Levoit Core 200S User manual

Dual 200S Smart Top-Fill Humidifier
Model: LUHD301SWEU
Questions or Concerns?
Please contact us at [email protected]
[email protected] | support.[email protected]
[email protected] | [email protected]
USER MANUAL
EN • DE • FR • ES • IT

2
EN • ENGLISH
Inhaltsverzeichnis
DE • DEUTSCH
Índice
ES • ESPAÑOL
FR • FRANÇAIS
Table des matières
Indice
IT • ITALIANO
Table of Contents
Package Contents
Specifications
Safety Information
Getting to Know Your Smart Humidifier
Controls & Display
Getting Started
VeSync App Setup
Using Your Smart Humidifier
Care & Maintenance
Troubleshooting
VeSync App Troubleshooting
Warranty Information
Customer Support
3
3
4
6
8
9
11
12
15
20
22
23
24
Lieferumfang
Technische Daten
Sicherheitshinweise
Ihr Smart-Luftbefeuchter
Bedienungstasten und Display
Erste Schritte
Einrichten der VeSync-App
Der Gebrauch Ihres Smart-Luftbefeuchters
Pflege und Wartung
Problemlösung
VeSync App Problembehebung bei Fehlern
Konformitätserklärung
Kundendienst
25
25
26
28
30
31
34
35
38
43
45
46
47
Contenu de l’emballage
Caractéristiques techniques
Consignes de sécurité
Prise en main de votre humidificateur
intelligent
Commandes et achage
Prise en main
Configuration de l’application VeSync
Utilisation de votre humidificateur intelligent
Nettoyage et maintenance
Dépannage
Dépannage de l’application VeSync
Informations relatives à la garantie
Service client
48
48
49
51
53
54
57
58
61
66
68
69
70
Contenido de la caja
Especificaciones
Información de seguridad
Componentes del humidificador inteligente
Controles y pantalla
Primeros pasos
Configuración de la aplicación VeSync
Uso de su humidificador inteligente
Cuidado y mantenimiento
Solución de problemas
Solución de problemas de la aplicación
VeSync
Información sobre la garantía
Atención al Cliente
71
71
72
74
76
77
80
81
84
89
91
92
93
Contenuto della confezione
Specifiche
Informazioni di sicurezza
Componenti dell’umidificatore smart
Comandi e display
Preparazione
Configurazione dell’app VeSync
Utilizzo dell’umidificatore smart
Cura e manutenzione
Risoluzione dei problemi
Risoluzione dei problemi dell’app VeSync
Informazioni sulla garanzia
Assistenza Clienti
94
94
95
97
99
100
102
103
106
111
113
114
115

Specifications
Package Contents
Note: To access additional smart humidifier functions, download the free VeSync app (see page 11).
ENGLISH
User Manual
Dual 200S Smart Top-Fill Humidifier
Model: LUH-D301S-WEU
1 ×Smart Top-Fill Humidifier
2 ×Water Filter Sponge (1 Pre-Installed)
1 ×Cleaning Brush
1 ×User Manual
1 ×Quick Start Guide
Power Supply 24V 1A
Rated Power 24W
Water Tank Capacity 3 L / 0.66 gal
Max Runtime
Up to 25 hours on low mist setting
Note: The humidifier may run for a longer or shorter time
depending on the environmental temperature and humidity.
Noise Level ≤ 28dB
Eective Range 1027 m / 107290 ft
Dimensions 18 × 18 × 30 cm / 7.1 × 7.1 × 11.8 in
Weight 1.4 kg / 3 lb
Power Adapter Input: 100240V~50/60Hz
Output: 24V 1A
Wi-Fi® Frequency Range 24122472MHz
E.I.R.P.: 18dBm
Bluetooth® Frequency Range 24022480MHz
E.I.R.P.: 8dBm
EN
3

