Lenovo ThinkPad Twist S230u Service manual

Personal Systems Reference
Lenovo®ThinkPad
®Edge Notebooks
July 2013 - Version 439 (Western Europe)
Visit www.lenovo.com/psref/we for the latest version

Lenovo®ThinkPad Twist S230u
(Tent Mode)
Lenovo®ThinkPad Twist S230u
Lenovo®ThinkPad Twist S230u
(Tablet Mode)
Lenovo®ThinkPad Twist S230u
Lenovo®ThinkPad Twist S230u
(Stand Mode)
Lenovo®ThinkPad Twist S230u
(Notebook Mode)

Supports ThinkVantage®technologies
Convertible tablet; one spindle
Intel®Core™i3-2375M processor (2 cores, 1.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
2G / PC3-10600 1333MHz DDR3 / soldered to systemboard,
no SO-DIMM sockets
None
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high, Active Protection System™
All: removable, upgradable
16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
12.5" (317.5mm) HD (1366x768) TFT color,
smudgeless and anti-reflective display with Corning®Gorilla®Glass,
LED backlight, 350 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS, rotate and swivel hinge
Bottom buttons: volume up / down and Windows buttons
Side buttons: power and auto rotation buttons
Projected Capacitive Touch (PCT) technology, supports 5-point multi-touch
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 in processor,
supports external digital monitor via Mini HDMI and Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600 (Mini DisplayPort)@60Hz;
1920x1200 (Mini HDMI)@60Hz
6-row, 83-key, spill-resistant, multimedia Fn keys
TrackPoint pointing device
UltraNav™, buttonless touchpad below keyboard, Tap Zones, multi-touch
Ambient light sensor
None
8-cell: 12.32" x 9.29" x 0.79"; 313mm x 236mm x 20mm
8-cell: from 3.50 lb (1.60kg)
Display cover: Magnesium + Polyphenylene sulfide (PPS); Bottom: Magnesium + PPS
Integrated Li-Polymer 8-cell, HW Authentication
None
8-cell (42.4Whr): up to 6.0 hr
Mobile Intel HM77 Express Chipset
4-in-1 reader (SD, SDHC, SDXC, MMC)
None
None
Two USB 3.0, external monitor (mini-HDMI, mini-DisplayPort), ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi + BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit Network Connection Realtek® RTL8111F, PHY, PCIe x1
None
High Definition (HD) Audio, Realtek ALC3202 codec /
stereo speakers, 2 watt x 2, Dolby®Home Theater®v4 certified /
volume up, down, mute buttons / dual array microphone , combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Multi-touch
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
Light sensor
ThinkLight™
Dimensions3
Weight2
Case material
Battery - type
Extended Battery
Battery - life10
Chipset
Multicard Reader
ExpressCard
Smart Card Read
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Twist S230u (3347) - TopSeller
3347-4TG i3-2375M 2GB 12.5" HD Multi 720p 320G 7200 Intel 2230 16GB None Black BT 8 Win8 64 01/13
65-watt AC Adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
ROHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(G-TANR1-2) January 2013
See footnotes for more detailed information
WE model(s) announced January 1, 2013
•Small and medium business (SMB) model(s), part of the WE TopSeller ™Program
•A depot repair service 1-year limited warranty
Type-model
Widescreen
displayMemory
Disk
SATA
GB8 rpm
PCIe
Mini Card
WLAN
Bat-
tery
cellsProcessor Camera
Preloaded operating system20
- Windows®8 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Blue-
tooth
Ann
date
(mm/yy)
SIM card Preload
Top
color
PCIe Mini Card
WWAN/
mSATA

