Lenovo Smartband swb100 User manual

LENOVO SMARTBAND

Quick Start

Basic operations

Basic operations on the Smartband:

Tap the screen once (hereinafter

called tap)

Tap the screen twice continuously

(hereinafter called double-tap)

The screen stays off when no operation is

performed. When needed, double-tap to

wake up the screen.

By default, the following home screen is

displayed when you wake up the screen.

The home screen switches between the

“time screen” and the “steps/calories

screen”. Tap to toggle among the

following screens: home, training mode,

sleep mode, and heart-rate mode.

Double-tapping on any of the mode

screens will turn on or turn off the mode.

Note: The “steps/calories” screen shows

the real-time step count and calories of

your daily activities.

Function modes

The Smartband provides three function

modes: training mode, sleep mode, and

heart-rate mode.

Training mode

You can set your training goals on the

Smartband app, such as running time,

distance, and calories. Turn on training

mode when you start running, and the

Smartband starts to record your workout

data. With the ease of getting the time,

distance, and calories data, your workout

gets well under control.

Related information or operations:

On the training mode screen, double-

tap to turn on training mode:

After you enter training mode, the

screen displays running time,

distance, calories, and real-time heart

rate in order. If you have set up a goal

on the Smartband app, such as

running time, this goal will be

displayed in the first place.

When you finish the workout, double-

tap to exit training mode. Your workout

data is saved.

Sleep mode

In sleep mode, Smartband helps you track

your sleeping quality. You can turn on and

turn off sleep mode by either operating on

the Smartband or setting on the

Smartband app.

Related information or operations:

Turning on sleep mode manually:

On the sleep mode screen, double-tap to

turn on sleep mode:

Turn off sleep mode manually:

Wake up the screen, on the following

screen, double-tap to turn off sleep mode.

Turning on or off sleep mode

automatically:

Set the starting and ending time for your

sleep on the Smartband app. At the pre-

set starting time, the Smartband enters

sleep mode automatically. It vibrates and

displays the following screen:

At the pre-set ending time, the Smartband

exits sleep mode automatically. It vibrates

and displays the following screen:

Double-tap, and the screen will display the

total time of this sleep and show you the

percentage of accomplishing your pre-set

goal through a progress bar:

Heart-rate mode

You can ask the Smartband for your real-

time heart rate. In addition, you can use

the heart-rate data to control your training

effect more precisely.

Related information or operations:

On the heart-rate mode screen,

double-tap to enter heart-rate mode:

Once in heart-rate mode, the

Smartband starts to monitor your heart

rate. During the process, the following

screen is displayed:

When the Smartband gets your heart-

rate data, it vibrates and displays the

data as follows:

In the Smartband app, you can set

upper and lower limits for your heart

rate. In training mode, when your heart

rate hits the upper or lower limit, the

Smartband vibrates to help you control

your training.

Note:

For accuracy of data, wear the

Smartband tight enough to keep the

heart-rate sensor closely against your

skin. The sensor is located in the

center on the bottom of the

Smartband.

Avoid any obstacle or scar between

the heart-rate sensor and your skin.

Heart-rate monitoring by the

Smartband is for your personal

reference only. Do not use it for

medical purposes.

Pairing

To make full use of the Smartband

functions, pair your Smartband with your

smartphone or computer.

To pair your Smartband with a device:

1. Ensure that your Smartband is not

running in any function mode.

2. On the home screen, double-tap to

display the following screen:

“XXXX” represents the Smartband ID.

3. On your smartphone or computer, turn

on Bluetooth and open the Smartband

app, and select the Smartband you

want to pair with. Then following the

instructions on the device screen.

Note:

If pairing succeeds, the Smartband

screen displays a “✓”.

If pairing fails, the Smartband screen

displays “X”.

Reminder

The Smartband provides multiple

reminders, such as workout reminder,

sleeping reminder, incoming call/SMS

reminder, and custom reminder. On each

type of reminder, the Smartband vibrates

and displays text.

