Leuze ELC 100 User manual

We reserve the right to make technical changes
EN • 2022-01-14 • 50145374
Original operating instructions
ELC 100
Safety Light Curtain

© 2022
Leuze electronic GmbH + Co. KG
In der Braike 1
73277 Owen / Germany
Phone: [phone]
Fax: [phone]
www.leuze.com
[email protected]
Leuze electronic GmbH + Co. KG ELC 100 2

Table of contents
Leuze electronic GmbH + Co. KG ELC 100 3
Table of contents
1 About this document ............................................................................................5
1.1 Used symbols and signal words ............................................................................................. 5
1.2 Checklists................................................................................................................................ 6
2 Safety .....................................................................................................................7
2.1 Intended use and foreseeable misuse.................................................................................... 7
2.1.1 Intended use........................................................................................................................8
2.1.2 Foreseeable misuse ............................................................................................................8
2.2 Necessary competencies........................................................................................................ 8
2.3 Responsibility for safety.......................................................................................................... 9
2.4 Disclaimer ............................................................................................................................... 9
3 Device description ..............................................................................................10
3.1 Structure and function........................................................................................................... 10
3.2 Connection technology ......................................................................................................... 11
3.3 Display elements .................................................................................................................. 12
3.3.1 Operating indicators on the ELC100 transmitter ..............................................................12
3.3.2 Operating indicators on the ELC110 receiver ..................................................................12
4 Applications ........................................................................................................14
4.1 Point of operation guarding................................................................................................... 14
5 Mounting..............................................................................................................15
5.1 Arrangement of transmitter and receiver .............................................................................. 15
5.1.1 Calculation of safety distanceS ........................................................................................15
5.1.2 Calculation of safety distance if protective fields act orthogonally to the approach direction
..........................................................................................................................................16
5.1.3 Minimum distance to reflective surfaces ...........................................................................20
5.1.4 Preventing mutual interference between adjacent devices ............................................... 21
5.2 Mounting the safety sensor................................................................................................... 22
5.2.1 Suitable mounting locations ..............................................................................................22
5.2.2 Fastening via sliding blocks...............................................................................................23
5.2.3 Fastening via BT-2SB05 swiveling mounting brackets .....................................................23
6 Electrical connection..........................................................................................24
6.1 Pin assignment transmitter and receiver .............................................................................. 25
6.1.1 ELC100 transmitter ..........................................................................................................25
6.1.2 ELC110 receiver...............................................................................................................25
6.1.3 Circuit diagram example....................................................................................................26
7 Starting up the device ........................................................................................27
7.1 Switching on ......................................................................................................................... 27
7.2 Aligning the sensor ............................................................................................................... 28
8 Testing .................................................................................................................29
8.1 Before commissioning and following modifications .............................................................. 29
8.1.1 Checklist for integrator – to be performed prior to commissioning and following modifica-
tions...................................................................................................................................29
8.2 To be performed periodically by competent persons............................................................ 31
8.3 Periodically by the operator .................................................................................................. 31
8.3.1 Checklist – periodically by the operator.............................................................................32
9 Care, maintenance and disposal .......................................................................33

Table of contents
Leuze electronic GmbH + Co. KG ELC 100 4
10 Diagnostics and troubleshooting......................................................................34
10.1 What to do in case of failure? ............................................................................................... 34
10.2 Operating indicators of the LEDs.......................................................................................... 34
11 Service and support ...........................................................................................35
12 Technical data .....................................................................................................36
12.1 General specifications .......................................................................................................... 36
12.2 Dimensions, weight, response time ...................................................................................... 39
12.3 Dimensioned drawings: Accessories .................................................................................... 40
13 Order guide and accessories.............................................................................41
13.1 Part number code ................................................................................................................. 41
13.2 Type overview....................................................................................................................... 41
13.3 Accessories........................................................................................................................... 42
14 EC Declaration of Conformity............................................................................43

