3.2.1 ON/OFF switch: The switch to turn on and turn off TPS-series TVSS.
3.2.2 Overload protector: Over current or short circuit protection
component; press the button to reset when the pin tripped.
3.2.3 AC INPUT: The power socket for plug in the input power cord.
3.2.4 Signal Surge Protector: The sockets for protecting transient surge
from telephone cable, antenna, data cable and etc.; Different model
provides different socket types, notice the caption below each socket.
INSTALLATION
4.1 Installation
4.1.1 Turn off all electrical equipment.
4.1.2 Connect signal cables (such as telephone lines,LAN cable, antenna
cable or coaxial cable) into Signal Surge Protector sockets at the side
of TPS-series TVSS as below
IN : The socket to connect input signal cable.
OUT : The socket to connect signal cable which are protected
to telephone, facsimile machine, modem, ADSL/ISDN/
HDSL/DSL devices or CATV devices.
4.1.3 Plug the power cord from your electrical equipments into the
TVSS output outlets.
4.1.4 Plug the TVSS into the grounded electrical outlet only.
Note: To achieve the maximum performance,the TVSS must be connected
to a grounded electrical outlet to work properly. Connecting to
non-grounded electrical outlet, the TVSS will not be able to properly
protect your electrical equipments.
4.2 Turn on and turn off TPS-Series
4.2.1 Turn on ON/OFF switch. PROTECTED indicator will be lit.
4.2.2 Turn on all connected eletrical equipment.
4.2.3 To turn off the TPS-series TVSS, turn off then turn off ON/OFF
switch.
TROUBLESHOOTING
FRONT PANEL AND COMPONENTS
3.1 Front panel
3.1.1 PROTECTED: Indicates that the TPS-series TVSS is operating normally.
3.1. 2 FAULT WIRING: Indicates that the electrical outlet is not properly
grounded or the line-neutral is reversed.
Table 1 shows relationship of LED indicators and operating status
3.1. 3 Output Outlet: 6 surge protection outlets for connecting to electrical
equipment.
3.2 Side and rear panel
3.1.1
3.1.2
3.1.3
Modular Plug
RJ45-8C
Coaxial F-Type
TPS-HOME CATV TEL./ADSL
TPS-CATV CATV #1 CATV #2
Type B
Coaxial F-Type Coaxial F-Type
Type C
Side view
(Type B)
Side view
(Type C)
INOUT
INOUT
INOUT
INOUT
Modular Plug
RJ45-8C
Modular Plug
RJ45-8C
TPS-RS232 RS232C#1 RS232C#2
TPS-RS425 RS422 / RS485#1 RS422 / RS485#2
TPS-LAN LAN #1 LAN #2
TPS-TEL TEL. LINE #1 TEL. LINE #2
TPS-ISDN ISDN #1 ISDN #2
TPS-DSL DSL #1 DSL #2
TPS-ADSL ADSL TEL./ADSL
TPS-HDSL HDSL #1 HDSL #2
TPS-PLC PLC #1 PLC #2
TPS-DATA DATA #1 DATA #2
TPS-SOHO LAN TEL./ADSL
TPS-MFG RS422 / RS485#1 RS232C
Type A
Side (Type A)
3.2.1
3.2.4
3.2.3 3.2.2
INOUTINOUT
Bottom
LED indicators Operating status
PROTECTED FAULT WIRING
ON OFF
ON ON
OFF ON
OFF OFF
The TVSS provides maximum surge protection.
The TVSS can not provide maximum surge protection
because of your electrical outlet is not properly
grounded or the line-neutral is reversed.
-The TVSS has sacrificed to protect your electrical
equipment.
-Line-neutral reversal or poor ground connection.
The TVSS has sacrificed to protect your electrical
equipment.
Symptoms Possible causes Solutions
1. Disconnect some electrical
equipment.
2. Reset overload protector.
3. If the symptom persists,
contact our service center.
Contact a qualified electrician
to inspect and correct the
wiring and grounding
problem.
The TVSS has to be replaced.
Please contact service center.
PROTECTED indicator is
lit, but electrical
equipment do not work.
Overload protector
tripped.
PROTECTED and FAULT
WIRING indicators are
lit.
PROTECTED indicator is
OFF but FAULT WIRING
indicator is it.
The connected electrical
equipment are exceed the
TVSS's capability.
Line-neutral reversal or poor
ground connection.
The TVSS has sacrificed to
protect your electrical
equipment.
