Lenovo YOGA BOOK with Windows How to use

YOGA BOOK
with Windows®
Safety, Warranty & Quick Start Guide
English/Bahasa Indonesia
I.40.LENOVO1.XXXXX.XXXX
PT.LENOVO INDONESIA
WISMA KOTA BNI46, 19 FLOOR, SUITE 19-05
JL.JEND SUDIRMAN KAV.1, JAKARTA PUSAT 10220 INDONESIA
TEL: [phone], FAX: [phone]

Reading first - regulatory information
Device models equipped with wireless communications comply with the radio frequency
and safety standards of any country or region in which it has been approved for wireless
use. In addition, if your product contains a telecom modem, it complies with the
requirements for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region before using the wireless
devices contained in your device. To obtain a PDF version of the Regulatory Notice, refer
to the “Downloading publications” section below.
Getting support
To get support on network services and billing, contact your wireless network operator.
To learn how to use your tablet and view its technical specifications, go to
http://support.lenovo.com/.
Downloading publications
Electronic versions of your publications are available from http://support.lenovo.com.
To download the publications for your tablet, go to http://support.lenovo.com and
follow the instructions on the screen.
Accessing your User Guide
Your User Guide contains detailed information about your tablet. To access your
User Guide, use one of the following methods:
• Go to http://support.lenovo.com and follow the instructions on the screen.
• Start your device and access the User Guide app.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other
countries, or both.
Other company, product, or service names may be trademarks or service marks of
others.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, Pro Logic,
and the double-D symbol are trademarks of Dolby Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant
a General Services Administration “GSA” contract, use, reproduction, or disclosure is
subject to restrictions set forth in Contract No. GS-35F-05925.
Read this guide carefully before using your tablet.
English

Contents
YOGA BOOK with Windows®overview..................................................1
Preparing your tablet ..........................................................................2
Starting to use your tablet...................................................................3
Replacing your Real Pen refill..............................................................4
Replacing your BOOK Pad paper .......................................................5
Important safety and handling information ..........................................6
European Union compliance statement ..............................................6
Service and support information .........................................................7
Warranty information ..........................................................................8
Environmental, recycling, and disposal information ...........................10

1
1 1
2
3
4
5
6
7
8 9 10 11
9
12 14 15
13
YOGA BOOK with Windows®overview
• The WLAN model (Lenovo YB1-X91F) does not have a Nano-SIM card slot.
• Your keyboard layout may be different depending on your location and language.
1Microphone 2Front-facing camera 3Touch screen
4Pen button 5Main camera 6Halo Keyboard/Create Pad
7Touchpad 8On/Off button 9Speakers
10 Volume buttons 11 Headset jack 12 Micro USB connector
13 Indicator 14 Card tray 15 Micro HDMI connector
Model Version
Lenovo YB1-X91F WLAN
Lenovo YB1-X91L WLAN + LTE

2
• Only Nano-SIM cards work with your tablet.
• Turn off your tablet before you remove or insert the Nano-SIM card.
Preparing your tablet
You can use cellular services with the WLAN + LTE model (Lenovo YB1-X91L) by
inserting the Nano-SIM card provided by your carrier.
Install the Nano-SIM and microSD cards as shown.
1. Insert the eject tool that comes with your tablet into the hole in the card tray.
2. Pull out the card tray.
3. Put a Nano-SIM card in Slot 1 and a microSD card in Slot 2.
4. Carefully insert the tray with the installed cards back into the slot.
1
4
3
2
SIM
microSD
Slot1
Slot2
SIM
microSD

3
Turning on/off
Starting to use your tablet
You might need to charge the battery before using your tablet.
Charge the battery as shown.
The best way to charge your device is to connect your tablet to a power outlet using the
included cable and USB power adapter.
Low battery Fully charged Charging
Turn on: Press and hold the On/Off button until the Lenovo
logo appears.
Turn off: Tap > Power off.

4
Replacing your Real Pen refill
Your Real Pen refill kit contains refills for replacement. Choose a refill that suits your
writing method and replace the refill as shown.
1. Use the Real Pen cap as a refill remover. Insert the refill into the hole on the top of the
cap.
2. Tilt the pen until the refill is locked.
3. Pull out the refill directly.
4. Insert the refill into the pen until it is locked into place.
3
1
4
2

5
Replacing your BOOK Pad paper
BOOK Pad is designed for use with the paper that fits your tablet.
When the paper is fully used up, change the paper as shown.
1. Lift the BOOK Pad cover.
2. Take out the used paper.
3. Put the new paper into the pad and replace the cover.
1
3
2

