Levoit LVAC-120 User manual

Cordless 2-in-1 Stick Vacuum Cleaner
Model: LVAC-120
Questions or Concerns?
Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT
at [email protected] or at [phone].
USER MANUAL

2
Thank you for purchasing the
LVAC120 CORDLESS
2IN1 STICK
VACUUM CLEANER
BY LEVOIT.
If you have any questions or concerns, please
reach out to us at [email protected].
We hope you enjoy your new vacuum!
Share the Levoit Love
Find @LevoitLifestyle on social media for
wellness + style inspiration. We make every
space mindful and chic.
@LevoitLifestyle
#LevoitLove • #LevoitLifestyle

3
Table of Contents
Package Contents
Specifications
Important Safety Instructions
Getting to Know Your Vacuum
Using Your Vacuum
Care & Maintenance
Troubleshooting
Warranty Information
Customer Support
3
3
4
6
7
9
12
13
14
Package Contents
1 x Cordless Vacuum
1 x Stick
1 x Roller Brush
1 x Crevice Nozzle
1 x 2-in-1 Brush Nozzle
1 x Cleaning Brush
1 x Wall Mount
1 x Charger
1 x User Manual
1 x Quick Start Guide
Specifications
Battery Type
DC 22.2V, 2200mAh,
48.84Wh Li-ion
batteries
Charger
Input: 100–240V,
50/60Hz 0.5A
Output: DC 26V,
400mA
Charging Time 5 hours
Dimensions 10.4 x 5.3 x 30.3 in /
26.3 x 13.5 x 77 cm
Weight 8.3 lb / 3.8 kg
Dust Bin
Capacity 2.1 cups / 0.5 L
Runtime 20–40 minutes
Suction Power 1.5 psi / 10 kPa

4
IMPORTANT SAFETY
INSTRUCTIONS
• Do not leave the vacuum unattended while it
is on. Unplug from outlet when not charging
and before servicing.
• Do not use outdoors or on wet surfaces.
• The vacuum is not a toy. Do not allow
children to play with the vacuum. Close
supervision is necessary when the vacuum is
used by children.
• Close supervision is necessary when the
vacuum is used by children, invalids, disabled
persons, or those who lack experience and
knowledge, unless they have been given
supervision or instruction on how to use the
vacuum and understand the hazards involved.
• Only use your vacuum as described in this
manual.
• Do not use your vacuum if it is damaged or
not working correctly, or if the charger or plug
is damaged. Do not try to repair it yourself.
Contact Customer Support (see page 14).
• Do not handle the charger or vacuum with
wet hands.
• Do not put any object into any opening.
Do not use the vacuum with any opening
blocked. Keep free of dust, lint, hair, or
anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all body
parts away from openings and moving parts.
• Use extra care when cleaning on stairs.
• The stick contains electrical wires. Do not
use if damaged, cut, or punctured. Avoid
vacuuming sharp objects.
When using this vacuum, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS
WARNING
• Do not vacuum the following or use where
they may be present:
• Large or sharp objects such as glass
shards
• Flammable or combustible liquids such
as solvents or detergents
• Inflammable or explosive substances
such as gasoline or alcohol
• Risk of injury. Brush may start unexpectedly.
Remove the main body before cleaning or
servicing.
• Prevent unintentional starting. Ensure the
switch is in the “O” position before picking
up or carrying the vacuum. Carrying the
vacuum with your finger on the switch may
cause accidents.
• Always turn the vacuum o before connecting
or disconnecting the stick, nozzles, brushes,
or vacuum head.
• Do not vacuum anything that is burning or
smoking, such as cigarettes, matches, or hot
ashes.
• Do not use without dust bin and filters in
place.
• Do not point the vacuum at any person or
animal while it is on.
• Store the vacuum on a small stand or flat
surface, or hang it from the wall.
• Do not use aftermarket or third-party
accessories with the vacuum. Only use the
accessories provided.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:

5
WARNING: Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
NOT FOR COMMERCIAL USE
HOUSEHOLD USE ONLY
• Do not pull or carry the vacuum by the
charging cable, use the cable as a handle,
close a door on the cable, or pull the cable
around sharp edges or corners. Do not run
any appliance over the cable.
• Do not pull on the cable to remove it from the
outlet. Only use the plug to pull it out from
the outlet.
• Never place the charger or its cable near any
heat source.
• Keep the charging cable out of areas where
people walk often. Place the cable where it
will not be tripped over.
• Do not use the charger to charge other
appliances besides this vacuum.
• Check to make sure the voltage specified
on the vacuum matches the voltage on the
charger.
• Only recharge the vacuum with the charger
specified by the manufacturer. A charger
that is suitable for one type of appliance
may create a risk of fire when used with
another battery pack. Charger model: charger
ZD012A260040US.
• Only use the battery pack specifically
designed for this vacuum. Use of any other
battery packs may create a risk of injury and
fire. Battery pack type: PF061JPF from Suzhou
Provac Technology Co., Ltd.
• When the battery pack is not in use, keep
it away from other metal objects, like paper
clips, coins, keys, nails, screws, or other small
metal objects that can make a connection
from one terminal to another. Shorting the
battery terminals together may cause burns
or a fire.
BATTERY & CHARGER
• Under abusive conditions, liquid may be
ejected from the battery. Avoid contact. If
contact occurs, flush with water. If liquid
contacts eyes, immediately flush with water
and seek medical help. Liquid ejected from
the battery may cause irritation or burns.
• Do not use the battery pack or vacuum if
they are damaged or modified. Damaged or
modified batteries may exhibit unpredictable
behavior resulting in fire, explosions, or risk
of injury.
• Have servicing performed only by a qualified
repair person using identical replacement
parts. This will ensure that the safety of the
vacuum is maintained.
• Do not modify or attempt to repair the
vacuum or the battery pack except as
indicated in the manual.
• Do not expose the battery pack or vacuum to
fire or excessive temperatures. Exposure to
fire or temperatures above 265°F / 129°C may
cause an explosion.
• Follow all charging instructions and do not
charge the battery pack or vacuum outside
of the temperature range specified in the
instructions. Charging improperly or at
temperatures outside of the specified range
may damage the battery and increase the
risk of fire.
• Environment Requirements: The vacuum or
the battery pack should be stored only in a
temperature range of -4°–95°F / -20°–35°C,
and used and charged only in a range of
39°–104°F / 4°–40°C.

6
GETTING TO KNOW YOUR VACUUM
A. Handle
B. On/O Button
C. Vacuum Body
D. Release Button
E. Stick
F. Vacuum Head
Release Button
G. Vacuum Head
H. Vacuum Cushions
I. Roller Brush
J. Brush Lock
K. Dust Bin
L. Cup Filter
M. Inner Dust Bin Chamber
N. Charging Port
O. Disc Filter
B
C
D
E
J
K
O
N
Q
R
T
S
U
L
M
P
G
I
H
F
A
P. Dust Door Release
Q. 2-in-1 Brush Nozzle
R. Crevice Nozzle
S. Wall Mount
T. Cleaning Brush
U. Charger

7
Note: Regularly check to make sure the
vacuum cushions and the roller brush
are clean to avoid scratching sensitive
floors or walls.
USING YOUR VACUUM
1. Unpack the vacuum and make sure all
parts are included.
2. Attach the vacuum head to the bottom
of the stick and attach the vacuum body
to the top [Figure 1.1].
3. Slide the On/O button forward to
turn the vacuum on. Slide the button
to Stage I for hard floors or small area
rugs, or slide to Stage II for carpets
[Figure 1.2].
4. Slide the On/O button back completely
to turn the vacuum o [Figure 1.2].
Figure 1.1 Figure 1.2
Status Description
5 solid lights Battery is fully
charged
3 solid lights Battery is at 50%
capacity
1 blinking light Battery is almost
empty
No light Battery is empty
Light Chart

