Level IPS-0008 User manual

IPS-0008
IP Power Switch
User Manual
Ver 1.0.1-0710
1

Preface
About this manual
Congratulations on purchasing the IPS-0008. This user manual provides
detailed descriptions of the hardware components and how to use it.
Read this manual carefully and follow the instructions while using the
IPS-0008.
Copyright information
No part of this manual, including the products and software described in
it, may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes,
without the express written permission of the manufacturer.
Products and corporate names appearing in this manual may or may not
be registered trademarks or copyrights of their respective companies,
and are used only for identification or explanation and to the owners’
benefit, with- out intent to infringe. All trademarks are the property of
their respective owners.
Copyright © 2007All rights reserved.
2

Safety instructions
Follow these safety instructions to avoid injury to self and damage to the
IPS-0008.
To reduce the risk of fire or electric shock, install the unit in a
temperature-controlled indoor area free of conductive
contaminants. Do not place the unit near liquids or in an
excessively humid environment.
Do not allow liquids or foreign objects to enter the unit.
The unit does not contain any user-serviceable parts. Do not open
the unit.
Servicing, maintenance, and repair for this equipment must be per-
formed by qualified service personnel. Remove rings, watches and
other jewelry before servicing the unit.
Before maintenance, repair or shipment, the unit must be
completely switched off and unplugged and all connections must
be removed.
Before plugging in the power cord of the device, make sure that the
power source rating matches the power rating of the IPS-0008.
Use a standard power cord when you connect any device to the
outlets of IPS-0008.
This unit has been provided with a real time clock circuit. There is a
danger of explosion if the battery is incorrectly replaced. Replace
only with a 3V Lithium cell (CR2032) or equivalent type. Discard
used batteries according to the manufacturer’s instructions.
3

Table Content
1. INTRODUCTION.......................................................................................................1
1.1. FEATURES........................................................................................................2
1.2. PACKAGE CONTENTS ........................................................................................3
1.3. HARDWARE COMPONENTS................................................................................4
1.3.1. Front Panel ...............................................................................................4
1.3.2. Status Indicator.........................................................................................6
1.3.3. Using the control buttons..........................................................................8
1.4. REAR PANEL ....................................................................................................9
2. GETTING STARTED ..............................................................................................11
2.1. ATTACHING THE FEET......................................................................................11
2.2. ATTACHING THE EARS.....................................................................................11
2.3. MAKING CONNECTIONS ..................................................................................12
2.4. CONNECTING INPUT POWER ...........................................................................14
2.5. CONNECTING OUTPUT DEVICES......................................................................15
2.6. CONNECTING DIGITAL OUTPUTS.......................................................................15
2.7. CONNECTING EMD ........................................................................................16
2.8. CONNECTING THE CONSOLE...........................................................................17
2.9. CONNECTING TO A WAN.................................................................................18
3. USING THE CONSOLE MENU ..............................................................................19
3.1. USING HYPERTERMINAL .................................................................................19
3.2. NAVIGATING THROUGH THE CONSOLE MENU...................................................22
3.3. SETTING THE IPADDRESS..............................................................................24
4. USING THE WEB INTERFACE..............................................................................25
4.1. OVERVIEW .....................................................................................................25
4.2. MODIFYING THE BASIC SETTINGS ...................................................................27
4.2.1. Setting The Date and Time.....................................................................27
4.2.2. Adding Users ..........................................................................................28
4.2.3. Changing Event Alert Settings................................................................29
4.3. MODIFYING APPLICATION SETTINGS................................................................31
4.3.1. Setting Control Options...........................................................................31
4.3.2. Setting Up a Schedule............................................................................32
4.3.3. Status......................................................................................................33
4.3.4. Configuration...........................................................................................33
4.4. POWER CYCLE...............................................................................................35
APPENDIX.........................................................................................................................36
SPECIFICATIONS.............................................................................................................36
ERROR CODES ...............................................................................................................37
REGULATORY INFORMATION ............................................................................................38
4

1. Introduction
Congratulations on purchasing the IPS-0008, an intelligent power
management system. The IPS-0008 provides the useful ability of
managing power for any combination of network equipment connected
to it. You can control the power on/off for any device connected to the
IPS-0008, manually or remotely, using a console or Ethernet connection.
The IPS-0008 comes with eight power outlets, each of which can be
monitored and controlled through the console or web interfaces. You can
also use the front panel to operate the power outlets. The IPS-0008 is
also equipped with a console port for connecting an EMD
(Environmental Monitored Device, optional) for sensing temperature and
humidity along with two alarms that can be activated when either of the
sensors shows unusual values. The IPS-0008 is provided with two digital
outputs which you can use for connecting status indicators or digital
switches.
The device is designed to remember the configuration of each outlet and
inlet and is also able to measure the input and output current
consumption.
1

