Lenovo IdeaCentre K210 User manual

To install Lenovo Bright Eye camera, do the following:
1
2
3 5
4
[J1]
(2)
(1)
S-1
S-2
S-3
S-4
S-5
Installation Guide for Lenovo Bright Eye Camera (This camera can also be used as a common camera)
J1- Four securing latches on the front side of the
camera base
There are four securing latches on the front side
of the camera base. Align the four latches to the
four slots on the top of computer display.
Embed the four securing latches of the camera
base into the four slots, and then push the case
downward until it is locked. After that, the
camera base is secured onto the display.
Move the camera with the camera bracket
into the base along the glide rail of the base
to install the camera.
If the camera is not in use, turn it leftward
or rightward to hide it.
S-1 Lens roller —— used to adjust the pitch
angle of the lens
S-2 Power LED —— used to indicate when
the computer is powered on
S-3 Lens of the camera
S-4 Camera bracket
S-5 USB cable —— used to connect the
camera to the computer
Note:
Press “Push” to move the camera upward
and eject the lens to start the camera.
Press “Push” again to move the camera
downward and hide the lens to shut down
the camera.
31032935