SAFETY INFORMATION
• Only use the humidifier as described in this manual.
• Place the humidifier and cord so that it will
not be knocked over. Do not place near large
pieces of furniture or in high-trac areas.
• When not in use, turn the humidifier o and
disconnect from power by removing the plug
from the outlet.
• Do not use the humidifier in wet environments.
• Keep the humidifier out of reach from children.
• Do not open the base or remove the water
level sensor for self-servicing.
• Always unplug your humidifier from the power
outlet before cleaning your humidifier or
detaching the water tank from the humidifier base.
• Always make sure to place the humidifier on a
flat, level surface before operation.
• Only fill the water tank with clean water. Never
fill the water tank with any other liquids.
• Do not place the humidifier near sources of
heat, such as stovetops, ovens, or radiators.
• Do not place the humidifier directly on floors,
carpets, or rugs.
• Do not use other items as replacement parts
for this product.
• Do not cover the nozzle while the humidifier
is on. Doing so may damage the humidifier.
• Remove the water tank from the base before
moving the humidifier.
• Do not immerse the humidifier base, power
cord, or plug in water. If the humidifier is
damaged or is not functioning properly, stop
using it and contact Customer Support
immediately (see page 24).
• This humidifier can be used by children 8 years
and older as well as persons with reduced
physical, sensory, or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
To reduce the risk of fire, electric shock, or other injury, follow all instructions and safety guidelines.
General Safety
of the humidifier in a safe way and understand
the hazards involved.
• Supervise children when they are near the
humidifier.
• Children should not clean or perform
maintenance on the humidifier without
supervision.
• Children should be supervised to ensure that
they do not play with the humidifier.
• Not for commercial use. Household use only.
READ AND SAVE THESE
INSTRUCTIONS
Power & Cord
• Do not handle the power cord or plug with
wet hands. Keep the plug and power cord
away from liquids.
• If the power supply cord is damaged, it
must be replaced by Arovast Corporation or
similarly qualified persons in order to avoid
an electric or fire hazard. Please contact
Customer Support (page 24).
• Unplugging the power cord will disable
remote control of the humidifier and
temporarily disconnect the humidifier
from VeSync and other third-party apps.
Do not add supplemental water
treatment liquids into the water tank
or base chamber. This will damage the
humidifier and cause leaks.
Caution: Risk of Leaks
and Electric Shock
EN
4

Maintenance Safety
SAFETY INFORMATION (CONT.)
• Be aware that high humidity levels may
encourage the growth of biological
organisms in the environment.
• Do not permit the area around the humidifier
to become damp or wet. If dampness occurs,
turn the output of the humidifier down. If the
humidifier output volume cannot be turned
down, use the humidifier intermittently.
Do not allow absorbent materials, such as
carpeting, curtains, drapes, or tablecloths, to
become damp.
• Unplug the humidifier during filling and cleaning.
• Never leave water in the reservoir when the
humidifier is not in use.
• Empty and clean the humidifier before storage.
Clean the humidifier before next use.
CLEAN THE WATER TANK
AND BASE CHAMBER
EVERY 3 DAYS OR LESS.
• Warning: Micro-organisms that may be
present in the water or in the environment
where the humidifier is used or stored, can
grow in the water reservoir and be blown in
the air causing very serious health risks when
the water is not renewed and the tank is not
cleaned properly every 3 days.
• Empty the tank and refill every third day.
Before refilling, clean it with fresh tap water
or cleaning agents (see Cleaning, page 15).
Remove any scale, deposits, or film that has
formed on the sides of the tank or on interior
surfaces, and wipe all surfaces dry. See
Cleaning (page 15) for in-depth instructions.
This symbol means the product must not be discarded as household waste, and
should be delivered to an appropriate collection facility for recycling. Proper disposal
and recycling helps protect natural resources, human health and the environment.
For more information on disposal and recycling of this product, contact your local
municipality, disposal service, or the shop where you bought this product.
This product is RoHS compliant. This product is in compliance with Directive 2011/65/EU, and its
amendments, on the restriction of the use of certain hazardous substances in electrical and electronic
equipment.
EN
5

GETTING TO KNOW YOUR SMART HUMIDIFIER
A. Nozzle
B. Water Tank Cover
C. Water Filter Housing
D. Water Filter
E. Mist Tube
F. Water Tank
G. Float
H. Base
I. Display
J. Cleaning Brush
K. Power Adapter
L. Max Water Line (Tank)
M. Water Outlet Valve
N. Noise Silencer
O. Air Outlet
P. Max Water Line (Base)
Q. Float Brackets
R. Transducer
S. Secondary Float
T. Humidity Sensor
U. Feet
V. Power Adapter Input
W. Air Inlet
A
B
M
G
K
W
T
U
S
R
J
D
N
L
F
E
C
H
I
O
P
Q
V
Water tank, upside down
EN
6

Getting To Know Your Smart Humidifier (cont.)
A B DC
G F
E
A. Mist Level Button
B. No Water Indicator
C. Wi-Fi® Indicator
D. Timer Indicator
Note: The timer must be
set in the VeSync app.
E. Power Button
F. Humidity Level Indicator
G. Mist Level Indicator
EN
7