About this document
Leuze electronic GmbH + Co. KG ELC 100 5
1 About this document
1.1 Used symbols and signal words
Tab.1.1: Warning symbols and signal words
Symbol indicating dangers to persons
Symbol indicating possible property damage
NOTE Signal word for property damage
Indicates dangers that may result in property damage if the measures for dan-
ger avoidance are not followed.
CAUTION Signal word for minor injuries
Indicates dangers that may result in minor injury if the measures for danger
avoidance are not followed.
WARNING Signal word for serious injury
Indicates dangers that may result in severe or fatal injury if the measures for
danger avoidance are not followed.
DANGER Signal word for life-threatening danger
Indicates dangers with which serious or fatal injury is imminent if the measures
for danger avoidance are not followed.
Tab.1.2: Other symbols
Symbol for tips
Text passages with this symbol provide you with further information.
Symbol for action steps
Text passages with this symbol instruct you to perform actions.
Symbol for action results
Text passages with this symbol describe the result of the preceding action.

About this document
Leuze electronic GmbH + Co. KG ELC 100 6
Tab.1.3: Terms and abbreviations
Response time The response time of the protective device is the maximum time between the
occurrence of the event that results in activation of the safety sensor and the
provision of the switching signal at the interface of the protective device (e.g.,
OFF state of the OSSD pair).
AOPD Active Optoelectronic Protective Device
(Active Optoelectronic Protective Device)
ESPE Electro-sensitive protective equipment
ELC Brief description of the safety sensor, consisting of transmitter and receiver
LED LED, display element in transmitter and receiver
MTTFdMean time to dangerous failure
(Mean Time To dangerous Failure)
OSSD Safety-related switching output
(Output Signal Switching Device)
PFHdProbability of a dangerous failure per hour
(Probability of dangerous Failure per Hour)
PL Performance Level
Safety sensor System consisting of transmitter and receiver
SIL Safety Integrity Level
State ON: device intact, OSSD switched on
OFF: device intact, OSSD switched off
Locking: device, connection or control / operation faulty, OSSD switched off
(lock-out)
1.2 Checklists
The checklists (see chapter 8 "Testing") serve as a reference for the machine manufacturer or supplier.
They replace neither testing of the complete machine or system prior to initial commissioning nor their peri-
odic testing by a qualified person (Necessary competencies). The checklists contain minimum testing re-
quirements. Depending on the application, other tests may be necessary.

Safety
Leuze electronic GmbH + Co. KG ELC 100 7
2 Safety
Before using the safety sensor, a risk assessment must be performed according to valid standards (e.g.
ISO/ENISO12100, ISO/ENISO13849-1, IEC/EN61508, IEC/EN62061). The result of the risk assess-
ment determines the required safety level of the safety sensor (Safety-relevant technical data). For mount-
ing, operating and testing, this document as well as all applicable national and international standards, reg-
ulations, rules and directives must be observed. Relevant and supplied documents must be observed,
printed out and handed to affected persons.
ÄBefore working with the safety sensor, completely read and observe the documents applicable to your
task.
In particular, the following national and international legal regulations apply for the commissioning, techni-
cal inspections and work with safety sensors:
• Machinery directive 2006/42/EC
• Low voltage directive 2014/35/EU
• EMC directive 2014/30/EU
• OSHA 1910 Subpart O
• Safety regulations
• Accident-prevention regulations and safety rules
• Ordinance on Industrial Safety and Health and employment protection act
• Product Safety Law (ProdSG)
NOTICE
For safety-related information you may also contact local authorities (e.g., industrial inspec-
torate, employer's liability insurance association, labor inspectorate, occupational safety and
health authority).
2.1 Intended use and foreseeable misuse
WARNING
A running machine may result in serious injury!
ÄMake certain that the safety sensor is correctly connected and that the protective function of
the protective device is ensured.
ÄMake certain that, during all conversions, maintenance work and inspections, the system is
securely shut down and protected against being restarted.