Supports ThinkVantage®technologies
Convertible tablet ultrabook™; one spindle
Intel®Core™i3-3217U processor (2 cores, 1.80GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3317U processor (2 cores, 1.70GHz, 3MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (2.60GHz), HT technology
Intel Core i7-3517U processor (2 cores, 1.90GHz, 4MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.00GHz), HT technology
4GB or 8GB / PC3-10600 1333MHz DDR3 / soldered to systemboard,
no SO-DIMM sockets
None
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high, Active Protection System™
All: removable, upgradable
Some: 24GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
12.5" (317.5mm) HD (1366x768) TFT color,
smudgeless and anti-reflective display with Corning®Gorilla®Glass,
LED backlight, 350 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS, rotate and swivel hinge
Bottom buttons: volume up / down and Windows buttons
Side buttons: power and auto rotation buttons
Projected Capacitive Touch (PCT) technology, supports 5-point multi-touch
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 4000 in processor,
supports external digital monitor via Mini HDMI and Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600 (Mini DisplayPort)@60Hz;
1920x1200 (Mini HDMI)@60Hz
6-row, 83-key, spill-resistant, multimedia Fn keys
TrackPoint pointing device
UltraNav™, buttonless touchpad below keyboard, Tap Zones, multi-touch
Ambient light sensor
None
8-cell: 12.32" x 9.29" x 0.79"; 313mm x 236mm x 20mm
8-cell: from 3.50 lb (1.60kg)
Display cover: Magnesium + Polyphenylene sulfide (PPS); Bottom: Magnesium + PPS
Integrated Li-Polymer 8-cell, HW Authentication
None
8-cell (42.4Whr): up to 6.0 hr
Mobile Intel HM77 Express Chipset
4-in-1 reader (SD, SDHC, SDXC, MMC)
None
None
Two USB 3.0, external monitor (mini-HDMI, mini-DisplayPort), ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi + BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+, GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit Network Connection Realtek® RTL8111F, PHY, PCIe x1
None
High Definition (HD) Audio, Realtek ALC3202 codec /
stereo speakers, 2 watt x 2, Dolby®Home Theater®v4 certified /
volume up, down, mute buttons / dual array microphone , combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Multi-touch
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
Light sensor
ThinkLight™
Dimensions3
Weight2
Case material
Battery - type
Extended Battery
Battery - life10
Chipset
Multicard Reader
ExpressCard
Smart Card Read
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Twist S230u (3347) - TopSeller (Ultrabook)
3347-29G i7-3517U 8GB 12.5" HD Multi 720p 128G SSD Intel 2230 Ericsson Lenovo Black BT 8 Win8 Pro64 10/12
3347-28G i7-3517U 8GB 12.5" HD Multi 720p 128G SSD Intel 2230 Ericsson Lenovo Black BT 8 Win8 64 10/12
3347-27G i5-3317U 4GB 12.5" HD Multi 720p 500G 7200 Intel 2230 24GB None Black BT 8 Win8 Pro64 10/12
3347-26G i5-3317U 4GB 12.5" HD Multi 720p 500G 7200 Intel 2230 24GB None Black BT 8 Win8 64 10/12
3347-4PG i3-3217U 4GB 12.5" HD Multi 720p 320G 7200 Intel 2230 24GB None Black BT 8 Win8 Pro64 12/12
3347-4NG i3-3217U 4GB 12.5" HD Multi 720p 320G 7200 Intel 2230 24GB None Black BT 8 Win8 64 12/12
65-watt AC Adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
ROHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(G-TANR1-1) December 2012
See footnotes for more detailed information
WE model(s) announced October 23 or December 4, 2012
•Small and medium business (SMB) model(s), part of the WE TopSeller ™Program
•A depot repair service 1-year limited warranty
Type-model
Widescreen
displayMemory
Disk
SATA
GB8 rpm
PCIe
Mini Card
WLAN
Bat-
tery
cellsProcessor Camera
Preloaded operating system20
- Some: Windows®8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Blue-
tooth
Ann
date
(mm/yy)
SIM card Preload
Top
color
PCIe Mini Card
WWAN/
mSATA

Lenovo®ThinkPad Edge E130
Lenovo ThinkPad Edge E130
Lenovo ThinkPad Edge E130
Lenovo ThinkPad Edge E130
Lenovo ThinkPad Edge E130
Lenovo ThinkPad Edge E130

65-watt AC adapter
EPEAT™Gold rating
(Windows 7 models)
ENERGY STAR®5.0-compliant
(Windows 7 models)
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: No operating system
- Some: DOS-Lic.
- Some: Genuine Windows®7
Home Premium 64
- Some: Genuine Windows 7
Professional 64
Ready to install applications14
(Windows 7 models; only some listed)
•OneKey Recovery Pro
•Password Manager
Preloaded applications14
(Windows 7 models; only some listed)
•Lenovo®Solution Center
•Lenovo Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•TrueSuite™(fingerprint models)
•ThinkVantage System Update
•ThinkVantage Power Manager
•Lenovo Cloud Storage
by SugarSync
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Evernote®
•Intel Small Business Advantage
•RapidBoot HDD Accelerator
•Symantec™VIP
•Windows Live™Essentials
• Microsoft®Office 2010 preloaded;
purchase product key to activate
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Pentium®977 processor (2 cores, 1.40GHz, 2MB cache), Intel HD Graphics,
DDR3 memory controller (up to 1333MHz)
Intel Pentium 997 processor (2 cores, 1.60GHz, 2MB cache), Intel HD Graphics,
DDR3 memory controller (up to 1333MHz)
Intel Core™i3-2365M processor (2 cores, 1.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-2367M processor (2 cores, 1.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-3227U processor (2 cores,1.90GHz,3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high,
removable, upgradable, Active Protection System ™
Some: mSATA Solid State Drive (SSD), via PCIe Mini Card slot
Some: 11.6" (295mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 11.6" (295mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics, Intel HD Graphics 3000 or Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard, multi-touch
None
11.6W" (WxDxH): 11.30" x 8.35" x 0.85-0.91"; 287mm x 212mm x 21.7-23mm
6-cell: from 3.40 lb (1.54kg)
Midnight black, Heatwave red, or Arctic blue (top), trimmed with a thin silver band (side);
black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4Whr): up to 8.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0, one powered USB 2.0, external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n, 1x1, Wi-Fi + BT combo adapter
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi + BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+, GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in
Wi-Fi + Bluetooth combo adapter
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 /
stereo speakers, 2 watt x 2 / monaural digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E130 3358 (Intel) - TopSeller
3358-5GG Pen 977 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n None None Black BT None 05/12
3358-5FG Pen 977 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n None None Red BT Prem 64 05/12
3358-5EG i3-2367M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 16GB mSATA None Red BT Prem 64 05/12
3358-5DG i3-2367M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 Ericsson Lenovo Black BT Pro 64 05/12
3358-6SG i3-2367M 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 None None Blue BT Prem 64 06/12
3358-28G i3-2367M 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 None None Black BT Pro 64 06/12
3358-7DG i3-2365M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Prem 64 08/12
3358-7CG i3-2365M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Pro 64 08/12
3358-8DG Pen 997 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n None None Black BT DOS-Lic. 10/12
3358-B8G i3-3227U 4GBx1 11.6" HD glossy 720p 500G 7200 Intel 2230 None None Black BT DOS-Lic. 03/13
3358-BBG i3-3227U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 None None Black BT DOS-Lic. 04/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-DT1-1) April 2013
Blue-
tooth
PCIe
Mini Card
WLANProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced May 29, June 12, August 7 or October 2, 2012; March 19 or April 16, 2013
Camera
PCIe Mini Card
WWAN
/mSATA
Ann
Date
(mm/yy)
Screen
type SIM card

