Lenovo Tab P11 Plus
Safety, Warranty & Quick Start Guide
Lenovo TB-J616F
Lenovo TB-J616X

Contents
English............................................................................................................1
Čeština...........................................................................................................18
Slovenčina.................................................................................................... 35

1
Reading before using your device
Reading first - regulatory information
Device models equipped with wireless communications comply with the radio
frequency and safety standards of any country or region in which it has been approved
for wireless use. In addition, if your product contains a telecom modem, it complies with
the requirements for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region before using
the wireless devices contained in your device. To obtain a PDF version of the
Regulatory Notice, go to https://support.lenovo.com.
Getting support
To get support on network services and billing, contact your wireless network
operator. To learn how to use your device and view its technical specifications, go
to https://support.lenovo.com.
Accessing your User Guide
Your User Guide contains detailed information about your device. To download
the publications for your device, go to https://support.lenovo.com and follow the
instructions on the screen.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other
countries, or both.
Other company, product, or service names may be trademarks or service marks of
others.
Dolby, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby
Laboratories Licensing Corporation. Manufactured under license from Dolby
Laboratories. Confidential unpublished works. Copyright © 2012–2021 Dolby
Laboratories. All rights reserved.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered
pursuant a General Services Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
Read this guide carefully before using your device.
All information labeled with * in this guide only refers to the WLAN + LTE model.
https://support.lenovo.com
https://forums.lenovo.com
English

2
Device overview
Model Version
Lenovo TB-J616F WLAN
Lenovo TB-J616X WLAN + LTE
1233
4
56
7
8
9
9
9
9
10
11 12 13
14
1Volume up button 2Volume down button 3Microphone
4Front-facing
camera 5Light sensor 6ToF sensor
7Card tray 8Power button 9Speakers
10 USB-C connector 11 Touch screen
12 4-point pogo-pin smart connector (for the compatible keyboard and Smart
Charging Station)
13 Flashlight 14 Rear camera

3
Charging your device
Connect your device to a power
outlet using the USB cable and
power adapter provided.
Turning on
Press and hold the Power button until
the Lenovo logo appears.
• The WLAN version does not have a Nano-SIM card slot.
• All pictures and illustrations in this document are for your reference only and
may dier from the final product.
Preparing your device
Installing cards
Install the cards as shown in the figure.
microSD
mc
iroSD
Nano
*
SIM
WLAN WLAN+LTE
• Power o the device before inserting or removing a card.
• Note that the WLAN version does not have a Nano-SIM card slot.

4
Accessories (optional)
The accessories do not come with all models, and are sold separately.
Keyboard pack
1
24
5
3
Keyboard Stand Cover
1Keyboard connector 2Keyboard 3Trackpad
4
Hinge
5Kickstand
Keyboard layouts vary from country to country. The Keyboard layout in this
document is for reference only and your Keyboard may dier.
Attaching the Keyboard pack
Attach the stand cover and keyboard to the tablet as shown in the following
figure.
1 2
When you are attaching the Stand Cover to the Tablet, make sure that the
camera hole is aligned with the tablet’s rear camera.

5
Keyboard pack configurations
The Tablet can be used with the entire Keyboard pack attached, or with the
Stand Cover alone.
Opening and adjusting the Kickstand
You can adjust the Tablet angle using the Stand Cover. Grasp either side of
the kickstand and gently open it until you reach the desired angle.
1
2 3
To prevent damage, do not apply excessive pressure to the Stand Cover or
force the Kickstand beyond its natural range of motion.