CONTROLS & DISPLAY
Note: You can also control these functions using
the VeSync app, as well as additional functions
(see page 13).
Power Button
• Press to turn the humidifier
on/o.
• Press and hold for 5
seconds to pair with the
VeSync app. See the
VeSync in-app instructions
for more information.
• Press and hold for 15
seconds to reset the
humidifier. This will restore
the humidifier’s default
settings and disconnect
it from Wi-Fi® and the
VeSync app (see page 11).
Wi-Fi Indicator
• Turns on, o, or blinks to
indicate pairing status.
See the VeSync in-app
instructions for more
information.
No Water Indicator
• Blinks when there is no
water in the tank. After this
indicator blinks 10 times,
the humidifier will turn o.
Refill the tank and properly
place it on the base to use
your humidifier.
• Lights up when the
water tank is removed.
Remains on until the
tank is replaced.
Mist Level Button
• Press repeatedly to cycle
through mist level settings:
Low, High, and Auto Mode.
(For more details on Auto
Mode, see page 13.)
• Press and hold for
3 seconds to turn o
the humidifier display.
EN
8

GETTING STARTED
1. Remove all packaging.
2. Take the water tank o of the base and
remove all tape, including any tape on
the float. Figure 1.1
Figure 1.3
Figure 1.1
Figure 1.4
Figure 1.5
Figure 1.2
3. Rinse and reassemble all parts before
first use (see Cleaning, page 15).
Note:
• Check to make sure that the water filter
is correctly in place. If not, then rotate
the filter clockwise to secure it in place.
Figure 1.2
4. Choose a hard, flat location for the
humidifier at least 30 cm / 12 inches
away from any walls. The surface
must be water-resistant. Figure 1.4
5. Mist should be directed away
from walls, furniture, bedding, and
appliances. Figure 1.5
• Check to make sure that the float is
securely in place. Figure 1.3
30 cm /
12 in
30 cm /
12 in
EN
9

Filling & Refilling
1. Remove the water tank cover by
holding the nozzle and pulling upward.
Figure 1.6
Figure 1.6
Figure 1.7
2. Fill the tank with room-temperature water.
Figure 1.7 Do not fill with hot water.
Note:
• We recommend using purified or distilled
water to fill the tank.
• Do not fill past the tank’s max water line.
Figure 1.8
Figure 1.9
• Do not add water directly into
the base chamber. Figure 1.8
CAUTION
Note: Make sure the water tank is clean
before filling.
• Do not add water through the
mist tube. Figure 1.9
EN
10

Figure 1.10
Figure 1.11
Figure 1.12
Note: Due to ongoing updates and improvements,
the VeSync app may be slightly dierent than
shown in the manual. In case of any dierences,
follow the in-app instructions.
Note: Make sure the nozzle on the water
tank cover is placed over the mist tube,
or the humidifier may not work correctly.
Figure 1.10
Note: For best results, we recommend using
pure essential oil.
Note: For Android™ users, choose “Allow” to use VeSync.
Note: You must create your own VeSync account
to use third-party services and products. These
will not work with a guest account. With a VeSync
account, you can also allow your family and
friends to control your smart humidifier.
1. To download the VeSync app, scan
the QR code or search “VeSync” in the
Apple App Store® or Google Play Store.
Figure 1.12
VESYNC APP SETUP
2. Open the VeSync app. If you already
have an account, tap Log In. To create a
new account, tap Sign Up.
3. Follow the in-app instructions to set up
your smart humidifier.
Filling & Refilling (cont.)
3. Replace the water tank cover.
Wi-Fi Connection:
• To disconnect Wi-Fi, press and hold for
15 seconds until the Wi-Fi indicator turns o.
This will restore the smart humidifier’s default
settings and disconnect it from the VeSync app.
• To reconnect, please follow the instructions in
the VeSync app for adding a device.
4. Optionally, add 10–15 drops of
essential oil into the base chamber for
aromatherapy. Figure 1.11
Note:
• You can use the VeSync app to connect your
smart humidifier to Amazon Alexa or Google
Assistant™. Follow the in-app instructions to
connect VeSync to your voice assistant.
• Your phone must have Location turned
on while your phone is connecting to your
smart humidifier. This is required to establish
the Bluetooth® connection. You can turn
Location o after your smart humidifier is
finished connecting to the VeSync app.
EN
11

