Lenze 2173 Quick guide

L
Manual
Global Drive
PC system bus adapter
2173 / 2177
Software installation & configuration

CAUTION:
The software is supplied to the user as described in this document. Any risks resulting from
its quality or use remain the responsibility of the user. The user must provide all safety
measures protecting against possible maloperation.
We do not take any liability for direct or indirect damage, e.g. profit loss, order loss or any
loss regarding business.
Version ID no. Changes
1.1 09/2003 TD11 Revised edition
E2003 Lenze Drive Systems GmbH
No part of this documentation may be copied or made available to third parties without the explicit
written approval of Lenze Drive Systems GmbH.
All information given in this online documentation has been carefully selected and tested for
compliance with the hardware and software described. Nevertheless, discrepancies cannot be ruled
out. We do not accept anyresponsibility or liability for any damage that may occur. Required corrections
will be included in the updates of this documentation.
Microsoft, Windows and Windows NT are either registered trademarks or trademarks of Microsoft
Corporation in the USA and/or other countries.
All other product names mentioned in this documentation are trademarks of the corresponding owners.

Contents
L1PC system bus adapter EN 1.1
1 Preface and general information 2...................................
1.1 Conventions used 2........................................................
1.2 Terminology used 3........................................................
1.3 Layout of the safety information 3..............................................
2 System requirements 4...........................................
3 Hardware installation 4...........................................
4 Software installation 5............................................
4.1 Driver installation 5........................................................
4.1.1 PC system bus adapter 2173 5........................................
4.1.2 PC system bus adapter 2177 5........................................
4.2 Installation of the system bus configuration tool 6..................................
5 Software configuration 7..........................................
5.1 Activation / deactivation / definition of the system bus adapter as a standard 8.............
5.2 Addition / deletion of system bus adapters 8......................................
5.3 Configuration of the system bus adapter 8........................................
5.3.1 PC system bus adapter 2173 9........................................
5.3.2 PC system bus adapter 2177 11........................................
5.4 Diagnostics 12.............................................................
5.5 Display of driver information 12................................................
5.6 Checking and saving of the configuration 13.......................................
5.7 What’s coming next? 13......................................................
6 Appendix 14.....................................................
6.1 FAQ - Frequently asked questions and answers 14...................................
6.1.1 PC system bus adapter 2173 14........................................
6.1.2 PC system bus adapter 2177 14........................................
6.2 Glossary 15...............................................................

PC system bus adapter 2173 / 2177
L
2PC system bus adapter EN 1.1
1 Preface and general information
The PC system bus adapter is a communication module for data transfer between a target system
(drive controller, Drive PLC, etc.) and a PC via the system bus (CAN). Two types are available:
•The PC system bus adapter 2173 is the classic type. It is connected to the parallel interface
(LPT port/printer connection) of the PC or notebook.
•The PC system bus adapter 2177 can be used for PCs & notebooks with a USB port (Universal
Serial Bus).
This type is recommended for notebooks which do not have a parallel interface for printer
connection.
Note!
This Manual contains information
•about the software installation of the device drivers required for the PC system bus adapters
and
•the software configuration of the PC system bus adapters using the system bus
configuration tool from Lenze.
Information about the mechanical/electrical connection of the PC system bus adapters can be found
in the corresponding Mounting Instructions for the PC system bus adapters.
1.1 Conventions used
This Manual uses the following conventions to distinguish between different types of information:
Type of information Marking Example
Names of dialog boxes, input fields
and selection lists
italics The dialog box Options
Buttons bold Click Ok to...
Menu commands bold Use the command Copy you can...
If several commands must be used in sequence
to carry out a function, then the individual com-
mands are separated by an arrow:
Select File WOpen to...
Keyboard commands <bold> Use <F1> to open the online help.
If a command requires a combination of keys,
the commands are linked with ”+”:
Use <Shift>+<ESC> to...

