 8 Professional (and CD)
− Contribute 4 (and CD)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD±RW)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Vista
logo
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 2GB 45J5916
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable 160GB Hard Disk 43R1784
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1700p 17" Monitor 9417HE2
ThinkVision L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
• These models have a 3-year limited warranty1
☞

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E5200 with dual-core,
800MHz system bus, and 2MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 9482-H8U 2x3 Pentium E5200 2.50 2MB 2 1GB 160GB2 DVD GMA Business32 Premium None Nov 08
M57e 9482-H9U 2x3 Pentium E5200 2.50 2MB 2 1GB 160GB DVD±RW GMA Business32 Premium None Nov 08
M57e 9482-J1U 2x3 Pentium E5200 2.50 2MB 2 2GB 160GB DVD±RW GMA Business32 Premium None Nov 08
ThinkCentre®M57e Small (9482) - Vista®(October 2008)
GHzType-model Processor Memory8
SATA
disk
SATA
optical Graphics
Cores
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
US models announced October 21, 2008
© Lenovo
(MONA3-1) October 2008
Vista
preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Vista
logo
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Security Memory Key 4GB 41U5120
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
DVD-ROM DL SATA 1.5Gb/s 16-48X Max 41N5618
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1700p 17" Monitor 9417HE2
ThinkVision L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
• These models have a 3-year limited warranty1

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
SATA Combo
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Core™2 Duo Processor E4600 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB shared L2 cache or
Intel Core 2 Duo Processor E8200 or E8400 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 6MB shared L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Italics: standard memory in both sockets; no sockets avail;
Non-italics: standard memory in one socket; one socket available
All: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to
256MB), one analog VGA DB-15 connector
Some: ADD2 DVI-I PCIe Connection Adapter, PCI Express®
adapter in PCIe x16 slot, provides DVI-I connector to
support second monitor, no DVI-to-VGA dongle
160GB or 250GB, SATA 3.0Gb/s 7200 rpm, vibration dampening
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15, DVI-I in some models)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo® logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing, 80% PSU
M57e 9487-ADU 2x3 Core 2 Duo E4600 2.40 2MB Dual 1GB 160GB2 Combo GMA ES40 Stand Bus32 Basic Gbl Mar 08
M57e 9487-AFU 2x3 Core 2 Duo E4600 2.40 2MB Dual 1GB 160GB Combo GMA+ADD2 ES40 Bus32 Basic Gbl Mar 08
M57e 9487-AEU 2x3 Core 2 Duo E8200 2.66 6MB Dual 1GB 160GB Combo GMA ES40 Stand Bus32 Basic Gbl Mar 08
M57e 9487-AGU 2x3 Core 2 Duo E8400 3.00 6MB Dual 2GB 250GB DVD±RW GMA+ADD2 ES40 Bus32 Prem Gbl Mar 08
ThinkCentre®M57e Small (9487) - ENERGY STAR®4.0
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics Core
Avail
dateName Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
US models announced March 18, 2008
© Lenovo
(MONA1-7) March 2008
Vista
preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista®
Business Edition (32-bit)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (combo, DVD±RW)
•Corel®WinDVD®(combo, DVD±RW)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•Some: system floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)*
Slot 2: Low Profile, 32-bit PCI 2.3
* used in some models
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Vista
logo
EPEAT™Gold rating
ENERGY STAR 4.0-compliant
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
• These models have a 3-year limited warranty1
Floor
stand
ENERGY
STAR 4.0

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2180 or E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo Processor E7200 or E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing, 80% PSU
M57e 9487-B3U 2x3 Pentium E2180 2.00 1MB Dual 1GB 160GB2 DVD±RW GMA ES40 XP Pro None Sep 08
M57e 9487-B4U 2x3 Pentium E2200 2.20 1MB Dual 2GB 160GB DVD±RW GMA ES40 XP Pro None Sep 08