6
Important safety and handling information
Plastic bag notice
Danger: Plastic bags can be dangerous. Keep plastic bags away from babies and
children to avoid danger of suffocation.
Built-in rechargeable battery notice
Danger: Do not attempt to replace the internal rechargeable lithium ion battery. Contact
Lenovo Support for factory replacement.
Caution about high volume usage
Warning: Exposure to loud noise from any source for extended periods of time may affect
your hearing. The louder the sound, the less time is required before your hearing could be
affected. To protect your hearing:
• Limit the amount of time you use headsets or headphones at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in
your ears, ringing in your ears or muffled speech, you should stop listening to the device
through your headset or headphones and have your hearing checked.
European Union compliance statement
European Union conformity
EU contact: Lenovo, Einsteinova 21, 851 01 Bratislava, Slovakia
0560

7
Compliance with the R&TTE Directive
This product is in compliance with the essential requirements and other relevant
provisions of the EU Council Radio and Telecommunications Terminal Equipment
(R&TTE) Directive, 1999/5/EC. The Declaration of Conformity information is located in the
Regulatory Notices, which you can download from the Lenovo Support Web site. See
“Downloading publications” in this document for additional information.
NOTE: R&TTE 1999/5/EC remains in force during the transition period of Radio
Equipment Directive (RED) 2014/53/EU until 12 June, 2017. After then, RED 2014/53/
EU will take the place of R&TTE 1999/5/EC.
Service and support information
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Limited Warranty (LLW) for a full explanation of Lenovo warranty terms. See
“Lenovo Limited Warranty notice” later in this document for details on accessing the full
warranty.
Online technical support
Online technical support is available during the lifetime of a product at:
http://www.lenovo.com/support
Telephone technical support
You can get help and information from the Customer Support Center by telephone.
Before contacting a Lenovo technical support representative, please have the following
information available: model and serial number, the exact wording of any error message,
and a description of the problem.
Your technical support representative might want to walk you through the problem while
you are at your device during the call.
Worldwide Lenovo Support telephone list
Important: Telephone numbers are subject to change without notice. The most up-to-
date telephone list for the Customer Support Center is always available at:
http://www.lenovo.com/support/phone
If the telephone number for your country or region is not listed, contact your Lenovo
reseller or Lenovo marketing representative.

8
Warranty information
Lenovo Limited Warranty notice
This product is covered by the terms of the LLW, version L505-0010-02 08/2011. Read
the LLW at http://www.lenovo.com/warranty/llw_02. You can read the LLW in a number
of languages from this Web site. If you cannot view the LLW from the Web site, contact
your local Lenovo office or reseller to obtain a printed version of the LLW.
Warranty period and type of warranty service
Country or region Warranty period Type of warranty
service
Germany, Italy, Austria, United Kingdom,
Israel, Australia, New Zealand
Parts and Labor - 1 year
Battery Pack - 1 year 1,3
Guatemala, Costa Rica, Venezuela, Peru,
Uruguay, Ecuador, Colombia, Chile,
Argentina, Indonesia, Vietnam, India,
Malaysia, Thailand, Philippines, Singapore,
Hong Kong, El Salvador, Taiwan
Parts and Labor - 1 year
Battery Pack - 1 year 1,4
Russia, Ukraine, Egypt, Lebanon, Morocco,
South Africa, Tunisia, Mauritius, Mozambique,
United Arab Emirates, Jordan, Kenya, Nigeria,
Uganda, Ghana, Oman, Tanzania, Namibia
Parts and Labor - 1 year
Battery Pack - 1 year 4
United States of America, Canada, Mexico,
Japan
Parts and Labor - 1 year
Battery Pack - 1 year 1,5
Panama Parts and Labor - 1 year
Battery Pack - 1 year 2,4
South Korea Parts and Labor - 1 year
Battery Pack - 1 year 3,4
Brazil Parts and Labor - 1 year
Battery Pack - 1 year 2,5
Spain, Switzerland, Portugal, Netherlands,
Belgium, Sweden, Denmark, Norway, Finland,
Estonia, Latvia, Lithuania, Iceland, France
Parts and Labor - 2 years
Battery Pack - 1 year 1,3
Czech Republic, Hungary, Romania, Bulgaria,
Greece, Croatia, Slovenia, Slovakia, Cyprus,
Poland
Parts and Labor - 2 years
Battery Pack - 1 year 1,5