6
1. Do not overtilt or apply excessive pressure to the Stand Cover, doing so
may damage the hinges.
2. Adjust the tablet angle by opening the Kickstand and changing the
position of the tablet until the desired angle is found.
3. The Tablet, Keyboard, and Stand Cover all contain magnetic materials. To
avoid loss of magnetism, avoid exposing the Tablet, Keyboard, and Stand
Cover to high temperatures or direct sunlight.
4. To prevent demagnetization of credit cards and other items with magnetic
data, keep them away from the Tablet, Keyboard, and Stand Cover.
Lenovo Precision Pen 2
You can use Lenovo Precision Pen 2 in place of your fingers for a better the
experience, such as working with specific applications to write or draw on
the screen.
Overview
1Pen cap
2Indicator LED
3Upper button
4Lower button
5Tip
2
1
3
4
5

7
Charging the pen
1. Remove the pen cap in the
direction shown in the figure.
2. Connect the pen to a charger
with a USB-C cable.
3. Replace the pen cap on the
pen. You can start to use the
pen after charging.
1 2 3
• The indicator light will have an amber glow while charging the pen and a
white glow after it is fully charged.
• Please be cautious when using the pen. The pen contains sensitive electronic
components. Dropping it may cause damage.
Replace tip
1. Pinch the tip with tweezers or another suitable tool.
2. Remove the tip.
3. Install the stand-by tip (supplied).
1
13
2

8
Store the Pen
Method one:
1. Slide the pen into the pen case.
2. Remove the transparent film on the back of the pen case.
3. Stick the pen case to the plastic panel.
4. Thread the ring through the X-shaped hole in the top of the plastic panel.
3 4
1 2
Method two:
1. Slide the pen into the pen case.
2. Remove the transparent film on the back of the pen case.
3. Stick the pen case to the back of the tablet or stand cover.
1 2

9
3
Use the Pen
1. Hold the pen close to the tablet until a white dot appears on the screen.
2. Use the upper and lower button functions of the pen.
Using the pen on a coated screen may interfere with the pen-writing
experience.
If your pen is not responsive, please try switching pen protocols. Hold both buttons
consecutively for 25 seconds to switch between pen protocols (WGP& AES).

10
Smart Charging Station
Name Model
Smart Charging Station Lenovo CR-421
12
3
1Removable back
support 2Smart connector 3USB-C connector
As shown in the picture, you can charge the battery through the Smart Charging
Station.
• Frequent insertion and removal of back support may result in looseness.
• This product is designed to work only with bundled adaptor and charging
cable, please use them in order to make the product work correctly.

11
Important safety and handling information
Plastic bag notice
Danger: Plastic bags can be dangerous. Keep plastic bags away from babies and
children to avoid danger of suocation.
Caution about high volume usage
Warning: Exposure to loud noise from any source for extended periods of time
may aect your hearing. The louder the sound, the less time is required before your
hearing could be aected. To protect your hearing:
• Limit the amount of time you use headsets or headphones at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness
in your ears, ringing in your ears or mued speech, you should stop listening to the
device through your headset or headphones and have your hearing checked.
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
Safety instructions for parents and adult supervisors
Your mobile device is not a toy. As with all electrical products, precautions should
be observed during handling and using of electrical products to reduce the risk of
electric shock. If parents choose to allow children to use the device, they should
caution his or her child about the potential hazard while using and handling the
mobile device.
Parents should inspect the mobile device (including the ac power adapter and
the small part, as applicable) periodically for damage. Routinely check this mobile
device to ensure that the device is working properly and is safe for children to use.
Internal rechargeable battery warning
Danger: Do not attempt to replace the internal rechargeable lithium ion battery.
Replacing the original battery with an incompatible type may result in an increased
risk of personal injury or property damage due to explosion, excessive heat, or other
risks. Do not attempt to disassemble or modify the battery pack. Attempting to do
so can cause a harmful explosion or battery fluid leakage.

12
When disposing of the battery, comply with all relevant local ordinances or
regulations. Do not dispose the battery pack in municipal waste. Dispose used
batteries according to the instructions.
The battery pack contains a small amount of harmful substances.
To avoid injury:
• Keep the battery pack away from open flames or other heat sources.
• Do not expose the battery pack to water, rain, or other corrosive liquids.
• Do not leave the battery in an environment with extremely high temperature.
• Avoid short-circuiting the battery pack.
• Keep the battery pack out of reach of small children and pets.
• Do not leave the battery in an environment with extremely low air pressure. It
may result in an explosion or the leakage of flammable liquid or gas from the
battery.
To extend battery life, we recommend charging the battery to at least 30% to 50%
capacity each time, and recharging it every three months to prevent over discharge.
Eye Protection and Safety Information
While concentrating on the performance capabilities of its screens, Lenovo also
places importance on user’s eye health. This product has received TÜV Rheinland’s
“Low Blue Light” certification and can be used with confidence.
EurAsia compliance mark