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Windows®7 Professional
64 preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
- Some: Windows 8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications (only some
listed)
- Windows 7 models
•Access Connections™
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft Office 2010 preloaded;
purchase product key to activate
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo Mobile Access
•Lenovo Cloud Storage
• Microsoft Office 2013 preloaded;
purchase product key to activate
- All models
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Pentium®997 processor (2 cores, 1.60GHz, 2MB cache), Intel HD Graphics,
DDR3 memory controller (up to 1333MHz)
Intel Core™i3-2365M processor (2 cores, 1.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-2375M processor (2 cores, 1.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-3217U processor (2 cores, 1.80GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high,
removable, upgradable, Active Protection System ™
Some: 16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
Some: 11.6" (295mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 11.6" (295mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics, Intel HD Graphics 3000 or Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard, multi-touch
None
11.6W" (WxDxH): 11.30" x 8.35" x 0.85-0.91"; 287mm x 212mm x 21.7-23mm
6-cell: from 3.40 lb (1.54kg)
Midnight black, Heatwave red, or Arctic blue (top), trimmed with a thin silver band (side);
black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4Whr): up to 8.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0, one powered USB 2.0, external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n, 1x1, Wi-Fi + BT combo adapter
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi + BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+, GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in
Wi-Fi + Bluetooth combo adapter
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 /
stereo speakers, 2 watt x 2 / monaural digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E130 3358 (Intel) - TopSeller (Windows 8)
3358-8SG i3-2365M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Win7 Pro64 10/12
3358-8RG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 None None Black BT Win7 Pro64 10/12
3358-8QG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 Ericsson Lenovo Black BT Win7 Pro64 10/12
3358-8CG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 Ericsson Lenovo Blue BT Win8 64 10/12
3358-8BG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 Ericsson Lenovo Black BT Win8 Pro64 10/12
3358-8AG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 None None Black BT Win8 Pro64 10/12
3358-89G i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 16GB None Red BT Win8 64 10/12
3358-88G i3-2365M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Win8 Pro64 10/12
3358-87G i3-2365M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Win8 64 10/12
3358-86G Pen 997 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n None None Red BT Win8 64 10/12
3358-9GG i3-2375M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Win8 64 01/13
3358-9FG i3-2375M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Win7 Pro64 01/13
3358-9EG i3-2375M 4GBx1 11.6" HD anti-glare 720p 320G 7200 Intel 2230 None None Black BT Win8 Pro64 01/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-DT1-2) February 2013
Blue-
tooth
PCIe
Mini Card
WLANProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced October 23, 2012 or January 22, 2013
Camera
PCIe Mini Card
WWAN
/mSATA
Ann
Date
(mm/yy)
Screen
type SIM card

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Windows®7 Professional
64 preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
- Some: Windows 8 64-bit
Preloaded applications (only some
listed)
- Windows 7 models
•Access Connections™
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft Office 2010 preloaded;
purchase product key to activate
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo Mobile Access
•Lenovo Cloud Storage
• Microsoft Office 2013 preloaded;
purchase product key to activate
- All models
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Core™i3-2375M processor (2 cores, 1.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-3217U processor (2 cores, 1.80GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i3-3227U processor (2 cores, 1.90GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high,
removable, upgradable, Active Protection System ™
None
Some: 11.6" (295mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 11.6" (295mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 or Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard, multi-touch
None
11.6W" (WxDxH): 11.30" x 8.35" x 0.85-0.91"; 287mm x 212mm x 21.7-23mm
6-cell: from 3.40 lb (1.54kg)
Midnight black, Heatwave red, or Arctic blue (top), trimmed with a thin silver band (side);
black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4Whr): up to 8.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0, one powered USB 2.0, external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11a/b/g/n, PCIe Half Mini Card, ThinkPad a/b/g/n,
2x2 , Wi-Fi / BT combo adapter
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi + BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+,
GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 /
stereo speakers, 2 watt x 2 / monaural digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E130 3358 (Intel) - TopSeller (Windows 8) - II
3358-B2G i3-2375M 4GBx1 11.6" HD anti-glare 720p 500G 5400 TP 11a/b/g/n None None Black BT Win8 64 02/13
3358-AZG i3-2375M 4GBx1 11.6" HD anti-glare 720p 500G 5400 Intel 2230 None None Black BT Win7 Pro64 02/13
3358-AYG i3-3227U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 None None Red BT Win8 64 02/13
3358-AXG i3-3227U 4GBx1 11.6" HD anti-glare 720p 500G 7200 TP 11a/b/g/n None None Black BT Win7 Pro64 02/13
3358-AWG i3-3227U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 Ericsson Lenovo Black BT Win7 Pro64 02/13
3358-B7G i3-3227U 4GBx1 11.6" HD anti-glare 720p 500G 7200 Intel 2230 Ericsson Lenovo Blue BT Win8 64 03/13
3358-BEG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 5400 TP 11a/b/g/n None None Black BT Win8 64 05/13
3358-BDG i3-3217U 4GBx1 11.6" HD anti-glare 720p 500G 5400 TP 11a/b/g/n None None Black BT Win7 Pro64 05/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-DT1-3) June 2013
Blue-
tooth
PCIe
Mini Card
WLANProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced February 19, March 19 or May 21, 2013
Camera
PCIe Mini Card
WWAN
/mSATA
Ann
Date
(mm/yy)
Screen
type SIM card

