English
Read this guide carefully before using your device.
1

Lenovo PHAB2 overview
Lenovo PB2-650M
Model Version
WLAN + LTE (Voice)
5
10
13
Micro USB connector
2
6
3
79
4
1
11 12
On/Off button
Speaker
Microphone
Volume buttons
Headset jack
Card tray
Rear camera
Touch screen
8
Front camera
Receiver
Light/Proximity sensor
Flash 14 15
Anti-noise microphones
Indicator
2
1
2
4
3
5 66
9
11 10
12
14
15
13
8
7

Micro-SIM
microSD
Micro-SIM1
Micro-SIM2
Step 3. Carefully insert the card tray with the installed
cards back into the slot.
Install the Micro-SIM and the microSD cards as shown.
Preparing your device
Step 1. Insert the eject tool that comes with your device
into the hole in the card tray.
Step 2.
Insert the Micro-SIM and microSD cards
into the corresponding card slot.
Insert the Micro-SIM1 and Micro-SIM2
cards into the corresponding card slot.
Pull out the card tray and do one of the following:
Only Micro-SIM cards work with your device.
Only microSD cards formated with FAT32 work with your device. You might need
to format your microSD card before using by following the instructions on the
screen.
Do not insert or remove the Micro-SIM card while your device is on. Doing so can
permanently damage your Micro-SIM card or device.
3

Turning on/off
You might need to charge the battery before using your device.
Charge the battery as shown.
Connect your device to a power outlet using the cable and USB power adapter
provided.
Low battery Fully charged Charging
Turn on: Press and hold the On/Off button until the Lenovo logo appears.
Turn off: Press and hold the On/Off button for a few seconds, then tap Power off.
Restart: Press and hold the On/Off button for a few seconds, then tap Reboot.
Starting to use your device
Taking screenshots
Press and hold the On/Off button and the Volume down button at the same time.
4