M57e 9487-B5U 2x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB DVD±RW GMA ES40 XP Pro None Sep 08
M57e 9487-B6U 2x3 Core 2 Duo E7200 2.53 3MB Dual 2GB 160GB DVD GMA ES40 XP Pro None Sep 08
M57e 9487-B1U 2x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB DVD±RW GMA ES40 Bus32 Basic None Jul 08
M57e 9487-B7U 2x3 Core 2 Duo E7300 2.66 3MB Dual 1GB 160GB DVD±RW GMA ES40 Bus32 Prem None Sep 08
ThinkCentre®M57e Small (9487) - ENERGY STAR®4.0 (June 2008)
GHzType-model Processor Memory8
SATA
disk
SATA
optical Graphics
Core
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global
Educ
L2
cache
See footnotes for important warranty information
☞US models announced August 19, 2008; previous model on June 24, 2008
© Lenovo
(MONA2-2) August 2008
Preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Microsoft®Windows® XP
Professional with Vista®COA
- Some: Microsoft Windows Vista
Business Edition (32-bit)
Preloaded applications5(all OSes)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Multimedia Center for Think Offerings
(DVD, DVD±RW) (XP)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
•Corel WinDVD Creator (DVD±RW) (XP)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Vista
logo
EPEAT™Gold rating
ENERGY STAR 4.0-compliant
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
DVD-ROM DL SATA 1.5Gb/s 16-48X Max 41N5618
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
• These models have a 3-year limited warranty1
ENERGY
STAR 4.0
☞
☞
☞
☞
☞

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Core™2 Duo Processor E8400 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 6MB L2 cache
Processor in FC-LGA8 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing, 80% PSU
M57e 6178-B1U 2x3 Core 2 Duo E8400 3.00 6MB Dual 1GB 160GB2 DVD±RW GMA ES40 Business32 3-yr G P Jul 08
ThinkCentre®M57e Small (6178) - ENERGY STAR®4.0 (GMP)
GHzType-model Processor Memory8
SATA
disk
SATA
optical Graphics
Core
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
Global (G)
GMP (P)
L2
cache
See footnotes for important warranty information
US model announced June 24, 2008
© Lenovo
(MONA2-3) June 2008
Vista
preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•4-year LOR 9x5, Next Business Day
(ThinkPlus™part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista®
Business Edition (32-bit)
✧Vista Basic logo
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD±RW)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Limited
warranty1
• This model is part of the Global Models Plus (GMP) program with limited onsite service33-year limited warranty
ENERGY
STAR 4.0
EPEAT™Gold rating
ENERGY STAR 4.0-compliant
RoHS-compliant
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Security Memory Key 4GB 41U5120
USB 2.0 Ultra Secure Memory Key 2GB 45J5916
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable 160GB Hard Disk 43R1784
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1700p 17" Monitor 9417HE2
ThinkVision L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories

Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
SATA Combo
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
and 800MHz system bus with 1MB shared L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo® logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
280 watts with variable speed fan, autosensing
M57e 7066-AAU 2x3 Pentium E2200 2.20 1MB Dual 1GB 160GB2 Combo GMA Business32 Basic 3-yr G P Apr 08
ThinkCentre®M57e Small (7066) - GMP
GHz
Type-model Processor Memory8
SATA
disk
SATA
optical Graphics Core
Avail
dateName Slot x
bay
Personal Systems Reference (PSREF)
Global (G)
GMP (P)
L2
cache
See footnotes for important warranty information
US model announced March 18, 2008
© Lenovo
(MONA1-11) March 2008
Vista
preload
Security
•Security slot (in rear for attachment of
optional Kensington®Microsaver®cable)
- optional cable also locks the cover by
deactivating the cover release buttons
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•4-year LOR 9x5, Next Business Day
(ThinkPlus™part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Supports ThinkVantage®technologies
Preloaded operating system20
- Microsoft®Windows®Vista®
Business Edition (32-bit)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (combo)
