LevelOne CAS-3030 User manual

CAS-3030 IR Illuminator
User’s Manual
CAUTION
Before installation, please read the user manual carefully and please keep this manual for
future checking.
Please check the package contents if there is any missing or damaged. Please do not
install or operate the product and then contact the dealer for assistance immediately.
To prevent electric shock or other hazards, please do not try to remove screws or covers.
Use the bundled power adapter and make sure everything is correct before turning on
the power.
The brightness of the IR light will be influenced by the environment, geography and
reflection object. (The object such as people, trees, lawn or wall is good for IR light
reflection. The object such as glass, painting , lake, river or ocean will weaken the
brightness of IR)
GENERAL
Thank you for choosing LeveOne IR illuminator. All products are certified by CE, LVD, FCC
and RoHS inspection and have passed quality control before shipping. The IR illuminator with
the new generation Metal-board and new AlGaInP High-Light LED provides excellent
performance in the dark. It is the premier product of surveillance technology and an ideal
solution to your tough surveillance requirement.
CHECK YOUR PACKAGE CONTENTS
The carton should contain the following items:
CAS-3030
Power Adapter
Bracket
If any item is found missing or damaged, please contact your local reseller for replacement.

FEATURE
AlGaInP LED(Piranha) provides excellent performance in the dark
Long life of LED up to 20,000 hours
Special metal board enhances lighting and dissipates heat
Photo sensor delay control to avoid IR turning on/off repeatedly
IP-66 rated weatherproof protection of the housing for indoor and outdoor use.
CONSTRUCTION
95mm
SPECIFICATIONS
IR Distance 30M (Based on object of view reflected IR light)
IR LED 12 pcs
IR View Angle 80°, beam spread:20~30°° per LED
IR Wavelength 850nm
IR Status Under 10 Lux by photo sensor auto control
LED Life More than 20,000 hours
Protection Class IP-66 rated
Power Supply 12VDC/1.5A
Power Consumption IR on: 400mA
Construction Aluminum with sunshield weatherproof
Temperature Operation: -20°~90°C, Storage:-30°~90°C
Dimension 95(Φ)x150(L) mm
Weight 0.65 kg