9
* Excludes some components. 90-day limited warranty for power adapters, keyboards,
plastics, and hinges.
Type of warranty service
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Service
3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Customer Two-Way Mail-in Service
7. Product Exchange Service
For a full explanation of the types of warranty service, refer to the full warranty.
See “Lenovo Limited Warranty notice” for details on accessing the full warranty.
EurAsia compliance mark
Country or region Warranty period Type of warranty
service
Turkey Parts and Labor - 2 years
Battery Pack - 1 year 3,4
Saudi Arabia Parts and Labor - 2 years
Battery Pack - 1 year 4
Serbia Parts and Labor - 2 years
Battery Pack - 1 year 1,4

10
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to responsibly
recycle their equipment when it is no longer needed. Lenovo offers a variety of programs
and services to assist equipment owners in recycling their IT products. For information on
recycling Lenovo products, go to http://www.lenovo.com/recycling.
Important battery and WEEE information
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://www.lenovo.com/recycling/japan
Additional recycling statements
Additional information about recycling device components and batteries is in your User
Guide. See “Accessing your User Guide” for details.
Battery recycling marks
Battery recycling information for Taiwan
ᔘ䴱⊖䄁ഔ᭬
Battery recycling information for the United States and Canada
Batteries and electrical and electronic equipment marked with the symbol
of a crossed-out wheeled bin may not be disposed as unsorted municipal
waste. Batteries and waste of electrical and electronic equipment (WEEE)
shall be treated separately using the collection framework available to
customers for the return, recycling, and treatment of batteries and WEEE.
When possible, remove and isolate batteries from WEEE prior to placing
WEEE in the waste collection stream. Batteries are to be collected separately
using the framework available for the return, recycling, and treatment of
batteries and accumulators.
Country-specific information is available at: http://www.lenovo.com/recycling

11
Battery recycling information for the European Union
Energy efficiency mark
Restriction of Hazardous Substances Directive (RoHS)
Turkey
The Lenovo product meets the requirements of the Republic of Turkey Directive on the
Restriction of the Use of Certain Hazardous Substances in Waste Electrical and Electronic
Equipment (WEEE).
Türkiye AEEE Yönetmeligine Uygunluk Beyanı
Bu Lenovo ürünü, T.C. Çevre ve Orman Bakanlıgı’nın “Atık Elektrikli ve Elektronik Esya Bazı
Zararlı Maddelerin Kullanımının Sınırlandırılmasına Dair Yönetmelik (AEEE)” direktierine
uygundur.
AEEE Yönetmeligine Uygundur.
Ukraine
Цим підтверджуємо, що продукція Леново відповідає вимогам нормативних актів
України, які обмежують вміст небезпечних речовин
India
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
Vietnam
Lenovo products sold in Vietnam, on or after September 23, 2011, meet the requirements
of the Vietnam Circular 30/2011/TT-BCT (“Vietnam RoHS”).
European Union
Lenovo products sold in the European Union, on or after 3 January 2013 meet the
requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”). For more
information about Lenovo progress on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf

Baca terlebih dulu - Informasi peraturan
Model perangkat yang dilengkapi dengan komunikasi nirkabel telah sesuai dengan
frekuensi radio dan standar keamanan dari negara atau kawasan yang mengizinkan
penggunaan fitur nirkabel. Selain itu, jika produk Anda memiliki modem telekomunikasi,
modem tersebut juga memenuhi persyaratan untuk koneksi ke jaringan telepon di
negaraAnda.
Pastikan Anda membaca Pemberitahuan Peraturan untuk negara atau kawasan
Anda sebelum menggunakan perangkat nirkabel yang ada di perangkat Anda. Untuk
mendapatkan Pemberitahuan Peraturan versi PDF, lihat bagian “Mengunduh publikasi”
berikut ini.
Mendapatkan dukungan
Untuk mendapatkan dukungan mengenai penagihan dan layanan jaringan, hubungi
operator jaringan nirkabel Anda. Untuk mempelajari tentang cara menggunakan tablet
Anda dan melihat spesifikasi teknisnya, kunjungi http://support.lenovo.com/.
Mengunduh publikasi
Publikasi versi elektronik bisa diperoleh dari http://support.lenovo.com. Untuk mengunduh
publikasi untuk tablet Anda, kunjungi http://support.lenovo.com dan ikuti petunjuk di layar.
Mengakses Panduan Pengguna Anda
Panduan Pengguna berisi detail informasi tentang tablet Anda. Untuk mengakses
Panduan Pengguna Anda, gunakan salah satu metode berikut:
• Kunjungi http://support.lenovo.com dan ikuti petunjuk di layar.
• Mulai jalankan perangkat Anda dan akses aplikasi Panduan Pengguna.
Pemberitahuan hukum
Lenovo dan logo Lenovo adalah merek dagang dari Lenovo di Amerika Serikat, negara
lain, atau keduanya.
Nama perusahaan, produk, atau layanan lainnya bisa jadi merupakan merek dagang atau
merek layanan dari pihak lain.
Diproduksi di bawah lisensi dari Dolby Laboratories. Dolby, Dolby Audio, Pro Logic,
dan simbol Ddobel adalah merek dagang milik Dolby Laboratories.
PEMBERITAHUAN TENTANG HAK YANG TERBATAS DAN TIDAK BEBAS: Jika data
atau perangkat lunak diberikan sesuai dengan kontrak Administrasi Layanan Umum/
General Services Administration “GSA”, maka penggunaan, penggandaan, atau
pengungkapannya tunduk terhadap pembatasan yang ditetapkan dalam Kontrak
No. GS-35F-05925.
Baca panduan ini dengan saksama sebelum menggunakan tablet.
Bahasa Indonesia