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Genuine Windows®7
Home Premium 64
- Some: Genuine Windows 7
Professional 64
Ready to install applications14 (only
some listed)
•OneKey Recovery Pro
•Password Manager
Preloaded applications14 (only some
listed)
•Lenovo®Solution Center
•Lenovo Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•ThinkVantage System Update
•ThinkVantage Power Manager
•Lenovo Cloud Storage
by SugarSync
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Evernote®
•RapidBoot HDD Accelerator
•Symantec™VIP
•Windows Live™Essentials
• Microsoft®Office 2010 preloaded;
purchase product key to activate
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
AMD Accelerated Processor E-300 (dual-core, 1.30GHz, 1MB L2 cache),
integrated AMD Radeon ™ HD 6310 Graphics,
integrated DDR3 memory controller (up to 1066MHz)
AMD Accelerated Processor E2-1800 (dual-core, 1.70GHz, 1MB L2 cache),
integrated AMD Radeon HD 7340 Graphics,
integrated DDR3 memory controller (up to 1333MHz)
8GB max7/ PC3-10600 1333MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1066MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high,
removable, upgradable, Active Protection System ™
None
Some: 11.6" (295mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 11.6" (295mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
AMD Radeon HD 6310 or 7340 graphics in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Maximum external resolution: 2048x1536 (VGA)@60Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard, multi-touch
None
11.6W" (WxDxH): 11.30" x 8.35" x 0.85-0.91"; 287mm x 212mm x 21.7-23mm
6-cell: from 3.40 lb (1.54kg)
Midnight black, Heatwave red, or Arctic blue (top), trimmed with a thin silver band (side);
black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4Whr): up to 8.5 hr
AMD A68M FCH Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0, one powered USB 2.0, external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
One PCI Express Mini Card slot
Some: 11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n, 1x1, Wi-Fi + BT combo adapter
Some: 11a/ b/g/n , PCIe Half Mini Card, ThinkPad 11a/ b/g/n, 2x2, Wi-Fi + BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Realtek®RTL8111F Gigabit Network Connection
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 /
stereo speakers, 2 watt x 2 / monaural digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E135 3359 (AMD) - TopSeller
3359-64G E-300 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11a/b/g/n Black None BT 6 Pro 64 07/12
3359-62G E-300 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11a/b/g/n Red None BT 6 Prem 64 07/12
3359-5ZG E-300 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n Black None BT 6 Prem 64 07/12
3359-5YG E2-1800 4GBx1 11.6" HD anti-glare 720p 500G 7200 TP 11b/g/n Red None BT 6 Prem 64 07/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-DT11-1) July 2012
Blue-
tooth
PCIe
Mini Card
WLANProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced July 10, 2012
Camera
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
Date
(mm/yy)
Screen
type
Finger
print
reader
Bat-
tery
cells

65-watt AC adapter
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- DOS-Lic.
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
AMD Accelerated Processor E-300 (dual-core, 1.30GHz, 1MB L2 cache),
integrated AMD Radeon ™ HD 6310 Graphics, DDR3 memory controller (up to 1066MHz)
AMD Accelerated Processor E2-1800 (dual-core, 1.70GHz, 1MB L2 cache),
integrated AMD Radeon HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
AMD Accelerated Processor E2-2000 (dual-core, 1.75GHz, 1MB L2 cache),
integrated AMD Radeon HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
8GB max7/ PC3-10600 1333MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1066MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high,
removable, upgradable, Active Protection System ™
None
Some: 11.6" (295mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 11.6" (295mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
AMD Radeon HD 6310 or 7340 graphics in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Maximum external resolution: 2048x1536 (VGA)@60Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard, multi-touch
None
11.6W" (WxDxH): 11.30" x 8.35" x 0.85-0.91"; 287mm x 212mm x 21.7-23mm
6-cell: from 3.40 lb (1.54kg)
Midnight black, Heatwave red, or Arctic blue (top), trimmed with a thin silver band (side);
black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4Whr): up to 8.5 hr
AMD A68M FCH Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0, one powered USB 2.0, external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
One PCI Express Mini Card slot
11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n, 1x1, Wi-Fi + BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Realtek®RTL8111F Gigabit Network Connection
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 /
stereo speakers, 2 watt x 2 / monaural digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E135 3359 (AMD) - TopSeller (DOS)
3359-65G E-300 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n Black None BT 6 DOS-Lic. 07/12
3359-63G E2-1800 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n Black None BT 6 DOS-Lic. 07/12
3359-7EG E2-2000 4GBx1 11.6" HD glossy 720p 500G 7200 TP 11b/g/n Black None BT 6 DOS-Lic. 03/13
3359-7FG E2-2000 4GBx1 11.6" HD anti-glare 720p 500G 7200 TP 11b/g/n Black None BT 6 DOS-Lic. 04/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-DT11-2) April 2013
Blue-
tooth
PCIe
Mini Card
WLANProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced July 10, 2012; March 19 or April 16, 2013
Camera
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
Ann
Date
(mm/yy)
Screen
type
Finger
print
reader
Bat-
tery
cells