Safety
Leuze electronic GmbH + Co. KG ELC 100 8
2.1.1 Intended use
• The safety sensor may only be used after it has been selected in accordance with the respectively ap-
plicable instructions and relevant standards, rules and regulations regarding labor protection and safety
at work, and after it has been installed on the machine, connected, commissioned, and checked by a
competent person (Necessary competencies). The devices are designed for indoor use only.
• When selecting the safety sensor it must be ensured that its safety-related capability meets or exceeds
the required performance level PLr ascertained in the risk assessment (see chapter 12.1 "General
specifications").
• The safety sensor protects persons or body parts at points of operation, danger zones or access points
of machines and systems.
• With the access guarding function, the safety sensor detects persons only when they enter the danger
zone but cannot tell whether there are any persons inside the danger zone. For this reason, a start/
restart interlock or a suitable stepping behind protection in the safety chain is essential in this case.
• Maximum permissible approach speeds (see ISO/ENISO13855):
• 1.6m/s for access guarding
• 2.0m/s for guards of points of operation
• The construction of the safety sensor must not be altered. When manipulating the safety sensor, the
protective function is no longer guaranteed. Manipulating the safety sensor also voids all warranty
claims against the manufacturer of the safety sensor.
• The improper repair of the protective device may result in loss of the protective function. Make no re-
pairs to the device components.
• The safety sensor must be inspected regularly by a competent person to ensure proper integration and
mounting (Necessary competencies).
• The safety sensor must be exchanged after a maximum of 20 years. Repairs or the exchange of wear
parts do not extend the mission time.
2.1.2 Foreseeable misuse
Any use other than that defined under the “Approved purpose” or which goes beyond that use is consid-
ered improper use.
In principle, the safety sensor is not suitable as a protective device for use in the following cases:
• Danger posed by ejected objects or the spraying of hot or hazardous liquids from within the danger
zone
• Applications in explosive or easily flammable atmospheres
• Applications outdoors or submerged in water or other liquids
2.2 Necessary competencies
The safety sensor may only be configured, installed, connected, commissioned, serviced and tested in its
respective application by persons who are suitably qualified for the given task. General prerequisites for
suitably qualified persons:
• They have a suitable technical education.
• They are familiar with the relevant parts of the operating instructions for the safety sensor and the oper-
ating instructions for the machine.
Task-specific minimum requirements for competent persons:
Configuration
Specialist knowledge and experience in the selection and use of protective devices on machines as well as
the application of technical rules and the locally valid regulations on labor protection, safety at work and
safety technology.
Specialist knowledge in programming safety-related controls SRASW acc. to ISO/ENISO13849-1.
Mounting
Specialist knowledge and experience needed for the safe and correct installation and alignment of the
safety sensor with regard to the respective machine.

Safety
Leuze electronic GmbH + Co. KG ELC 100 9
Electrical installation
Specialist knowledge and experience needed for the safe and correct electrical connection as well as safe
integration of the safety sensor in the safety-related control system.
Operation and maintenance
Specialist knowledge and experience needed for the regular inspection and cleaning of the safety sensor –
following instruction by the person responsible.
Servicing
Specialist knowledge and experience in the mounting, electrical installation and the operation and mainte-
nance of the safety sensor in accordance with the requirements listed above.
Commissioning and testing
• Experience and specialist knowledge in the rules and regulations of labor protection, safety at work and
safety technology that are necessary for being able to assess the safety of the machine and the use of
the safety sensor, including experience with and knowledge of the measuring equipment necessary for
performing this work.
• In addition, a task related to the subject matter is performed in a timely manner and knowledge is kept
up to date through continuous further training ‑ Competent person in terms of the German Betrieb-
ssicherheitsverordnung (Ordinance on Industrial Safety and Health) or other national legal regulations.
2.3 Responsibility for safety
Manufacturer and operator must ensure that the machine and implemented safety sensor function properly
and that all affected persons are adequately informed and trained.
The type and content of all imparted information must not lead to unsafe actions by users.
The manufacturer of the machine is responsible for:
• Safe machine construction and information on any residual risks
• Safe implementation of the safety sensor, verified by the initial test performed by a competent person
• Imparting all relevant information to the operating company
• Adhering to all regulations and directives for the safe commissioning of the machine
The operator of the machine is responsible for:
• Instructing the operator
• Maintaining the safe operation of the machine
• Adhering to all regulations and directives for labor protection and safety at work
• Regular testing by competent persons
2.4 Disclaimer
LeuzeelectronicGmbH+Co.KG is not liable in the following cases:
• The safety sensor is not used as intended.
• Safety notices are not adhered to.
• Reasonably foreseeable misuse is not taken into account.
• Mounting and electrical connection are not properly performed.
• Proper function is not tested (see chapter 8 "Testing").
• Changes (e.g., constructional) are made to the safety sensor.