8
Note: You can also attach the vacuum
body directly to the vacuum head
[Figure 2.4].
Nozzles
Your vacuum comes with attachments to
help you tackle almost any cleanup job. To
use an attachment:
1. Press and hold the vacuum body
release button and gently pull the
vacuum body from the stick [Figure 2.1].
2. Slide the crevice nozzle or 2-in-1 brush
nozzle onto the vacuum body
[Figure 2.2].
3. Optionally, leave the stick attached to
the vacuum body and press the vacuum
head release button to remove the
vacuum head. Then, attach the nozzle
or brush to the end of the stick
[Figure 2.3].
Figure 2.1
Figure 2.2
Figure 2.4
Figure 2.3

9
CARE & MAINTENANCE
Charging the Vacuum
Your vacuum uses a DC 22.2V, 2200mAh Li-ion
battery and on a full charge, lasts 20 minutes
on Stage II and 40 minutes on Stage I. Use the
included charger to charge the vacuum.
Cleaning the Dust Bin
1. Turn the vacuum o.
2. To empty the dust bin, remove the stick
by pressing the vacuum body release
button.
3. Hold the dust bin over a trash can and
press the dust door release button
[Figure 3.1]. Use caution, as the dust
door will automatically open when the
release button is pushed. Empty out
debris and dirt. Then, close the dust
door until you hear it click shut.
4. To wash the dust bin, remove the bin by
pulling it outward [Figure 3.2].
1. Insert the charger into the charging port.
2. Plug the charger into an outlet. The
indicator lights will blink while charging.
Note: Make sure the vacuum is turned
o before charging.
Figure 3.1
Figure 3.3
Figure 3.2
Note:
• Charging time is about 5 hours.
• The charger may be warm during
charging. This is normal.
3. When the vacuum has fully charged,
the indicator lights will stay on for 3–5
minutes. They will then turn o to save
power.
5. Remove the inner chamber from the
dust bin. Twist the top part of the inner
chamber to the right, then pull up to
take the chamber apart [Figure 3.3].
Empty out any remaining dirt.
6. Rinse the dust bin and inner chamber
with water and dry thoroughly.
Reassemble and place all parts back on
the vacuum body.

10
Cleaning the Filters
Cleaning the Wheel Axles
Cleaning the Roller Brush
To clean the disc filter, rinse with water and
allow to dry completely before replacing
inside the dust bin. The disc filter should be
cleaned once a month.
To clean the cup filter, pull out any hair or
pet fur trapped in the cup. Then, replace
inside the dust bin. The cup filter should be
cleaned every 2–3 uses.
Use the cleaning brush to remove any dirt
or trapped hair from the wheel axles. If
necessary, carefully cut away any tangled
hair with scissors or a sharp knife.
Periodically clean the roller brush to avoid
blockage or jamming.
1. Turn the vacuum o. Detach the vacuum
head from the stick by pressing the
vacuum head release button.
2. Use a coin to unlock the roller brush by
turning the brush lock counterclockwise
until the slot is vertical. Pull the roller
brush out [Figure 4.1].
3. Carefully use a pair of scissors or a
sharp knife to remove any hair tangled
around the roller brush.
4. Replace the roller brush and use the
coin to turn the brush lock clockwise
until the slot is horizontal.
Note:
• The disc filter should be replaced
every 6–8 months.
• To maintain the performance of
your vacuum, only use ocial
Levoit filters. To buy replacement
filters, visit Levoit’s online store. Go
to levoit.com for more information.
Figure 4.1

11
Storage
There are 2 ways to store your vacuum.
Note:
• Always store the vacuum on flat
ground. If the vacuum is stored on
a slanted surface it may fall and be
damaged.
• If storing for long periods of time,
periodically charge the battery to
preserve the life of the battery.
Figure 5.1
Figure 5.2
To store on the ground:
3. Place the roller brush on flat ground and
attach the stick. Lock the stick into the
standing position [Figure 5.2].
4. Take the vacuum body, remove any
attachments, and store the vacuum
body on top of the vacuum head by
hanging it on the hook near the bottom
of the stick [Figure 5.2].90°
To use the wall mount:
1. Install the wall mount by screwing it into
the wall [Figure 5.1].
2. Hang the vacuum on the wall mount
[Figure 5.1].

