Lenovo PHAB 2 Pro How to use

Read this guide carefully before using your device.
Lenovo PHAB 2 Pro
Safety, Warranty & Quick Start Guide
Lenovo PB2-690Y

Reading before using your device
Reading first - regulatory information
Be sure to read the Regulatory Notice for your country or region before using the
wireless devices contained in your device. To obtain a PDF version of the Regulatory
Notice, refer to the “Downloading publications” section below.
Getting support
To get support on network service and billing, contact your wireless network operator.
To learn how to use your device and view its technical specifications, go to
http://support.lenovo.com.
Downloading publications
Electronic versions of your publications are available from http://support.lenovo.com.
To download the publications for your device, go to http://support.lenovo.com and
follow the instructions on the screen.
Accessing your User Guide
Your User Guide contains detailed information about your device. To access your User
Guide, use one of the following methods:
Go to http://support.lenovo.com and follow the instructions on the screen.
Start your device, access the User Guide app.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other
countries, or both.
Other company, product, or service names may be trademarks or service marks of
others.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, and the
double-D symbol are trademarks of Dolby Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant
a General Services Administration “GSA” contract, use, reproduction, or disclosure is
subject to restrictions set forth in Contract No. GS-35F-05925.

55
10
Indicator2
6
3
789
4
1
11
Front-facing camera
Touch screen Back button Home button
Multitask button Card tray Headset connector
Depth cameraRear-facing camera
Receiver
12 Flash
13 14 Fingerprint sensorFisheye camera 15 Micro USB connector
16 17 Volume buttonsOn/Off button
6
Lenovo PHAB 2 Pro overview
Model Version
Lenovo PB2-690Y WLAN + LTE (Voice)
12
3
4
56
7
8
9
10
11
12
13
14
15
16
17

Preparing your device
①Only Nano-SIM cards work with your device.
② Always turn off your smartphone first before you insert or remove a Nano-SIM
card. Insert or remove a Nano-SIM card with your device on may damage your
Nano-SIM card or smartphone permanently.
③ Both of the card slots support 4G/3G/2G data services, but you can enable only
one Nano-SIM card for data connection at a time. If you want to change the
Nano-SIM card used for data connection, go to Settings > SIM management.
SIM
SIM
microSD
Slot1
Slot2
SIM
microSD
Nano
SIM
SIM
Step 1.
Step 2.
Step 3.
Insert the eject tool that comes with your device into the hole in the card tray.
Pull out the card tray and do one of the following:
Position a Nano-SIM card in Slot 1 and a microSD card in Slot 2;
Position a Nano-SIM card in Slot 1 and another Nano-SIM card in Slot 2
③
.
Carefully insert the tray with the installed cards back into the slot.
A Nano-SIM card provided by your carrier is required in order to use cellular services①. A
microSD card is required to store data.
Install the Nano-SIM cards and the microSD card as shown
②
.

Turning on/off
You might need to charge the battery before using your device.
Charge the battery as shown.
Connect your device to a power outlet using the cable and USB power adapter
provided.
Low battery Fully charged Charging
Turn on: Press and hold the On/Off button until the
Lenovo logo appears.
Tur n of f: Press and hold the On/Off button for a few
seconds, then tap Power off.
Starting to use your device
Taking screenshots
Press and hold the On/Off button and the Volume down button at the same time.

Important safety and handling information
Plastic bag notice
DANGER: Plastic bags can be dangerous. Keep plastic bags away from babies and
children to avoid danger of suffocation.
Built-in rechargeable battery notice
DANGER: Do not attempt to replace the internal rechargeable lithium ion battery. Risk
of explosion if the battery is replaced with an incorrect type. Contact Lenovo Support
for factory replacement.
Water resistance
Advanced nano-coating technology creates a water repellent barrier to help protect
against moderate exposure to water such as accidental spills, splashes or light rain.
Not designed to be submersed in water, or exposed to pressurized water, or other
liquids; not waterproof.
Caution about high volume usage
Warning：exposure to loud noise from any source for extended periods of time may
affect your hearing. The louder the sound,the less time is required before your hearing
could be affected. To protect your hearing:
Limit the amount of time you use headsets or headphones at high volume.
Avoid turning up the volume to block out noisy surroundings.
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in
your ears, ringing in your ears or muffled speech, you should stop listening to the
device through your headset or headphones and have your hearing checked.