13
Service and support information
Lenovo Limited Warranty notice
This product is covered by the terms of the Lenovo Limited Warranty (LLW),
version L5050010-02 08/2011. Read the LLW at
https://www.lenovo.com/warranty/llw_02. You can view the LLW in a number of
languages from this website.
Warranty information
Lenovo provides a warranty period for your device. To check the warranty status of
your device purchase upgrades, go to https://support.lenovo.com/warrantylookup,
and then select the product and follow the on-screen instructions.
Get support
To download Lenovo service tool - LMSA:
https://support.lenovo.com/downloads/ds101291
Visit the website above for information on devices compatible with LMSA.
Visit Lenovo’s support website (https://support.lenovo.com) with the device serial
number to get more Lenovo support options, or scan the QR code, and then follow
the on-screen instructions.

14
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to
responsibly recycle their equipment when it is no longer needed. Lenovo oers a
variety of programs and services to assist equipment owners in recycling their IT
products. For information on recycling Lenovo products, go to
http://www.lenovo.com/recycling.
Important Battery Recycling & WEEE information
Don’t dispose of your product or battery with your household waste.
Refer to the User Guide that came with your product for further
information, or go to https://www.lenovo.com/recycling
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://www.lenovo.com/recycling/japan
Additional recycling statements
Additional information about recycling device components and batteries is in your
User Guide. See “Accessing your User Guide” for details.
Battery recycling marks
Battery recycling information for Taiwan
Battery recycling information for the United States and Canada

15
Restriction of Hazardous Substances Directive (RoHS)
Turkey
Lenovo products sold in Turkey, on or after June 1, 2009, meet the requirements of
the former Republic of Turkey Restriction of Hazardous Substances legislation from
30th of May 2008 and the Control of Waste Electrical and Electronic Equipment
Regulations from 22nd of May 2012(“Turkey RoHS”).
Ukraine
Lenovo products sold in Ukraine, on or after January 1, 2011, meet the requirements
of the Technical Directive on Restriction of Hazardous Substances in Electric
and Electronic Equipment enforced by the Government, Decision No 1057 dated
2008/12/03” (“Ukraine TR on RoHS”).
India
Lenovo products sold in India, on or after May 1, 2012, meet the requirements of the
India E-waste (Management) Rules (“India RoHS”).
Vietnam
Lenovo products sold in Vietnam, on or after September 23, 2011, meet the
requirements of the Vietnam Circular 30/2011/TT-BCT (“Vietnam RoHS”).
European Union (EU) / United Kingdom (UK) RoHS
This Lenovo product, with included parts (cables, cords, and so on) meets the requi-
rements of EU Directive 2011/65/EU as amended by Directive 2015/863/EU and UK
SI 2012 No. 3032 on the restriction of the use of certain hazardous substances in
electrical and electronic equipment (“RoHS recast” or “RoHS 2”).
For more information about Lenovo progress on RoHS, go to:
https://www.lenovo.com/us/en/social_responsibility/RoHS-Communication.pdf
Singapore
Lenovo products sold in Singapore, on or after June 1, 2017, meet the requirements
of Government Gazette order No. S 263/2016 Restriction of Hazardous Substances
in Electrical and Electronic Equipment in Singapore (“SG-RoHS”).