1.1. Features
Eight power outlets that can be turned on or off in multiple ways,
with easy monitoring of current consumption
Active extended devices via digital outputs
Monitor and manage connected devices and sensors remotely
Control the IPS-0008 manually, or remotely through console or
network
Intelligent turn on/off devices based on event occurrence or
planned schedule
Comprehensive power management and flexible configuration
through web browser, NMS, Telnet, SNMP, or HyperTerminal
(console)
Configurable user security control
User-friendly interface to display input and output status
Detailed data-logging for statistical analysis and diagnostics
Upgrade utility for easy firmware upgrade
Event notification through SNMP trap or Email alerts
Daily history report through Email
Supports SSL V3 and SSH V1 protocol
Administrator and multiple users with password protection for
double-layer security
Address-specific IP security masks to prevent unauthorized access
Available in 110V and 220V models
Optional versatile sensors supported through EMD (Environmental
Monitoring Device) inputs
2

1.2. Package contents
Make sure that your package has the following items. If any of items is
missing or damaged, contact your nearest service center or vendor.
1. IPS-0008 IP Power Switch
2. Rack-mount Brackets
3. U-type Handle
4. U-type Handle Screws
5. Bracket Screws
6. Feet Screws
7. CD Manual
8. Rubber Feet
9. Quick Installation Guide
10. Power Cord
11. Console Cable
3

1.3. Hardware Components
Take a moment to familiarize you with the IPS-0008 front and rear panels.
The following sections provide descriptions about the front and rear
panel components and how to use them.
1.3.1. Front Panel
Component Description
1 Output power status
indicator (A ~ H) Displays output current, power status, and remote control status for
each power outletA through H.
2 Input power
consumption indicator Displays percentage of input power consumed.
3 Status indicator Displays input current, voltage,
frequency, and error code.
4 Remote control button Enables you to manually control
power and enable remote control
configuration for each power outlet
A through H.
4

Component Description
5 Reset button Enables you to reset the IPS-0008
in case the system locks up.
6 Operation mode DIP
switch Sets the mode of operation for the IPS-0008. S1 off, S2 off: Normal
operation (default mode)
7 Serial (CONSOLE) port Enables you to configure the
IPS-0008 using the serial port. You
can also connect an optional EMD
to this port.
8 Ethernet (LAN) port Enables you to configure the
IPS-0008 through a LAN or WAN.
5

1.3.2. Status Indicator
The front panel of the IPS-0008 has several LED indicators that provide
information about the input and output power status. The following table
describes these status indicators.
Status Indicator Description
Output power status indicator (A~
H)
Displays status of each power
outlet (A ~ H)
as follows:
1. Current level indicator:
Displays the amount of current
being drawn by the connected
output device through the
power outlet.
2. Outlet power indicator:
Displays the out- let power
status.
– Grey: power off
– Green: power on
3. Remote control indicator:
Displays the remote control
status of each outlet.
– Grey: remote control is
enabled.
– Red: remote control is
disabled.
4. Control button:
Allows manual control of each
power outlet. Press repeatedly
to switch between remote
control and power on/off
mode. See “Using the control
but- tons” on page 7
6

Status Indicator Description
Input power consumption
indicator
Displays input power consumed
by the output devices connected
to the IPS-0008 outlets. The
power consumption is displayed
as a percentage value.
Input power status indicator
Displays input voltage (Volts),
input current (Ampere), and
frequency (Hz), sequentially on
the 7-segment switching display.
This indicator also shows system
errors in the form of an error code
such E01, E02, E03, and so on.
Refer to “Error codes” on page 27
under the appendix for a list of all
error codes.
7

1.3.3. Using the control buttons
You can turn on power manually for each of the eight output devices with
the control buttons provided under each status indicatorA through H.
Each button allows you to set the remote control function as well as turn
power on/off for each outlet manually.
The control button has two modes of operation. Press the button
repeatedly to switch between Remote Control mode and Power On/Off
mode. When you press the control button, the IPS-0008 switches modes
as follows:
After switching modes, you need to press the control button again within
5 seconds to change the mode status.
Remote control mode
1. Press the control button once. The remote control indicator starts
flashing red.
2. Now press control button again within 5 seconds and hold for more
than 5 seconds. The remote control indicator starts flashing red at
a faster speed and then inverts its original state.
For instance, if remote control indicator is enabled (grey) before you
press the control button, it turns on (red) after step 2, indicating that
remote control is disabled.
8