USING YOUR SMART HUMIDIFIER
1. Plug in the humidifier. Press to turn
your humidifier on. The humidifier will
automatically begin misting on high
for 3 seconds, then change to the low
mist setting.
2. Tap repeatedly to cycle through mist
settings: Auto Mode, Low, and High.
Figure 3.1
3. Rotate the nozzle to adjust the direction
of the mist. Figure 3.2
4. When your room has reached your
preferred humidity level, turn the
humidifier to a lower setting, or turn it
o. A healthy humidity level is between
40% and 50%. Figure 3.3
5. Press to turn your humidifier o.
Figure 3.1
Figure 3.2
Figure 3.3
Note: Using the VeSync app allows you to control
your smart humidifier remotely and access additional
functions and features (see page 13).
Note: You can also use Auto Mode to keep
the humidity level between 40% and 50%.
Note: If there is no water in the tank, will
flash 10 times, and the humidifier will turn o. Fill
the water tank (see Getting Started, page 9).
Note:
• The humidifier will not mist in Auto Mode
if the humidity level is above 50%. If
you want the humidifier to keep misting,
change the mist setting, or change the
Auto Mode settings in the VeSync app.
• For more information about Auto Mode,
see page 13.
Note:
• If there is no water in the tank, the
humidifier will stop misting, will flash
10 times, and the humidifier will turn o.
Refill the tank and properly place it on
the base to use your humidifier.
• If the water tank is removed, will
remain on until the tank is replaced.
EN
12

Auto Mode
Auto Mode uses the humidifier’s sensor to
automatically adjust the mist level (or turn it
o) to maintain a comfortable and healthy
level of humidity.
• Auto Mode automatically adjusts the
mist level to maintain 40–50% relative
humidity. You can change the target
humidity level in the VeSync app.
• By default, Auto Mode uses Automatic
Stop. The humidifier will stop misting
when the highest target humidity level is
reached. If the humidity drops below the
target humidity level, the humidifier will
begin misting again.
• In the VeSync app, you can turn
Automatic Stop on/o. If Automatic Stop
is o, the humidifier will keep running on
Low mist level when the highest target
humidity level is reached.
• If Auto Mode is selected when the
humidity is higher than the target
humidity range, the humidifier will not
start misting until the humidity lowers.
Note: The VeSync app is continually updated
and app features will expand.
The VeSync app allows you to access
additional smart functions, including those
listed below.
Remote Control
• Turn the humidifier on/o from
your phone.
• Cycle through mist levels and turn
on/o Auto Mode from your phone.
• Turn the display lights on/o from
your phone.
• Customise Auto Mode settings
like target humidity and auto-o.
Monitor Humidity Levels
• Check current humidity levels in the
humidifier’s environment.
Set Timers & Schedules
• Program individual timers or create a
schedule for your smart humidifier.
Third-Party Voice Control
• Compatible with Amazon Alexa and
Google Assistant™ for voice commands.
VeSync App Functions
EN
13

Figure 3.4
Figure 3.5
Figure 3.6
Important Tips
Your humidifier must have the correct level of
water in the base chamber to work properly. If
there is too much water in the base chamber,
the humidifier cannot create mist.
• Never pour water directly into the
base chamber. Figure 3.4 Only add
water to the water tank. The humidifier
will automatically release the correct
amount of water into the base chamber.
• Avoid moving or shaking the humidifier.
Figure 3.5 This may cause the water
tank to release too much water into the
base chamber.
• Before moving the humidifier, turn it o,
unplug it, and remove the water tank.
• If your humidifier doesn’t produce mist
correctly, check the max water line to
see if there is too much water in the
base chamber. Pour out extra water if
water is over the max line. Figure 3.6
Note: The max water line is only for this purpose.
Do not pour water into the base chamber.
EN
14

Figure 4.1
Figure 4.3
Figure 4.2
CARE & MAINTENANCE
Note:
• All maintenance should be done on a water-
resistant surface, such as a kitchen counter.
• Change the water daily to avoid bacteria growth.
• Use a tissue or cloth to clean the nozzle regularly.
• If not using the humidifier for 1 week or longer,
do not leave water inside. Clean and dry the
humidifier instead.
• For more safety information, see Maintenance
Safety (page 5).
Note: When pouring out water, hold
down the float to ensure that it does
not fall out of the base chamber.
Note:
• Never immerse the base in water or liquid.
• Do not use detergents to clean the humidifier.
• The water tank, water tank cover, water
filter housing, nozzle, float, and silencer are
dishwasher safe.
• Do not put the water filter in the dishwasher
or it may become discolored.
Cleaning
You should clean your humidifier water tank
and base chamber every 3 days, and when
you’re ready to store it.
1. Unplug the humidifier.
2. Remove and rinse the water tank cover.
Figure 4.1
4. Remove the water filter assembly from
the tank by rotating it anticlockwise and
lifting it out. Figure 4.3
3. Remove the water tank from the base
and pour out any water from the tank
and base chamber. Figure 4.2
EN
15