12
Problem Possible Solution
Vacuum will not turn on. Slide On/O button to either Stage I or Stage II (see Using
Your Vacuum, page 7).
Recharge the vacuum (see Charging the Vacuum, page
9).
Vacuum isn’t charging. Make sure the charger is plugged into the vacuum and outlet
correctly (see Charging the Vacuum, page 9).
Vacuum has low suction
power.
Recharge the battery to full charge (see Charging the
Vacuum, page 9).
Roller brush may have hair tangled around it. Clean the roller
brush (see Cleaning the Roller Brush, page 10).
Empty the dust bin (see Cleaning the Dust Bin, page 9).
TROUBLESHOOTING
If your problem is not listed, please contact Customer Support (see page 14).

13
Terms & Policy
Arovast Corporation warrants all products to be of
the highest quality in material, craftsmanship, and
service, eective from the date of purchase to the
end of the warranty period.
Arovast Corporation will replace any product
found to be defective due to manufacturer flaws
based on eligibility. Refunds are available within
the first 30 days of purchase. Refunds are only
available to the original purchaser of the product.
This warranty extends only to personal use and
does not extend to any product that has been
used for commercial, rental, or any other use in
which the product is not intended for. There are
no warranties other than the warranties expressly
set forth with each product.
This warranty is non-transferrable. Arovast
Corporation is not responsible in any way for any
damages, losses, or inconveniences caused by
equipment failure by user negligence, abuse, or
use noncompliant with the user manual or any
additional safety, use, or warnings included in the
product packaging and manual.
This warranty does not apply to the following:
• Damage due to abuse, accident, alteration,
misuse, tampering, or vandalism.
• Improper or inadequate maintenance.
• Damage in return transit.
• Unsupervised use by children under 18 years
of age.
Arovast Corporation and its subsidiaries assume
no liability for damage caused by the use of the
product other than for its intended use or as
instructed in the user manual. Some states do not
allow this exclusion or limitation of incidental or
consequential losses so the foregoing disclaimer
may not apply to you. This warranty gives you
specific legal rights and you may also have other
rights which may vary from state to state.
ALL EXPRESSED AND IMPLIED WARRANTIES,
INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE
PERIOD OF THE LIMITED WARRANTY.
Additional 1-Year Warranty
You can extend your 1-year warranty by an
additional year. Log onto www.levoit.com/warranty
to register your new product for the extended
warranty.
Please fill out all required fields and include your
order ID, place of purchase, and purchase date, if
applicable.
Defective Products & Returns
If you discover your product is defective within the
specified warranty period, please contact Customer
Support via [email protected] with a copy of
your invoice and order ID. DO NOT dispose of your
product before contacting us. Once our Customer
Support Team has approved your request, please
return the product with a copy of the invoice and
order ID.
Product Name Cordless 2-in-1 Stick
Vacuum Cleaner
Model LVAC-120
Default Warranty
Period
1 year
For your own reference, we strongly recommend
that you record your order ID and date of
purchase.
Date of Purchase
Order ID
WARRANTY INFORMATION

14
CUSTOMER SUPPORT
If you have any questions or concerns about
your new product, please contact our helpful
Customer Support Team.
Arovast Corporation
1202 N. Miller St., Suite A
Anaheim, CA 92806
Email: [email protected]
Toll-Free: [phone]
Mon–Fri, 9:00 am–5:00 pm PST/PDT
Support Hours
*Please have your order invoice and order ID
ready before contacting Customer Support.

15
Connect with us @LevoitLifestyle

levoit.com
AU1019AL-M1.1_0919LVAC-120