PC system bus adapter 2173 / 2177
L3PC system bus adapter EN 1.1
1.2 Terminology used
Term In the following text used for
DDS Drive PLC Developer Studio
GDC Global Drive Control
System bus adapter PC system bus adapter 2173 or PC system bus adapter 2177
USB Universal Serial Bus
1.3 Layout of the safety information
•All safety information have a uniform layout:
–The pictograph characterises the type of danger.
–The signal word characterises the severity of danger.
–The note describes the danger and suggests how to avoid the danger.
Signal word
Note
Pictographs used Signal words
Warning of
danger to
persons
Warning of
hazardous
electrical
voltage
Danger! Warns of impending danger.
Consequences if disregarded:
Death or severe injuries.
Warning of a
general
danger
Warning! Warns of potential, very hazardous situations.
Possible consequences if disregarded:
Death or severe injuries.
Caution! Warns of potential, hazardous situations.
Possible consequences if disregarded:
Light or minor injuries.
Warning of
damage to
material
Stop! Warns of potential damage to material.
Possible consequences if disregarded:
Damage to the controller/drive system or its
environment.
Other notes Tip!
Note!
Indicates a tip or note.
If observed, it will make handling the product easier.

PC system bus adapter 2173 / 2177
L
4PC system bus adapter EN 1.1
2 System requirements
The following minimum requirements on hardware and software must be met in order to use the system
bus adapters:
PC system bus adapter 2173 PC system bus adapter 2177
•Microsoft Windows 95/98/Me/NT/2000/XP
•IBM compatible PC
(Pentium 90 processor or higher)
•32 MB RAM
•Parallel interface (LPT port)
Note:
Please make sure that the operating mode ”ECP”
(Extended Capability Port) is selected for the
parallel interface in the PC BIOS.
•Microsoft Windows 98/Me/2000/XP
•IBM compatible PC
(Pentium 266 processor or higher)
•64 MB (RAM)
(128 MB RAM with Windows 2000/XP)
•Free USB port with 200 mA power supply
Note:
If the PC internal power supply is insufficient for the
USB port a USB hub with external power supply is
required to ensure the power supply of the system
bus adapters!
The following Lenze tools can be used for communication via the system bus adapters:
•Drive Server
•Global Drive Control (PC system bus adapter 2177: as from GDC version 4.3)
•Global Drive Loader
•Global Drive PLC Developer Studio (PC system bus adapter 2177: as from DDS version 1.4)
3 Hardware installation
Information about the mechanical/electrical connection of the system bus adapters can be
found in the corresponding Mounting Instructions for the system bus adapters.
Tip!
System bus adapter LED:
•PC system bus adapter 2173: The LED lights up as soon as the system bus adapter is
connected to the PC and the PC is switched on. If the LED does not light up the system bus
adapter does not work properly.
•PC system bus adapter 2177: The LED only lights up if the operating system has identified
the system bus adapter and found an appropriate driver. The LED flashes as soon as a Lenze
tool communicates via the system bus adapter.

PC system bus adapter 2173 / 2177
L5PC system bus adapter EN 1.1
4 Software installation
A driver has to be installed to ensure that the system bus adapter can be recognised by the operating
system.
•The following section describes the installation of the drivers required for the individual system
bus adapters.
4.1 Driver installation
Note!
Windows NT/2000/XP requires administrator rights for installing the drivers!
4.1.1 PC system bus adapter 2173
The driver required for PC system bus adapter 2173 is part of the Lenze tools.
It is automatically installed when the corresponding Lenze tools are installed or can be manually
selected for installation.
You need not install any additional software for the system bus adapter.
4.1.2 PC system bus adapter 2177
The driver required for PC system bus adapter 2177 is part of the Lenze tools.
It is automatically installed when the corresponding Lenze tools are installed or can be manually
selected for installation.
Note!
The installation program of the following Lenze tools does not yet include the driver required for PC
system bus adapter 2177. A separate driver update has to be installed here:
•Drive Server 1.0
•Global Drive Control 4.4
•Global Drive Loader 1.0
•Global Drive PLC Developer Studio 1.4
The driver updates can be found at the Lenze homepage in the Internet:
http://www.Lenze.de WDownloads WUpdate versions
Please proceed as follows:
1. Download the driver update from the Lenze homepage to your local hard disk.
(File ”UPDATE_CAN_DRIVER.EXE”)
2. Install the Lenze tools you want to communicate via the system bus adapter.
3. Select the file ”UPDATE_CAN_DRIVER.EXE” to install the driver update.
4. Follow the instructions of the installation program.
Windows 98/Me/2000
When the system bus adapter is plugged into a free USB port the new hardware will be automatically
recognised and the required driver will be loaded.