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Windows®7 Professional
64 preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
- Some: Windows 8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications (only some
listed)
- Windows 7 models
•Access Connections™
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft Office 2010 preloaded;
purchase product key to activate
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
• Microsoft Office 2013 preloaded;
purchase product key to activate
- All models
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
AMD Accelerated Processor E2-1800 (dual-core, 1.70GHz, 1MB L2 cache),
integrated AMD Radeon™HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
AMD Accelerated Processor E2-2000 (dual-core, 1.75GHz, 1MB L2 cache),
integrated AMD Radeon HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
8GB max7/ PC3-10600 1333MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high,
removable, upgradable, Active Protection System ™
None
Some: 11.6" (295mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 11.6" (295mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
AMD Radeon HD 7340 graphics in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Maximum external resolution: 2048x1536 (VGA)@60Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard, multi-touch
None
11.6W" (WxDxH): 11.30" x 8.35" x 0.85-0.91"; 287mm x 212mm x 21.7-23mm
6-cell: from 3.40 lb (1.54kg)
Midnight black or Heatwave red (top), trimmed with a thin silver band (side);
black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4Whr): up to 8.5 hr
AMD A68M FCH Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0, one powered USB 2.0, external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
One PCI Express Mini Card slot
Some: 11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n, 1x1, Wi-Fi + BT combo adapter
Some: 11a/ b/g/n , PCIe Half Mini Card, ThinkPad 11a/ b/g/n, 2x2, Wi-Fi + BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Realtek®RTL8111F Gigabit Network Connection
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 /
stereo speakers, 2 watt x 2 / monaural digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E135 3359 (AMD) - TopSeller (Windows 8)
3359-6EG E2-1800 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11a/b/g/n Black None BT 6 Win7 Pro64 10/12
3359-68G E2-1800 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11b/g/n Black None BT 6 Win8 64 10/12
3359-67G E2-1800 4GBx1 11.6" HD anti-glare 720p 500G 7200 TP 11b/g/n Red None BT 6 Win8 64 10/12
3359-66G E2-1800 4GBx1 11.6" HD anti-glare 720p 320G 7200 TP 11a/b/g/n Black None BT 6 Win8 Pro64 10/12
3359-72G E2-2000 4GBx1 11.6" HD anti-glare 720p 500G 5400 TP 11a/b/g/n Red None BT 6 Win8 64 02/13
3359-6ZG E2-2000 4GBx1 11.6" HD anti-glare 720p 500G 5400 TP 11a/b/g/n Black None BT 6 Win7 Pro64 02/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-DT11-3) February 2013
Blue-
tooth
PCIe
Mini Card
WLANProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced October 23, 2012 or February 19, 2013
Camera
Ann
Date
(mm/yy)
Screen
type
Finger
print
reader
Bat-
tery
cells

Lenovo®ThinkPad Edge E330
Lenovo ThinkPad Edge E335
Lenovo ThinkPad Edge E330
Lenovo ThinkPad Edge E330
Lenovo ThinkPad Edge E330
Lenovo ThinkPad Edge E330

65-watt AC adapter
EPEAT™Gold rating
(Windows 7 models)
ENERGY STAR®5.0-compliant
(Windows 7 models)
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: DOS-Lic.
- Some: Genuine Windows®7
Home Premium 64
- Some: Genuine Windows 7
Professional 64
Ready to install applications14
(Windows 7 models; only some listed)
•OneKey Recovery Pro
•Password Manager
Preloaded applications14
(Windows 7 models; only some listed)
•Access Connections™
•ThinkVantage System Update
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Pentium®B970 processor (2 cores, 2.30GHz, 2MB cache), Intel HD Graphics,
DDR3 memory controller (up to 1333MHz)
Intel Core™i3-2328M processor (2 cores, 2.20GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-2370M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
None
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics or Intel HD Graphics 3000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 2560x1600 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™,buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.8mm
6-cell: from 3.97 lb (1.80kg)
Midnight black or Heatwave red (top), trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one powered USB 2.0,
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11a/b/g/n, PCIe Half Mini Card, ThinkPad a/b/g/n,
2x2 , Wi-Fi / BT combo adapter
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi / BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+,
GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E330 3354 (Intel) - TopSeller
3354-4SG i3-2370M 4GBx1 13.3" HD 720p 500G 7200 TP 11a/b/g/n + BT None None Red 6 Prem 64 05/12
3354-4RG i3-2370M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Pro 64 05/12
3354-4QG i3-2370M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Pro 64 05/12
3354-95G Pen B970 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT None None Black 6 Prem 64 06/12
3354-96G i3-2370M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 DOS-Lic. 06/12
3354-9RG i3-2328M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT None None Black 6 Prem 64 08/12
3354-9QG i3-2328M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Pro 64 08/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN1-1) August 2012
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced May 29, June 12, June 26 or August 14, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
date
(mm/yy)SIM card