•Corel®WinDVD®(combo)
•Business black color; metal case
•12.5" W X 14.0" D X 3.9" H
•317mm W X 355mm D X 99mm H
•16.1 lb (7.3 kg) in maximum configuration
•Bays 1, 2, 3 flip up (latched and pivoting)
•Toolless cover flips up and tilts backward on rear hinges
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
•Toolless systemboard retention
•Steel chassis supports 100 lb (45kg) monitor on top
•System floor stand for vertical orientation
Small
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, 32-bit PCI 2.3
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, no access, std disk
Bay ③3.5", .5" high, access, open (reader/diskette)
optical disk
(in rear)
Limited
warranty1
RoHS-compliant
• This model is part of the Global Models Plus (GMP) program with limited onsite service33-year limited warranty
Vista
logo
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 2GB 45J5916
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable 160GB Hard Disk 43R1784
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1700p 17" Monitor 9417HE2
ThinkVision L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories

•Business black color
•13.0" W X 16.2" D X 4.1" H
•331mm W X 412mm D X 104mm H
•19.4 lb (8.8 kg) in max configuration
•Toolless cover removal
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
SATA Combo
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Celeron®Processor 420 with single-core, Intel 64 Tech,
Execute Disable Bit, 800MHz system bus, and 512KB L2 cache or
Intel Pentium®Dual-Core Processor E2160 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB shared L2 cache or
Intel Core™2 Duo Processor E4500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB shared L2 cache or
Intel Core 2 Duo Processor E6550 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, 1333MHz system bus, and 4MB shared L2 cache or
Intel Core 2 Duo Processor E8200 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 6MB shared L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max4Drive
Some: CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
220 watts with variable speed fan, manual switch
M57e 9481-A1U 4x3 Celeron 420 1.60 512KB Single 1GB 160GB2DVD GMA XP Pro 3-yr None Mar 08
M57e 9481-A6U 4x3 Pentium E2160 1.80 1MB Dual 1GB 160GB Combo GMA XP Pro 3-yr None Mar 08
M57e 9481-A2U 4x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA XP Pro 3-yr None Mar 08
M57e 9481-A7U 4x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 160GB DVD±RW GMA XP Pro 3-yr None Mar 08
M57e 9481-BAU 4x3 Core 2 Duo E8200 2.66 6MB Dual 1GB 160GB Combo GMA XP Pro 3-yr None Mar 08
ThinkCentre®M57e Desktop (9481)
GHzType-model Memory8
SATA
disk
SATA
optical
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
L2
cache
Desktop
See footnotes for important warranty information
☞US model announced March 18, 2008; previous models on February 26, 2008
✂ US models withdrawn effective September 2008 or January 2009
© Lenovo
(MONA1-5) March 2008
PreloadCoreProcessor Graphics
optical
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, access, open (reader/diskette)
Bay ③3.5", 1" high, no access, std disk
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, PCI Express x1
Slot 3: Low Profile, 32-bit PCI 2.3
Slot 4: Low Profile, 32-bit PCI 2.3
Global
Educ
Limited
warranty1
②
Security
•One lock to secure both cover and
entire system to fixed object:
- Padlock loop (in rear for opt padlock)
- Security slot (in rear for optional
Kensington®Microsaver®cable)
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Supports ThinkVantage®technologies
RoHS-compliant
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
ThinkVision
®
L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
NVIDIA®Quadro®256MB NVS 290 43R1765
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
disk
Preloaded operating system20
- Microsoft®Windows® XP Professional
with Vista®COA
✧Disk-to-Disk Recovery (in hidden
protected area)
Preloaded applications5(only some listed)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
•Diskeeper®Home
• Microsoft Office 2007 Trial (60-day)
•Multimedia Center for Think Offerings
(combo, DVD, DVD±RW)
•Sonic RecordNow and Drive Letter
Access (combo, DVD±RW)
•Corel®WinDVD®(combo, DVD, DVD±RW)
•Corel WinDVD Creator (DVD±RW)
☞
✂
✂

•Business black color