Device description
Leuze electronic GmbH + Co. KG ELC 100 10
3 Device description
The safety sensors from the ELC100 series are active optoelectronic protective devices. They satisfy the
following standards:
ELC100
Type in accordance with IEC/ENIEC61496 4
Category in acc. with ISO/ENISO13849-1:2015 4
Performance Level (PL) in accordance with ISO/ENISO13849-1:2015 e
Safety Integrity Level (SIL) in accordance with IEC/EN61508 or SILCL in accordance
with IEC/EN62061
3
The safety sensor consists of a transmitter and a receiver. It is protected against overvoltage and overcur-
rent acc. to IEC/EN60204-1 (protection class3). The safety sensor is not dangerously influenced by typical
ambient light.
3.1 Structure and function
The ELC100 safety light curtain is a piece of electro-sensitive protective equipment (ESPE) that consists of
a transmitter and a receiver.
A series of parallel infrared light beams creates a protective field between transmitter and receiver that
safeguards the danger zone (point of operation, access point and danger zone safeguarding). As soon as
one or more beams are completely interrupted, the safety light curtain reports the interruption of the light
path by means of a signal change at the safe switching outputs (OSSDs). The machine or its control must
safely evaluate the signals (e.g. with a safe control or a safety relay) and end the dangerous state.
Transmitter and receiver automatically synchronize themselves using optical means. An electrical connec-
tion between the two components is not necessary.
Protective field properties
The beam distance and the number of beams are dependent on the resolution and protective field height.

Device description
Leuze electronic GmbH + Co. KG ELC 100 11
Fig.3.1: ELC transmitter/receiver
Absence of dead zones
Due to the design and construction of the safety light curtain, the protective function of a device is free of
dead zones up to the end of the housing.
The absence of dead zones reduces space requirements when integrating in the machine.
3.2 Connection technology
The transmitter and receiver feature an M12 connector as an interface to the machine control with the fol-
lowing number of pins:
Device model Device type Device plug
ELC100 Transmitter 4-pin
ELC110 Receiver 4-pin

Device description
Leuze electronic GmbH + Co. KG ELC 100 12
3.3 Display elements
The display elements of the safety sensors simplify start-up and fault analysis.
3.3.1 Operating indicators on the ELC100 transmitter
12
1 LED pair1, red
2 LED pair 2, green
Fig.3.2: Indicators on the ELC100 transmitter
Tab.3.1: Meaning of the LEDs on the transmitter
LED Color State Description
1 Red Flashing Error
Flash sequence 2x ON/OFF (250ms),
followed by a pause (750ms)
Connection error
Rapid flashing (10Hz) Device error
2 Green OFF Device switched off
ON Transmitter switched on
3.3.2 Operating indicators on the ELC110 receiver
123456
1 LED pair1, red, open OSSD icon
2 LED pair 2, green, closed OSSD icon
3 LED3, blue
4 LED4, blue
5 LED5, blue
6 LED6, blue
Fig.3.3: Indicators on the ELC110 receiver

Device description
Leuze electronic GmbH + Co. KG ELC 100 13
Tab.3.2: Meaning of the LEDs on the receiver
LED Color State Description
1 Red ON OSSD off
Slow flashing (approx. 0.5Hz) External error
Rapid flashing (approx.10Hz) Internal error
Flash sequence 2x ON/OFF (250ms),
followed by a pause (750ms)
Connection error
2 Green ON OSSD on
3 Blue Flashes Light reception strength 1
ON Light reception strength 2
4 Blue Flashes Light reception strength 3
ON Light reception strength 4, OSSD
switches on
5 Blue Flashes Light reception strength 5
ON Light reception strength 6
6 Blue Flashes Light reception strength 7
ON Light reception strength 8, optimum
alignment
Flashes brightly Fault in light reception

