5. Attach the other part 3 side panel to the end panels with four part 9 screw/washer sets.
9.Confirm that the rods are arranged correctly
and the players on the same team face the
same direction.
FIG. 3
3
9
2
2
FIG. 5
FIG. 5C
10
21
The Hole
FIG. 5A
FIG. 5B
19 20
21
21
18
OR
26
26
= RED / Rojo
= BLUE / Azul
ORDER OF PLAYERS
(Overhead View)
FIG.5
6.Slide part 21 bumper, part 26 stop ring, part 19 red player, another stop ring, and bumper onto part 18
player rod and position it in the goalie slot. Repeat on the other side with a part 20 blue player (figure 5B).
7.Build the remaining player rods with a bumper, three red/blue players, and another bumper. The ends with
a hole are arranged on the same side.
8.Secure the players and stop rings with eighteen part 10 screws, one per player or stop ring (figure 5C).