•13.0" W X 16.2" D X 4.1" H
•331mm W X 412mm D X 104mm H
•19.4 lb (8.8 kg) in max configuration
•Toolless cover removal
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2180 or E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo Processor E7200 or E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
All: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to
256MB), one analog VGA DB-15 connector
Some: ADD2 DVI-D Monitor Connection (HDCP), PCI Express®
adapter in PCIe x16 slot, provides DVI-D connector to
support second monitor, HDCP-compliant
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15, DVI-D in some models)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
220 watts with variable speed fan, manual switch
M57e 9481-J1U 4x3 Pentium E2180 2.00 1MB Dual 1GB 160GB2 DVD GMA XP Pro 3-yr None Aug 08
M57e 9481-J2U 4x3 Pentium E2180 2.00 1MB Dual 1GB 160GB DVD±RW GMA+ADD2 XP Pro 3-yr None Aug 08
M57e 9481-J3U 4x3 Pentium E2200 2.20 1MB Dual 1GB 160GB DVD GMA XP Pro 3-yr None Aug 08
M57e 9481-J4U 4x3 Pentium E2200 2.20 1MB Dual 2GB 160GB DVD±RW GMA XP Pro 3-yr None Aug 08
M57e 9481-J6U 4x3 Core 2 Duo E7200 2.53 3MB Dual 2GB 160GB DVD GMA XP Pro 3-yr None Aug 08
M57e 9481-J5U 4x3 Core 2 Duo E7200 2.53 3MB Dual 2GB 160GB DVD±RW GMA+ADD2 XP Pro 3-yr None Aug 08
M57e 9481-J7U 4x3 Core 2 Duo E7300 2.66 3MB Dual 1GB 160GB DVD±RW GMA XP Pro 3-yr None Aug 08
ThinkCentre®M57e Desktop (9481) - August 2008
GHz
Type-model Memory8
SATA
disk
SATA
optical
Avail
date
Name
Slot x
bay
Personal Systems Reference (PSREF)
L2
cache
Desktop
See footnotes for important warranty information
US models announced August 19, 2008
© Lenovo
(MONA2-13) August 2008
PreloadCoreProcessor Graphics
optical
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, access, open (reader/diskette)
Bay ③3.5", 1" high, no access, std disk
Slot 1: Low Profile, PCI Express x16 (35w max)*
Slot 2: Low Profile, PCI Express x1
Slot 3: Low Profile, 32-bit PCI 2.3
Slot 4: Low Profile, 32-bit PCI 2.3
* used in some models
Global
Educ
Limited
warranty1
②
Security
•One lock to secure both cover and
entire system to fixed object:
- Padlock loop (in rear for opt padlock)
- Security slot (in rear for optional
Kensington®Microsaver®cable)
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Supports ThinkVantage®technologies
RoHS-compliant
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
NVIDIA®Quadro®256MB NVS 290 43R1765
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
disk
Preloaded operating system20
- Microsoft®Windows® XP Professional
with Vista®COA
✧Disk-to-Disk Recovery (in hidden
protected area)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
•Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Multimedia Center for Think Offerings
(DVD, DVD±RW)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
•Corel WinDVD Creator (DVD±RW)

•Business black color
•13.0" W X 16.2" D X 4.1" H
•331mm W X 412mm D X 104mm H
•19.4 lb (8.8 kg) in max configuration
•Toolless cover removal
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
SATA Combo
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Celeron®Processor 420 with single-core, Intel 64 Tech,
Execute Disable Bit, 800MHz system bus, and 512KB L2 cache or
Intel Pentium®Dual-Core Processor E2160 or E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB shared L2 cache or
Intel Core™2 Duo Processor E4500 or E4600 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB shared L2 cache or
Intel Core 2 Duo Processor E6550 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, 1333MHz system bus, and 4MB shared L2 cache or
Intel Core 2 Duo Processor E8200 with dual-core,
Intel 64 Technology, Virtualization Technology, Execute Disable Bit,
EIST, TXT, and 1333MHz system bus with 6MB shared L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max4Drive
Some: CD-RW/DVD-ROM Combo SATA 1.5Gb/s Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
220 watts with variable speed fan, manual switch
M57e 9481-A5U 4x3 Celeron 420 1.60 512KB Single 1GB 160GB2DVD GMA Business32 3-yr Mar 08
M57e 9481-A4U 4x3 Pentium E2160 1.80 1MB Dual 1GB 160GB Combo GMA Business32 3-yr Mar 08
M57e 9481-D5U 4x3 Pentium E2200 2.20 1MB Dual 1GB 160GB Combo GMA Business32 3-yr Gbl Mar 08
M57e 9481-A3U 4x3 Core 2 Duo E4500 2.20 2MB Dual 1GB 160GB Combo GMA Business32 3-yr Mar 08