Applications
Leuze electronic GmbH + Co. KG ELC 100 14
4 Applications
The safety sensor only creates square protective fields.
4.1 Point of operation guarding
Point of operation guarding for hand and finger protection is typically the most common application for this
safety sensor. The necessary safety distance, among other things, follows from the various resolutions
(see chapter 5.1.1 "Calculation of safety distanceS").
Fig.4.1: Point of operation guarding

Mounting
Leuze electronic GmbH + Co. KG ELC 100 15
5 Mounting
WARNING
Improper mounting may result in serious injury!
The protective function of the safety sensor is only ensured if appropriately and professionally
mounted for the respective, intended area of application.
ÄOnly allow the safety sensor to be installed by qualified persons (Necessary competencies).
ÄMaintain the necessary safety distances (see chapter 5.1.1 "Calculation of safety dis-
tanceS").
ÄMake sure that stepping behind, crawling under or stepping over the protective device is reli-
ably ruled out and reaching under, over or around is taken into account in the safety dis-
tance, if applicable with additional distanceCRO corresponding to ISO/ENISO13855.
ÄTake measures to prevent that the safety sensor can be used to gain access to the danger
zone, e.g. by stepping or climbing into it.
ÄObserve the relevant standards, regulations and these instructions.
ÄClean the transmitter and receiver at regular intervals: environmental conditions (see chap-
ter 12 "Technical data"), care (see chapter 9 "Care, maintenance and disposal").
ÄAfter mounting, check the safety sensor for proper function.
5.1 Arrangement of transmitter and receiver
Optical protective devices can only perform their protective function if they are mounted with adequate
safety distance. When mounting, all delay times must be taken into account, such as the response times of
the safety sensor and control elements as well as the stopping time of the machine, among others.
The following standard specifies calculation formulas:
• ISO/ENISO13855, "Safety of machines - The positioning of protective equipment in respect of ap-
proach speeds of parts of the human body": mounting situation and safety distances
NOTICE
In accordance with ISO/ENISO13855, with a vertical protective field, it is possible to pass un-
der beams over 300mm or pass over beams under 900mm. If the protective field is horizontal,
climbing on the safety sensor must be prevented through suitable installation or with covers and
the like.
5.1.1 Calculation of safety distanceS
General formula for calculating the safety distanceS of an Optoelectronic Protective Device acc. to ISO/
ENISO13855
S [mm] = Safety distance
K [mm/s] = Approach speed
T [s] = Total time of the delay, sum from (ta+ti+tm)
ta[s] = Response time of the protective device
ti[s] = Response time of the safety relay
tm[s] = Stopping time of the machine
C [mm] = Additional distance to the safety distance
NOTICE
If longer stopping times are determined during regular inspections, an appropriate additional
time must be added to tm.

Mounting
Leuze electronic GmbH + Co. KG ELC 100 16
5.1.2 Calculation of safety distance if protective fields act orthogonally to the approach direction
With vertical protective fields, ISO/ENISO13855 differentiates between
• SRT: safety distance concerning access through the protective field
• SRO: safety distance concerning access over the protective field
The two values are distinguished by the way additional distanceC is determined:
• CRT: from a calculation formula or as a constant (see chapter 5.1.1 "Calculation of safety distanceS")
• CRO: from the following table "Reaching over the vertical protective field of electro-sensitive protective
equipment (excerpt from ISO/ENISO13855)"
The larger of the two values SRT and SRO is to be used.
Calculation of safety distanceSRT acc. to ISO/ENISO13855 when access occurs through the
protective field:
Calculation of safety distanceSRT for point of operation guarding
SRT [mm] = Safety distance
K [mm/s] = Approach speed for point of operation guarding with approach reaction and normal approach di-
rection to the protective field (resolution 14to40mm): 2000mm/s or 1600mm/s, when
SRT>500mm
T [s] = Total time of the delay, sum from (ta+ti+tm)
ta[s] = Response time of the protective device
ti[s] = Response time of the safety relay
tm[s] = Stopping time of the machine
CRT [mm] = Additional distance for point of operation guarding with approach reaction with resolutions of
14to40mm, d=resolution of protective device CRT=8×(d-14)mm
Calculation example
The feeding-in area in a press with a stopping time (including press Safety PLC) of 190ms is to be safe-
guarded with a safety light curtain with 17mm of resolution and 1200mm of protective field height. The
safety light curtain has a response time of 17ms.
ÄCalculate safety distanceSRT using the formula acc. to ISO/ENISO13855.
K [mm/s] = 2000
T [s] = (0.017+0.190)
CRT [mm] = 8×(17-14)
SRT [mm] = 2000mm/s×0.207s+24mm
SRT [mm] = 438
SRT is smaller than 500mm; this is why the calculation may not be repeated with 1600mm/s.
NOTICE
Implement the stepping behind protection required here, e.g. through the use of an additional
safety sensor.