Service and support information
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Limited Warranty (LLW) for a full explanation of Lenovo warranty terms. See
“Lenovo Limited Warranty notice” later in this document for details on accessing the
full warranty.
Online technical support
Online technical support is available during the lifetime of a product at:
http://www.lenovo.com/support
Telephone technical support
You can get help and information from the Customer Support Center by telephone.
Before contacting a Lenovo technical support representative, please have the
following information available: model and serial number, the exact wording of any
error message, and a description of the problem.
Your technical support representative might want to walk you through the problem
while you are at your device during the call.
Worldwide Lenovo support telephone list
Important: Telephone numbers are subject to change without notice. The most
up-to-date telephone list for the Customer Support Center is always available at:
http://www.lenovo.com/support/phone
If the telephone number for your country or region is not listed, contact your Lenovo
reseller or Lenovo marketing representative.

* Excludes some components. 90-day limited warranty for power adapters, keyboards,
plastics and hinges.
Type of warranty service
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Service
3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Customer Two-Way Mail-in Service
7. Product Exchange Service
For a full explanation of the types of warranty service, refer to the full warranty. See
“Lenovo Limited Warranty notice” for details on accessing the full warranty.
Country or region Warranty period
Guatemala, Costa Rica, Venezuela, Peru,
Uruguay, Ecuador, Colombia, Chile, Argentina,
El Salvador
1,4
Type of warranty
service
Parts and Labor - 1 year
Battery Pack/Earphone
- 1 year
United States of America, Canada, Mexico 1,5
Panama 2,4
Brazil 2,5
Parts and Labor - 1 year
Battery Pack/Earphone
- 1 year
Parts and Labor - 1 year
Battery Pack/Earphone
- 1 year
Parts and Labor - 1 year
Battery Pack/Earphone
- 1 year
Warranty information
Lenovo Limited Warranty notice
This product is covered by the terms of the LLW, version L505-0010-02 08/2011. You
can read the LLW at http://www.lenovo.com/warranty/llw_02. You can read the LLW in
a number of languages from this Web site. If you cannot view the LLW from the Web
site, contact your local Lenovo office or reseller to obtain a printed version of the LLW.
Warranty period and type of warranty service

Energy efficiency mark
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to responsibly
recycle their equipment when it is no longer needed. Lenovo offers a variety of
programs and services to assist equipment owners in recycling their IT products. For
information on recycling Lenovo products, go to http://www.lenovo.com/recycling.
Important battery and WEEE information
Additional recycling statements
Additional information about recycling device components and batteries is in your User
Guide. See “Accessing your User Guide” for details.
Battery recycling marks
Batteries and electrical and electronic equipment marked with the symbol of a
crossed-out wheeled bin may not be disposed as unsorted municipal waste.
Batteries and waste of electrical and electronic equipment (WEEE) shall be
treated separately using the collection framework available to customers for
the return, recycling, and treatment of batteries and WEEE. When possible,
remove and isolate batteries from WEEE prior to placing WEEE in the waste
collection stream. Batteries are to be collected separately using the
framework available for the return, recycling, and treatment of batteries and
accumulators.
Country-specific information is available at:
http://www.lenovo.com/recycling

Restriction of Hazardous Substances Directive (RoHS)
The latest environmental information about our products is available at
http://www.lenovo.com/ecodeclaration.
European Union
This Lenovo product,with included parts (cables, cords, and so on) meets the
requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”).
For more information about Lenovo worldwide compliance on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
The device is going on be operated in 5150~5250 frequency range. It is restricted indoor environment only.(for Canada)

10

1.010.96101010

10 mm10 mm

5SC9A467R3
© Copyright Lenovo 2016.
Printed in China
V1.0_20160502
MC