PC system bus adapter 2173 / 2177
L
6PC system bus adapter EN 1.1
Windows XP
When the system bus adapter is plugged into a free USB port the Hardware update wizard will be
automatically displayed.
•Open the dialog box Hardware update wizard, go to ”Automatic software installation” and press
the button Next to install the software for the system bus adapter.
The driver for PC system bus adapter 2177 has now been installed.
Note!
If the Hardware update wizard does not automatically find the required driver, indicate the below
directory:
[Drive] :\Programs\Lenze\Drivers
Enter the letter of the hard disk drive selected for the installation of the Lenze tool as ”[Drive]”.
4.2 Installation of the system bus configuration tool
The Lenze system bus configuration tool for a convenient configuration of the system bus adapters
is installed together with the driver for PC system bus adapter 2177.
Note!
If PC system bus adapter 2173 is used with older versions of the Lenze tools the system bus
configuration tool might not yet be available on your PC.
In this case, a separate driver update has to be installed which can be found at the Lenze homepage
in the Internet:
http://www.Lenze.de WDownloads WUpdate versions
Please proceed as follows:
1. Download the driver update from the Lenze homepage to your local hard disk.
(File ”UPDATE_CAN_DRIVER.EXE”)
2. Install the Lenze tools you want to communicate via the system bus adapter.
3. Select the file ”UPDATE_CAN_DRIVER.EXE” to install the driver update.
4. Follow the instructions of the installation program.

PC system bus adapter 2173 / 2177
L7PC system bus adapter EN 1.1
5 Software configuration
The system bus adapter has to be configured to allow communication of the Lenze tools via the system
bus adapter.
Select ProgramsWLenzeWCommunicationWSystem bus configuration tool in the start menu to
open the system bus configuration tool:
Under ”Hardware Name” you will find a list of all system bus adapters installed. The status of the
individual system bus adapters is indicated under ”State”:
Symbol Meaning
The system bus adapter is active and used by Lenze tools.
The system bus adapter is active and used by Lenze tools. It is defined as a standard.
•Lenze tools which can only access one system bus adapter use the standard system bus adapter.
•Lenze tools which can access more than one system bus adapter at the same time can use all
active system bus adapters.
The system bus adapter is inactive and not used by Lenze tools.
The system bus adapter could not be accessed without error.
•For more information see FAQ (Frequently Asked Questions) in the appendix. ^14

PC system bus adapter 2173 / 2177
L
8PC system bus adapter EN 1.1
5.1 Activation / deactivation / definition of the system
bus adapter as a standard
When positioning the pointer over an entry and clicking the right mouse key a
context menu opens via which you can activate or deactivate the system bus
adapter.
You can also use the context menu to define the system bus adapter as a
standard.
Note!
It is possible to use several PC system bus adapters of type 2177 at the same time. It is, however, not
possible to use a PC system bus adapter of type 2177 together with a PC system bus adapter of type
2173. This is why it may happen that certain combinations cannot be activated in the system bus
configuration tool.
5.2 Addition / deletion of system bus adapters
If additional system busadapters are to be configured for your PC you can add themto the list by clicking
the button Add.
By clicking the button Remove you can remove a system bus adapter from the list.
•The commands Add and Remove are also available in the context menu.
5.3 Configuration of the system bus adapter
Depending on the type of system bus adapter used different communication parameters have to be set.
Select the corresponding system bus adapter from the list and set the parameters on the right-hand
side in the register Settings.
