EMERGENCY LIGHTS Architectural
COOPER LIGHTING (1) Consult your Cooper Lighting Representative. (2) Provision for one meter only.
COOPER LIGHTING - SURE-LITES®
DIMENSIONS
• Dual-voltage input
120/277VAC, 60Hz
• 20 gauge die-formed steel
housing with white powder
coat finish
• Heads match housing
finish
• Knockout, conduit or cord
set
• Supplied with hanger bars,
T-Bar clips
• Single modular electrical
connector
• Remote capability
• Line-latching, Solid-State
voltage limited charger,
Solid-State switching,
low- voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator
light
• UL 924 Listed, Life Safety
NFPA 101, NEC/OSHA,
most state and local codes
DESCRIPTION
The RD Series is a recessed
emergency lighting system
designed for locations where
aesthetics are of utmost
importance. The housing is
fully recessed in dry wall or
grid ceiling installations.
Designer pinchback heads
rotate 358° and swivel 90° to
0°. Ideal for commercial and
institutional environments
where easy recessed
installation and minimal
maintenance are desired.
The RLM Series is a recessed
system packaged in an
attractive flame-resistant
metal housing. It is the unit
of choice for installations
where a recessed product is
desired and the size and cost
of emergency lighting must
be kept to a minimum
without sacrificing
dependability or light output.
RD SERIES
Two Injection Molded
Thermoplastic Heads
RD1 SLC 6 18 15 10 8 Tungsten Halogen 6 29-12
RD3 SLC 6 27 24 18 14 Tungsten Halogen 12 29-66
RD4 SLC 12 54 - - - Incandescent 9 029-86
RD6 SNC 6 15 12 8 6 Tungsten Halogen 6 29-12
RD7 SNC 6 24 18 12 10 Tungsten Halogen 12 29-66
RLM1 SLC 6 10.8 7.2 - - Incandescent 5.4 29-121
RLM2 SLC 6 18 15 10 8 Incandescent 9 29-84
RLM3 SLC 6 27 24 18 14 Incandescent 9 29-84
RLM4 SLC 12 54 - - - Incandescent 9 029-86
RLM8 SNC 6 15 12 8 - Incandescent 7.2 29-88
RLM9 SNC 6 24 18 12 10 Incandescent 7.2 29-88
ORDERING INFORMATION
SAMPLE NUMBER: RD1V
5 1/8"
(130mm)
10 1/4" (260mm)
12 7/8" (327mm)
3 1/2"
(89mm)
7" max.
(178mm)
6"
(152mm)
(RD4 Only)
8 1/4"
(210mm)
9 1/4" (235mm)
6 1/4" (159mm)
4 5/8"
(118mm)
Options
(Add as suffix)
A=Ammeter(2)
SD=Self-Diagnostics
TDM=Time Delay Monitor
V=Voltmeter(2)
Alternate Lamps(1)
Other Options(1)
Model Number
RD1
RD3
RD4
RD6
RD7
RLM1
RLM2
RLM3
RLM4
RLM8
RLM9
Accessories
(Order separately)
WG2 =Wire Guard
WG7 =Wire Guard
VS=Choose polycarbonate
vandal shield desired
from accessories
sheet
Energy Data
Input Current (Max.):
Model No. 120V 277V
RD1, RD3 .12A .05A
RD4, RLM4 .30A .13A
RD6 .06A .03A
RD7 .07A .04A
RLM1, RLM2, RLM3 .12A .05A
RLM8 .06A .03A
RLM9 .07A .04A
ELECTRICAL RATINGS
Rated Wattage to 87 1/2% of rated D.C. Voltage Lamp Information
Model Battery DC Voltage 1 1/2 hours 2 hours 3 hours 4 hours Type Wattage Number
SLC=Sealed Lead Calcium Battery
SNC=Sealed Nickel Cadmium Battery
RLM SERIES
Two High-Impact
Thermoplastic Heads
Recessed Housing
EMERGENCY LIGHT
9 1/4" (235mm)
6 1/4"
(159mm)
12 7/8" (327mm)
10 1/4" (260mm)
9 1/4"
(235mm)
3 1/2"
(89mm)
5 1/8"
(130mm)
8 1/4"
(210mm)
6"
(152mm)
(RLM4 Only)
4 5/8"
(118mm)