M57e 9481-D6U 4x3 Core 2 Duo E4600 2.40 2MB Dual 1GB 160GB Combo GMA Business32 3-yr Gbl Mar 08
M57e 9481-A8U 4x3 Core 2 Duo E6550 2.33 4MB Dual 1GB 160GB DVD±RW GMA Business32 3-yr Mar 08
M57e 9481-A9U 4x3 Core 2 Duo E8200 2.66 6MB Dual 1GB 160GB Combo GMA Business32 3-yr Gbl Mar 08
ThinkCentre®M57e Desktop (9481) - Vista®
GHzType-model Memory8
SATA
disk
SATA
optical
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
L2
cache
Desktop
See footnotes for important warranty information
☞US models announced March 18, 2008; previous models on February 19, 2008
✂ US models withdrawn effective September 2008 or January 2009
© Lenovo
(MONA1-2) March 2008
Vista
preloadCoreProcessor Graphics
optical
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, access, open (reader/diskette)
Bay ③3.5", 1" high, no access, std disk
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, PCI Express x1
Slot 3: Low Profile, 32-bit PCI 2.3
Slot 4: Low Profile, 32-bit PCI 2.3
Global
Educ
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
✧Vista Basic logo
Preloaded applications5(only some listed)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•Norton Internet Security™
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (combo, DVD±RW)
•Corel®WinDVD®(combo, DVD,
DVD±RW)
Limited
warranty1
②
Security
•One lock to secure both cover and
entire system to fixed object:
- Padlock loop (in rear for opt padlock)
- Security slot (in rear for optional
Kensington®Microsaver®cable)
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Supports ThinkVantage®technologies
RoHS-compliant
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
ThinkVision
®
L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
NVIDIA®Quadro®256MB NVS 290 43R1765
Other accessories at lenovo.com/accessories
disk
☞
☞
☞
✂
✂

•Business black color
•13.0" W X 16.2" D X 4.1" H
•331mm W X 412mm D X 104mm H
•19.4 lb (8.8 kg) in max configuration
•Toolless cover removal
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Core™2 Duo Processor E7200 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA8 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
220 watts with variable speed fan, manual switch
M57e 9481-F2U 4x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB2DVD±RW GMA Business32 3-yr None Jun 08
ThinkCentre®M57e Desktop (9481) - Vista®(June 2008)
GHz
Type-model Memory8
SATA
disk
SATA
optical
Avail
date
Name
Slot x
bay
Personal Systems Reference (PSREF)
L2
cache
Desktop
See footnotes for important warranty information
US model announced June 24, 2008
© Lenovo
(MONA2-5) June 2008
Vista
preload
Core
Processor Graphics
optical
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, access, open (reader/diskette)
Bay ③3.5", 1" high, no access, std disk
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, PCI Express x1
Slot 3: Low Profile, 32-bit PCI 2.3
Slot 4: Low Profile, 32-bit PCI 2.3
Global
Educ
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
✧Vista Basic logo
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD±RW)
Limited
warranty1
②
Security
•One lock to secure both cover and
entire system to fixed object:
- Padlock loop (in rear for opt padlock)
- Security slot (in rear for optional
Kensington®Microsaver®cable)
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Supports ThinkVantage®technologies
RoHS-compliant
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Security Memory Key 4GB 41U5120
USB 2.0 Ultra Secure Memory Key 2GB 45J5916
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable 160GB Hard Disk 43R1784
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1700p 17" Monitor 9417HE2
ThinkVision L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
NVIDIA®Quadro®256MB NVS 290 43R1765
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
disk
• This model has a 3-year limited warranty1

•Business black color
•13.0" W X 16.2" D X 4.1" H
•331mm W X 412mm D X 104mm H
•19.4 lb (8.8 kg) in max configuration
•Toolless cover removal
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E5200 with dual-core,
800MHz system bus, and 2MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to 256MB),
one analog VGA DB-15 connector,
supports dual independent display with optional ADD2 adapter
