Lenovo 3249ERU User manual

thinkpad
x201-x201s
Windows®. Life without Walls™.
Lenovo®recommends Windows 7.
EXPERIENCE
ENHANCED
thE thinkpad®x201/x201snOtEBOOk
The new Lenovo ThinkPad X201 and X201s notebooks are
designed for today’s mobile professionals, offering the freedom to
work whenever, wherever and however you work best.
Faster: Free up your time to focus on what really matters with the
fastest computing available in an enterprise-class ultra-portable
notebook. With CPU base frequencies of up to 2.66 GHz (25%
faster than Low Voltage CPUs), starting up, shutting down and
loading applications are fast.
25% faster CPUs than competing low-volt only CPU solutions•
Lenovo Windows• ®7 Enhanced Experience—startup time - 20 sec and shutdown time - 5 sec
Intel• ®Core™ i7 & Core™ i5 CPUs with Turbo Boost and Hyper-Threading technologies
Faster log on experience with the advanced fingerprint reader•
More Secure: The most comprehensive suite of enterprise-class
security features frees from overbearing fears of data loss and theft.
Central management of hardware passwords including self-encrypting hard drives•
BIOS port lockout options•
CompuTrace• ®Theft Recovery and Remote Data Disablement
Advanced fingerprint reader technology•
MOBILE FREEDOM—PRODUCTIVITY ANYWHERE
tOp REaSOnS tO OWn
FASTER•
MORE MOBILE•
MORE SECURE•
MORE DURABLE•
More Mobile: Free yourself from the walls of your office and stay
productive even when you are on the move with the low weight,
long battery life and superior wireless connectivity options.
Over 12 hours maximum battery life•
Lightweight ultraportable—starting at 2.48 lbs•
Multiple wireless connectivity options—WiMAX, 3G with GPS and Wireless WAN•
More Durable: Free yourself from unnecessary worry with laptop
designed from the inside out to withstand the rigors of life outside
the office.
Designed to pass 8 rigorous MilSpec tests•
(physical shock, thermal shock, altitude, dust, vibration, humidity, heat and cold)
Shock-mounted hard drive protection with Active Protection System™•
Spill-resistant keyboards•
Magnesium alloy or carbon-glass fiber top and bottom covers•
ThinkVantage• ®Rescue and Recovery®
LEnOVO EnhanCEd ExpERiEnCE
FOR WindOWS®7.
FaSt. SECURE. BUiLt FOR BUSinESS.
Discover a better way of doing business with the new Lenovo Enhanced
Experience for Windows®7 on Think-branded PCs. Faster, more durable and
greener Think-branded PCs are optimized for Windows®7 to deliver improved
ease of use. It enhances productivity and foolproof security that your business
cannot do without.

thinkpad
x201-x201s
Windows®. Life without Walls™.
Lenovo®recommends Windows 7.
EXPERIENCE
ENHANCED
SERVICE OFFERINGS
thinkpLUS™SUppORt
Lowers overall IT support costs and reduces unbudgeted support
and repair expenses.
BaSE WaRRantY SERViCE
Provides Lenovo standard award-winning service and support
think pLUS WaRRant Y E xtEnSiOn and UpGRadE
Protects investment and increases productivity with the enhanced
service-level upgrade and term extension
thinkpLUS pRiORitY SUppORt
Provides technical support for the business—increases helpdesk
productivity with 24x7 advanced-level technical support and service
call-tracking tools
thinkpLUS pRiORitY 4
Offers enhanced onsite response within 4 hours for critical IT
support needs
thinkpLUS pROtECtiOn
Protects PCs and data from the unexpected—saves money,
reduces hassles and offers peace-of-mind
haRd diSk dRiVE REtEntiOn
Allows you to retain your hard drive if it fails and thus protects data
from falling into the wrong hands
thinkpLUS SECURE BUSinESS
Provides security—the protection bundle includes
Next Business Day (NBD) onsite service, ThinkPad Protection and
Lenovo Online Backup
LEnOVO OnLinE BaCkUp
Provides secure, encrypted and offsite storage for your
customer’s data
thinkpad pROtECtiOn (tpp)
Includes repair of accidental damage, drops, or spills not covered
by warranty
thinkpLUS EntERpRiSE SOLUtiOnS
Offer peace-of-mind with Lenovo as a single-point-of-contact—
manages infrastructure, consolidates contracts and streamlines the
number of vendors
LEnOVO pROFESSiOnaL SERViCES
Offer professional engineering and project management services to
implement new technologies
LEnOVO iMaGinG SERViCES
Offer image creation, image verification and management services
LEnOVO ManaGEd dEpLOYMEnt
Offers factory integration, imaging, installation, deployment and
consulting services
LEnOVO aSSEt RECOVERY SERViCES
Recover value from old assets and help you dispose,
data securely—turns old PC trash into cash
EnViROnMEntaLLY RESpOnSiBLE dESiGn
Lenovo has always advocated for a greener environment. Hence, the
ThinkPad X201 and X201s notebooks fully comply with environmental
standards such as EPEAT®Gold, Energy Star®5.0 and RoHS.