Mounting
Leuze electronic GmbH + Co. KG ELC 100 17
Calculation of safety distanceSRo acc. to ISO/ENISO13855 when protective field is accessed from
above:
Calculation of safety distanceSRo for point of operation guarding
SRO [mm] = Safety distance
K [mm/s] = Approach speed for point of operation guarding with approach reaction and normal approach di-
rection to the protective field (resolution 14to40mm): 2000mm/s or 1600mm/s, when
SRO>500mm
T [s] = Total time of the delay, sum from (ta+ti+tm)
ta[s] = Response time of the protective device
ti[s] = Response time of the safety relay
tm[s] = Stopping time of the machine
CRO [mm] = Additional distance in which a body part can move towards the protective device before the pro-
tective device triggers: value (see the following table “Reaching over the vertical protective field
of electro-sensitive protective equipment (excerpt from ISO/ENISO13855)”).
a
3
CRO
KxT
b
12
SRO
1 Safety sensor
2 Danger zone
3 Floor
a Height of the point of operation
b Height of the upper beam of the safety sensor
Fig.5.1: Additional distance to the safety distance in the case of reaching over

Mounting
Leuze electronic GmbH + Co. KG ELC 100 18
Tab.5.1: Reaching over the vertical protective field of electro-sensitive protective equipment(excerpt from ISO/
ENISO13855)
Heighta
of the
point of
opera-
tion
[mm]
Heightb of the upper edge of the protective field of the electro-sensitive protective
equipment
900 1000 1100 1200 1300 1400 1600 1800 2000 2200 2400 2600
Additional distanceCRO to the danger zone [mm]
2600000000000000
2500 400 400 350 300 300 300 300 300 250 150 100 0
2400 550 550 550 500 450 450 400 400 300 250 100 0
2200 800 750 750 700 650 650 600 550 400 250 0 0
2000 950 950 850 850 800 750 700 550 400 0 0 0
1800 1100 1100 950 950 850 800 750 550 0 0 0 0
1600 1150 1150 1100 1000 900 850 750 450 0 0 0 0
1400 1200 1200 1100 1000 900 850 650 0 0 0 0 0
1200 1200 1200 1100 1000 850 800 0 0 0 0 0 0
1000 1200 1150 1050 950 750 700 0 0 0 0 0 0
800 1150 1050 950 800 500 450 0 0 0 0 0 0
600 1050 950 750 550 0 0 0 0 0 0 0 0
400 900 700 0 0 0 0 0 0 0 0 0 0
200 600 0 0 0 0 0 0 0 0 0 0 0
0 000000000000
Depending on the specified values you can work with the above-mentioned table in three ways:
1. Given are:
• Heighta of the point of operation
• DistanceS of the point of operation from the safety sensor, and additional distanceCRO
To be determined is the required heightb of the upper beam of the safety sensor and thereby its protective
field height.
ÄLook for the line with the specification of the point of operation height in the left column.
ÄIn this line, look for the column with the next highest specification for additional distance CRO.
ðThe required height of the upper beam of the safety sensor is up top in the column head.
2. Given are:
• Heighta of the point of operation
• Heightb of the upper beam of the safety sensor
To be determined is the required distance S of the safety sensor to the point of operation and thereby addi-
tional distance CRO.
ÄIn the column head, look for the column with the next lowest entry for the height of the upper beam of
the safety sensor.
ÄLook for the line with the next highest specification of the point of operation heighta in this column.
ðIn the intersection point of the line and the column, you will find additional distanceCRO.
3. Given are:
• DistanceS of the point of operation from the safety sensor, and additional distanceCRO.
• Heightb of the upper beam of the safety sensor