Workout reminder

If you do not meet your pre-set workout

goal for three consecutive days, the

Smartband will remind you with the

following screen every morning at 9:00

am:

Sleeping reminder

If you do not meet your pre-set sleeping

time goal for three consecutive days, the

Smartband will remind you with the

following screen every evening at 8:00

pm:

Incoming call/SMS reminder

If your smartphone is paired with your

Smartband and has Bluetooth turned on,

the Smartband will remind you when you

receive an incoming call or an SMS. The

Smartband will display the phone number

of the incoming call or the SMS. If the

phone number belongs to one of your

phone contacts, the contact name will be

displayed.

Note:

After you read the reminder, tap and

the reminder will disappear.

The reminder only shows the latest

incoming call or SMS.

The screen displays a maximum of 32

characters or 16 Chinese characters.

Custom reminder

You can set your custom reminder text

and time in the Smartband app. Example:

Data sync

After you have paired your Smartband

with your smartphone or computer, the

Smartband will automatically sync with the

Smartband app when you open the app. If

the Smartband has entered a function

mode, it does not affect the syncing.

You can also click the sync button in the

Smartband app to manually sync data

anytime.

During data syncing, the Smartband

displays the following screen:

When syncing is done, the home screen is

displayed.

Resetting the Smartband

To reset the Smartband, do the following:

1. On the home screen, tap continuously

for 5 seconds, and the following

screen is displayed:

2. Double-tap to activate the reset, and

the following screen is displayed:

3. Tap continuously for 5 seconds until

the circle disappears.

4. Reset is completed when the following

screen is displayed:

Installing Smartband app

Windows:

Android:

iOS:

FAQ

Q: How to set the time on the Smartband?

A: When the Smartband syncs with

another device, the time on the device is

automatically synchronized to the

Smartband. No operation is needed.

Q: Why can’t I find my Smartband on the

smartphone or computer app?

A: Ensure that:

Bluetooth is turned on.

The Smartband has sufficient power.

The Smartband is not paired with

another device.

If the cause is still unknown, try to

reset the Smartband, restart the other

device, or reset Bluetooth.

Q: Why can’t the Smartband detect my

heart rate?

A: Ensure that:

The heart-rate sensor is kept closely

against your skin.

There is no obstacle or scar between

the heart-rate sensor and your skin.

The cover on the sensor is clean.

Specifications

Item Description

Battery life 7 days (Daily activity

and sleep tracking only.

Shorter when a function

mode is turned on.)

Data hold 7 days

Connection Bluetooth 4.0 BLE

OS support Windows 8 and later

Android 4.3 and later

iOS 7 and later

Size Min wearable size: 5.59

in (142 mm)

Max wearable size:

7.56 in (192 mm)

Weight 0.78 ounces (22 grams)

Water-proof

level

IP67

Thisdevicecomplies withPart 15 oftheFCC Rules.Operationissubject tothefollowing two

conditions: (1)thisdevicemaynot cause harmfulinterference,and (2)thisdevicemust

accept any interferencereceived,including interferencethat maycause undesired operation.

FCC Caution:

Changesormodificationsnotexpresslyapprovedbythepartresponsibleforcompliancecouldvoidthe

user'sauthoritytooperatetheequipment.

FCC Statement:

"ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15 oftheFCC Rules. Theselimitsaredesignedtoprovidereasonableprotection

againstharmfulinterferenceinaresidentialinstallation. Thisequipmentgenerates, usesandcanradiate

radiofrequencyenergyand,ifnotinstalledandusedinaccordance withtheinstructions, maycause

harmfulinterference toradiocommunications. However, thereisnoguarantee thatinterference willnot

occurinaparticularinstallation. Ifthisequipmentdoescauseharmfulinterference toradioor

televisionreception, whichcanbedeterminedbyturning theequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterference byoneormoreofthefollowing measures:

Reorientorrelocatethereceiving antenna.

Increasetheseparationbetweentheequipmentandreceiver.

Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris

connected.

Consultthedealeroranexperiencedradio/TVtechnicianforhelp."