160GB or 250GB, SATA 3.0Gb/s 7200 rpm, vibration dampening
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express®x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
220 watts with variable speed fan, manual switch
M57e 9481-JCU 4x3 Pentium E5200 2.50 2MB 2 1GB 160GB2DVD GMA Business32 Premium None Nov 08
M57e 9481-JDU 4x3 Pentium E5200 2.50 2MB 2 1GB 250GB DVD±RW GMA Business32 Premium None Nov 08
ThinkCentre®M57e Desktop (9481) - Vista®(October 2008)
GHz
Type-model Memory8
SATA
disk
SATA
optical
Avail
date
Name
Slot x
bay
Personal Systems Reference (PSREF)
L2
cache
Desktop
See footnotes for important warranty information
US models announced October 21, 2008
© Lenovo
(MONA3-2) October 2008
Vista
preload Vista
logo
Cores
Processor Graphics
optical
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, access, open (reader/diskette)
Bay ③3.5", 1" high, no access, std disk
Slot 1: Low Profile, PCI Express x16 (35w max)
Slot 2: Low Profile, PCI Express x1
Slot 3: Low Profile, 32-bit PCI 2.3
Slot 4: Low Profile, 32-bit PCI 2.3
Global
Educ
Preloaded operating system20
- Microsoft®Windows®Vista
Business Edition (32-bit)
Preloaded applications5
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
(90 days of virus definitions)
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
②
Security
•One lock to secure both cover and
entire system to fixed object:
- Padlock loop (in rear for opt padlock)
- Security slot (in rear for optional
Kensington®Microsaver®cable)
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Supports ThinkVantage®technologies
RoHS-compliant
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Essential Memory Key 32GB 45K1258
USB 2.0 Security Memory Key 4GB 41U5120
USB 2.0 Ultra Secure Memory Key 4GB 45J5917
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable 160GB Hard Disk 43R1784
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
DVD-ROM DL SATA 1.5Gb/s 16-48X Max 41N5618
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L1700p 17" Monitor 9417HE2
ThinkVision L1940p Wide 19" Monitor 4424HB6
ThinkVision L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
NVIDIA®Quadro®256MB NVS 290 43R1765
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
disk
• These models have a 3-year limited warranty1

•Business black color
•13.0" W X 16.2" D X 4.1" H
•331mm W X 412mm D X 104mm H
•19.4 lb (8.8 kg) in max configuration
•Toolless cover removal
•Toolless disk, diskette drive, optical drive removal
•Toolless adapter retention
Positioning
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
eSATA port
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Internal connector
Rear audio ports
Audio
Speaker
Ethernet
Intel AMT
Modem
Security chip
Keyboard
Mouse
Power supply
Mainstream enterprise stability and manageability
Intel®Pentium®Dual-Core Processor E2180 or E2200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo Processor E7200 or E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
1GB or 2GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets;
Non-italics: standard memory in one socket; one socket available
All: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory (up to
256MB), one analog VGA DB-15 connector
Some: ADD2 DVI-D Monitor Connection (HDCP), PCI Express®
adapter in PCIe x16 slot, provides DVI-D connector to
support second monitor, HDCP-compliant
160GB, SATA 3.0Gb/s 7200 rpm, vibration dampening mounts
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max4Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors on planar
None
Enhanced IDE, ATA-100, integrated in ICH7, one EIDE connector on planar
None
None
Intel G31 Express Chipset; I/O Controller Hub 7 (ICH7) for SATA 3.0Gb/s,
ATA-100 EIDE, PCI Express x1, PCI 2.3, USB, LPC bus /
ITE Tech®IT8718 Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, serial (9-pin), parallel (25-pin), keyboard (PS/2), mouse (PS/2),
ethernet (RJ-45), monitor (VGA DB-15, DVI-D in some models)
Two USB 2.0 planar connectors (one used; one open for media reader)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone (stereo, 3.5mm)
High Definition (HD) Audio, Realtek®ALC662 codec
One internal speaker for business audio
Gigabit ethernet on planar, Marvell®88E8056, PCIe x1, Wake on LAN®
None
None
None
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo®logo
