LevelOne WBR-6803 User manual

2
150Mbps Wireless 3G
Travel Router WBR-6803
The LevelOne WBR-6803 is a true portable solution
to share your 3G Internet connection wherever you
are. Simply attach your 3G modem into the WBR-6803
USB port and it will share the Internet connection
via Wireless LAN. It supports 3G data cards covering
WCDMA (HSPA), CDMA2000, TD-SCDMA, and it
supports mobile phone tethering too.
The WBR-6803 is compatible to 802.11n wireless
standard with data rates of up to 150Mbps by using
N wireless technology. It is downwards compatible to
802.11b/g devices. The compact design enables a full
portability, and the WBR-6803 can be powered with
a high capacity 1700mAh Li-ion battery, no external
power supply is required.
Key Features
- Share your 3G Internet connection
- IEEE 802.11n provides wireless transfer rates up to
150Mbps
- Supports WEP, WPA-PSK, WPA2-PSK Wireless Security
and QoS
- Quick and Easy Installation Wizard
- Built-in NAT function allows several PCs to share one
Internet connection
- USB port for external USB modem card, such as
HSPA+, HSxPA, EVDO, TDSCDMA
- Built-in 1700mAh Li-Ion battery for long lasting
operation up to 240 minutes
WUA-0614
150Mbps Wireless USB Adapter
Works Well With
1. LED Indicators
2. USB Port
3. Rest Button
4. WPS Button
5. RJ-45 Port
6. Power Switch
7. Power Port
H/W Version: 1
WCS-0040
Wireless 1.3-Megapixel Network
Camera
2 3 4 5 6 711

www.level1.com
I
one world_one brand_one level_ Broadband Routers and Gateways 3
and 802.1x RADIUS
Antenna:
PIFA internal antenna
Software Features:
NAT, Port Forwarding, DMZ, QoS, DHCP Client, Syslog, UPnP,
Wake-On-LAN
Firewall:
Stateful Packet Inspection (SPI), URL Filter, MAC Filter, Host
Filter, IP Filter, Port Filter
Management:
SNMP, UPnP IGD, syslog , HTTP Web Interface, Firmware
Upgradable
Operating Environment:
Temperature 0 ~ 40˚C, Humidity 10 ~ 90% (non-condensing)
Battery
3.7V / 1700mAh Li-Ion battery compliant to NP120 form factor
(35.3 x 52.8 x 11mm)
Power:
5 VDC, 1A
Dimension:
107mm x 76mm x 21mm
WAN /LAN Interface and Standards
USB 2.0 for external 3G/3.75G modem
3G(WCDMA, HSPA, CDMA2000, EVDO)
iPhone/ MW phone Tethering Support
RJ-45 port, 10/100Mbps, WAN/LAN Congurable
Data Rate:
802.11n (40MHz) up to 150Mbps
802.11n (20MHz) up to 78 Mbps
802.11g 54, 48, 36, 24, 18, 12 und 6.9Mbps
802.11b 11, 5.5, 1.2Mbps
RF Specications:
802.11n TX power 14dBm @ 150 Mbps
802.11g TX power 14dBm @ 54 Mbps
802.11b TX power 17dBm @ 11 Mbps
802.11n RX sensitivity -68~87dBm @150 Mbps
802.11g RX sensitivity -72~-91dBm @54 Mbps
802.11b RX sensitivity -89~-91dBm @ 11 Mbps
Operating Frequency
2.4 ~ 2.483GHz
Standards:
IEEE 802.11n Draft 2.0, IEEE 802.11g, IEEE 802.11b
Wireless Security:
Hidden SSID Broadcast, 64/128-bit WEP Encryption, WPA, WPA2
Technical Specications
Product Diagram
Order Information WBR-6803: 150Mbps Wireless 3G Travel Router
Package Contents WBR-6803, RJ-45 Cable, Power Adapter, Quick Installation Guide, CD Manual/QIG/Utility, Li-Ion Battery
All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.
© Copyright Digital Data Communications GmbH. All Rights Reserved.
WBR-6803
V1.0
Internet
Wireless Network
Camera
ComputerCable/DSL Modem
Wireless USB Adapter
Wireless PCI Card
3G Moblie
Network
3G/3.5G
Modem
LAN ModeWAN Mode or