65-watt AC adapter
EPEAT™Gold rating
(Windows 7 models)
ENERGY STAR®5.0-compliant
(Windows 7 models)
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: DOS-Lic.
- Some: Genuine Windows 7
Professional 64
Ready to install applications14
(Windows 7 models; only some listed)
•OneKey Recovery Pro
•Password Manager
Preloaded applications14
(Windows 7 models; only some listed)
•Access Connections™
•ThinkVantage System Update
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Microsoft Office 2010 preloaded;
purchase product key to activate
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Core™i3-3110M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
None
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™,buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.8mm
6-cell: from 3.97 lb (1.80kg)
Midnight black (top), trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one powered USB 2.0,
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2, Wi-Fi / BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+, GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E330 3354 (Intel) - TopSeller - II
3354-93G i5-3210M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Pro 64 06/12
3354-4NG i5-3210M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Pro 64 06/12
3354-BFG i5-3210M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Pro 64 08/12
3354-ALG i3-3110M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 DOS-Lic. 08/12
3354-AHG i5-3210M 4GBx1 13.3" HD 720p 500G 5400 Intel 2230 + BT None None Black 6 DOS-Lic. 08/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN1-2) August 2012
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced June 26 or August 28, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
date
(mm/yy)SIM card

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Windows®7 Professional
64 preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
- Some: Windows 8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications (only some
listed)
- Windows 7 models
•Access Connections™
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft Office 2010 preloaded;
purchase product key to activate
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo Mobile Access
•Lenovo Cloud Storage
• Microsoft Office 2013 preloaded;
purchase product key to activate
- All models
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Pentium®B980 processor (2 cores, 2.40GHz, 2MB cache), Intel HD Graphics,
DDR3 memory controller (up to 1333MHz)
Intel Core™i3-2328M processor (2 cores, 2.20GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-2348M processor (2 cores, 2.30GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-3110M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
Some: 16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics, Intel HD Graphics 3000 or Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™,buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.8mm
6-cell: from 3.97 lb (1.80kg)
Midnight black, Heatwave red or Arctic blue (top),
trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one powered USB 2.0,
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11a/b/g/n, PCIe Half Mini Card, ThinkPad a/b/g/n, 2x2 , Wi-Fi / BT combo adapter
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi / BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+,
GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E330 3354 (Intel) - TopSeller (Windows 8)
3354-BNG i3-2328M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Win7 Pro64 10/12
3354-BMG i3-3110M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Win7 Pro64 10/12
3354-BKG i3-3110M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Win7 Pro64 10/12
3354-BJG i5-3210M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Win7 Pro64 10/12
3354-AVG i5-3210M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Win8 Pro64 10/12
3354-ATG i5-3210M 4GBx1 13.3" HD 720p 750G 5400 Intel 2230 + BT 16GB None Blue 6 Win8 64 10/12
3354-ASG i3-3110M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Win8 Pro64 10/12
3354-ARG i3-3110M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Win8 Pro64 10/12
3354-AQG i3-3110M 4GBx1 13.3" HD 720p 500G 7200 TP 11a/b/g/n + BT None None Red 6 Win8 64 10/12
3354-APG i3-2328M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT None None Black 6 Win8 64 10/12
3354-ANG i3-2328M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Win8 Pro64 10/12
3354-AMG Pen B980 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT None None Black 6 Win8 64 10/12
3354-CSG i3-2348M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Win7 Pro64 01/13
3354-CRG i3-2348M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT None None Black 6 Win8 64 01/13
3354-CQG i3-2348M 4GBx1 13.3" HD 720p 320G 7200 Intel 2230 + BT None None Black 6 Win8 Pro64 01/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN1-4) January 2013
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced October 23, 2012 or January 1, 2013
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
Ann
date
(mm/yy)SIM card