Daftar Isi
Ikhtisar YOGA BOOK with Windows®....................................................1
Menyiapkan tablet Anda .....................................................................2
Mulai menggunakan tablet Anda.........................................................3
Mengganti isi ulang Real Pen Anda.....................................................4
Mengganti kertas BOOK Pad Anda ....................................................5
Informasi penting tentang keamanan dan penanganan .......................6
Pernyataan kesesuaian untuk Uni Eropa.............................................6
Informasi layanan dan dukungan ........................................................7
Informasi garansi ................................................................................8
Informasi tentang lingkungan, daur ulang, dan pembuangan ............10

1
1 1
2
3
4
5
6
7
8 9 10 11
9
12 14 15
13
Ikhtisar YOGA BOOK with Windows®
• Model WLAN (Lenovo YB1-X91F) tidak memiliki slot kartu SIM-Nano.
• Tata letak keyboard Anda mungkin berbeda tergantung pada lokasi dan
bahasa Anda.
1Mikrofon 2Kamera depan 3Layar sentuh
4Tombol pena 5Kamera utama 6Halo Keyboard/Create Pad
7Panel sentuh 8Tombol On/Off 9Speaker
10 Tombol volume 11 Jack headset 12 Konektor USB Mikro
13 Indikator 14 Baki kartu 15 Konektor HDMI Mikro
Model Versi
Lenovo YB1-X91F WLAN
Lenovo YB1-X91L WLAN + LTE

2
• Hanya kartu SIM-Nano yang berfungsi dengan tablet Anda.
• Matikan tablet Anda sebelum Anda mengeluarkan atau memasukkan kartu
SIM-Nano.
Menyiapkan tablet Anda
Anda dapat menggunakan layanan seluler dengan model WLAN + LTE (Lenovo YB1-X91L)
dengan memasukkan kartu SIM-Nano yang disediakan oleh operator Anda.
Pasang kartu SIM-Nano dan kartu microSD seperti yang ditunjukkan.
1. Masukkan alat pelontar yang dikirimkan bersama tablet Anda ke dalam lubang yang
ada di dalam baki kartu.
2. Tarik keluar baki kartu.
3. Masukkan kartu SIM-Nano ke dalam Slot 1 dan kartu microSD ke dalam Slot 2.
4. Masukkan baki secara hati-hati, dengan kartu yang telah terpasang, kembali ke
dalam slot.
1
4
3
2
SIM
microSD
Slot1
Slot2
SIM
microSD

3
Menghidupkan/mematikan
Mulai menggunakan tablet Anda
Anda mungkin perlu mengisi daya baterai sebelum menggunakan tablet.
Isi baterai seperti yang ditunjukkan pada gambar.
Cara terbaik untuk mengisi daya perangkat Anda adalah dengan menyambungkan tablet
Anda ke stopkontak daya menggunakan kabel dan adaptor daya USB yang disertakan.
Daya baterai rendah Terisi penuh Mengisi daya
Menyalakan: Tekan dan tahan tombol On/Off hingga logo
Lenovo muncul.
Mematikan: Ketuk > Matikan.

4
Mengganti isi ulang Real Pen Anda
Kit ujung pena Real Pen Anda berisi ujung pena untuk penggantian. Pilih ujung pena
yang sesuai dengan metode penulisan Anda dan ganti ujung pena tersebut seperti yang
ditampilkan.
1. Gunakan penutup Real Pen sebagai alat untuk mengeluarkan ujung pena. Masukkan
ujung pena tersebut ke dalam lubang yang ada di bagian atas penutup.
2. Miringkan pena sampai ujung penanya terkunci.
3. Tarik keluar ujung pena tersebut secara langsung.
4. Masukkan ujung pena ke dalam pena sampai terkunci di tempatnya.
3
1
4
2