Mounting
Leuze electronic GmbH + Co. KG ELC 100 19
To be determined is the permitted heighta of the point of operation.
ÄIn the column head, look for the column with the next lowest entry for the height of the upper beam of
the safety sensor.
ÄLook for the next lowest value for real additional distance CRO in this column.
ðIn this line, go to the left column: here you will find the permitted height of the point of operation.
ÄNow calculate safety distanceS using the general formula acc. to ISO/ENISO13855 (see chapter
5.1.1 "Calculation of safety distanceS").
ðThe larger of the two values SRT and SRO is to be used.
Calculation example
The feeding-in area in a press with a stopping time of 130ms is to be safeguarded with a safety light cur-
tain with 17mm of resolution and 600mm of protective field height. The response time of the safety light
curtain is 9.5ms; the press Safety PLC has a response time of 40ms.
The safety sensor can be reached over. The upper edge of the protective field is located at a height of
1400mm; the point of operation is located at a height of 1000mm
Additional distanceCRO to the point of operation is 700mm (see table “Reaching over the vertical protective
field of electro-sensitive protective equipment (excerpt from ISO/ENISO13855)”).
ÄCalculate safety distanceSRO using the formula acc. to ISO/ENISO13855.
K [mm/s] = 2000
T [s] = (0.0095+0.040+0.130)
CRO [mm] = 700
SRO [mm] = 2000mm/s×0.17915s+700mm
SRO [mm] = 1058
SRO is larger than 500mm; this is why the calculation may be repeated with approach speed 1600mm/s:
K [mm/s] = 1600
T [s] = (0.0095+0.040+0.130)
CRO [mm] = 700
SRO [mm] = 1600mm/s×0.17915s+700mm
SRO [mm] = 987
NOTICE
Depending on the machine construction, stepping behind protection, e.g. using a second hori-
zontally arranged safety light curtain, is necessary.

Mounting
Leuze electronic GmbH + Co. KG ELC 100 20
5.1.3 Minimum distance to reflective surfaces
WARNING
Failure to maintain minimum distances to reflective surfaces may result in serious injury!
Reflective surfaces can indirectly deflect the transmitter beams to the receiver. In this case, in-
terruption of the protective field is not detected.
ÄDetermine the minimum distancea (see figure below).
ÄMake certain that all reflective surfaces are the necessary minimum distance away from the
protective field according to IEC/ENIEC61496-2 (see the following diagram “Minimum dis-
tance to reflective surfaces as a function of the protective field width”).
ÄCheck that reflective surfaces do not impair the detection capability of the safety sensor be-
fore start-up and at appropriate intervals.
ÄAfter mounting, check the detection capability of the safety sensor in the entire protective
field using a test rod (see chapter 8.3.1 "Checklist – periodically by the operator").
a
b
c
a Required minimum distance to reflective surfaces [mm]
b Protective field width [m]
c Reflective surface
Fig.5.2: Minimum distance to reflective surfaces depending on protective field width
a
900 mm
200 mm
800 mm
300 mm
400 mm
600 mm
500 mm
700 mm
3 m 5 m 10 m b
131 mm
15 m 20 m 25 m
1100 mm
1000 mm
a Required minimum distance to reflective surfaces [mm]
b Protective field width [m]
Fig.5.3: Minimum distance to reflective surfaces as a function of the protective field width
Tab.5.2: Formula for calculating the minimum distance to reflective surfaces
Distance(b) transmitter-receiver Calculation of the minimum distance(a) to reflective sur-
faces
b≤3m a[mm]=131
b>3m a[mm]=tan(2.5°)×1000×b[m]=43.66×b[m]