Power on/off mode
1. Press the control button twice. The outlet power indicator starts
flashing green.
2. Now press control button again within 5 seconds and hold for more
than 5 seconds. The outlet power indicator starts flashing green at
a faster speed and then inverts its original state.
For instance, if outlet power indicator is off (grey) before you press the
control button, it turns on (green) after step 2, indicating that outlet power
is turned on.
1.4. Rear Panel
220AC Model
110AC Model
9

Rear Panel Component
Component Description
1 Input power Connect to a power outlet.
2 Breaker Prevents excessive current flow to protect
the system.
3 Power outlet (A ~ H) Connect a device to each power outlet to
sup- ply power to it.
4 Dry contact port Connect dry contact UPS that can be
remotely managed through network card.
This is currently not supported by the
IPS-0008.
5 Digital output Connect up to digital outputs that are
normally open or normally closed.
10

2. Getting Started
This section provides information about setting up the IPS-0008,
connecting power, and connecting devices to it before you start using it
for power management. Read this section carefully to learn how to
connect various devices to it.
2.1. Attaching the feet
The IPS-0008 comes with four
feet or spacers that are attached
to the bottom. Use the four
screws provided with the feet to
attach the feet to the bottom of
the IPS-0008 as shown:
Note: You do not need to attach the feet if you are going to install the
IPS-0008 in a rack.
2.2. Attaching the ears
The IPS-0008 is designed to be
placed in a rack arrangement
and comes with two ears that
help you to move the device
easily. Attach each ear with the
three screws provided in your
package as shown:
11

2.3. Making Connections
The IPS-0008 is a versatile product that can be connected to several
different types of input and output devices. This makes it a useful tool for
connecting devices to it and controlling their power on/off status through
its user interface.
The IPS-0008 can be attached to eight output devices whose power
status can be controlled remotely and manually. It also supports an EMD
(Environmental Monitored Device) or sensors for detecting
environmental conditions as well as digital outputs or devices with
normally open or normally closed conditions. Moreover, the IPS-0008
supports a serial (con- sole) and Ethernet (LAN/WAN) connection that
lets you control the IPS-0008 outputs remotely.
Note: The EMD is optional
12

The following procedure describes the basic steps needed to set up the
IPS-0008:
1. To set up the hardware, connect power to the power inlet and
output devices to the power outlets. Connect digital outputs to the
digital I/O ports, and an EMD to the console port.
2. To configure the IPS-0008, you can use the console or WAN port.
Connect the IPS-0008 to a console and a WAN to enable its
configuration through the console or browser menu.
3. After connecting to a console, use a console application such as
Tel- net or HyperTerminal to access the console menu. Select the
System Group submenu under the IPS-0008 Configuration to set
up the IP address and the system date/time. This IP address will be
used while accessing the web interface to configure the IPS-0008
parameters.
4. After connecting to WAN, open a browser from a PC in the network
and use the IPS-0008 IP address specified through the console
menu to open the web interface for system configuration.
The following sections provide instructions about how to make various
connections.
13

2.4. Connecting Input Power
The IPS-0008 has an IEC C20 power inlet for supplying and managing
power for the output devices. Connect the power cord to the power inlet
and plug the other end into a power outlet as shown:
14

2.5. Connecting Output Devices
The IPS-0008 has eight power outlets for connecting devices such as
workstations, servers, and printers. Their power on/off status can be
con- trolled manually as well as remotely through the LAN and Console
ports. Connect the power connectors of the devices to each of the power
outletsA through H with the power cords supplied with the devices as
shown:
2.6. Connecting digital outputs
The IPS-0008 provides two digital outputs to which you can connect
switches, indicators, or other output devices that are normally open or
normally closed. You can control the digital outputs remotely through the
con- sole or over the LAN.
15

2.7. Connecting EMD
An environmental monitored device that is connected to sensors for
detecting temperature, humidity, water level, and so on can be
connected to the IPS-0008 with the console port. The EMD can also be
connected to alarms or indicators and controlled through the IPS-0008.
Connect the EMD to the console port as shown:
Note: The EMD is optional
16