65-watt AC adapter
EPEAT™Gold rating
(exclude DOS models)
ENERGY STAR®5.0-compliant
(exclude DOS models)
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: DOS-Lic.
- Some: Windows®7 Professional
64 preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
- Some: Windows 8 64-bit
Preloaded applications (only some
listed, exclude DOS models)
- Windows 7 models
•Access Connections™
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft Office 2010 preloaded;
purchase product key to activate
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
• Microsoft Office 2013 preloaded;
purchase product key to activate
- All models(exclude DOS models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Core™i3-2348M processor (2 cores, 2.30GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-3110M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i3-3120M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3230M processor (2 cores, 2.60GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.20GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
None
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 or Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™,buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.8mm
6-cell: from 3.97 lb (1.80kg)
Midnight black, Heatwave red or Arctic blue (top),
trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one powered USB 2.0,
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11a/b/g/n, PCIe Half Mini Card, ThinkPad a/b/g/n, 2x2 , Wi-Fi / BT combo adapter
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2,
Wi-Fi / BT combo adapter
Some: Wireless WAN, Ericsson
®
H5321gw Mobile Broadband Module , PCIe Half Mini Card ,
GPRS/WCDMA/HSPA/HSPA+, GPS
Some: Lenovo SIM, out-of-box service, pay-as-you-go via credit card, no contract required
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E330 3354 (Intel) - TopSeller (Windows 8) - II
3354-DZG i3-3120M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT None None Black 6 DOS-Lic. 02/13
3354-DYG i3-2348M 4GBx1 13.3" HD 720p 500G 5400 TP 11a/b/g/n + BT None None Black 6 Win8 64 02/13
3354-DXG i3-2348M 4GBx1 13.3" HD 720p 500G 5400 Intel 2230 + BT None None Black 6 Win7 Pro64 02/13
3354-DWG i3-3120M 4GBx1 13.3" HD 720p 500G 7200 TP 11a/b/g/n + BT None None Red 6 Win8 64 02/13
3354-DVG i3-3120M 4GBx1 13.3" HD 720p 500G 7200 TP 11a/b/g/n + BT None None Black 6 Win7 Pro64 02/13
3354-DUG i3-3120M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Win7 Pro64 02/13
3354-DTG i5-3230M 4+4GB 13.3" HD 720p 750G 5400 Intel 2230 + BT None None Blue 6 Win8 64 02/13
3354-DSG i5-3230M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT Ericsson Lenovo Black 6 Win7 Pro64 02/13
3354-E9G i3-3110M 4GBx1 13.3" HD 720p 500G 5400 TP 11a/b/g/n + BT None None Black 6 Win8 64 05/13
3354-E8G i3-3110M 4GBx1 13.3" HD 720p 500G 5400 TP 11a/b/g/n + BT None None Black 6 Win7 Pro64 05/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN1-6) June 2013
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced May 21, 2013
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
Ann
date
(mm/yy)SIM card

90-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Genuine Windows®7
Home Premium 64
Ready to install applications14 (only
some listed)
•OneKey Recovery Pro
•Password Manager
Preloaded applications14 (only some
listed)
•Access Connections™
•ThinkVantage System Update
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Core™i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
NVIDIA®Optimus™technology, auto-switch between discrete and integrated graphics,
Intel HD Graphics 4000 in processor, and
NVIDIA GeForce®610M, PCI Express®x16, 1GB memory, DirectX®11,
NVIDIA PureVideo®HD technology,
External monitor support via analog VGA DB-15 connector / digital HDMI connector
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™,buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.8mm
6-cell: from 3.97 lb (1.80kg)
Arctic Blue or Heatwave red (top), trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one powered USB 2.0,
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2, Wi-Fi / BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E330 3354 (Intel) - Optimus (TopSeller)
3354-94G i5-3210M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT 16GB None Blue 6 Prem 64 06/12
3354-4PG i5-3210M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT 16GB None Red 6 Prem 64 06/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN1-3) July 2012
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced June 26, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
date
(mm/yy)SIM card

90-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Windows 8 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
Intel®Core™i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
NVIDIA®Optimus™technology, auto-switch between discrete and integrated graphics,
Intel HD Graphics 4000 in processor, and
NVIDIA GeForce®610M, PCI Express®x16, 1GB memory, DirectX®11,
NVIDIA PureVideo®HD technology,
External monitor support via analog VGA DB-15 connector / digital HDMI connector
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™,buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.8mm
6-cell: from 3.97 lb (1.80kg)
Heatwave red (top), trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one powered USB 2.0,
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230, 2x2, Wi-Fi / BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E330 3354 (Intel) - Optimus (TopSeller) - Windows 8
3354-AUG i5-3210M 4GBx1 13.3" HD 720p 500G 7200 Intel 2230 + BT 16GB None Red 6 Win8 64 10/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN1-5) October 2012
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced October 23, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
Ann
date
(mm/yy)SIM card