Optical Wheel Mouse (USB connector), 400 dpi, black, Lenovo logo
220 watts with variable speed fan, autosensing, 80% PSU
M57e 9438-AJU 4x3 Pentium E2180 2.00 1MB Dual 1GB 160GB2 DVD±RW GMA ES40 XP Pro No Sep 08
M57e 9438-AKU 4x3 Pentium E2200 2.20 1MB Dual 2GB 160GB DVD±RW GMA ES40 XP Pro No Sep 08
M57e 9438-ALU 4x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB DVD±RW GMA ES40 XP Pro No Sep 08
M57e 9438-AMU 4x3 Core 2 Duo E7200 2.53 3MB Dual 2GB 160GB DVD GMA+ADD2 ES40 XP Pro No Sep 08
M57e 9438-B1U 4x3 Core 2 Duo E7200 2.53 3MB Dual 1GB 160GB DVD±RW GMA ES40 Bus32 Basic No Jun 08
M57e 9438-ANU 4x3 Core 2 Duo E7300 2.66 3MB Dual 1GB 160GB DVD±RW GMA ES40 Bus32 Prem No Sep 08
ThinkCentre®M57e Desktop (9438) - ENERGY STAR®4.0
GHz
Type-model Memory8
SATA
disk
SATA
optical
Avail
dateName
Slot x
bay
Personal Systems Reference (PSREF)
L2
cache
Desktop
See footnotes for important warranty information
☞US models announced August 19, 2008; previous model on June 24, 2008
© Lenovo
(MONA2-6) August 2008
Preload
Vista
logo
☞
CoreProcessor Graphics
optical
Bay ①5.25", 1.6" high, access, std optical
Bay ②3.5", 1" high, access, open (reader/diskette)
Bay ③3.5", 1" high, no access, std disk
Slot 1: Low Profile, PCI Express x16 (35w max)*
Slot 2: Low Profile, PCI Express x1
Slot 3: Low Profile, 32-bit PCI 2.3
Slot 4: Low Profile, 32-bit PCI 2.3
* used in some models
☞
☞
☞
☞
Global
Educ
Preloaded operating system20
- Some: Microsoft®Windows® XP
Professional with Vista®COA
- Some: Microsoft Windows Vista
Business Edition (32-bit)
Preloaded applications5(all OSes)
•Rescue and Recovery™
•Client Security Solution™
•ThinkVantage Productivity Center
•System Migration Assistant
•Norton Internet Security™
• Diskeeper®Home
•PC-Doctor™ (diagnostics)
•Adobe®Reader
•Windows Live™Toolbar
•Windows Live Search
•Picasa from Google
• Microsoft Office 2007 Trial (60-day)
•Multimedia Center for Think Offerings
(DVD, DVD±RW) (XP)
•Sonic RecordNow and Drive Letter
Access (DVD±RW)
•Corel®WinDVD®(DVD, DVD±RW)
•Corel WinDVD Creator (DVD±RW) (XP)
②
Security
•One lock to secure both cover and
entire system to fixed object:
- Padlock loop (in rear for opt padlock)
- Security slot (in rear for optional
Kensington®Microsaver®cable)
• Power-on password
• Administrator password
• Hard disk password
• Boot sequence control
• Boot without keyboard, mouse, diskette
• Serial port I/O control
• Parallel port I/O control
• USB port disablement
Supports ThinkVantage®technologies
Limited Warranty1
➫ 3-year parts and labor
➫ International Warranty Service9
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Onsite service upgrade options
(in eligible locations):7
•3-year LOR 9x5, 4 hour response
(ThinkPlus™part number 41C9192)
•3-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9193)
•4-year LOR 9x5, Next Business Day
(ThinkPlus part number 41C9194)
•4-year LOR 9x5, 4 hour response
(ThinkPlus part number 41C9195)
•4-year LOR 24x7, 4 hour response
(ThinkPlus part number 41C9196)
➫ThinkPlus services at
lenovo.com/thinkplus/warranty
➫ Post warranty maintenance
services available
➫ 24 hour x 7 day14 toll-free support
during the warranty period1
via 800-426-7378
Accessories
1GB PC2-5300 CL5 NP DDR2 UDIMM 73P4984
2GB PC2-5300 CL5 NP DDR2 UDIMM 73P4985
1GB PC2-6400 NP DDR2 UDIMM 41U2977
2GB PC2-6400 NP DDR2 UDIMM 41U2978
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
USB Portable Diskette Drive 05K9276
USB 2.0 Lenovo Multimedia Headset 40Y8518
USB 2.0 Lenovo Webcam 40Y8519
USB 2.0 Ultra Secure Memory Key 8GB 45J5918
USB 2.0 Portable Secure 320GB Hard Disk 43R2019
Super Multi-Burner DL DVD±RW SATA Drive 41N5620
ThinkVision
®
L2240p Wide 22" Monitor 4422HB6
ThinkVision L2440p Wide 24" Monitor 4420HB2
Wireless Kbd & Opt Wheel Mouse (via USB) 73P4067
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074
Kensington Cable Lock from Lenovo 73P2582
ADD2 DVI-I PCIe Connection Adapter 73P2516
ADD2 DVI-D Monitor Connection (HDCP) 43R1985
AT I ™Radeon™HD 2400 Pro 128MB 43R1961
ATI Radeon HD 2400 XT 256MB 43R1962
NVIDIA®Quadro®256MB NVS 290 43R1765
Acc Guide in pdf lenovo.com/accessoriesguide
Other accessories at lenovo.com/accessories
disk
EPEAT™Gold rating
ENERGY STAR 4.0-compliant
RoHS-compliant
• These models have a 3-year limited warranty1
ENERGY
STAR 4.0