6. To descale the humidifier:
a. Remove the water filter from the
tank. Figure 4.5 Fill the tank with
710 mL / 3 US cups of distilled
white vinegar. Figure 4.6
Figure 4.5
Figure 4.6
b. Replace the tank cover and swish
the vinegar around the tank.
Figure 4.7
c. Place the tank on the base and
soak for 1520 minutes. Vinegar
will drain into the base chamber
and loosen scale (mineral buildup)
in the tank and in the base
chamber (including the transducer
and float). Figure 4.8
Figure 4.7
Cleaning (cont.)
Figure 4.8
Figure 4.4
5. Rinse the tank, water filter assembly,
and base chamber with room
temperature water. Figure 4.4
EN
16

Figure 4.10
Figure 4.11
Figure 4.12
Figure 4.13
f. Remove the float from the base
chamber by pulling up one
end of the float Figure 4.11 and
pulling the shaft out from the float
brackets. One side of the float
brackets is open (U-shaped) to
allow the shaft to be removed.
Figure 4.12
e. Flip the tank over and remove
the noise silencer. To remove the
noise silencer, press the release
tabs and gently pull away from the
humidifier. Figure 4.10
g. Place the float, water filter
assembly, and noise silencer in a
small container. Fill with enough
vinegar to cover them. Soak for
1520 minutes. Figure 4.13
d. Remove the tank, remove the tank
cover, and pour out any vinegar.
Figure 4.9
Cleaning (cont.)
Figure 4.9
EN
17

Figure 4.14
Figure 4.15
h. Use a soft cloth and the included
cleaning brush to remove scale
from all parts. Figure 4.14
i. Rinse all parts until any vinegar
smell is completely gone.
Figure 4.15
Cleaning (cont.)
7. Dry all parts with a cloth. Make sure
all parts are completely dry before
reassembling or storing.
Reassembling
1. Flip the water tank over and place
the noise silencer back into the tank.
Figure 4.16
2. Place the water filter assembly back
into the tank and rotate it clockwise to
secure it in place. Figure 4.17
Figure 4.16
Figure 4.17
EN
18

Reassembling (cont.)
Figure 4.18
Figure 4.19
c. Place the larger prong into
the open Ushaped side of
the float brackets.
4. Place the tank back on the base. Refill
the tank, if necessary.
5. Place the tank properly on the base and
place the tank cover on the water tank.
b. Insert the smaller prong into the
closed side of the float brackets.
Figure 4.19
Storing
Replacing the Filter Assembly
Follow the cleaning instructions (see page 15)
and allow all parts to dry completely before
storing. Store in a cool, dry location.
If the filter assembly is damaged or water
cannot flow into the base chamber, the filter
or filter assembly needs to be replaced.
For more information, contact Customer
Support (see page 24).
3. Place the float back into the base chamber:
a. Make sure the correct side of the
float is facing up. Figure 4.18
EN
19

Problem Possible Solution
Humidifier doesn’t turn on, or
turns o unexpectedly.
Plug in the humidifier and turn it on.
Add purified or distilled water to the water tank.
Check to see if the humidifier is in Auto Mode. Depending on
Auto Mode settings, the humidifier may automatically turn o
when the humidity level is above the target level.
Little or no mist comes out.
Turn the mist level to a higher setting.
Fill the water tank.
There may be too much water in the base chamber. Empty the
base chamber. Refill the water tank (not the base chamber) and
place the water tank properly onto the base.
Make sure the air inlet on the bottom of the base is not blocked.
The humidifier should not be set on carpet or other surfaces that
may block the air inlet.
Make sure the nozzle is not blocked or clogged.
Make sure the humidifier is on a level surface.
The water temperature may be too low. Turn the mist level to
the highest setting and let the humidifier run for a while, then
adjust to the desired setting.
If the water tank or base was washed with detergent, rinse
thoroughly with clean water to remove any detergent.
Clean the water filter assembly (see page 15) or replace it with
a new one (see page 24).
Humidifier uses water too quickly.
The humidifier uses up water based on the environmental
temperature and humidity. If your environment is cold and/or
dry, the humidifier will run out of water faster.
Humidifier produces an
unusual smell.
If the humidifier is new, unplug and rinse all parts, then place in a
cool, dry place for 12 hours.
If essential oils were diused, clean all parts with white vinegar
(follow the descaling instructions on page 16), and allow the
humidifier to dry.
Clean the water tank and base chamber (see Care & Maintenance,
page 15).
White dust appears around the
humidifier.
We recommend using purified or distilled water to fill the
humidifier. Avoid using water with high mineral content.
Clean the humidifier (see Care & Maintenance, page 15).
TROUBLESHOOTING
EN
20