65-watt AC adapter
EPEAT™Gold rating
(Windows 7 models)
ENERGY STAR®5.0-compliant
(Windows 7 models)
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: DOS-Lic.
- Some: Genuine Windows®7
Home Premium 64
- Some: Genuine Windows 7
Professional 64
Ready to install applications14
(Windows 7 models; only some listed)
•OneKey Recovery Pro
•Password Manager
Preloaded applications14
(Windows 7 models; only some listed)
•Access Connections™
•ThinkVantage System Update
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
AMD Accelerated Processor E2-1800 (dual-core, 1.70GHz, 1MB L2 cache),
integrated AMD Radeon™HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
None
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
AMD Radeon HD Graphics in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@60Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.7mm
6-cell: from 3.97 lb (1.80kg)
Midnight black or Heatwave red (top), trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
AMD A68M FCH
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one USB 2.0 (powered),
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
One PCI Express Mini Card slot
Some: 11b/g/n, PCIe Half Mini Card, ThinkPad b/g/n, 1x1 , Wi-Fi / BT combo adapter
Some: 11a/b/g/n, PCIe Half Mini Card, ThinkPad a/b/g/n, 2x2 , Wi-Fi / BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E335 3355 (AMD) - TopSeller
3355-64G E2-1800 4GBx1 13.3" HD 720p 500G 7200 TP 11b/g/n + BT None None Black 6 DOS-Lic. 07/12
3355-63G E2-1800 4GBx1 13.3" HD 720p 500G 7200 TP 11b/g/n + BT None None Red 6 Prem 64 07/12
3355-62G E2-1800 4GBx1 13.3" HD 720p 320G 7200 TP 11a/b/g/n + BT None None Red 6 Prem 64 07/12
3355-5ZG E2-1800 4GBx1 13.3" HD 720p 500G 7200 TP 11b/g/n + BT None None Black 6 Pro 64 07/12
3355-5YG E2-1800 4GBx1 13.3" HD 720p 320G 7200 TP 11a/b/g/n + BT None None Black 6 Pro 64 07/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN11-1) July 2012
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced July 17, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
●Small and medium business (SMB) model(s), part of the WE TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
date
(mm/yy)SIM card

65-watt AC adapter
EPEAT™Gold rating
(exclude DOS models)
ENERGY STAR®5.0-compliant
(exclude DOS models)
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: DOS-Lic.
- Some: Windows®7 Professional
64 preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
- Some: Windows 8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications (only some
listed, exclude DOS models)
- Windows 7 models
•Access Connections™
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft Office 2010 preloaded;
purchase product key to activate
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
• Microsoft Office 2013 preloaded;
purchase product key to activate
- All models(exclude DOS models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
Sophisticated design with quality, durability and reliability for SMB customers; one spindle
AMD Accelerated Processor E2-1800 (dual-core, 1.70GHz, 1MB L2 cache),
integrated AMD Radeon™HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
AMD Accelerated Processor E2-2000 (dual-core, 1.75GHz, 1MB L2 cache),
integrated AMD Radeon HD 7340 Graphics, DDR3 memory controller (up to 1333MHz)
8GB max7/ PC3-12800 1600MHz DDR3, non-parity, dual-channel capable,
two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
None
13.3" (338mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
AMD Radeon HD Graphics in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@60Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, "Press-to-Select," Internet Scroll Bar13
UltraNav™, buttonless touchpad below keyboard
None
13.3W" (WxDxH): 12.67" x 8.98" x 0.79-1.09"; 322 x 228mm x 20-27.7mm
6-cell: from 3.97 lb (1.80kg)
Midnight black or Heatwave red (top), trimmed with a thin silver band (side); black bottom
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell, HW Authentication
6-cell (62.4 Whr): up to 7.5 hr
AMD A68M FCH
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Two USB 3.0 port, one USB 2.0 (powered),
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
One PCI Express Mini Card slot
Some: 11b/g/n, PCIe Half Mini Card, ThinkPad b/g/n, 1x1 , Wi-Fi / BT combo adapter
Some: 11a/b/g/n, PCIe Half Mini Card, ThinkPad a/b/g/n, 2x2 , Wi-Fi / BT combo adapter
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit ethernet, Realtek®RTL8111F
None
High Definition (HD) Audio, Realtek ALC269 codec / stereo speakers, 2 watt x 2/
dual array digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E335 3355 (AMD) - TopSeller (Windows 8)
3355-6AG E2-1800 4GBx1 13.3" HD 720p 320G 7200 TP 11a/b/g/n + BT None None Black 6 Win7 Pro64 10/12
3355-69G E2-1800 4GBx1 13.3" HD 720p 500G 7200 TP 11b/g/n + BT None None Black 6 Win7 Pro64 10/12
3355-68G E2-1800 4GBx1 13.3" HD 720p 500G 7200 TP 11b/g/n + BT None None Black 6 Win8 Pro64 10/12
3355-67G E2-1800 4GBx1 13.3" HD 720p 320G 7200 TP 11a/b/g/n + BT None None Black 6 Win8 Pro64 10/12
3355-66G E2-1800 4GBx1 13.3" HD 720p 320G 7200 TP 11a/b/g/n + BT None None Red 6 Win8 64 10/12
3355-65G E2-1800 4GBx1 13.3" HD 720p 500G 7200 TP 11b/g/n + BT None None Red 6 Win8 64 10/12
3355-72G E2-2000 4GBx1 13.3" HD 720p 500G 5400 TP 11a/b/g/n + BT None None Black 6 DOS-Lic. 02/13
3355-6ZG E2-2000 4GBx1 13.3" HD 720p 500G 5400 TP 11a/b/g/n + BT None None Red 6 Win8 64 02/13
3355-6YG E2-2000 4GBx1 13.3" HD 720p 500G 5400 TP 11a/b/g/n + BT None None Black 6 Win7 Pro64 02/13
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(G-PRN11-2) February 2013
PCIe
Mini Card
WLAN / BTProcessor PreloadTop color
See footnotes for more detailed information
WE model(s) announced October 23, 2012 or February 19, 2013
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
Ann
date
(mm/yy)SIM card