16
European Union (EU) / United Kingdom (UK)
compliance statement
Lenovo PC HK Limited declares that the radio equipment type: Lenovo TB-J616F
is in compliance with the EU Radio Equipment Directive 2014/53/EU, as well as
the UK Radio Equipment Regulations SI 2017 No. 1206. The full text of the system
declarations of conformity are available at :
https://www.lenovo.com/us/en/compliance/eu-doc for EU and
https://www.lenovo.com/us/en/compliance/uk-doc for UK.
This radio equipment operates with the following frequency bands and maximum
radio-frequency power:
Model Name Frequency Bands Maximum Power (dBm)
Lenovo TB-J616F
WLAN 2400-2483.5 <20
WLAN 5150-5725 <20
WLAN 5725-5850 <14
Bluetooth 2400-2483.5 <10
Restrictions of use:
Usage of this device is limited to indoor in the band 5150 to 5350MHz.
AT BE FI
RO
BG
FR
SE
CH
HR
SI
CY
HU MT
SK
CZ
IE NL
TR
DE
IS
PL
DK
IT
PT
EE EL ES
LI LT LU LV
NO UK（NI）UK
The above information is for EU countries and UK. Please refer to the actual
product for supported frequency bands in other countries.

17
Specific Absorption Rate information
YOUR MOBILE DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE
TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves (radio frequency electromagnetic fields)
recommended by international guidelines. The guidelines were developed by an
independent scientific organization (ICNIRP) and include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health. The
radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for your device model are listed
below:
Maximum SAR for this model and conditions under which it was recorded.
EU/UK 10g
SAR Limit
(2.0 W/kg)
Lenovo TB-J616F
Body
WLAN,
Bluetooth
1.484 W/kg
EU/UK 10g
SAR Limit
(4.0 W/kg)
Limb 1.484 W/kg
During use, the actual SAR values for your device are usually well below the
values stated. This is because, for purposes of system eciency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the data connection. The
lower the power output of the device, the lower its SAR value. If you are interested
in further reducing your RF exposure then you can easily do so by limiting your
usage or simply using a hands-free kit to keep the device away from the head and
body.

18
Přečtěte si, než začnete zařízení používat
Přečtěte si jako první– regulatorní informace
Modely vybavené bezdrátovou technologií odpovídají normám pro rádiová zařízení
abezpečnostním normám každé země aoblasti, kde byly schváleny pro bezdrátové použití.
Pokud váš produkt navíc obsahuje telekomunikační modem, splňuje požadavky na připojení
do telefonní sítě ve vaší zemi.
Před použitím bezdrátových zařízení obsažených ve vašem zařízení si přečtěte dokument
Prohlášení o souladu pro svoji zemi či oblast. Na https://support.lenovo.com můžete získat
PDF verzi dokumentu Prohlášení osouladu.
Podpora
Podporu ksíťovým službám afakturaci získáte od svého poskytovatele bezdrátové sítě. Další
informace o používání zařízení a technické specikace naleznete na https://support.lenovo.com.
Přístup k příručce pro uživatele
Vaše Příručka pro uživatele obsahuje podrobné informace ovašem zařízení. Chcete-li si
stáhnout dokumenty pro svoje zařízení, přejděte na webovou stránku https://support.
lenovo.com apostupujte podle pokynů na obrazovce.
Právní informace
Lenovo alogo Lenovo jsou ochranné známky společnosti Lenovo ve Spojených státech a/
nebo vjiných zemích.
Další názvy společností, produktů nebo služeb mohou být ochranné známky nebo servisní
známky jiných stran.
Dolby, Dolby Atmos asymbol dvojitého D jsou registrované ochrannými známkami
společnosti Dolby Laboratories Licensing Corporation. Vyrobeno pod licencí společnosti
Dolby Laboratories. Jde o důvěrná neuveřejněná díla. Copyright © 2012-2021 Dolby
Laboratories. Všechna práva vyhrazena.
UPOZORNĚNÍ NA PRÁVNÍ OMEZENÍ: Pokud jsou data nebo software dodávány vsouladu se
smlouvou General Services Administration (GSA), používání, reprodukce nebo zpřístupňování
jsou předmětem omezení uvedených ve smlouvě č. GS-35F-05925.
Tuto příručku si před použitím zařízení důkladně pročtěte.
Všechny informace, které jsou v této příručce označené *, odkazují pouze na model
WLAN + LTE.
https://support.lenovo.com
https://forums.lenovo.com
Čeština