THINKPAD
X201-X201s
Windows®. Life without Walls™.
Lenovo®recommends Windows 7.
EXPERIENCE
ENHANCED
MODEL NAME – X201/X201s LAPTOP
CPU/Chipset
X201
2.53 GHz Intel• ®Core™ i5-540M
2.40 GHz Intel• ®Core™ i5-520M
X201s
2.13 GHz Intel• ®Core™ i7-640LM
2.0 GHz Intel• ®Core™ i7-620LM
Operating Systems
Genuine Windows• ®XP Professional
Genuine Windows• ®7 Home Premium
Genuine Windows• ®7 Professional
DOS (support)•
Dimensions
X201
X201
4/6 cell: 295 x 210 x 20.7 - 35.3 mm•
(11.6 x 8.3 x 0.8 - 1.4")
9 cell: 295 x 233.8 x 20.7 - 35.3 mm•
(11.6 x 9.2 x 0.8 - 1.4")
X201s
4 cell: 295 x 210 x 20.7 - 28.7 mm•
(11.6 x 8.3 x 0.08 -1.1")
6 cell: 295 x 210 x 20.7 - 35.3 mm•
(11.6 x 8.3 x 0.08 - 1.4")
9 cell: 295 x 210 x 20.7 - 35.3 mm•
(11.6 x 9.2 x 0.08 -1.4")
Camera
2.0 MP low-light camera 9•
Display
X201
12.1" WXGA, LED Display (16:10)•
X201s
12.1" WXGA + LED Display (16:10)•
Weight
X201
4 cell: 2.89 lbs (1.34 kg)•
6 cell: 3.18 lbs (1.47 kg)•
9 cell: 3.52 lbs (1.63 kg)•
X201s
4 cell: 2.48 lbs (1.10 kg)•
6 cell: 2.77 lbs (1.23 kg)•
9 cell: 3.11 lbs (1.39 kg)•
I/O Ports
Gigabit Ethernet•
Modem (optional)•
3 USB ports•
VGA port•
Microphone/line-in•
Headphone/line-out•
ExpressCard (54 mm) slot•
5-1 Media Card Reader with modem/•
3-1 Media Card Reader with modem and no modem for
weight optimized system
Storage
5400 RPM SATA Hard Drives: 160GB, 250GB, 320GB•
7200 RPM SATA Hard Drives: 320GB, 500GB•
Solid State Drive: 128GB•
Memory
1GB, 2GB, 3GB, 4GB, 6GB, 8GB•
Wireless Connectivity
ThinkPad Wireless BGN•
Intel• ®Centrino®Wireless-N 1000 BGN
Intel• ®Centrino®Advanced-N 6200 AGN
Intel• ®Centrino®Ultimate-N 6300 AGN
Bluetooth• ®
Keyboard
100% full-size, spill-resistant keyboard•
Battery life
X201
Up to 3.3 hours for a 4-cell battery•
Up to 6.6 hours for a 6-cell battery•
Up to 11.0 hours for a 9-cell battery•
X201s
Up to 3.6 hours for a 4-cell battery•
Up to 7.3 hours for a 6-cell battery•
Up to 12.2 hours for a 9-cell battery•
Durability Features
Shock-mounted hard drive•
Active Protection System™ for hard drive•
Spill-resistant keyboards•
MilSpec testing•
Navigation
ThinkPad UltraNav™ TrackPoint• ®and
multi-touch touchpad
THE LENOVO®THINKPAD®X201/X201s
LAPTOP SPECIFICATIONS
*
*not available for X201s

Windows®. Life without Walls™.
Lenovo®recommends Windows 7.
EXPERIENCE
ENHANCED
THINKPAD
X201-X201s
Kensington Cable Lock
Help reduce theft, increase physical asset security
ThinkPad only: MicroSaver – 73P2582
ThinkPad and Monitor: Twin Head – 45K1620
Reliable 2.4GHz Wireless keyboard and mouse
combination; contemporary, low profile design
Lenovo Ultraslim Wireless Keyboard and
Mouse (US English) – 57Y4700
ThinkPad Batteries
Carry spare battery, or replace system batteries when
charge capacity diminishes with time
43R9253 ThinkPad Battery 47 (4-cell)
43R9254 ThinkPad Battery 47+ (6-cell)
43R9255 ThinkPad Battery 47++ (9-cell)
www.lenovo.com/support/docks
www.lenovo.com/support/poweradapters
www.lenovopowertips.com
www.lenovo.com/support/keyboards
For compatibility by X201, X201s model, go to:
www.lenovo.com/support/privacyfilters
ThinkPad USB Portable Secure Hard Drive
Secure valuable data in a slim, lightweight design
43R2018 160GB
43R2019 320GB
ThinkPad Privacy Filter
Keeps screen information private.
Easy to insert and remove.
Stays in place even when ThinkPad is closed.
43R2470 ThinkPad X200s (WGA+ only)
55Y9264 ThinkPad X200/X200s (WXGA only)
USB-to-DVI Monitor Adapter –45K5296
High-Definition as easy as plugging into a USB.
One USB-to-DVI Adapter required for each monitor.
Lenovo 90W Ultraslim AC/DC Combo Adapter – 41R4502
Simultaneously power your notebook and your cell phone in
the office, on the road or in the air.
new
new
Carry case easily transport and protect your ThinkPad against bumps and jolts
ThinkPad X200 UltraBase (43R8781)
Pass-through cable management that you can carry with you
anywhere.
Leave at your desk for quick and easy access to peripherals
or carry with your system for convenient device expansion.
Includes an integrated spare battery charger and an
Ultrabay™ Slim for an optical or second hard disk drive.Offers
two monitors ports; VGA analog and DisplayPort, that allows
simoultaneous attachment of dual monitors
Wenger Deluxe Slim Case for
Lenovo – 57Y4272
ThinkPad Ultraportable – 41U5062
